1
30” ELECTRIC RANGE
SERVICE MANUAL
MODEL: LSSE3026ST
LSSE3029BD
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL37118336
June, 2015
Printed in Korea
삼흥
정판
Internal Use Only

This LG Service Manual, “ 30” Freestanding Self-Cleaning Electric Range,” provides the
technician with information on the operation and service of the Freestanding Self-Cleaning
Electric Range. It is to be used as a training Service Manual. For specific information on the
model being serviced, refer to the “Owner’s Manual” or “Tech Sheet” provided with the electric
range.
SAFETY PRECAUTIONS
• Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs
may result in dangerous situations. If you need repairs, contact an LG Service Center or your
dealer.
• If the power cord is defective, it must be replaced by a qualified service agent with a UL listed
range cord.
• Electrical leads and cables should not be allowed to touch the oven.
• Rating plate is located on the left side of warming drawer.
• The power supply of the appliance should be turned off when it is being repaired.
FORWARD
LG Electronics assumes no responsibility for any repairs made
on our products by anyone other than Authorized Service Technicians.
WARNING
• DISCONNECT power supply cord from the outlet before servicing.
• Replace all panels and parts before operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or electrical shock.
• DO NOT Touch when the oven operates.
- The interior parts will be very hot.
!

(Page)
GENERAL -------------------------------------------------------------------------------------------- 1-1 ~ 1-5
• Important safety instructions -------------------------------------------------------------------------------------- 1-1 ~ 1-3
• Model & Serial number label and tech sheet locations ----------------------------------------------------------- 1-4
• Specifications ------------------------------------------------------------------------------------------------------------------ 1-5
USING YOUR RANGE ------------------------------------------------------------------------- 2-1 ~ 2-5
• General information --------------------------------------------------------------------------------------------------------- 2-1
• Control panel features ---------------------------------------------------------------------------------------------- 2-2 ~ 2-5
- SETTING THE CLOCK
- TO TURN ON/OFF THE OVEN LIGHT
- TIMER ON/OFF
- SETTING PAD: 5 types of category
1) CONVECTION AUTO CONVERSION
2) THERMOSTAT ADJUSTMENT
3) PREHEATING ALARM LIGHT ON/OFF
4) BEEPER VOLUME
5) TEMPERATURE UNIT (°F or °C)
- BAKE, TIMED BAKE, DELAYED TIMED BAKE
- OVEN LOCKOUT
- CHANGING HOUR MODE ON CLOCK
- SELF-CLEAN
- WARMING DRAWER
COMPONENT ACCESS
--------------------------------------------------------------------- 3-1 ~ 3-21
- Component Locations
------------------------------------------------------------------------------------------------------ 3-1
- REMOVIING THE BACK COVER -------------------------------------------------------------------------------------------- 3-2
- REMOVIING THE OVEN RELAY PCB, POWER PCB,POWER RELAY AND SURGE FIILTER ----- 3-3
- REMOVIING THE CONTROLLER ------------------------------------------------------------------------------------ 3-4
- REMOVIING THE MAIIN PCB AND KEY PCB ASSEMBLY
---------------------------------------------------- 3-5
- REMOVIING KNOB AND IINFIINIITE SWIITCH -------------------------------------------------------------------- 3-6
- REMOVIING THE CERAMIIC GLASS COOKTOP, THESURFACE ELEMENT AND THE HOT SURFACE LAMP ---- 3-7 ~ 3-9
- REMOVIING THE BROIIL ELEMENT ----------------------------------------------------------------------- 3-10~ 3-11
- REMOVIING THE CONVECTIION ELEMENT, FAN BLADE AND FAN MOTOR ---------------------- 3-12
- REMOVIING THE OVEN LIIGHT & SOCKET ASSEMBLY --------------------------------------------------- 3-13
- REMOVIING THE LATCH DRIIVE ASSEMBLY ------------------------------------------------------------------ 3-14
- REMOVIING THE OVEN TEMPERATURE SENSORS -------------------------------------------------------- 3-15
- REMOVIING & REPLACIING THE LIIT--OFF OVEN DOOR AND DRAWER ------------------- 3-16~3-17
- REMOVIING A SIIDE PANEL ------------------------------------------------------------------------------------------ 3-18
- REMOVIING THE OVEN DOOR HANDLE & GLASS --------------------------------------------------- 3-19~3-20
- REMOVIING THE OVEN DOOR GASKET ------------------------------------------------------------------------ 3-21
COMPONENT TEST --------------------------------------------------------------------------- 4-1 ~ 4-15
- Convection Motor ------------------------------------------------------------------------------------------------------------ 4-1
- Door locking Motor --------------------------------------------------------------------------------------------------------- 4-2
- Micro Switch ------------------------------------------------------------------------------------------------------------------- 4-2
- Oven Sensor ----------------------------------------------------------------------------------------------------------------- 4-2
- Door switch ------------------------------------------------------------------------------------------------------------------- 4-3
- Outer Broil heater ------------------------------------------------------------------------------------------------------------ 4-3
- Inner Broil heater ------------------------------------------------------------------------------------------------------------- 4-3
- Convection heater ----------------------------------------------------------------------------------------------------------- 4-3
- Oven lamp --------------------------------------------------------------------------------------------------------------------- 4-4
- Infinite switch (LR, RR Switch) ------------------------------------------------------------------------------------------- 4-5
- Infinite switch (CR Switch) ------------------------------------------------------------------------------------------------ 4-5
TABLE OF CONTENTS

(Page)
COMPONENT TEST --------------------------------------------------------------------------- 4-1 ~ 4-15
- Infinite switch (LF Switch) ------------------------------------------------------------------------------------------------- 4-6
- Infinite switch (RF Switch) ------------------------------------------------------------------------------------------------- 4-6
- Variable Thermostat ------------------------------------------------------------------------------------------------------ 4-11
- Single surface units: (LR, RR Element) ----------------------------------------------------------------------------- 4-12
- Center Rear(CR) Element ----------------------------------------------------------------------------------------------- 4-13
- Dual surface units (LF Element) --------------------------------------------------------------------------------------- 4-14
- Triple surface unit: (RF Element) -------------------------------------------------------------------------------------- 4-15
SCHEMATIC DIAGRAM -----------------------------------------------------------------------
5-1 ~ 5-5
- CONV. BAKE / CONV. ROAST ------------------------------------------------------------------------------------------ 5-2
- SELF CLEANING ------------------------------------------------------------------------------------------------------------ 5-2
- OVEN LIGHT ------------------------------------------------------------------------------------------------------------------ 5-3
- Warming Drawer ------------------------------------------------------------------------------------------------------------- 5-3
- CR Cook-top Element
----------------------------------------------------------------------------------------------------- 5-3
- RR Cook-top Element
----------------------------------------------------------------------------------------------------- 5-3
- LR Cook-top Element
------------------------------------------------------------------------------------------------------- 5-4
- LF Cook-top Element
------------------------------------------------------------------------------------------------------- 5-4
- RF Cook-top Element
------------------------------------------------------------------------------------------------------ 5-4
- LF Cook-top Element
------------------------------------------------------------------------------------------------------- 5-5
- Warm-Proof-Easy-clean
--------------------------------------------------------------------------------------------------- 5-5
- Bake-Speed roost
------------------------------------------------------------------------------------------------------------ 5-5
COMPOSITION OF CONTROL ------------------------------------------------------------- 6-1 ~ 6-5
- Wiring Diagram --------------------------------------------------------------------------------------------------------------- 6-1
- Main PCB ---------------------------------------------------------------------------------------------------------------------- 6-3
- Relay PCB ---------------------------------------------------------------------------------------------------------------------- 6-4
- SMPS PCB --------------------------------------------------------------------------------------------------------------------- 6-4
- Encoder PCB ------------------------------------------------------------------------------------------------------------------ 6-5
- Touch PCB --------------------------------------------------------------------------------------------------------------------- 6-5
- Buzzer PCB -------------------------------------------------------------------------------------------------------------------- 6-5
SVC TEST MODE ---------------------------------------------------------------------------------- 7-1~7-3
TROUBLE SHOOTING
-------------------------------------------------------------------------- 8-1~8-2
• Check the Failure Code ----------------------------------------------------------------------------------------------------- 8-1
• Failure Code Summary ----------------------------------------------------------------------------------------------------- 8-2
CHECKING FLOW CHART BY FAILURE --------------------------------------------- 9-1 ~ 9-20
- Power Failed(Dead), No display? ----------------------------------------------------------------------------- 9-1 ~ 9-3
- No heating, F9? ---------------------------------------------------------------------------------------------------- 9-4 ~ 9-7
- Door Lock System Failure / F10 ----------------------------------------------------------------------------- 9-8 ~ 9-11
- Sensing Fail / F1 / F2 ----------------------------------------------------------------------------------------- 9-12 ~ 9-14
- Oven hot, F6? -------------------------------------------------------------------------------------------------- 9-15 ~ 9-18
- Key not working / F3 Error ---------------------------------------------------------------------------------- 9-19 ~ 9-20
APPENDIX ------------------------------------------------------------------------------------------------- 10-1
EXPLODED VIEW
---------------------------------------------------------------------------- 11-1 ~ 11-6
REPLACEMENT PARTS LIST
---------------------------------------------------------- 12-1 ~ 12-3

1-1
GENERAL
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, injury to person, or
damage when using the range. This guide don’t cover all possible conditions that may occur. For further assistance
contact your service agent or manufacturer.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hunt you
and others. All safety messages will follow the safety alert symbol and either the word “WARNING”
or “CAUTION”. These word means :
!
This symbol will alert you to hazards or unsafe practices which could cause
serious bodily harm or death.
!
WARNING
This symbol will alert you to hazards or unsafe practices which could cause
bodily injury or property damage.
!
CAUTION
WARNING
• DO NOT step or sit on the door and install the Anti-Tip Bracket packed with range.
- The range could be tipped and injury might result from spilled hot liquid, food, or the range itself.
- If the range is pulled away from the wall for cleaning, service, or any other reason, ensure that the Anti-Tip
Device is properly reengaged when the range is pushed back against the wall.
• DISCONNECT power supply cord from the outlet before servicing.
• Replace all panels and parts before operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or electrical shock.
• DO NOT touch heating elements or interior surfaces of oven.
- Heating element may be hot even though they are dark in color.
- Interior surfaces of an oven become hot enough to cause burns.
• During and after use, do not touch, or let clothing or other flammable materials
contact heating elements or interior surfaces of oven until they have had sufficient
time to cool.
-Other surfaces of the appliance may become hot enough to cause burns among these surfaces are oven vent
openings and surfaces near these openings, oven doors, and windows of oven doors.
• DO NOT store items of interest to children in cabinets above a range or on the back guard of a range.
- Children climbing on the range to reach items could be seriously injured.
!
CAUTION
• Always use Pot Holders or oven mitts when removing food from the Warming Drawer.
- You can be burned as cookware and plates will be hot.
• Be careful when you work on the electric range handling the sheet metal part.
- Sharp edge may be present and you can cut yourself.
• Be careful not to bend the fan blade
- Failure to do so can result in vibration, noise, and poor performance of convection when operating.
• Be careful not to scratch or chip the oven liner paint when you remove the oven light socket
in the next step.
• Turn power OFF before removing the Warming Drawer.
• Be careful when removing and lifting the door.
• DO NOT lift the door by the handle.
- Failure to do so can result in personal injury as the door is very heavy.
!

1-2
GENERAL
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
• Be sure your appliance is properly installed and grounded by a
qualified technician.
• Do not repair or replace any part of the appliance unless
specifically recommended in the manual.
All other servicing should be referred to a qualified technician.
• Always disconnect power to appliance before servicing by
removing the fuse or switching off the circuit breaker
To reduce the risk of tipping of the range, the range must be
secured by properly installed anti-tip devices. To check if the
bracket is installed properly,
- Warming drawer : grasp the top rear edge of the Range and
carefully attempt to tilt it forward.
verify that the anti-tip devices are engaged.
- Storage drawer : Remove drawer and verify leveling leg is
inserted into and fully secured by the anti-tip devices.
Refer to the installation manual for proper anti-tip bracket
installation.
WARNING
• DO NOT touch heating elements or
interior surfaces of oven.
- Heating element may be hot even though they are
dark in color.
- Interior surfaces of an oven become hot enough to
cause burns.
• During and after use, do not touch, or
let clothing or other flammable
materials contact heating elements or
interior surfaces of oven until they
have had sufficient time to cool.
-Other surfaces of the appliance may become hot
enough to cause burns among these surfaces are
oven vent openings and surfaces near these
openings, oven doors, and windows of oven
doors.
!
WARNING
• DO NOT store items of interest to
children in cabinets above a range or
on the back guard of a range.
- Children climbing on the range to reach items
could be seriously injured.
!
WARNING
• DO NOT step or sit on the
door and install the Anti-Tip
Bracket packed with range.
- The range could be tipped and injury
might result from spilled hot liquid,
food, or the range itself.
- If the range is pulled away from the
wall for cleaning, service, or any other
reason, ensure that the Anti-Tip Device
is properly reengaged when the range
is pushed back against the wall.
!

1-3
GENERAL
SURFACE COOKING UNITS
• Use Proper Pan Size – This appliance is equipped with one or more
surface units of different sizes. Select utensils having flat bottoms large
enough to cover the surface unit heating element. The use of
undersized utensils will expose a portion of the heating element to direct
contact and may result in ignition of clothing. Proper relationship of
utensil to burner will also improve efficiency.
• Never Leave Surface Units Unattended at High Heat Settings – Boil
overs may cause smoking and greasy spillovers may ignite.
• Make Sure Reflector Pans or Drip Bowls Are in Place – Absence of
these pans or bowls during cooking may subject wiring or components
underneath to damage.
• Protective Liners – Do not use aluminum foil to line surface unit drip
bowls or oven bottoms, except as suggested in the manual. Improper
installation of these liners may result in a risk of electric shock, or fire.
• Glazed Cooking Utensils – Only certain types of glass, glass/ceramic,
ceramic, earthenware, or other glazed utensils are suitable for range-
top service without breaking due to the sudden change in temperature.
• Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Units – To reduce the risk of burns, ignition of
flammable materials, and spillage due to unintentional contact with the
utensil, the handle of a utensil should be positioned so that it is turned
inward, and does not extend over adjacent surface units.
• Do Not Soak Removable Heating Elements – Heating elements
should never be immersed in water.
• Be sure you know which control pads operate each surface unit.
Make sure you turned on the correct surface unit.
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
SELF-CLEAN OVENS
• Do Not Clean Door Gasket – The door gasket is essential for a
good seal. Care should be taken not to rub, damage, or move the
gasket.
• Do Not Use Oven Cleaners – No commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
• Clean in the self-clean cycle only parts listed in this manual.
Before self-cleaning the oven, remove the broiler pan and any
utensils from the oven.
• Never keep pet birds in the kitchen – the health of birds is
extremely sensitive to the fumes released during an oven self-
clean cycle. Fumes may be harmful or fatal to birds. Move birds to
well-ventilated room.
• Important Instruction – In the event the self-clean mode “F”
code goes on, or three long beeps sound, oven is malfunctioning
in the self-clean mode. Turn off or disconnect appliance from
power supply and have serviced by a qualified technician.
VENTILATING HOODS:
• Clean Ventilating Hoods Frequently – Grease should not
be allowed to accumulate on hood or filter.
• When flaming foods under the hood, turn the fan on.
OVEN
• Use Care When Opening Door – Let hot air or steam escape
before you remove or replace food in the oven
• Do Not Heat Unopened Food Containers – Build-up of pressure
may cause container to burst and result in injury.
• Keep Oven Vent Ducts Unobstructed – the oven vent is located
above the left rear surface unit. this area could become hot during
oven use. Never block this vent and never place plastic or heat-
sensitive items on vent
• Placement of Oven Racks – Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot, do not let potholder contact hot heating element in oven.
• Do Not allow aluminum foil or meat probe to contact heating
elements.
GLASS/CERAMIC COOKING SURFACES
• Do Not Cook on Broken Cook-Top – If cook-top should break,
cleaning solutions and spillovers may penetrate the broken cook-
top and create a risk of electric shock. Contact a qualified
technician immediately.
• Clean Cook-Top With Caution – If a wet sponge or cloth is used
to wipe spills on a hot cooking area, be careful to avoid steam
burn. Some cleaners can produce noxious fumes if applied to a hot
surface.
DEEP FAT FRYERS:
• Use extreme caution when moving the grease kettle or disposing
of hot grease.
• Do Not Leave Children Alone - Children should not be left alone or
unattended in area where appliance is in use. They should never be
allowed to sit or stand on any part of the appliance.
• Never Use Your Appliance for Warming or Heating the Room.
• Storage in or on Appliance – Flammable materials should not be stored
in an oven or near surface units. Be sure all packing materials are removed
from the appliance before operating it. Keep plastics, clothes and paper
away from parts of the appliance that may become hot
• Wear Proper Apparel – Loose-fitting or hanging garments should never
be worn while using the appliance.
• Do Not Use Water on Grease Fires – Turn off oven to avoid spreading
the flame. Smother the fire or flame by closing the door or use dry
chemical, baking soda or foam- type extinguisher.
• Use Only Dry Potholders – Moist or damp potholders on hot surfaces
may result in burns from steam.
Do not let potholder touch hot heating elements. Do not use a towel or
other bulky cloth.
WARNING
• DISCONNECT power supply cord from
the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!

1-4
GENERAL
The Model/Serial Number label and Tech Sheet locations are shown below.
Tech Sheet Location
MODEL & SERIAL NUMBER LABEL
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCA
AND TECH SHEET LOCATIONS TIONS
Model & Serial
Number Location

1-5
GENERAL
SPECIFICA
SPECIFICATIONS TIONS
Model Number LSSE3026ST / LSSE3029BD
Category Slide-in oven range
Overall
Control
Cooktop
Power
Oven
Drawer
Dimensions
(inch)
Power
Width
Installation type
Color availability
Oven
Cooktop
Display
Electronic clock & timer
Control lock capability
Audible preheat signal
Special function
Material
# of element
LR
RR
CR
LF
RF
Capacity(cu.ft)
Broil element
Bake element
Convection System
-Convection element
# of Racks
Interior oven light
Proof
Cook & warm
Favorites
Easy clean
Door lockout
Type
Element
Warming rack
Oven Interior(W x H x D)
Exterior - Width
Exterior - Height
Exterior - Depth
Net weight: Lbs (Kg)
Rating
29⅞
Slide-In
STS
Glass Touch
Knob
VFD
Yes
Yes
Yes
Setting (6 categories)
1. Change hour mode on clock
2. Convection Auto Conversion On/Off
3. Oven Temp Adjust
4. Preheat alarm light On/Off
5. Beeper volume High/Low/Mute
6. Select Fahrenheit or Celsius temperature
Ceramic glass
5
6"-1,200
6"-1,200
7"- 100W
Dual(6"/9"-1,400/3,200 watts)
12"/9"/6"-3000W/2200W/1100W
6.3
Inner/Outer 1,600/2,400 watts
Yes
Yes(2500 watts, 240V)
3 (2 Heavy, 1 offset)
120V, 40Watts
Yes
Yes
Yes
Yes
Warming drawer
500 watts
Yes
24 7/8x 21 3/8x 20
29 7/8
35 15/16 (Cooktop), 47 5/16 (Backguard)
26 9/16 (Door), 28 7/8 (Handle)
187.8 lbs (85.2kg)
13.5Kw(120/240V AC) / 10.1Kw(120/208V AC)

2-1
USING YOUR RANGE
Rating Label
Model numbers are recorded on the rating label.
Rating label is located on the lower front left corner
of the oven frame. It can be seen by opening the
storage drawer or warming drawer. Before ordering
parts, write down the correct model and serial
number from rating label. This avoids incorrect
shipments and delays. Please refer to parts
reference material when ordering replacement parts.
Functional Operation
Bake Mode
Top and hidden bottom elements operate during
bake. Bake can be used to cook foods which are
normally baked. Oven must be preheated.
Broil Mode
Top element operates during broil. Broil can be
used to cook foods which are normally broiled. All
foods should be turned at least once except fish,
which does not need to be turned.
Convection Bake / Roast Mode
Upper element, lower element, Rear element(some
model) and fan operate during convection bake.
Convection bake should be used for cooking
casseroles and roasting meats. Oven should be
preheated for best results when using convection
bake. Pans do not need to be staggered. Cooks
approximately 25% quicker than bake.
Cooking Guide
Refer to the owners manual for recommendations
of times and temperatures. Times, rack position,
and temperatures may vary depending on
conditions and food type. For best results, always
check food at minimum time. When roasting,
choose rack position based on size of food item.
GENERAL INFORMA
GENERAL INFORMATION TION
Broil element
Convection
element
Broil element
Broil element

2-2
USING YOUR RANGE
CONTROL P
CONTROL PANEL FEA ANEL FEATURES TURES
A
B C
I
DH G E F
SINGLE
DUAL TRIPLE
SINGLE
WARM
ZONE
A. ELEMENT ON/OFF INDICATOR LIGHT: Shows
whether the surface element is turned on/off or hot.
B. LEFT FRONT (DUAL) CONTROL KNOB : Use to
control Left Front Element.
C. LEFT REAR (SINGEL) CONTROL KNOB : Use to
control Left Rear Element.
D. CENTER REAR (WARM) CONTROL KNOB : Use
to control Center Rear Element.
E. RIGHT REAR (SINGLE) CONTROL KNOB : Use
to control Center Rear Element.
F. RIGHT FRONT (TRIPLE) CONTRON KNOB : Use
to control Right Front Element.
G. LOWER OVEN CONTROL KNOB : Use to control
lower oven
H. ELECTRIC OVEN CONTROL : Use to control
Electric Oven.
I. HOT SURFACE INDICATOR LIGHT : It will glow
as long as any surface cooking area is too hot to
touch

2-3
USING YOUR RANGE
Use to turn on the surface elements. An infinite
choice of heat settings is available from LOW to
HIGH. The knobs can be set on or between any of
settings.
To turn on a Single element:
1. Push the Single element knob in.
2. Turn the knob in either direction to the desired
setting.
The control knob clicks when it is positioned at
both Off and Hi.
NOTE:
• Hi is the highest temperature available.
• Lo is the lowest temperature available.
To turn on the Dual element:
There is one dual element located in the left front
position. Use the dual element as a dual or single
element.
1. Push in the appropriate knob.
2-1. Turn the knob counterclockwise to use it as a
Single element.
2-1. Turn the knob clockwise to use it as a Dual
unit.
To turn on the Dual element:
There is one dual element located in the left front
position. Use the dual element as a dual or single
element.
1. Push in the appropriate knob.
2-1. Turn the knob counterclockwise to use it as a
Single element.
2-1. Turn the knob clockwise to use it as a Dual
unit.
To turn on a Triple element (on some
models):
There is one triple element that can be used as
either a single, dual or triple element.
1. Turn the knob counterclockwise to use the Single
element.
2-1. Turn the knob counterclockwise to use the
Single element.
2-2. Turn the knob clockwise to the Dual position to
use as a Dual element.
2-3. Turn the knob clockwise to the Triple position
to use as a Triple element.
Off On
Single
Single Dual Triple
A B
Heating with inner
(smaller) element only
Heating with both
elements together

2-4
USING YOUR RANGE
To turn on the Warming Zone:
The Warming Zone, located in the back center of
the glass surface, will keep hot, cooked food at
serving temperature. Use the Warming Zone to
keep food warm after it has already been cooked.
Attempting to cook uncooked or cold food on the
Warming Zone could result in a food-borne illness.
1. Turn the control knob to the On position.
NOTE:
• For best results, food on the warmer should be
kept in its container or covered with a lid or
aluminum foil to maintain food quality.
• The warmer will not glow red like the other cooking
elements.
• The Warming Zone can be operated as a single
element on some models.
CAUTION
• FOOD POISON HAZARD: Bacteria
may grow in food at temperatures
below 140 °F.
- Always start with hot food. Do not use the
warm setting to heat cold food.
- Do not use the warm setting for more than 2
hours.

2-5
USING YOUR RANGE
CONTROL P
CONTROL PANEL FEA ANEL FEATURES TURES
1. Smart Diagnosis TM – Use during the Smart
Diagnosis feature.
2. Smart Features – The Tag On icon, for use with
Smart Features.
3. Cook Time / Clock
– Press the button to set the desired amount of time
for food to cook. The oven shuts off when the set
cooking time runs out.
– Press and hold button for three seconds to set the
time of day.
4. START TIME / SETTING
– Press the button to set the delayed timed cook.
The oven starts at the set time.
– Press and hold button for three seconds to select
and adjust oven settings.
5. Probe / Lockout
– Press the button to select Probe function.
– Press and hold button for three seconds to lock
the door and control panel.
6. Timer On/Off – Press the button to set or cancel
timer on oven.
7. Oven Light – Press the button to turn oven light on
or off.
8. Warming Drawer – Press the button to select the
warming drawer function.
9. - /+ – Press the plus button to increase cooking time
or oven temperature.
Press the minus button to decrease cooking time or
oven temperature.
10. Start – Press the button to start all oven features.
11. Oven Mode Knob – Turn the knob to select oven
operating mode

2-6
USING YOUR RANGE
1. SETTING THE CLOCK
1. Set both oven mode knobs to the Off position.
2. Press and hold Cook Time for three seconds.
3. Press plus(+) or minus(-) to select the desired
time. Plus(+) to increase the time and minus(-)
to decrease the time.
4. Press Start to enter the time and start the
clock.
2. TO TURN ON/OFF THE OVEN LIGHT
The oven light automatically turns ON when the
door is opened. The oven light may also be
manually turned ON or OFF by pressing the
OVEN LIGHT pad
Note: The oven light cannot be turned on if self-clean
feature is active.
3. TIMER ON/OFF
The Timer On/Off serves as an extra timer in the
kitchen that beeps when the set time has run out. It
does not start or stop cooking.
The Timer On/Off feature can be used during any of
the oven control functions.
To set the Timer (for example to set 5 minutes):
1. Set the oven mode knob to the Off position.
2. Press the Timer On/Off. 0:00 with HR inside it
appears and Timer flashes in the display.
3. Press plus(+) or minus(-) to set the desired
time. Plus(+) to increase the time and minus(-)
to decrease the time.
4 .Press Timer On/Off to start the Timer.
The remaining time countdown appears in the
display.
Note: If Timer On/Off is not pressed, the timer returns to
the time of day.
4. SETTING PAD: 6 types of category
1) CHANGE HOUR MODE ON CLOCK
1. Set the oven mode knob to the Off position.
2 .Press and hold Start Time for 3 seconds.
3 .Press plus(+) or minus (-) to set the desired
hour mode on the clock.
4 .Press Start to accept the desired change.
2) CONVECTION AUTO CONVERSION
1. Set the oven mode knob to the Off position.
2 .Press and hold Start Time for 3 seconds.
Then press Start Time twice. Auto appears
in the display.
3 .Press plus(+) or minus(-) to enable or
disable the feature.
4 .Press Start to accept the change.
3) THERMOSTAT ADJUSTMENT
1. Set the oven mode knob to the Off position.
2. Press and hold Start Time for three
seconds.
Then press Start Time repeatedly until
AdJU appears in the display.
3. To increase the temperature, press plus (+)
until the desired amount appears in the
display.
To decrease the temperature, press minus
(-) until the desired amount appears in the
display.
4. Press Start to accept the change.
4) PREHEATING ALARM LIGHT ON/OFF
1. Set the oven mode knob to the Off position.
2. Press and hold Start Time for three seconds
Then press Start Time repeatedly until PrE
appears in the display.
3. Press plus(+) or minus(-) to turn the function
on/off.
4. Press Start to accept the change.
5) BEEPER VOLUME
1. Set the oven mode knob to the Off position.
2. Press and hold Start Time for three
seconds. Then press Start Time repeatedly
until Beep appears in the display.
3. Press plus(+) or minus(-) to select the
desired volume.
4. Press Start to accept the change.
6) TEMPERATURE UNIT (°F or °C)
1. Set the oven mode knob to the Off position.
2. Press and hold Start Time for three
seconds. Then press Start Time repeatedly
until Unit appears in the display.
3. Press plus(+) or minus(-) to select
F(Fahrenheit) or C(Centigrade).
4. Press Start to accept the change.

5. BAKE, TIMED BAKE, DELAYED TIMED BAKE
* This feature can also be used with the:
CONVECTION BAKE and CONVECTION ROAST
modes.
6. OVEN LOCKOUT
1. Set the oven mode knob to the Off position.
2. Press and hold Probe for three seconds.
3. The lock melody sounds, Loc appears in the
display and the lock icon blinks in the display.
4. Once the oven door is locked, the lock
indicator stops blinking and remains on.
5. To deactivate the Lockout feature, press and
hold Probe for three seconds. The unlock
melody sounds and the door and the controls
unlock.
7. SELF-CLEAN
1. Remove all racks and accessories from the
oven.
2. Turn the oven mode knob to select Self Clean.
The oven defaults to the recommended four
hour Self Clean for a moderately soiled oven.
Press plus(+) or minus(-) to select a Self Clean
Time from 3 to 5 hours.
3. Press Start Time.
4. Press plus(+) or minus(-) to enter the time of
day you would like the Self Clean to start.
5. Press Start.
BAKE Desired
temperature START
COOK
TIME Desired time START
START
TIME
Desired
start time START
2-7
USING YOUR RANGE

The Warming Drawer keeps hot cooked foods at
serving temperature.
All food placed in the Warming Drawer should be
covered with an oven-safe lid or aluminum foil to
maintain quality. Do not place foil on bottom or
sides of drawer. Do not use plastic wrap to cover
food. Plastic may melt onto the drawer and be very
difficult to clean. Use only utensils and cookware
recommended for oven use in the Warming Drawer.
Setting the Warming Drawer Control
1. Press Warming Drawer Set/Off. The indicator
light will flash. (If no further buttons are
pressed within 25 seconds, the display will
clear.)
2. Use the plus(+) or minus(-) button to set the
power level: 1 for Low, 2 for Medium, and 3
for High.
3. When the food is ready, or to cancel, press
Warming Drawer Set/Off.
2-8
USING YOUR RANGE
W
WARMING DRA ARMING DRAWER WER
Warming drawer rack in position
CAUTION
• Do not use the warming drawer for storage
of racks, broiler pans, insert pans, plates,
or utensils.
- The warming drawer contains a heating element
which may damage any items not specifically
designed to be used with it and should only be
used to store cookware specifically supplied by LG
with your range.
• Do not put food or foil directly on the
surface or base of the warming drawer.
- This may result in damage to your drawer and may
spoil your food.
• Do not place plastic wrap in the warming
drawer or use it to cover food being heated
in the warming drawer.
- Plastic may melt onto the drawer or surrounding
areas and is very difficult to remove. Use only
aluminum foil or cookware that is capable of
withstanding baking temperature to heat or cover
your food.
• Do not use the warming drawer to heat water
or any other liquids. Spilled liquids may cause
an electrical short or result in severe personal
injury, electric shock or death.
• Never place plastics, paper, canned foods or
other combustible material into the warming
drawer.
- These items pose a severe risk of fire, damage and
injury.
• In the unlikely event that an item falls
behind the warming drawer, always turn
the power off and wait for the warming
drawer to cool before retrieving the item.
- Never attempt to retrieve any items that fall behind
the warming drawer without first turning the power
off and ensuring the warming drawer cavity has
cooled off. Failure to do so may result in severe
personal injury, electric shock or death.

This section instructs you on how to service each component inside the range. The components and their
locations are shown below.
COMPONENT LOCA
COMPONENT LOCATIONS TIONS
Door Locking Motor
& Micro Switch
Oven lamp
Inner broil heater
Encoder PCB
Oven Sensor
Outer broil heater
Convection Heater
Warm drawer
heater
Convection Motor
Surface Elements
Hinge
Door Switch
Infinite switch
Door Latch Assembly
Infinite switch
3-1
USING YOUR RANGE

3-2
COMPONENT ACCESS
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3. To remove the back cover, remove 15 screws
from the back cover
REMOVING THE BACK COVER
REMOVING THE BACK COVER
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
!
Back
Cover

3-3
COMPONENT ACCESS
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3. Remove back cover (See step 3 on page 3-2)
4. To remove the Oven Relay PCB, Disconnect 8ea
connectors.
5. To remove the Power Relay, Disconnect 2ea
connectors.
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
!
REMOVING THE OVEN RELA
REMOVING THE OVEN RELAY PCB, POWER PCB, Y PCB, POWER PCB,
POWER RELA
POWER RELAY AND SURGE FIL Y AND SURGE FILTER TER
Oven Relay PCB
Power Relay
