LG LSG4513BD User manual

!"
INSTALLATION
ENGLISH
#$%&'(('&#)$
*+,-.+/#012344506/27+/8306+
Make sure your range is properly installed and grounded by a qualified installer, according to the installation
instructions. Any adjustment and service should be performed only by qualified gas range installers or service
technicians.
#0/27+/9-::-0;+3427/-,/<3113=7>1+221
•This product must be installed by a licensed plumber or gas fitter.
•When using ball type gas shut-off valves, they must be the T-handle type.
•When using a flexible gas connector, it must not exceed 3 feet in length.
[email protected]/,-./#012344325-0
&--41/$++A+A
Phillips screwdriver
Open-end or adjustable
wrench
Pencil and ruler
Level
Flat-blade screwdriver
Pipe wrench (2)
(one for support)
<32+.5341/B->/<3C/$++A
•Gas line shut-off valve
•Pipe joint sealant that resists action of natural and LP gases
•Flexible metal appliance connector (
3
/
4
" or
1
/
2
" NPT x
1
/
2
" I.D.)
Never use an old connector when installing a new range.
•Flare union adapter for connection to gas supply line (
3
/
4
" or
1
/
2
" NPT x
1
/
2
" I.D.)
•Flare union adapter for connection to pressure regulator on range (
1
/
2
" NPT x
1
/
2
" I.D.)
•Liquid leak detector or soapy water
•Lag bolt or
1
/
2
" O.D. sleeve anchor (for concrete floors only)

!D INSTALLATION
#012344506/27+/8306+
E0@3=F506/30A/<-G506/27+/8306+
9'E&#)$
•B->/17->4A/>1+/2;-/-./:-.+/@+-@4+/2-/:-G+/
30A/5012344/27+/.306+H/IJK=+115G+/L+5672/
M3N3.AO Failure to do so can result in back or
other injury.
•P-/0-2/>1+/27+/A--./730A4+1/2-/@>17/-./
@>44/27+/.306+/A>.506/5012344325-0/-./;7+0/
:-G506/27+/.306+/->2/,-./=4+30506/-./
1+.G5=+H/Doing so can result in serious damage
to the door of the range.
Remove packing material, tape and any temporary
labels from your range before using. Do not remove
any warning-type labels, the model and serial number
label, or the Tech Sheet that is located on the back of
the range.
To remove any remaining tape or glue, rub the area
briskly with your thumb. Tape or glue residue can also
be easily removed by rubbing a small amount of liquid
dish soap over the adhesive with your fingers. Wipe
with warm water and dry.
Do not use sharp instruments, rubbing alcohol,
flammable fluids, or abrasive cleaners to remove tape
or glue. These products can damage the surface of
your range.
Your range is heavy and can be installed on soft
floor coverings such as cushioned vinyl or carpeting.
Use care when moving the range on this type of
flooring. Use a belt when moving the range to prevent
damaging the floor. Or slide the range onto cardboard
or plywood to avoid damaging the floor covering.
97--1506/27+/?.-@+./(-=325-0
Do not locate your range where it may be subject to
strong drafts. Any openings in the floor or wall behind
the range should be sealed. Make sure the openings
around the base of the range that supply fresh air
for combustion and ventilation are not blocked by
carpeting or woodwork.
Your range, like many other household units, is heavy
and can be installed on soft floor coverings such as
cushioned vinyl or carpeting. Use care when moving
the range on this type of flooring.
This appliance must not be installed with a ventilation
system that blows air downward toward the range.
This type of ventilation system may cause ignition and
combustion problems with the gas cooking appliance
resulting in personal injury or unintended operation.
When the floor covering ends at the front of the
range, the area that the range will be installed on
should be built up with plywood to the same level
or higher than the floor covering. This will allow the
range to be moved for cleaning and servicing, as well
as provide proper air flow to the range.
Also, make sure the floor covering can resist
temperatures of at least 167 °F (75 °C). See the
Installation Safety Instructions included in this
manual.
Make sure the wall coverings around your range
can resist the heat generated up to 194 °F (90 °C)
by the range. See the Installation Safety Instructions
included in this manual.
Q31/?5@+/30A/J4+=2.5=34/)>24+2/
(-=325-01
30"
(76.2 cm)
7
14
/
16
"
(20 cm)
11
13
/
16
"
(30 cm)
3
6
/
16
"
(8.5 cm)
3"
(7.6 cm) 17
15
/
16
"
(45.6 cm) 5
14
/
16
"
(15 cm)
6
11
/
16
"
(17 cm)

!R
INSTALLATION
ENGLISH
P5:+015-01/30A/94+3.30=+1
Provide proper clearance between the range and adjacent combustible surfaces. These dimensions must be met
for safe use of your range. The location of the electrical outlet and pipe opening (see Gas Pipe and Electrical
Outlet Locations, page 14) may be adjusted to meet specific requirements. The range may be placed with 0"
clearance (flush) at the back wall.
#012344325-0/94+3.30=+1
30"
(76.2 cm)
30" (76.2 cm)
Minimum
15"
(38.1 cm)
36"
(91.4 cm)
13"
(33.0 cm)
Maximum
depth for
cabinets above
coutertops
Front edge of
the range side
panel forward
from cabinet 0"
To cabinets
below
cooktop and
at the range
back
1
/
4
"
P5:+015-01
28
3
/
4
"
(73.0 cm)
Height
37
59
/
64
"
(96.3 cm)
Depth with door open
43
5
/
32
" (109.6 cm)
Depth with door closed
(includes door handle)
36"
(91.4 cm)
29
7
/
8
"
(75.7 cm)

!S INSTALLATION
#012344506/27+/'025T25@/P+G5=+
Anti-tip
bracket Wall plate
Screw must
enter wood or
concrete
The anti-tip bracket is packaged with an installation
template. The instructions include necessary
information to complete the installation. Read and
follow the range installation instruction sheet.
L'8$#$Q
•Range must be secured with an approved
anti-tip device.
•The range could be tipped by standing, sitting
or leaning on an open door if the range or
anti-tip device is not properly installed.
•After installing the anti-tip device, verify that it is
in place by carefully attempting to tilt the range
forward.
•This range has been designed to meet all
recognized industry tip standards for all normal
conditions.
•The installation of the anti-tip device must meet
all local codes for securing the appliance.
•The use of this device does not preclude tipping
of the range when not properly installed.
•A child or adult can tip the range and be killed.
•Install the anti-tip device to the structure and/
or the range. Verify the anti-tip device has been
properly installed and engaged by following the
guide of the Anti tip bracket template.
•Engage the range to the anti-tip device by
following the guide of the Anti tip bracket
template. Ensure the anti-tip device is re-
engaged when the range is moved by following
the guide of the Anti tip bracket template.
•Re-engage the anti-tip device if the range is
moved. Do not operate the range without the
anti-tip device in place and engaged.
•See installation instructions for details.
•Failure to do so can result in death or serious
burns to children or adults.
)@25-034/8+3./U544+.
If the counter does not bridge the opening at the rear
wall the rear filler kit, that is provided with the slide in
range, will be needed.
$)&J
If the countertop depth is greater than 25" there will
be a gap between the filler kit and the back wall.
If the countertop depth is less than 24", the control
panel will not sit flush with the countertop.
#012344506/27+/8+3./U544+.
!Using a screwdriver, remove the upper four
screws that attach the rear bracket and loosen
the lower two screws.
VPlace the rear filler on the rear bracket.
"Tighten the two lower screws on the rear
bracket. Insert one of the screws removed in
step 1 in the slot at each end of the rear filler.
DStore the remaining two screws with these
instructions for future use.
?.-G5A506/'A+W>32+/Q31//
%>@@4C
Your range is designed to operate at a pressure of
5" of water column on natural gas or 10" of water
column on LP.
Make sure you are supplying your range with the type
of gas for which it is configured.
This range is convertible for use on natural or LP gas.
When using this range on LP gas, conversion must
be made by a qualified LP installer before attempting
to operate the range.
For proper operation, the pressure of natural gas
supplied to the regulator must be between 5" and 13"
of water column.
For LP gas, the pressure supplied to the regulator
must be between 10" and 13" of water column. When
checking for correct operation of the regulator, the
inlet pressure must be at least 1" more than the
operating (manifold) pressure as given above.
The pressure regulator located at the inlet of the
range must remain in the supply line regardless of
which type of gas is being used.
A flexible metal appliance connector used to connect
the range to the gas supply line should have an I.D.
of
5
/
8
" and a maximum length of 5 feet. In Canada,
flexible connectors must be single wall metal
connectors less than 6 feet in length.

!X
INSTALLATION
ENGLISH
9-00+=2506/27+/8306+/2-/Q31
Shut off the range gas supply valve before removing
the old range and leave it off until the new hook-up
has been completed.
Because hard piping restricts movement of the range,
the use of a CSA International-certified flexible metal
appliance connector should be used unless local
codes require a hard-piped connection.
A manual valve shall be installed in an accessible
location in the gas piping external to the appliance
for the purpose of turning on or shutting off gas to the
appliance.
Never reuse an old connector when installing a new
range.
To protect against gas leaks, use a qualified pipe joint
sealant on all external threads.
!Install a male
1
/
2
" or
3
/
4
" flare union adapter to the
NPT internal thread of the manual shut-off valve,
taking care to back-up the shut-off valve to keep
it from turning.
VInstall a male
1
/
2
" flare union adapter to the
1
/
2
"
NPT internal thread at the inlet of the pressure
regulator. Use a backup wrench on the pressure
regulator fitting to prevent damage.
Check that the gas pressure regulator valve is in the
open position.
Lever’s open
position
Lever’s closed
position
$)&J
•The gas pressure regulator valve is open when
shipped. If the range does not work properly
after installation, make sure the regulator valve
is still open.
"Connect a flexible metal appliance connector to
the adapter on the range. Position the range to
permit connection at the shut-off valve.
DWhen all connections have been made, be sure
all range controls are in the OFF position and the
pressure regulator valve is open before turning
on the main gas supply valve. Gas leaks may
occur in your system and create a hazard. Gas
leaks may not be detected by smell alone.
Check all gas connection joints and fittings for
leaks with a non-corrosive leak detection fluid,
then wipe off.
Gas suppliers recommend you purchase and
install a UL approved gas detector. Install
and use in accordance with the installation
instructions.
L'8$#$Q
•Do not use a flame to check for gas leaks.
•Isolate the range from the gas supply system
by closing its individual shut-off valve during
any pressure testing of the gas supply system
at test pressures equal to or less than
1
/
2
" psig
(3.5 kPa).
U4+K5Y4+/9-00+=2-./M--F>@
1
/
2
" Adapter
1
/
2
" Adapter
Pressure regulator
Flex connector
(6 ft. max.)
Adapter
Gas shut-off
valve
1
/
2
" or
3
/
4
" Gas
pipe
Gas Flow into Range
Installer: Inform the consumer of the location of the gas
shut-off valve.
?.+11>.+/8+6>432-./?-1525-0/
Pressure Regulator

!Z INSTALLATION
J4+=2.5=34/9-00+=25-01
J4+=2.5=34/8+W>5.+:+021
120 Volt, 60 Hz, properly grounded dedicated circuit
protected by a 15 or 20 Amp circuit breaker, or slow
blow fuse.
If an external electrical source is utilized, the
appliance, when installed, must be electrically
grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical
Code, ANSI/NFPA 70.
Q.->0A506
IMPORTANT: FOR PERSONAL SAFETY, THIS
APPLIANCE MUST BE PROPERLY GROUNDED.
The power cord of this appliance is equipped with
a 3-prong (grounding) plug which mates with a
standard 3-prong grounding wall receptacle to
minimize the possibility of electric shock hazard from
this appliance.
The customer should have the wall receptacle and
circuit checked by a qualified electrician to make sure
the receptacle is properly grounded.
Where a standard two-prong wall receptacle is
encountered, it is the personal responsibility and
obligation of the customer to have it replaced with a
properly grounded three-prong wall receptacle.
DO NOT, UNDER ANY CIRCUMSTANCES, CUT OR
REMOVE THE THIRD (GROUND) PRONG FROM
THE POWER CORD.
A word about GFCI’s – GFCI’s are not required or
recommended for gas range receptacles.
Ground Fault Circuit Interrupters (GFCI’s) are
devices that sense leakage of current in a circuit
and automatically switch off power when a threshold
leakage level is detected. These devices must
be manually reset by the consumer. The National
Electrical Code requires the use of GFCI’s in kitchen
receptacles installed to serve countertop surfaces.
Performance of the range will not be affected
if operated on a GFCI-protected circuit but the
occasional resetting of the circuit can become an
annoyance.
Ensure proper ground
exists before use
?.+,+..+A/
<+27-A
9'E&#)$
Have the circuit checked by a qualified electrician
to make sure the receptacle is properly grounded.
Do not use an adapter plug. Disconnecting of the
power cord places undue strain on the adapter
and leads to eventual failure of the adapter ground
terminal.
Installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54.
The installation of appliances designed for mobile
home installation must conform with the Manufactured
Home Construction and Safety Standard, Title 24
CFR, Part 3280 (formerly the Federal Standard
for Mobile Home Construction and Safety, Title
24, HUD, Part 280) or, when such standard is not
applicable, the Standard for Manufactured Home
Installations, latest edition (Manufactured Home Sites,
Communities and Set-Ups), ANSI A225.1, latest
edition, or with local codes. In Canada, mobile home
installation must be in accordance with the current
CAN/CSA Z240/MH Mobile Home Installation Code.
%+34506/27+/)@+05061
Seal any openings in the wall and floor after electrical
and gas supplies are completed.

![
INSTALLATION
ENGLISH
'11+:Y4506/27+/%>.,3=+/
*>.0+.1
9'E&#)$
Do not operate the burners without all parts in
place.
Place the burner caps and heads on the cooktop.
Make sure that the caps and heads are placed in the
correct locations. There is one small, one medium,
one large, one oval(center), and one extra large
burner head and cap.
Center Burner
(For Model : LSG4513)
Oval (Center) burner
head/cap assembly
(For Model : LSG4511)
Medium burner head
and cap
Small burner
head and
cap
Medium
burner
head
and cap
Large burner
head and cap
Front of range Extra large burner
head and cap
Hole
Electrode
Make sure the hole in the burner head is positioned
over the electrode.
97+=F506/#60525-0/-,/27+/
%>.,3=+/*>.0+.1
J4+=2.5=/#60525-0
Select a surface burner knob and simultaneously
push in and turn to the (52+ position. You will hear
a clicking sound indicating proper operation of the
spark module.
Once the air has been purged from the supply lines
the burner should ignite within 4 seconds. After the
burner ignites, rotate the knob out of the (52+ position.
Try each burner in succession until all burners have
been checked.
\>3452C/-,/U43:+1
The combustion quality of the burner flames needs to
be confirmed visually.
A B+44-;/,43:+1/- Call for service.
B B+44-;/25@1/-0/->2+./=-0+1 - This
is normal for LP gas.
C %-,2/Y4>+/,43:+1 - This is normal
for natural gas.
$)&J
•With LP gas, some yellow tipping on outer
cones is normal.
'A]>12506/27+/%>.,3=+/*>.0+./2-/27+/
(-;/U43:+/I%5::+.O/%+22506
!Light all surface burners.
VTurn the knob on the burner being adjusted to
(-.
"Remove the knob.
DInsert a small, flat-blade screwdriver into the
valve shaft.
$)&J
Hold the valve shaft with one hand while turning
the screw to adjust with the other.
RReplace the knob.
STest the flame stability.
Test 1: Turn the knob from M5 to (- quickly. If the
flame goes out, increase the flame size and test
again.
Test 2: With the burner on a (- setting, open
and close the oven door quickly. If the flame is
extinguished by the air currents created by the
door movement, increase the flame height and
test again.
XRepeat steps 1-6 for each surface burner.

V^ INSTALLATION
97+=F506/)@+.325-0/-,/*3F+/_/*.-54/
*>.0+.1
To check ignition of the Bake burner, follow the steps
below:
!Remove all packing materials from inside the
oven cavity.
VTurn oven mode knob to select *3F+. 350 °F
appears in the display.
"Press %23.2.
It may take between 30 and 90 seconds for the
burner to start heating.
To check ignition of the Broil burner, follow the steps
below:
!Turn oven mode knob to select *.-54/M567. M5
appears in the display.
VMake sure the door is closed.
"Press %23.2.
It may take between 30 and 90 seconds for the
burner to start heating.
$)&J
Do not try to light either the Bake or Broil burners
during a power outage. The range has an
electrical ignition system and cannot be used
without power.
'A]>12506/'5./%7>22+.1/I,-./(?/
9-0G+.15-01O
The range comes from the factory with the air
shutters adjusted for proper air flow for natural gas.
If converted to LP, follow the instructions provided in
the conversion kit to properly adjust the air shutters.
LP conversion must be performed by a qualified
technician.
(+G+4506/27+/8306+
Level the range by adjusting the leveling legs.
Extending the legs slightly may also make it easier to
insert the rear leg into the anti-tip bracket.
Use a level to check your adjustments. Place the level
diagonally on the oven rack, and check each direction
for level.
First check direction .
Then check direction . If the level doesn’t show level
on the rack, adjust the leveling legs.
1
2
J0636506/27+/'025T25@/P+G5=+
Anti-tip
bracket
Leveling leg
!Slide the range against the wall, making sure
the back leg slides into and engages the anti-tip
bracket.
VCheck for proper installation by grasping
the front edge of the cooktop and carefully
attempting to tilt the range forward.
