RJP-201B/202B
Remote Jack Pack
Installation & Setup Guide
Warranty

206-4094
2
For Customer Support/Service, please call: 1-888-865-3026
www.lgcommercial.com
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK - - USE ONLY INDOORS
ATTENTION:
RISQUE DE CHOCS ÉLECTRIQUE - - POUR INSTALLATION À L¡¯INTÉRIEUR SEULEMENT
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
AVERTISSEMENT:
L’appareil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures et de
plus qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a residential installation. This equipment gen-
erates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or more of the follow-
ing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way (except as noted herein) without written authoriza-
tion from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to oper-
ate this product.
COMPLIANCE:
The responsible party for this product’s compliance is:
LG Electronics U.S.A., Inc., 2000 Millbrook Drive
Lincolnshire, IL 60069, USA • Phone: [phone].
© Copyright 2008, LG Electronics U.S.A., Inc.
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069

3
206-4094
Table of Contents
Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Installation
Installation in Wall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installer Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8
End-User Operation
End-User Connections Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
End-User Multi-Media Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
End-User Connectable Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
End-User Audio/Video Input Priorities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Reference: Cable Bundle Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessory Cable: DVI-HDMI Adapter Cable/Strain Relief . . . . . . . . . . . . . . . . . . . . . 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 16
Troubleshooting
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting Flow Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Quick Setup Reference Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Wall Hole Cutout Template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 22- 23
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

206-4094
4
Overview
The Remote Jack Pack (RJP) contains circuitry to determine the pres-
ence of a signal at each input jack.
(Note: Audio In, Audio In L-R and Video In inputs detect the pres-
ence of the inserted plug, regardless if a signal is present or not.)
When a source is detected, its priority is compared to the priority of
other sources which may be present. If the newly-connected active
source is of higher priority than the existing source(s), the RJP
directs the TV display panel to that source.
Video and audio are monitored and switched independently.
Power is supplied to the RJP by the TV display panel via the control
signal cable.

5
206-4094
Introduction
Conveniently installed right in the room where guests will stay, the LG Remote
Jack Pack, (RJP) multi-media interface is available to end-users to connect audio,
video and computer devices to hear and view on the in-room TV display panel.
The RJP can be set up to interface with the TV display panel to show the image
and/or sound from a portable DVD/CD Player, Camcorder, MP-3 Player, Notebook
computer, or portable Video Game Player. Or, devices with digital video output
such as DVD players. If the end-user does not connect any devices, then the in-
room TV display panel will remain on the source selected. When the end-user con-
nects a device, the interface switches the TV display panel to the new source.
The RJP interface is designed to be able to process audio from one source, and
video separately from a different source, if required. (The end-user can work on a
laptop computer while listening to music from an MP-3 player.) However, only
one audio and one video source can be heard/seen at the same time.
The end-user can simply plug in its Audio/Video cable(s) to the RJP input jack(s)
and turn the device on. The RJP completes the connection between the newly-
connected audio and/or video source and the TV display panel. No end-user
menus are involved, all connections are made directly to the interface.
The RJP continually monitors its source inputs. When a signal is detected, (a
device is plugged into one of the RJP inputs) the interface sends a message to
the TV display panel to switch to the newly-connected source (if the new source
is of higher priority). The interface allows only the higher priority audio and
video to be heard and seen on the TV display panel. The control cable supplies
12 Volt DC power from the TV display panel to operate the interface.
Overview
CLEANING CAUTION:
Since the end-user jack panel is exposed, use extreme caution when
cleaning. Do not use liquid cleaners on the connections panel. Do
not allow liquids to be spilled, sprayed onto or otherwise come into
contact with the connections panel on both the end-user side and
the installer side. Clean with a slightly damp cloth.

206-4094
6
The RJP can only be installed in a vertical position into the cutout
provided in the wall. Vertical mounting in the cutout is
required so that a liquid will not be able to flow into the
RJP. The cable wiring assembly and individual cables will
need to be connected to the RJP. Route cable bundle to
avoid damage from chaffing, binding etc. The RJP must only be
installed in the cutout opening. It will then need to be secured with
the two retainer clips and machine screws provided.
Note: The connector set with right angle connectors is for connecting
to the RJP.
Installation Instructions
1. Route cable bundle.
2. Connect cable bundle to RJP.
3. Remove Screw Covers at each end of RJP.
4. Preset retainer screw/clips to vertical position to pass through wall
cutout opening.
5. Insert the RJP into the wall cutout opening.
6. Rotate screws to position clips horizontally to engage wall cutout.
7. Tighten screws provided to hold the RJP securely in place. Check
to assure that the RJP is securely mounted.
8. Replace screw covers.
Installation in Wall Cutout
CONTROL OUT AUDIO OUT
R L RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CONTROL OUT AUDIO OUT
R L VIDEO OUT RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CAUTION: The cable wiring assembly should be handled
carefully to avoid damage, as it is routed between display
panel and the RJP.
CONTROL OUT AUDIO OUT
R L RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CONTROL OUT AUDIO OUT
R L VIDEO OUT RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
Note: The actual appearance of the cable assembly, cabinet, mounting hardware etc., may be different than shown in
these drawings.
Wall Wall
4.
6.
4.
6.

7
206-4094
CONTROL OUT AUDIO OUT
R L RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CONTROL OUT AUDIO OUT
R L VIDEO OUT RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CAUTION: Be sure power is
turned off before attempt-
ing to connect the RJP to
the TV display panel.
Installer Connections
Control Cable (8-Pin RJ-45)
w/Yellow Protective Sleeve
Connect to RJP port on TV
display panel.
Audio/Video Cables
Connect to Left-Right
Audio/composite Video
input jacks on TV display
panel.
RGB PC Video Cable
Connect to RGB input on
TV display panel.
Digital Video Cable
Connect to digital video
input on TV display panel.
The RJP cables listed below are to be connected to the TV display panel.

206-4094
8
Installer Connections Contd.
After completing connections between the RJP and the TV display panel, be sure
the installer menu items have been updated to enable the RJP. Installer Menu
item 040 Auto Camport needs to be set to 000 and 093 RJP Available needs to be
set to 001. (See TV installation guide for complete instructions on new TV installa-
tions.) A brief description of each of the available RJP connections is provided
below.
Digital Video Output
Connect to digital video input on TV display panel to allow the end-user to show
DVD’s high-resolution digital video on the in-room TV.
PC RGB Output
Connect to RGB input on TV display panel to allow the end-user to show a com-
puter/Laptop image on the in-room TV.
Control 8-Pin RJ-45 Output Port
Connect to RJP port on TV display panel for control and power supply for the RJP
multi-media interface.
Left-Right Audio/Video Output Jacks
Connect to Left-Right Audio/composite Video inputs on TV display panel.

9
206-4094
The end-user simply plugs a device such as a laptop computer with the appropriate
cables, as shown in the example, into the RJP connection panel. The Remote Jack
Pack senses the new source connection and switches the TV to the newly-connected
source. The device’s sound and image are then presented on the in-room TV display
panel. The TV display panel adjusts automatically to the computer output format.
When the laptop is disconnected, the interface directs the TV to revert back to the
previous source for video and audio. The end-user has several
audio/video connection
options available for con-
necting external devices. The
guest/user can connect a
portable DVD Player, CD
Player, Camcorder, MP-3
Player, Notebook Computer,
Portable Video Game Player,
etc.
An end-user could connect
and hear audio from one
device and connect and view
video from a different device.
The RJP offers two different
stereo audio input jacks to
accommodate various end-
user devices. However, only
the higher priority audio
source will be selected and
heard. Similarly, multiple
video inputs are available,
but only the higher priority
video source will be selected
and displayed. (See page 12
input priorities.)
Typical
In-Room TV
Display Panel
End-User
Connection Panel
Mounted on Wall
®
Today's
Report
Today's
Report
AUDIO IN
VIDEO IN
AUDIO IN
L R
PC VIDEO IN
DIGITAL VIDEO IN
End-User Connections Overview

206-4094
10
End-User Multi-Media Interface Connections
AUDIO IN
VIDEO IN
AUDIO IN
L R
PC VIDEO IN
DIGITAL VIDEO IN
Audio/Video Input Jacks
Connection for Left-Right
Audio/composite Video
sources.
PC Video (RGB) Input port
Connection for PC Video.
3.5 mm Stereo Audio
Input Jack
Connection for MP-3 player
or PC audio.
Digital Video Input Port
Connection for digital
video sources. (portable
DVD)
(Note: Audio In, Audio In
L-R and Video In inputs
detect the presence of an
inserted plug, regardless if
a signal is present or not.)

11
206-4094
Examples of devices a guest/end-user
can connect are shown to the right.
The End-User Can Connect:
• PC Laptop/Notebook Computers
• Portable Video Game Players
• Portable DVD/CD Players
• Camcorders
• Digital Cameras
• MP-3 Audio Players
End-User Connectable External Source Devices

206-4094
12
End-User Audio/Video Input Priorities
End-User Audio/Video Input Priorities
Note: The highest priority is listed first.
Audio Inputs/Sources
1st. 3.5 mm Stereo Audio Jack
2nd. Left - Right Audio Jacks
3rd. Digital Video Audio
4th. TV Display Panel Tuner Audio (Audio Default)
Video Inputs
1st. Digital Video
2nd. PC Video
3rd. Video Composite jack
4th. TV Display Panel Tuner Video (Video Default)

13
206-4094
Cable Bundle Assembly
Reference
1.
AUDIO
L-R
2.
VIDEO
4.
RGB 5.
DIGITAL
VIDEO
3.
CONTROL
w/Yellow
Sleeve
Cable
Assembly
approx.
12.0
Feet
in
Length
Output Cable Assembly Parts List
Item Description
No.
1. Left/Right Audio Cable.
2. Composite Video Cable.
3. RJ-45 Control Cable
w/Yellow Protective Sleeve
s
4. RGB Cable.
5. Digital Video Cable.
6. Cable Ties.
Connect to Outputs on RJP
6. Cable Tie
Mesh Sleeving
AUDIO
L - R
VIDEO
RGB DIGITAL
VIDEO
CONTROL
.. .. .. ..
.. .. .. ..
.. .. .. ..
Cable
Assembly
Approx.
3.0
Feet
in
Length
RJP-202B
Size RJP-201B
Size
Note: Connector set
with right angle
connectors is for
connecting to RJP.

206-4094
Accessory Cable: DVI to HDMI Adapter Cable
Strain Relief
.....
.....
.....
.....
....
DVI/PC
AUDIO
IN HDMI/DVI
IN
RS-232C
PC IN
UPDATE
DIGTAL
AUDIO
OUT (OPTICAL)
RS-232C
NORMAL
(DTV)
CONTROL
AUDIO IN VIDEO 1 IN
VIDEO 2 IN
AUDIO IN
M.P.I.
ANTENNA
CABLE
RJP
INTERFACE FUTURE
USE
AC IN
Strain Relief for
Accessory HDMI Cable
The weight of the DVI
adapter connection /
cable bundle may put a
strain on the HDMI con-
nection, causing it to
become disconnected
from the TV. Relieve the
weight by attaching a
cable tie in the position
shown.
Note: The actual appear-
ance of the TV etc., may be
different than shown in the
drawing.
Special Connections
Note: DVI to HDMI
Adapter Cable
For TVs equipped with
HDMI, this adapter cable
will be required to connect
the RJP for digital
video/audio.
Male
Connector
Female
Connector
14

15
206-4094
Specifications
Application
Makes available to the hotel’s guests, a multi-media interface to the in-room TV display panel. Audio/Video
input jacks are provided for guest devices such as DVD/CD Players, Laptop Computers, Camcorders, etc.
Installer Connections
Digital Video Out Digital Video Connector
RGB OUT 15-pin RGB PC Monitor Connector
Control Out Control Jack (8-Pin RJ-45)
Video Out 1 Vpp into 75 ohms, Composite or Y+C Combined
Video Jack +/- 1 db @ 4.2 MHz
Audio Out L-R Left - Right Audio Jacks
Max: 1.6 V RMS (1 KHz) @ 600 ohms,
Typ: 250mV RMS @ 600 ohms
Supplied Accessories List
(Cable Assembly)
Note: RJP-201B cable bundle is approx. 12 feet in length and RJP-202B cable bundle is approx. 3 feet in length
• Digital Video Cable
• PC Video RGB Cable
• Control Cable (8-Pin RJ-45)
• 1-Set Left-Right Audio/Video Cables
(Misc. Hardware) • 2-Security (pin-in) Torx (T-20) head Screws (2-Installed)
• 2-Retainer Clips, L-Shaped (2-Installed)
• 1 Black Cable Tie (DVI to HDMI Adapter Cable see page 14.)
(Separate Cable) • DVI (F) to HDMI (M) Adapter Cable (Optional connection)
Note: Design and specifications are subject to change without prior notice.

206-4094
16
Specifications Contd.
Dimensions Height 2.125 Inches (53.975 mm)
Width 9.0 Inches (228.6 mm)
Depth 3.125 Inches (79.375 mm)
Weight (Approx.) .7 Pounds (0.317514 kgs)
End-User Device Inputs
Audio In 3.5mm Stereo Audio Jack
Audio In L-R Left - Right Audio Jacks
(Nom In: 250mV RMS @ 22K ohms)
Overload In: 1.6V RMS Max
Video In Composite Video Jack
1 Vpp, 75 ohms
PC Video In 15-pin RGB PC Monitor Connector
Digital Video In Digital Video Connector
Regulatory FCC Class B, Digital Video Device
Environmental Parameters
Operating Temperature 0°to 40°Degrees Celsius
(32°to 104°Degrees Fahrenheit)
Storage Temperature -20°to 85°Degrees Celsius
(-4°to 185°Degrees Fahrenheit)
Cooling Free Air Convection
Humidity 10% to 90% Non-condensing

17
206-4094
Troubleshooting
Equipment Setup Analysis Notes
• Make sure all connectors and connections are tight and secure on user device, RJP and TV.
• Check to assure user device, RJP and TV are all powered up and working properly and that the TV Installer menu items
are set correctly.
• Audio and Video can be from different sources. Default is TV tuner Audio and Video, if no other audio/video source is
connected.
• Audio source must be viable. The audio output from the customer’s device must be present when connected to be
heard at the TV.
Test Procedures
• Test and connect only one user device to determine if RJP is providing audio/video to TV.
• Test user device on another RJP (perhaps located in a different room) to determine if user device is compatible with
RJP.
• On LCD or Plasma TV, Installer menu items:
040 Auto Camport needs to be disabled by setting it to 000.
093 RJP Available needs to be set to 001 to enable RJP mode.
Following are some possible solutions to problems:
Problem Possible Cause(s) Check RJP, User Device and In-Room TV
No Power • Power not connected?
No Audio • Have all audio connections been made?
• Audio output available?
• Volume level turned up?
• Sound muted?
• TV setup correct for RJP? (Installer menu item 040 is set to 000 and 093 set to 001.)
• Try another RJP.
• Priority level? (Disconnect other devices.)
• Connections made after 040 and 093 menu items set.
(Make connections before adjusting menu items 040 and 093.)
No Video • Video output available?
• All video cables connected?
• TV setup correct for RJP? (Installer menu item 040 is set to 000 and 093 set to 001.)
• Priority level? (Disconnect other devices.)
Poor Video • Check connections. (Video pass-through no user action possible.)

206-4094
18
Troubleshooting Flow Charts
No
Power
Power
Failure? Restore
Power
TV
Is power cord
connected
?
Connect
Power
Cord
TV
Is TV power
turned on
?
Turn
Power
On
Yes
No
No
Yes
No
Yes
User
Device
Is power cord
connected
?
Connect
Power
Cord
No
Yes
User
Device
Is device
turned On
?
Turn
Power
On
No
Yes
Yes
No
No
Yes
Yes
Yes
No
RJP
Are other
audio devices
connected
?
Disconnect
other
Audio devices
No Audio (or
not desired
Audio)
RJP
Is Audio
connected
?
TV
Are
Speakers
turned Off
?
Turn
Speakers
On
Connect
Audio
Cables
TV
Is sound
Muted
or set too
low
?
Press
Volume
Up
No
No
Yes
User
Device
Audio
available &
turned up
?
Turn
Volume
Up
User
Device
Is Audio
connected
?Connect
Yes
No
TV
Is TV
turned
On
?
Turn
TV On
Are
Installer menu
items set up?
No
Yes
No
Yes
No
Yes
No
RJP
Are other
Video devices
connected
?
Disconnect
other
Video devices
No
User
Device
Is correct
Video output
selected
?
Select
correct Video
output
No
Yes
No Video (or
not desired
Video)
RJP
Is Video
connected
?
TV
Is TV
turned
On
?
Turn
TV On
Connect
Video
Cable
User
Device
Is Video
connected
?Connect
Are
Installer menu
items set up?
Yes
PC
External
Port

19
206-4094
Quick Setup Guide
CONTROL OUT AUDIO OUT
R L RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
CONTROL OUT AUDIO OUT
R L VIDEO OUT RGB OUT DIGITAL VIDEO OUT
REMOTE
AUDIO IN
.....
.....
.....
.....
....
DVI/PC
AUDIO
IN HDMI/DVI
IN
RS-232C
PC IN
UPDATE
DIGTAL
AUDIO
OUT (OPTICAL)
RS-232C
NORMAL
(DTV)
CONTROL
AUDIO IN VIDEO 1 IN
VIDEO 2 IN
AUDIO IN
M.P.I.
ANTENNA
CABLE
RJP
INTERFACE FUTURE
USE
AC IN
RJP-110W Remote Jack Pack (See other side)
• An example of usage would be to have your cell phone and PC computer plugged into
the AC outlets recharging while you listen to a CD player and watch the stock report on TV.
Or, listen to the hotel entertainment network and use your personal PC computer.
• You can connect your portable DVD/CD Player, Camcorder, MP-3 Player, Laptop PC, Video
Game Player or other personal entertainment devices like your cell phone.
®
PC Game
Machine DVD
Player Camcorder MP3
Player
Digital
Camera
1.
2.
3.
Typical TV Display Panel
Installer Menu
Item Description Set
040 Auto Camport 000
093 RJP Available 001
RJP-110W Remote Jack Pack
Hotel Guest Multi-Media Interface
• The LG Remote Jack Pack is provided to connect personal audio, video
and PC devices to hear and view on the in-room TV/display panel.
• As shown on the left, you can connect a portable DVD/CD Player,
Camcorder, MP-3 Player, Laptop PC, Video Game Player and other enter-
tainment devices -- charge your cell phone, laptop etc. and watch TV.
CAUTION: Do not connect hair dryers, clothing irons, coffee makers or
other similar high-current electric devices to the four AC power outlets
provided. The maximum load for all four outlets is 10 Amps.
How to Use the Multi-Media Interface
• Plug your device’s power cord into one of the four AC outlets.
• Connect the device’s audio/video output to the multi-media interface.
• Listen to audio from one device and view video from a different
device. For example you can listen to your MP-3 player while you work
on your laptop PC. The in-room TV plays sound from your MP-3 player
and displays your laptop PC’s image on the TV’s screen. Or, more typically
audio/video from the same device. (See other side for available connec-
tions.)
PC
Game
Machine
DVD
Player
Camcorder
MP3
Player
Digital
Camera
Multi-Media Interface
Quick Reference Guide
Note: All the multi-media connection optionsshown above may not be available at this hotel.
Please check with the hotel to confirm what resources are available.
7AMP MAXIMUM CURRENT
P
R
E
S
T
O
S
R
E
S
E
T
AUDIOIN
VIDEOIN
AUDIOIN
L R
PCVIDEO IN
DIGITALVIDEO IN
Standard
120 Volt
60Hz AC
Power
Outlet
Installer RJP Quick Setup Reference
Guide Following are the tasks associ-
ated with installing and setting up
an RJP System.
1. Make all hard wire connections to
RJP and TV.
2. Install RJP in wall cutout.
3. Plug all system components into
power sources.
4. Adjust TV installer menu items 040
and 093 to enable RJP capability.
(See TV installation guide for com-
plete instructions on new TV
installations. The master TV setup
can be modified to include RJP
settings for multiple system instal-
lations.)
5. Test the system with user-type
devices to assure TV sound/picture
are as desired.
6. Provide user information in
room. (As applicable to your enter-
tainment system.)
• RJP Tent Card. (Or comparable
equivalent from Lodge)
• RJP Quick Reference Guide. (Or
comparable equivalent from Lodge)

LG Electronics U.S.A., Inc.
2000 Millbrook Drive, Lincolnshire, IL 60069 206-4094
Issue A
Remote Jack Pack Welcome to the LG family! We believe that you will be pleased with your new LG product.
Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law.
This warranty gives you specific legal rights, and you may also have other rights that vary
from state-to-state within the U.S.A.
LG’S RESPONSIBILITY
Warranty Term One year parts and labor from date of purchase or delivery date.
Parts New or remanufactured replacements for factory-defective parts may be used. Such replace-
ment parts are warranted for the remaining portion of the original warranty period.
Warranty Service Warranty service is provided call 1-888-865-3026 for further information.
Not Covered This warranty covers manufacturing defects and does not cover installation, adjustment of
customer controls, installation or repair of antenna systems, cable converters or cable compa-
ny-supplied equipment; it also does not cover damage due to misuse, abuse, negligence, acts
of God or other causes beyond the control of LG. Any alteration of the product after manufac-
ture voids this warranty in its entirety.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICU-
LAR PURPOSE, AND LG SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, OR
INCIDENTAL DAMAGES OF ANY KIND, INCLUDING LOST REVENUES OR PROFITS IN CONNEC-
TION WITH THIS PRODUCT. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU.
OWNER’S RESPONSIBILITY
Effective Warranty begins on the date of installation of the RJP Multi-Media Interface.
Warranty Date For your convenience, keep the dealer’s dated bill of sale or delivery ticket as evidence
of the purchase date.
Installation Read the Installation and Setup Guide carefully so that you will understand the functions of
Guide the RJP and how to make adjustments.
Antenna Reception problems caused by inadequate antenna or faulty antenna connections are the
owner’s responsibility.
Audio Output Audio problems caused by inadequate audio devices or audio material with sound level lapses
are not within the control of LG and therefore are the owner’s responsibility.
Warranty Service For warranty service information, call 1-888-865-3026.
- A replacement unit that is LG’s responsibility (see above) will be provided without charge.
Other service is at the owner’s expense.
- If you have any problem in obtaining satisfactory warranty service, call 1-888-865-3026.
- You must provide the model number, serial number and date of purchase or date of original
installation.
- Before you ask for warranty service, reread this guide. You might avoid a service call.
For Customer Support/Service please call: 1-888-865-3026
www.lgcommercial.com
RJP-201B/202B Warranty
