LG DSH6 User manual

SIMPLE MANUAL
Wireless
Sound Bar
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
DSH6
Copyright © 2017 LG Electronics. All Rights Reserved
www.lg.com
*MFL70239902*
ENGLISH
Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
Subwoofer Connection1
The buttons are located on the rear.
Rear Panel
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
PORTABLE IN ········ Connect to a Portable device
USB port ················· Connect to a USB device
HDMI IN ········· Connect to HDMI out on a device
HDMI OUT (TV ARC) ·············· Connect to a TV
Place the wireless subwoofer near the speaker and
follow steps below.
aConnect the power cord of wireless subwoofer
to the outlet.
bTurn on the main unit. :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
green LED turns on.
Subwoofer Connection Manually
aReset the Subwoofer
If the green LED on the subwoofer blinks quickly,
skip this step and go to b
• Press and hold pairing button for 5 seconds.
• The LED lights up alternately in red and green.
• Plug out the power cord. After the LED turns
off completely, plug in the power cord again.
When the reset is completed, the subwoofer's green
LED blinks quickly.
bReset the sound bar
• Adjust volume to minimum. "MIN" appears on
display window.
• Press and hold (Mute) button on the
remote control for 3 seconds.
"SUB - WF RESET" appears on display
window.
• Turn the sound bar’s power off and on while
the subwoofer’s green LED blinks.
When the connection is completed, you can see the
green LED on the subwoofer.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1m to prevent wireless
interference.
>1m
8: Turns down the volume at night.
AV SYNC: Synchronizes the audio and video.
AUTO VOL: Adjusts the volume level appropriately.
AUTO POWER: Automatically turns on by an input source.
Replacement of battery
Remote control
aConnect the sound bar to the TV using
Optical cable.
bSet up [External Speaker (Optical)] on
your TV setting menu.
TV
TV
TV Connection2
Optical Connection
HDMI(ARC) Connection
aConnect the sound bar to the TV using
HDMI cable.
bSet up [External Speaker (HDMI ARC)] on
your TV setting menu.
Connect with the Sound Bar and TV using
Optical ( ) or HDMI ARC ( ).
Additional Device Connection
aConnect to the external device as follows.
TV
OR
(Set-top Box,
Player etc.)
bSet the input source by pressing Fon the remote
control or unit repeatedly.
OR
HDMI connection is unavailable if your TV does
not support HDMI ARC.
Specication
Power
consumption
Refer to the main label.
Networked standby : 0.5 W
(If all network ports are activated.)
AC adapter
yModel :
DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput :
100 - 240 V ~ 50 - 60 Hz
1.2 A
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
945 mm x 53 mm x 85 mm
Without foot
Net Weight Approx. 2.6 kg
Bus Power
Supply (USB) 5 V 0 500 mA
Amplier
(Total RMS
Output power)
320 W RMS
Designandspecicationsaresubjecttochangewithout
notice.
How to disconnect the wireless network
connection or the wireless device
Set up the AUTO POWER ON/OFF function to off and
turn off the unit.
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
Wireless Sound Bar is in compliance with Directive 2014/53/
EU. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be
installed and operated with a minimum distance of 20 cm
between the device and the body.
Frequency range Output power (Max.)
2402 to 2480 MHz 10 dBm
5730 to 5821 MHz 13 dBm
Additional Information
