LG FH6 Specification sheet

www.lg.com
*MFL69492411*
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
FH6
SIMPLE MANUAL
HIGH POWER
SPEAKER
SYSTEM
ENGLISH
FOR THE GUARANTEE TERMS & CONDITIONS, PLEASE REFER TO LAST
SECTION ON THE OTHER SIDE OF THE BACK COVER.
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 1 2016-04-25  11:25:06

Top panel
a
b
c
d
e
f
g
h
i
j
k
l
m
n
aUSB
You can play or record sound by connecting the USB device.
bUSB REC / DEMO
- Records to USB.
- Shows Demo mode.
c MIC (Microphone) VOL +/-
d VOICE CANCELLER
You can enjoy the function while playing the music, by
reducing singer vocal of music in the various source.
Press to switch this mode on or off.
e SCRATCH / SEARCH & LEVEL CONTROL
- Turns clockwise or counterclockwise to make Scratch sound.
 -Searchesafolderorale.
- Adjust DJ EFFECT level.
f DJ EFFECT
Selects DJ EFFECT mode.
g LIGHTING
- Turns on/off the lighting effects.
- Press and hold to turn on/off the Flash Lighting.
hCLUB, DRUM, USER (DJ PRO)
Press and hold to select CLUB, DRUM or USER sound effect
for mix.
(If you want to use USER, you have to register a source with
“Music Flow Bluetooth” app.)
1, 2, 3 (DJ PRO PAD)
Press a desired sound pad.
i OK / RDS
- Selects a folder when searching a file.
- RDS (Radio Data System)
j SEARCH
Moves to folder or file in selection mode.
k BLUETOOTH
Changes input source to the Bluetooth.
(Even in power off mode, if you press BLUETOOTH,
then power is on and automatically changed to Bluetooth
function.)
lUSER EQ / BASS BLAST
- Selects the sound effect created by your own.
- Press and hold to select BASS effect directly.
mKEY CHANGER ( / )
Changes the key to suit your vocal range.
n WIRELESS LINK
Selects Wireless Party Link mode.
Download the Music Flow Bluetooth App to your
device.
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 2 2016-04-25  11:25:06

Front panel / Rear panel
aDisplay window
b U (Skip/Search)
- Skips forward.
 -Searchesforasectionwithinale.
- Selects the radio stations.
c T(Play/Pause)
- Starts or pauses playback.
- Selects Stereo/Mono (Horizon mode Only)
d Y (Skip/Search)
- Skips backward.
- Searchesforasectionwithinale.
- Selects the radio stations.
e +/- (Volume)
Adjusts speaker volume.
fF (Function)
Selects the function and input source.
g1/!(Standby/On)
hMIC (Microphone) 1 / 2 jack
iRemote control receiver
jFM ANTENNA
kAUX IN (L/R)
lPower cord
Vertical Horizon
How to place the unit
a
d
b
c
e
f
g
h
i
k
j
l
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 3 2016-04-25  11:25:07

Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption
Refer to the main label on
the unit.
Networked standby : 0.5 W
(If all network ports are
activated.)
Dimensions (W x H x D) Approx. 818 mm X
318 mm X 388 mm
Net Weight Approx. 17.2 kg
Bus Power Supply (USB) 5 V 01 A
Amplier
(Total RMS output power) 600 W
Designandspecicationsaresubjecttochangewithout
notice.
Note
yDo Not look directly at the light emitting path when
lighting function is operational.
yIf the brightness from the illuminating light source
causes excessive glare and eye discomfort during
operation then turn On room lights or turn Off the
LIGHTING of the unit.
How to disconnect the wireless network
connection or the wireless device
Turn off the unit by pressing the power button for more
than 5 seconds.
Replacement of battery
(R03)
(R03)
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 4 2016-04-25  11:25:08

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Thislightningashwitharrowheadsymbolwithin
an equilateral triangle is intended to alert the user
to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sufcientmagnitudetoconstituteariskofelectric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:Donotinstallthisequipmentinaconnedspacesuchas
a book case or similar unit.
CAUTION: Do not use high voltage products around this product.
(ex. Electrical swatter) This product may malfunction due to electrical
shock.
CAUTION: Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the product and to protect it from over
heating. The openings shall be never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This product shall not
be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instruction has
been adhered to.
CAUTION concerning the Power Cord
The Power Plug is the disconnecting device. In case of an emergency,
the Power Plug must remain readily accessible.
CAUTION: The apparatus shall not be exposed to water (dripping or
splashing)andnoobjectslledwithliquids,suchasvases,shallbe
placed on the apparatus.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the
equipment: Remove the old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent contamination of the
environment and bring on possible threat to human and animal health,
the old battery or the battery put it in the appropriate container at
designated collection points. Do not dispose of batteries or battery
together with other waste. It is recommended that you use local, free
reimbursement systems batteries and accumulators. The battery shall
notbeexposedtoexcessiveheatsuchassunshine,reorthelike.
NOTICE: For safety marking information including product
identicationandsupplyratings,pleaserefertothemainlabelonthe
bottom or the other surface of the product.
CAUTION:Nonakedamesources,suchaslightedcandles,shouldbe
placed on the apparatus.
POWER: This unit operates on a mains supply of
200 - 240 V ~, 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved main plug.
When replacing the fuse, always use of the same rating approved
to BS 1362. Never use this plug with the fuse cover omitted. To
obtain a replacement fuse cover contact your dealer. If the type of
plug supplied is not suitable for the mains sockets in your home,
thentheplugshouldberemovedandasuitabletypetted.Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of this unit
must be destroyed. A mains plug with bared wires is hazardous
if inserted in a mains socket. Do not connect either wire to the
earth pin, marked with the letter E or with the earth symbol 6or
colouredgreenorgreenandyellow.Ifanyotherplugistted,use
same rating of fuse in the plug.
Important: The wires in this mains lead are coloured in accordance
with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in
the mains lead of this unit may not correspond with the coloured
marking identifying the terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black. The wire
which is coloured brown must be connected to the terminal which
is marked with the letter L or coloured red.
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 5 2016-04-25  11:25:08

Disposal of your old appliance
1. This crossed-out wheeled bin symbol indicates that
waste electrical and electronic products (WEEE)
should be disposed of separately from the municipal
waste stream.
2. Old electrical products can contain hazardous substances so
correct disposal of your old appliance will help prevent potential
negative consequences for the environment and human health.
Your old appliance may contain reusable parts that could be used
to repair other products, and other valuable materials that can be
recycled to conserve limited resources.
3. You can take your appliance either to the shop where you
purchased the product, or contact your local government waste
office for details of your nearest authorised WEEE collection point.
For the most up to date information for your country please see
www.lg.com/global/recycling
Disposal of waste batteries/accumulators
Pb
1. This symbol may be combined with
chemical symbols for mercury (Hg),
cadmium (Cd) or lead (Pb) if the
battery contains more than 0.0005%
of mercury, 0.002% of cadmium or
0.004% of lead.
2. All batteries/accumulators should be disposed separately from
the municipal waste stream via designated collection facilities
appointed by the government or the local authorities.
3. The correct disposal of your old batteries/accumulators will help
to prevent potential negative consequences for the environment,
animal and human health.
4. For more detailed information about disposal of your old batteries/
accumulators, please contact your city office, waste disposal
service or the shop where you purchased the product. (http://www.
lg.com/global/sustainability/environment/take-back-recycling/
global-network-europe)
Declaration of Conformity
Hereby, LG Electronics European Shared Service Center B.V.,
declares that this HIGH POWER SPEAKER SYSTEM is compliant
with the essential requirements and other relevant provisions of
Directive 1999/5/EC. The complete Declaration of Conformity
may be requested through the following postal address:
LG Electronics European Shared Service Center B.V.
Krijgsman 1
1186 DM Amstelveen
The Netherlands
or can be requested at our dedicated DoC website:
http://www.lg.com/global/support/cedoc/cedoc#
This device is a 2.4 GHz wideband transmission system, intended
for use in all EU member states and EFTA countries.
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 6 2016-04-25  11:25:08

Technology with the human touch
GUARANTEE
• LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee.
1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period of 12 months
from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be reimbursed for any labour provided in the repair of this LG
equipment, for a period of 12 months from the original date of purchase. These claims must be made in accordance with
the published scale of service charges and relevant claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if unauthorized modifications are made to the apparatus, or
if non standard components are used or if the serial number of the apparatus is removed, defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from whom the equipment was originally purchased. The
dealer may, before carrying out service under guarantee, require a receipted account as evidence of the date of purchase.
D. We respectfully point out that your dealer is not obligated to replace batteries if they become exhausted or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this guarantee.
This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAIN YOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OF YOUR RECEIPT MUST BE SURRENDERED AT THE
TIME GUARANTEE SERVICE IS PROVED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This will enable LG to
assist you in the future should you lose your receipt, your units be stolen, or should modifications be necessary.
• To obtain information or assistance:
Call UK: 0344 847 5454 IE: 01 686 9454
MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*
In all cases of difficulty - consult your LG dealer from whom the product was purchased
LGEUK Website : www.lg.com/uk
(Service website : www.lg.com/uk/support)
FH6-DK_DGBRLLK_SIM_ENG_2411.indd 7 2016-04-25  11:25:08

FH6-DK_DGBRLLK_SIM_ENG_2411.indd 8 2016-04-25  11:25:08
