LG Musicflow HS6 Specification sheet

www.lg.com
Model : LAS650M (HS6)
SMART Hi-Fi AUDIO
Wireless Multi-room Sound Bar
bSet up the sound output of your TV : TV setting menu
[[Sound] [[TV Sound output] [[LG Sound Sync
(Optical)]
LG Sound SyncOptical operation
a
Optical
HDMI ARC (Audio Return Channel) operation
a
b
Set up the sound output of your TV :
1. TV setting menu [[Sound] [[T V Sound output] [
[External speaker (HDMI ARC)]
2. Set up ARC mode to [On].
3. Activate HDMI CEC and select sound output of your TV.
Details of TV setting menu vary depending on the manufacturers or models of your TV.
,
For specic information of operating, refer to the instruction manual of yourTV.
,
When the connections failed, make sure of the conditions of this unit and your TV : power, function
and cable connection.
,
The amount of time to turn o this unit is dierent depending on your TV when you set AUTO POWER
function to ON.
,
a
bSelect OPTICAL.
cSelect OPTICAL.
TV Speaker
External Speaker
LG Sound Sync (Optical)
LG Sound Sync (Wireless)
TV Speaker
External Speaker (HDMI ARC)
LG Sound Sync (Optical)
LG Sound Sync (Wireless)
Set up the sound output of your TV : TV setting menu
[[Sound] [[TV Sound output] [[External Speaker
(Optical)]
TV Speaker
External Speaker (Optical)
LG Sound Sync (Optical)
LG Sound Sync (Wireless)
,Some TV need to change setting of sound output. Refer to the description below.
Some TV need to change setting of sound output. Refer to the description below.
The ARC function enables an HDMI capable TV to send the audio sream to HDMI OUT of the unit. ARC function is automatically selected when you turn on your TV no matter what kind of the function you are
using.
SIMPLINK
SIMPLINK enables you to control some functions of this unit by a remote control of your TV. Controllable
functions are power on/o and volume up/down, etc. Make sure that your TV has SIMPLINK logo as shown
above.
LG Sound Sync enables you to control some functions of this unit by a remote control of your LG TV.
Controllable functions are volume up/down and mute. Make sure that your TV has LG Sound Sync logo as
shown above.
HDMI operation
a
bSelect HDMI IN.
Cable ties Wall brackets and screws
Wall bracket install guide
Instruction manual
LG Tag On
Sticker
ENGLISH | SIMPLE MANUAL (1 of 2)
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from
your unit.
Unpacking
Adapter and power cord
LAS650M-N.BGBRLLK_ENG_6732.indd 1 2014-10-24  11:21:37

Remote Control
Make the sound clear when the volume is too low. (Dolby
Digital only)
Adjusts the volume level appropriately.
Using External device
a
bSelect PORTABLE.
Play the music on the connected external device.
Portable cable (Not included)
c
Using Bluetooth
b
c
Play music on your Bluetooth device.
aSelect Bluetooth function.
Music Flow HS6 (XX:XX)
Enter the PIN code (0000) as needed.
,
This unit can be paired simply and easily with an NFC-enabled device.
Attach the supplied LG Tag On sticker on the remote control.
NFC for Easy Pairing (Android Only)
a
b
When you are enjoying the music with Music Flow Player app, seamless playback is activated instead
of Bluetooth pairing.
,
e
a c
Installation
bd
Screws and wall plugs are not supplied.
,
Because it is dicult to make a connection after installing this unit, you should connect the cables
before installation.
,
Do not install this unit on Metallic furniture.
,
OPTICAL function is selected directly. If you press this
button again, the function is returned to previous one.
Adjust the sound level of woofer. (- 40 dB to 6 dB)
Controls playback on Wi-Fi mode.
MUSIC
CINEMA
FL AT
BOOST
TRE/BASS (Treble / Bass)
STANDARD
DIMMER
SLEEP 180 SLEEP 10
OFF
z
Sound quality may become lower or disconnected depending on the distance, interference or
obstacles.
,
Depending on the type of the device, you may not be able to use the Bluetooth function. /
,
Depending on the connected device, this function may not operate.
,
If you turned o the unit directly, it cannot be turned on automatically by AUTO POWER function.
However the unit can be turned on by AUTO POWER function when optical signal comes in after 5
seconds of no signal.
,
After the unit is turned on by AUTO POWER function, it will be automatically turned o if there is no
signal for a certain period of time from the external device.
,
Auto power On/Off
This unit automatically turns on and o by an input source : Optical.
Turns on or o AUTO POWER function.
Press and hold to turn on or o this function.
Synchronizes the audio and video. (0 to 300 ms)
Press once.
Using your TV remote control
You can control some functions of this unit by yourTV remote control even in other company’s product.
Controllable functions are volume up/down and mute.
Make sure that the sound output of your TV is set to [External speaker].
,
Depending on the remote control, this function may not work well.
,
Supported TV brands
,
LG Panasonic Philips Samsung Sharp Sony Toshiba Vizio
LAS650M-N.BGBRLLK_ENG_6732.indd 2 2014-10-24  11:21:43

www.lg.com
Model : LAS650M (HS6)
SMART Hi-Fi AUDIO
Wireless Multi-room Sound Bar
Before using “Music Flow Player” App
Step 1
aBe sure to have a wireless network using a
broadband router installed in your home.
bConnect your smart device to your home
network.
cConnect the speaker to the power supply using
the supplied AC adapter.
The wireless router should be connected to the internet.
,
Wireless signal interference may lead to disruption of network stability and playback.
,
Depending on the speed of your network, playback of music services may not work well.
,
Installing “Music Flow Player” App
Download “Music Flow Player” on the iTunes store or Google Play Store. Using Music Flow Player app, select [Wired connection] and follow the on-screen instructions.
Using Music Flow Player app, select [Wireless connection] and follow the on-screen instructions.
Type“Music Flow Player”in the search bar and
tap “Search”.
AScan the QR code using a scanning
application.
B
Depending on the device, “Music Flow Player” app may not work.
,
If you restart the router, you will also need to reset the power of the speaker.
,
If you install a new router, you will need to setup the network connection for the speaker.
,
Music Flow Player app will be available with versions of the software as follow;
Android O/S : Ver 2.3.3 (or later) iOS O/S :Ver 5.1.1 (or later)
,
Network Connection (Option 1 : Wired)
Music Playback
Playing a song on this device
Network Connection (Option 2 : Wireless)
ENGLISH | SIMPLE MANUAL (2 of 2)
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from
your unit.
NOTE
Step 2 Step 3
Step 3 Step 4
Technology with the human touch
GUARANTEE
• LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee.
1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period of 12 months
from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be reimbursed for any labour provided in the repair of this LG
equipment, for a period of 12 months from the original date of purchase. These claims must be made in accordance with
the published scale of service charges and relevant claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if unauthorized modifications are made to the apparatus,
or if non standard components are used or if the serial number of the apparatus is removed, defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from whom the equipment was originally purchased.
The dealer may, before carrying out service under guarantee, require a receipted account as evidence of the date of
purchase.
D. We respectfully point out that your dealer is not obligated to replace batteries if they become exhausted or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this guarantee.
This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAINYOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OFYOUR RECEIPT MUST BE SURRENDERED AT THETIME
GUARANTEE SERVICE IS PROVED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This will enable LG to
assist you in the future should you lose your receipt, your units be stolen, or should modifications be necessary.
• To obtain information or assistance:
Call UK: 0344 847 5454 IE: 01 686 9454
MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*
In all cases of difficulty - consult your LG dealer from whom the product was purchased
LGEUK Website : www.lg.com/uk
(Service website : www.lg.com/uk/support)
LAS650M-N.BGBRLLK_ENG_6732.indd 3 2014-10-24  11:21:46

Safety InformationSpecication
ENGLISH
AC adapter
requirements
Input : 100 - 240 V ~ 50 / 60 Hz
Output : 25 V 02 A
Power consumption
30 W
Networked standby : 5.7 W
(If all network ports are activated.)
Amplier Total output 320 W
Bluetooth Version 4.0
Codec SBC
Dimensions
(W x H x D)
(1020 x 42 x 82) mm
(with Foot)
Net Weight (Approx.) 2 kg
Design and specications are subject to change without
notice.
Reset this Sound Bar System
Press and hold the button until you hear the beep sound once. Then all wireless network ports are
deactivated and delete the stored wireless network information.
Press and hold the button until you hear the beep sound twice.
Initializing the network settings
Factory Set
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE
COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION: The apparatus shall not be exposed to water (dripping or splashing)
and no objects lled with liquids, such as vases, shall be placed on the
apparatus.
WARNING: Do not install this equipment in a conned space such as a book
case or similar unit.
CAUTION: Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
Slots and openings in the cabinet are provided for ventilation and to ensure
reliable operation of the product and to protect it from over heating.The
openings shall be never be blocked by placing the product on a bed, sofa,
rug or other similar surface. This product shall not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or
the manufacturer’s instruction has been adhered to.
CAUTION concerning the PowerCord
The Power Plug is the disconnecting device.
In case of an emergency, the Power Plug must remain readily accessible.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the equipment:
Remove the old battery or battery pack, follow the steps in reverse order than
the assembly. To prevent contamination of the environment and bring on
possible threat to human and animal health, the old battery or the battery put
it in the appropriate container at designated collection points. Do not dispose
of batteries or battery together with other waste. It is recommended that you
use local, free reimbursement systems batteries and accumulators. Thebatter y
shall not be exposed to excessive heat such as sunshine, re or the like.
CAUTION: Only use the AC adapter supplied with this device. Do not use a
power supply from another device or another manufacturer. Using any other
power cable or power supply may cause damage to the device and void your
warranty.
NOTICE: For safety marking information including product identication and
supply ratings, please refer to the main label on the bottom or rear of the
apparatus.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed
by the government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of
your old appliance, please contact your city office,
waste disposal service or the shop where you
purchased the product.
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled bin symbol is
attached to batteries/accumulators of Yourproduct
it means they are covered by European Directive
2006/66/EC.
2. This symbol may be combined with chemical
symbols for mercury(Hg), cadmium(Cd) or lead(Pb)
if the battery Contains more that 0.0005% of
mercury,0.002% of cadmium or 0.004% of lead.
3. All batteries/accumulators should be disposed
separately from the municipal waste stream via
designated collection facilities appointed by the
government or the local authorities.
4. The correct disposal of Your old batteries/
accumulators will help to prevent potential negative
consequences for the environment, animal and
human health.
5. For more detailed information about disposal of
Your old batteries/accumulators, please contact
Your city office, waste disposal service or the shop
where Youpurchased the product.
For Wirelessproduct European Union Notice
LG Electronics hereby declares that this/these product(s) is/are in compliance
with the essential requirements and other relevant provisions of Directive
1999/5/EC, 2004/108/EC, 2006/95/EC, 2009/125/EC and 2011/65/EU.
Please contact to the following address for obtaining a copy of the DoC
(Declaration of Conformity).
Contact oce for compliance of this product:
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
yPlease note that this is NOT a Customer Service contact point. For
Customer Service Information, see Warranty Card or contact the dealer that
you purchased this product.
Indoor Use Only
RF Radiation Exposure Statement
This equipment should be installed and operated with minimum distance
20 cm between the radiator and your body.
POWER: This unit operates on a mains supply of 100 - 240 V ~ 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved main plug. When
replacing the fuse, always use of the same rating approved to BS 1362. Never
use this plug with the fuse cover omitted. To obtain a replacement fuse cover
contact your dealer. If the type of plug supplied is not suitable for the mains
sockets in your home, then the plug should be removed and a suitable type
tted. Please refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of this unit must be
destroyed. A mains plug with bared wires is hazardous if inserted in a mains
socket. Do not connect either wire to the earth pin, marked with the letter E or
with the earth symbol 6or coloured green or green and yellow. If any other
plug is tted, use same rating of fuse in the plug.
Important: The wires in this mains lead are coloured in accordance with the
following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in the mains
lead of this unit may not correspond with the coloured marking identifying
the terminals in your plug, proceed as follows: The wirewhich is coloured
blue must be connected to the terminal which is marked with the letter N or
coloured black. The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
When you enjoy the grouping or surround playback, at least one speaker should be connected by
LAN cable.
,
If the speakers are not grouped, you can enjoy dierent music on each speaker.
,
The weak signal because of the long distance between speakers or wireless router and signal
interference may cause abnormal playback.
,
If the speakers are connected only wirelessly, disconnect all the wireless connections and reconnect
them after connecting one wired.
,
For smooth playback, it is recommended to select the speaker connected by LAN cable as a master
speaker.
,
Before using the playbacks, you should add another LG SMART Hi-Fi AUDIO.
Music Flow Bar 1
Music Flow 2Music Flow 1
Multiple sound playback
There are a number of diering ways of listening to sound : Grouping and Surround playbacks. To use this
playbacks, you should have several LG SMART Hi-Fi AUDIO.
Any number of speakers can be grouped together to play the same music in synchrony. On Music Flow
Player app, select [Connected Speakers] and follow the directions on screen. You can enjoy surround sound by adding another two speakers. On Music Flow Player app, select [Connected
Speakers] and follow the directions on screen.
Grouping Surround
LAS650M-N.BGBRLLK_ENG_6732.indd 4 2014-10-24  11:21:51
