LG NB3520A User manual

Please read this manual carefully before operating
your set and retain it for future reference.
NB3520A (NB3520A, SHS36-D)
OWNER’S MANUAL
300 W Sound Bar System
www.lg.com
Downloaded From TheatreSystem-Manual.com Manuals

1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with
arrowhead symbol within an
equilateral triangle is intended to
alert the user to the presence of
uninsulated dangerous voltage
within the product’s enclosure
that may be of sucient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. hen installing the product, ensure
that the plug is easily accessible.
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started 3
Getting Started
1
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or
moisture, does not operate normally, or has
been dropped.
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started4
Getting Started
1
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment
and receiver.
yConnect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
yConsult the dealer or an experienced radio/TV
technician for help.
CAUTION : Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
FCC WARNING: This equipment may generate
or use radio frequency energy. changes or
modications to this equipment may cause harmful
interference unless the modications are expressly
approved in the instruction manual. The user could
lose the authority to operate this equipment if an
unauthorized change or modication is made.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with minimum distance 20 cm between the
radiator and your body. End users must follow the
specic operating instructions for satisfying RF
exposure compliance. This transmitter must not be
co-located or operating in conjunction with any
other antenna or transmitter.
FCC Radio Frequency Interference
Requirements
This device is restricted to indoor use due to its
operation in the 5.15 to 5.25 GHz frequency range.
FCC requires this product to be used indoors for
the frequency range 5.15 to 5.25 GHz to reduce the
potential for harmful interference to co-channel
Mobile Satellite systems. High power radars are
allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations
can cause interference with and/or damage this
device. This device cannot be co-located with any
other transmitter.
CAUTION: Regulations of the FCC and FAA prohibit
airborne operation of radio-frequency wireless
devices because their signals could interfere with
critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc. 1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : [phone]
Downloaded From TheatreSystem-Manual.com Manuals

Table of Contents 5
1
2
3
4
5
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 – Portable In
6 – Speaker ez (easy) Setup
6 Accessories
7 Introduction
7 – Symbols Used in this Manual
7 Playable file
7 – MP3/ WMA file requirement
8 Remote control
9 Front panel
9 Rear panel
2 Connecting
10 Mounting the main unit on a wall
12 Setting up
12 – Pairing wireless subwoofer
13 Optional Equipment Connection
13 – PORT. (Portable) IN Connection
13 – Listening to music from your portable
player
13 – OPTICAL In connection
13 – Speaker ez (easy) setup
14 – USB Playback
3 Operating
15 Basic Operations
15 – USB Operation
15 Other Operations
15 – DOLBY DRC (Dynamic Range
Control)
15 – AV Sync
15 – AUTO POWER On/Off
16 – AUTO POWER DOWN
16 – Sleep Timer Setting
16 – Dimmer
16 – Turn off the sound temporarily
16 – Adjust the woofer level settings
16 – Displaying file and input source
17 Sound adjustment
17 – Setting the surround mode
17 – 3D Sound Effect
18 Using Bluetooth technology
18 – Listening to music stored on the
Bluetooth devices
20 Controlling a TV with the Supplied
Remote Control
20 – Setting up the remote to control your
TV
4 Troubleshooting
21 Troubleshooting
5 Appendix
22 Maintenance
22 – Handling the Unit
23 Trademarks and Licenses
24 Specifications
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started6
Getting Started
1
Unique Features
Portable In
Listen to music from your portable device. (MP3,
Notebook, etc)
Speaker ez (easy) Setup
Listen to sounds from TV, DVD or Digital device
with vivid 2.1 or 2.0 ch mode.
Accessories
Please check and identify the supplied accessories.
VOL+
VOL-
AV/INPUT
PR/CH
PR/CH
Remote control (1) Batteries (2)
Wall Mount Bracket
Installation Template
(1)
Wall bracket (1)
Optical cable (1)
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started 7
Getting Started
1
Introduction
Symbols Used in this Manual
, Note
Indicates special notes and operating features.
, Tip
Indicates tip and hints for making the task easier.
> Caution
Indicates cautions for preventing possible damages
from abuse.
Playable file
MP3/ WMA file requirement
MP3/ WMA le compatibility with this unit is limited
as follows :
ySampling frequency : within 32 to 48 kHz (MP3),
within 32 to 48 kHz (WMA)
yBit rate : within 32 to 320 kbps (MP3),
40 to 192 kbps (WMA)
yMaximum les : Under 999
yFile extensions : “.mp3”/ “.wma”
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started8
Getting Started
1
Remote control
VOL +
VOL -
AV/INPUT
PR/CH
PR/CH
Battery Installation
Remove the battery cover on the rear of the
Remote Control, and insert two (size AAA) battery
with and matched correctly.
• • • • • • • • • • a • • • • • • • • •
1(Power): Switches the unit ON or OFF.
INPUT: Changes input sources.
W/S FOLDER: Searches for a folder of MP3/
WMA les. When an USB containing MP3/ WMA
les in several folders is being played,
press W/S FOLDER to select the folder you want
to play.
OPTICAL: Changes input source to optical directly.
MUTE :Mutes the sound.
-/+ VOL: Adjusts speaker volume.
• • • • • • • • • • b • • • • • • • • •
AUTO POWER: This function is automatically
turned on the unit.
AV SYNC: Synchronizes the audio and video.
INFO: Displays the le or input source information.
REPEAT: Listens to your les repeatedly or
randomly.
C/V (Skip/ Search) :
- Skips Fast backward or Forward.
- Searches for a section within a track.
Z:Stops playback.
d/M:Starts playback. / Pauses playback.
SOUND EFFECT: Selects a sound eect mode.
3D SOUND: Turns on and o the 3D Sound mode.
WOOFER LEVEL: Sets the sound level of woofer.
• • • • • • • • • • c • • • • • • • • •
0 to 9 numerical buttons: Selects numbered les.
Enters the PIN code.
DOLBY DRC: Sets the Dobly DRC.
SLEEP: Sets the system to turn o automatically at
a specied time.
• • • • • • • • • • d • • • • • • • • •
TV Control buttons: See page 20.
Downloaded From TheatreSystem-Manual.com Manuals

Getting Started 9
Getting Started
1
ADisplay
BUSB Port
CF (Function)
Press it repeatedly to select other function.
DI(Stop)
ET(Play / Pause)
F– / + (Volume)
Adjusts speaker volume.
G1(Standby/On)
Precautions in using the touch buttons
yUse the touch buttons with clean and dry
hands.
- In a humid environment, wipe out any
moisture on the touch buttons before
using.
yDo not press the touch buttons hard to
make it work.
- If you apply too much strength, it can
damage the sensor of the touch buttons.
yTouch the button that you want to work in
order to operate the function correctly.
yBe careful not to have any conductive
material such as metallic object on the
touch buttons. It can cause malfunctions.
> Caution
Front panel
AB
CDEFG
Rear panel
B
A
APORT. (Portable) IN BOPTICAL IN 1/ 2
Downloaded From TheatreSystem-Manual.com Manuals

2 Connecting
Connecting10
Connecting
2
Mounting the main
unit on a wall
You can mount the main unit on a wall.
Prepare screws and brackets.
Unit
Wall bracket
Wall Mount Bracket
Installation Template
1. Match the TV’s BOTTOM EDGE of Wall Mount
Bracket Installation Template with the bottom
of TV and attach to the position.
TV
2. When you mount it on a wall (concrete), use
the wall plugs (Not supplied). You should drill
some holes. A guide sheet (Wall Mount Bracket
Installation Template) is supplied to drill. Use the
sheet to check the point to drill.
Wall Mount Bracket Installation Template
Screws and Wall Plugs are not supplied for
mounting the unit. We recommend the Hilti
(HUD-1 6 x 30) for the mounting. Please
purchase it.
, Note
Downloaded From TheatreSystem-Manual.com Manuals

Connecting 11
Connecting
2
3. Remove the Wall Mount Bracket Installation
Template.
4. Fix it with screws (not supplied) as shown in the
illustration below.
5. Hang the main unit onto the bracket as shown
below.
yDo not hang onto the installed unit and
avoid any impact to the unit.
ySecure the unit rmly to the wall so that it
does not fall o. If the unit falls o, it may
result in an injury or damage to the product.
yWhen the unit is installed on a wall, please
make sure that a child does not pull any of
connecting cables, as it may cause it to fall.
> Caution
Detach the unit from the bracket as shown
below.
, Note
Downloaded From TheatreSystem-Manual.com Manuals

Connecting12
Connecting
2
Setting up
Pairing wireless subwoofer
LED indicator of wireless subwoofer
LED Color Status
Blue or yellow The wireless subwoofer is
receiving the signal of the unit.
Blue or yellow
(blink)
The wireless subwoofer is trying
to connect.
Red The Wireless subwoofer is in
standby mode.
O (No
display)
The power cord of wireless
subwoofer is disconnected.
Setting up the wireless subwoofer
for the first time
1. Connect the power cord of the Wireless
subwoofer to the outlet.
2. Turn on the main unit : The main unit and
wireless subwoofer will be automatically
connected.
Manually pairing wireless subwoofer
When your connection is not completed, you can
see the red LED on the woofer and woofer is not
made sound. To solve the problem, follow the
below steps.
1. Press and hold ISTOP button on the unit
and MUTE button on the remote control
simultaneously.
- Displays the “REMATE”.
2. Press PAIRING on back of the woofer.
- The blue or yellow LED will flicker
3. Turn off and on the unit.
- If you see “blue or yellow” LED, it’ s successful.
4. If you don’t see “blue or yellow”LED, try again
Step 1 - Step 3.
yIf you operate main unit then wireless
subwoofer sound within a few seconds in
standby mode.
ySet the distance between this unit and
wireless subwoofer within 10 m (32 ft.).
yOptimum performance can be
implemented only when the unit and
the Wireless subwoofer within distance
of 2 m (6 ft.) to 10 m (32 ft.) is used since
communication failure may occur if longer
distance is used.
yIt takes a few seconds (and may take longer)
for the unit and subwoofer to communicate
with each other.
, Note
Downloaded From TheatreSystem-Manual.com Manuals

Connecting 13
Connecting
2
Optional Equipment
Connection
PORT. (Portable) IN
Connection
MP3 player, etc...
Listening to music from your
portable player
The unit can be used to play the music from many
types of portable player or external devices.
1. Connect the portable player to the
PORT. (Portable) IN connector of the unit.
2. Turn the power on by pressing 1(Power).
3. Select the PORTABLE function by pressing
INPUT.
4. Turn on the portable player or external device
and start playing it.
OPTICAL In connection
Connect an optical output of external devices to
the OPTICAL IN 1/ 2 connector.
To the digital
optical output jack
of external device
Speaker ez (easy) setup
Listens to sound from TV or DVD or Digital Device
with 2.1 or 2ch mode.
1. Connect the unit’s OPTICAL IN 1/ 2 jack to jack
on optical out of your TV (or Digital Device etc.).
2. Select the OPTICAL 1/ 2 by using the OPTICAL.
To select the OPTICAL 1/ 2 directly
3. Listen to sound with 2.1 or 2ch speaker.
4. Press OPTICAL to exit from OPTICAL 1/ 2.
Function is retuned to previous one.
Downloaded From TheatreSystem-Manual.com Manuals

3 Operating
Connecting14
Connecting
2
USB Playback
Insert USB memory device to the USB port on the
right side of the unit.
Removing the USB Device from the unit.
1.
Choose a different function mode or press
ISTOP twice in a row.
2. Remove the USB device from the unit.
Compatible USB Devices
yMP3 Player : Flash type MP3 player.
yUSB Flash Drive : Devices that support USB1.1.
yThe USB function of this unit does not support
some USB devices.
USB device requirement
yDevices which require additional program
installation connected to a computer, are not
supported.
yDo not extract the USB device while in operation.
yFor a large capacity USB, it may take longer than
a few minutes to be searched.
yTo prevent data loss, back up all data.
yIf you use a USB extension cable or USB hub, the
USB device is not recognized.
yThis unit is not supported when the total
number of les is 1000 or more.
yExternal HDD, Card readers, Locked devices,
or hard type USB devices are not supported.
yThe unit’s USB Port cannot be connected to PC.
The unit can not be used as a storage device.
Downloaded From TheatreSystem-Manual.com Manuals

3 Operating
Operating 15
Operating
3
Basic Operations
USB Operation
1. Connect the USB device to the USB port.
2. Select the USB function by pressing INPUT.
3. Select a file you want to play by pressing
Cor V.
To Do this
Stop Press Z.
Playback Press d/M.
Pause Press d/M.
Skipping to the
next/ previous
le
During playback, press C
or Vto go to the next le
or to return to the beginning
of the current le.
Press Ctwice briey to
step back to the previous le.
Searching for a
section within a
le
Press and hold C/V
during playback and release it
at the point you want to listen
to.
Playing
repeatedly or
randomly
Press REPEAT on the remote
control repeatedly, the display
change in the following order,
RPT 1 RPT D (DIRECTORY)
RPT ALL RANDOM OFF.
Selecting les
directly
Press 0 to 9 numerical
buttons on the remote
control to go to the desired
le directly.
Other Operations
DOLBY DRC (Dynamic Range
Control)
Make the sound clear when the volume is turned
down (Dolby Digital only). Set to [DRC ON] by using
DOLBY DRC.
AV Sync
When receiving audio signals from TV, sound and
images may not be matched. In the case, this
function can adjust the delay time.
1. Press AV SYNC.
2. Use
CVto scroll up and down through
the delay amount, which you can set at
anything between 0 and 300ms.
AUTO POWER On/Off
Before operating this function, make sure that you
have selected OPTICAL IN and turn on the AUTO
POWER. This function automatically turns on/o
the unit when you turn on/o the external device
(TV, DVD Player, Blu-ray Disc Player, etc.) connected
to this unit by the optical cable. This function turns
on or o each time you press AUTO POWER.
Display Operation
AUTO POWER ON AUTO POWER function is
turned on.
AUTO POWER OFF AUTO POWER function is
turned o.
yThis function is intentionally designed
to turn o the unit after 15 minutes of
inactivity. If you did not connect external
devices with optical cable or there is no
digital audio signal going to the unit,
the unit will turn o after 15 minutes of
inactivity if AUTO POWER function is turned
on.
yDepending on the connected device by the
optical cable, this function may not operate.
, Note
Downloaded From TheatreSystem-Manual.com Manuals

Operating16
Operating
3
AUTO POWER DOWN
This unit will be o itself to save electronic
consumption in the case main unit is not
connected to external device and is not used for 25
minutes.
So does this unit after six hours since Main unit
has been connected to other device using analog
input.
But the unit can turns on automatically based on
the [AUTO POWER] function you've set.
Sleep Timer Setting
Press SLEEP one or more times to select delay time
between 10 and 180 minutes, after the unit will
turn o.
To check the remaining time, press SLEEP.
To cancel the sleep function, press SLEEP
repeatedly until“SLEEP 10”appears, and then press
SLEEP once again while “SLEEP 10” is displayed.
You can check the remaining time before the
Unit turns o.
Press SLEEP. The remaining time appears in
the display window.
, Note
Dimmer
Press SLEEP once. The display window will be
darken by half. To cancel it, press SLEEP repeatedly
until dim o.
Turn off the sound temporarily
Press MUTE to mute your unit.
You can mute your unit, for example, to answer
the telephone, the“ ” is displayed in the display
window.
Adjust the woofer level
settings
You can adjust the sound level of woofer.
1. Press WOOFER LEVEL.
2. Press -/+ VOL to adjust the sound level of the
woofer.
Displaying file and input
source
You can display various information on the USB and
OPTICAL IN 1/ 2 mode by pressing INFO.
USB : MP3/ WMA containing file information
OPTICAL IN 1/ 2 : Audio format, Audio channel
Downloaded From TheatreSystem-Manual.com Manuals

Operating 17
Operating
3
Sound adjustment
Setting the surround mode
This system has a number of pre-set surround
sound fields. You can select a desired sound mode
by using SOUND EFFECT.
The displayed items for the equalizer may be
different depending on sound sources and effects.
On Display Description
NATURAL You can enjoy comfortable
and natural sound.
BYPASS You can enjoy the sound
without equalizer eect.
BASS
The BASS is Bass Blast. During
playback, reinforce the treble,
bass and surround sound
eect.
CLRVOICE
The CLRVOICE is Clear Voice.
This program make voice
sound clear, improving the
quality of voice sound. (We
encourage to use this EQ
when you watch the movie of
5.1 channel.)
GAME
The GAME is Game Equalizer.
You can enjoy more virtual
sound while playing video
games.
NIGHT
The NIGHT is Night Mode.
This may be useful when you
want to watch movies at low
volume late at night.
UPSCALER
The UPSCALER is MP3 Up-
Scaling. When listening to
MP3 les or other compressed
music, you can enhance the
sound. This mode is available
only to 2 channel sources.
LOUDNESS Improves the bass and treble
sound.
yIn some of surround modes, some speakers,
there’s no sound or low sound. It depends
on the mode of surround and the source of
audio, it is not defective.
yYou may need to reset the surround mode,
after switching the input, sometimes even
after the sound le changed.
, Note
3D Sound Effect
3D Sound features deliver sound creating a
wider spot so you can enjoy more immersive and
cinematic surround sound. Press 3D SOUND to
turn on or off the 3D Sound mode.
Downloaded From TheatreSystem-Manual.com Manuals

Operating18
Operating
3
Using Bluetooth
technology
About Bluetooth
Bluetooth® is wireless communication technology
for short range connection.
The available range is within 10 meters.
(The sound may be interrupted when the
connection interfered by the other electronic wave
or you connect the bluetooth in the other rooms.)
Connecting individual devices under
Bluetooth® wireless technology does not incur any
charges. A mobile phone with
Bluetooth® wireless technology can be operated
via the Cascade if the connection was made via
Bluetooth® wireless technology.
Available Devices : Mobile phone, MP3, Laptop,
PDA (This units be supported the Stereo Headset.)
Bluetooth Profiles
In order to use Bluetooth wireless technology,
devices must be able to interpret certain profiles.
This unit is compatible with following profile.
A2DP (Advanced Audio Distribution Profile)
Listening to music stored on
the Bluetooth devices
Pairing your unit and Bluetooth
device
Before you start the pairing procedure, make
sure the Bluetooth feature is turned on in to your
Bluetooth device. Refer to your Bluetooth device’s
user guide. Once a pairing operation is performed,
it does not need to be performed again.
1. Select the Bluetooth function by using the
INPUT.
Appears “BT” and then “BT READY” in display
window.
2. Operate the Bluetooth device and perform the
pairing operation. When searching for this unit
with the Bluetooth device, a list of the devices
found may appear in the Bluetooth device
display depending on the type of Bluetooth
device.Your unit appears as “LG Audio”.
3. Enter the PIN code.
PIN code : 0000
4. When this unit successfully paired with your
Bluetooth device, Bluetooth LED of this unit
lights up and appears “PAIRED”.
Depending on the Bluetooth device type,
some device have a dierent pairing way.
, Note
5. Listen to music.
To play a music stored on your Bluetooth device,
refer to your Bluetooth device’s user guide.
If you change the function of the unit, the
Bluetooth function is disconnected, operate
pairing again.
(Bluetooth Function other than the
Bluetooth)
, Note
Downloaded From TheatreSystem-Manual.com Manuals

Operating 19
Operating
3
yThe sound may be interrupted when
the connection interfered by the other
electronic wave.
yYou cannot control the Bluetooth device
with this unit.
yPairing is limited one Bluetooth device per
one unit and multi-pairing is not supported.
yAlthough the distance between your
Bluetooth and the set is less than 10m, there
are obstacles between both, your Bluetooth
device cannot be connected.
yDepending on the type of the device,
you may not be able to use the Bluetooth
function.
yYou can enjoy wireless system using phone,
MP3, Notebook, etc..
yWhen not connected the Bluetooth, “BT
READY” appears on the display window.
yThe Electrical malfunction due to devices
using same frequency such as Medical
equipment, Microwaves or wireless
LAN devices, the connection will be
disconnected.
yWhen someone stands and interrupts
communication between Bluetooth device
and the player, the connection will be
disconnected.
yIf the gotten away of the distance between
Bluetooth and the unit, the sound quality
is lower and lower the connection will
disconnect when the space between the
Bluetooth and the unit gets out of the
operating range of Bluetooth.
yThe device with Bluetooth wireless
technology is disconnected, if you turn o
the main unit or put the device away from
the main unit more than 10m.
, Note
Downloaded From TheatreSystem-Manual.com Manuals

4 Troubleshooting
Operating20
Operating
3
Controlling a TV with
the Supplied Remote
Control
You can control your TV using the buttons below.
VOL +
VOL -
AV/INPUT
PR/CH
PR/CH
Button Operation
MUTE Turn the TV’s volume on or
o
AV/INPUT
Switch the TV’s input source
between the TV and other
input sources.
1(TV POWER) Turn the TV on or o.
VOL +/– Adjust the volume of the
TV.
PR/CH W/S Scan up or down through
memorized channels.
Depending on the unit being connected, you
may not be able to control your TV using some
of the buttons.
, Note
Setting up the remote to
control your TV
You can operate your TV with the supplied remote
control.
If your TV is listed in the table below, set the
appropriate manufacturer code.
1. While holding down 1(TV POWER) button,
and press the manufacturer code for your
TV with the numerical buttons (see the table
below).
Manufacturer Code Number
LG 1(Default), 2
Zenith 1, 3, 4
GoldStar 1, 2
Samsung 6, 7
Sony 8, 9
Hitachi 4
2. Release the 1(TV POWER) button to complete
setting.
Depending on your TV, some or all buttons may not
function on the TV, even after entering the correct
manufacturer code. When you replace the batteries
of the remote, the code number you have set may
be reset to the default setting. Set the appropriate
code number again.
Downloaded From TheatreSystem-Manual.com Manuals
