LG QP5W User manual
www.lg.com
版權所有 © 2021 LG Electronics Inc. 保留一切權利。
2105_Rev01
MFL71810941
QP5W / QP5 / QP5BE
簡易手冊
無線
Sound Bar
WIRELESS SOUND BAR
ENGLISH
Specication
Power consumption
yRefer to the main label.
AC adapter
yModel: DA-65F19
yManufacturer: Asian Power Devices Inc.
yInput: 100 - 240 V ~ 50 - 60 Hz
yOutput: 19 V 03.42 A
Dimensions (W x H x D): Approx. 296.0 mm x 59.9 mm x 126.0
mm
Bus Power Supply (USB): 5 V 0500 mA
Amplier (Total RMS Output power): 320 W RMS
Open Source Software Notice Information
To obtain the source code under GPL, LGPL, MPL, and other open
source licenses that have the obligations to disclose source code,
that is contained in this product, and to access all referred license
terms, copyright notices and other relevant documents please
visit https://opensource.lge.com.
LG Electronics will also provide open source code to you on
CD-ROM for a charge covering the cost of performing such
distribution (such as the cost of media, shipping, and handling)
This offer is valid to anyone in receipt of this information for a
period of three years after our last shipment of this product.
IMPORTANT SAFETY NOTICE
The cord grip for the plug tted to this product is built into the
existing power cord as supplied. If, for any reason you need to
shorten the cord,
DO NOT RE-USE THE PLUG
A new plug must be used to ensure your continued safety by
securing the plug to the power cord in accordance with Plug &
Socket Regulations 1994.
Declaration of Conformity
Hereby, LG Electronics declares that the radio equipment type
Wireless Sound Bar is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at
the following internet address:
http://www.lg.com/global/support/cedoc/cedoc#
For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.
中文
規格
電源耗用
y請參閱主標籤。
電源適配器
y型號：DA-65F19
y製造商：Asian Power Devices Inc.
y輸入：100 - 240 V ~ 50 - 60 Hz
y輸出：19 V 0 3.42 A
尺寸（闊 x 高 x 深）: 大約 296.0 mm x 59.9 mm x 126.0 mm
匯流排電源供應 (USB): 5 V 0 500 mA
擴音器（RMS 總輸出功率）: 320 W RMS
注意：開放來源程式碼軟件
欲獲得 GPL、LGPL、MPL 及其他有義務公開包含本產品內
容原始程式授權的源代碼，及存取所有提及授權條款、版
權聲明及其他相關文件，請瀏覽 https://opensource.lge.com。
LG Electronics 也可應您要求，在由您支付相關費用（如
媒體成本、運費及處理費）的條件下以 CD-ROM 方
式提供開放原始程式碼，如有需要請寄送電子郵件至
該產品最後一次出貨的三年內，任何收到此資訊的人可
享此優惠。
安全注意事項
本機的插頭握柄是專爲本産品所設計,且與附
贈的電源線結合為一體,若您因爲任何理由而
需截短此電源線時
請勿再使用該插頭
應使用全新的插頭以確保連續使用之安全性。
請依據1994年之插頭及插座規範的規定,將插頭
確實地與電源線結合。
符合標準聲明
在此，LG電子聲明 無線Sound Bar類型的無線電設備符合
2014/53/EU指令。你可以從以下互聯網地址獲得歐盟符合
性聲明的全文：
http://www.lg.com/global/support/cedoc/cedoc#
為了使用者的考慮，安裝和使用設備時，設備需和身體之
間保持最少20厘米距離。
QP5W.DHKGLLK_SIMPLE (Sheet)_MFL71810941.indd 1-3 2021-10-13 11:14:36
ENGLISH
Installing and Using the Product
Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com or scan QR code and then download
Owner’s Manual. Some of the content in this manual may differ from your product.
ASound bar
BRemote Control Receiver /
Status LED (Refer to below table)
CWireless Subwoofer - Install it close to the sound bar.
D External Device - (Blu-ray player, game console, etc.)
Power on Standby OPTICAL /
HDMI ARC
Bluetooth
ready Bluetooth HDMI IN USB
Red blinking Red White Blue blinking Blue White White
a Connect the sound bar to your TV via an optical cable or an HDMI cable.
b If you are using an external device (ex. Blu-ray player, game console, etc.), connect it to the sound bar via an HDMI cable.
c Connect to power in the following order: wireless subwoofer [ sound bar. Then, turn on the sound bar. When the connection is
automatically established with the sound bar, the LED on the wireless subwoofer will light up in green.
d Using the product with your TV
A Press the Function button repeatedly until the rst LED light up in white among the three LEDs.
B On your TV’s settings, set the output speaker to [HDMI ARC], [Optical], or [External Speaker].
e Connecting the product to your smartphone via Bluetooth
A Tap the Settings button on your smartphone and select Bluetooth.
Turn on the Bluetooth function. ( Off > On)
BPress the Bluetooth pair button. After a moment, the second LED blink in blue among the three LEDs.
C Find and tap the product on your smartphone. The product appears as “LG QP5W / QP5 / QP5BE (XX)”.
f Connecting to the LG Sound Bar app
A Find and install the LG Sound Bar app on Google Play or App Store from your smartphone.
B You can get more information regarding its use by selecting [Help] in [Setting].
If you see a red LED on the bottom of the wireless subwoofer, it means that the sound bar is not connected to the speaker. If this is the
case, connect them in the following order.
APress the Power button on the sound bar to turn it off.
BPress the PAIRING button on the bottom of the wireless subwoofer. Check if each LED blinks green.
-If you still see a red LED on the bottom of the wireless subwoofer, press and hold the button on the bottom of the subwoofer again.
CPress the Power button on the sound bar to turn it on.
D When the connection is established, you will see a green LED light on the bottom of the wireless subwoofer light up in green.
Keep the sound bar, the subwoofer away from the device (ex. wireless router, microwave oven, etc.) over 1 m to prevent wireless interference.
yDesign and specications are subject to change without notice.
yGoogle Play is a trademark of Google LLC.
HDMI OUT
OPTICAL IN
HDMI OUT
(TV eARC/ARC)
HDMI IN
a
bC
D
a
B
A
HDMI IN
(ARC)
HDMI IN OPTICAL
OUT
更換電池
Replacement of Battery
中文
產品安裝及使用
操作設備前請仔細閱讀本手冊，並保留以備日後參考。
要檢視有關進階功能的指示，請造訪 http://www.lg.com 或掃描二維碼下載使用說明書。部份使用
說明的內容有可能與你的產品不同。
ASound Bar
B 遙控接收器 /
LED 指示燈狀態（請參閱下表）
C 無線重低音揚聲器 — 貼近Sound Bar安裝。
D 外置設備 — （藍光播放機、遊戲機等等）
開啟 待機 OPTICAL /
HDMI ARC Bluetooth 就緒 Bluetooth HDMI IN USB
紅色閃爍 紅色 白色 藍色閃爍 藍色 白色 白色
a 請用光纖線或 HDMI 線將Sound Bar連接至您的電視機。
b 若您正在使用外置設備（如藍牙播放機、遊戲機等等），請用 HDMI 線將其連接至Sound Bar。
c 按以下順序連接電源：無線重低音揚聲器 [ Sound Bar。然後開啟Sound Bar。與Sound Bar自動建立連線後，無線重
低音揚聲器的 LED 指示燈亮綠色。
d 與您的電視機配合使用產品
A 重複按功能 按鈕，直到三個 LED 中的第一個 LED 亮起白色。
B 在電視的設定上，將輸出揚聲器設定為 [HDMI ARC]、[光纖] 或 [外部揚聲器]。
e 透過 Bluetooth 將設備連接至您的智能電話
A 輕觸您的智能電話內的設定 按鈕，選擇 Bluetooth。開啟 Bluetooth 功能。（ 關閉 > 開啟）
B 按下 Bluetooth 配對 按鈕。片刻之後，三個 LED 中的第二個 LED 閃爍藍色。
C 於您的智能電話上找到並輕觸產品名稱。產品會顯示為「LG QP5W / QP5 / QP5BE (XX)」。
f 連接至 LG Sound Bar 應用程式
A 從您智能電話的 Play Store 或 App Store 應用程式中，找到並安裝 LG Sound Bar。
B 您可透過選擇 [設定] 內的 [幫助] 以獲得更多資訊。
如果無線重低音揚聲器底部的 LED 指示燈亮紅色，表示Sound Bar未連接到揚聲器。如果是這種情況，請按以下順序連接它們。
A 按下Sound Bar的電源 按鈕以關閉它。
B 按無線重低音揚聲器底部的 PAIRING 按鈕。確認每個 LED 指示燈是否閃爍綠色。
- 如果無線重低音揚聲器的底部仍出現一個紅色的 LED，請再次按住重低音揚聲器底部的按鈕。
C 按下Sound Bar的電源 按鈕以開啟它。
D 建立連線後，您會看見無線重低音揚聲器底部的 LED 指示燈變成綠色。
讓Sound Bar、無線重低音揚聲器遠離以下設備（例如無線路由器、微波爐等）最少 1 m 以上，以免無線訊號干擾。
y設計和規格若有更改，恕不另行通知。
yGoogle Play 是 Google LLC 的商標。
QP5W.DHKGLLK_SIMPLE (Sheet)_MFL71810941.indd 4-6 2021-10-13 11:14:38
