LG RK7 User manual

MODEL
RK7
SIMPLE MANUAL
HIGH POWER
SPEAKER
SYSTEM
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com and then download
Owner’s Manual. Some of the content in this manual may differ from your unit.
MFL69941724
Top panel
Download the Music Flow Bluetooth App to your
device. (Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync
Controller App
aDisplay window
b1(Standby)
Turns the power on or off.
3DUAL
Connects two speakers for DUAL mode in WIRELESS PARTY
LINK.
3MULTI
Connects multiple speakers for MULTI mode in WIRELESS
PARTY LINK.
The unit might not synchronize between audio and
video in DUAL/MULTI mode.
cF (Function)
- Selects the function and input source.
- Press and hold to select the PARTY LINK with AUX.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono (Horizon mode only).
C/V(Skip/Search)
- Skips backward or forward.
- Searches for a section within a file.
- Selects the radio stations.
d AUTO DJ
Selects the AUTO DJ mode.
USER EQ / DEMO
-Selects the sound effect created by your own.
- In power off status, if you press USER EQ / DEMO, show
DEMO mode.
SOUND EFFECT / BASS BLAST (or BASS BLAST+)
-Chooses sound impressions.
- Press and hold to select BASS (or BASS+) effect directly.
LIGHTING
Selects lighting mode.
e+/- (Volume)
Adjusts speaker volume.
c
a
e
d
b
Front panel / Rear panel
aRemote sensor bFM ANTENNA
cMIC (Microphone) jack
dAUX IN / OUT (L/R)
eOPTICAL IN
fUSB port
gAC IN socket
Vertical Horizon
How to place the unit
abcde f g
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 345 mm X
650 mm X 345 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 550 W RMS
Design and specications are subject to change without
notice.
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
Replacement of battery
(R03)
(R03)
Due to the environment government regulations about
import and batteries destruction in Colombia, this model
will not bring the batteries of remote control included.
ENGLISH
RK7-FK.DCOLLLK_SIM_ENG_SPA(MEX)_MFL69941724.indd 1-4 2019-03-14  3:52:17
