LG SJ4R Specification sheet

SIMPLE MANUAL
Wireless
Sound Bar
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODELS
SJ4R LASC58R
ENGLISH
FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and the
receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modications in construction of this device
which are not expressly approved by the party responsible
for compliance could void the user’s authority to operate
the equipment
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any other
transmitter.
Responsible Party:
LG Electronics USA, Inc.
1000 Sylvan Avenue
Englewood Cliffs, NJ 07632
Tel: [phone]
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com
MFL70205127
SJ4R.DUSASLK_SIM_ENG_MFL70205127.indd 1-4 2018-05-08  10:17:57

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
PORTABLE IN ········ Connect to a Portable device
USB ·················· Connect to a USB device
HDMI OUT (TV ARC) ·············· Connect to a TV
HDMI IN ········· Connect to HDMI out on a device
Subwoofer Connection1
The buttons are located on the rear. Place the wireless subwoofer near the speaker and
follow steps below.
aConnect the power cord of wireless subwoofer
and sound bar to the outlet.
bTurn on the main unit. :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
green LED turns on.
Subwoofer Connection Manually
If the subwoofer does not make sound, try to
connect manually.
aPress Pairing button on the rear of the wireless
subwoofer.
yThe green LED on the rear of wireless
subwoofer blinks quickly.
bTurn on the main unit.
cPairing is completed.
yThe green LED on the rear of wireless
subwoofer turns on.
Keep the sound bar and the subwoofer away
from certain devices (ex. wireless router,
microwave oven, etc.) over 1m (3.28 ft) to
prevent wireless interference.
>1m
3.28 ft
ASC/BASS BLAST/CINEMA: Selects the sound effect.
REAR LEVEL +/-: Adjusts the volume level of rear
speakers. (For rear speakers)
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Battery Replacement
Remote control
aConnect the sound bar to the TV using
Optical cable.
bSet up [External Speaker (Optical)] on
your TV setting menu.
TV
TV
TV Connection2
Optical Connection
HDMI(ARC) Connection
aConnect the sound bar to the TV using
HDMI cable.
bSet up [External Speaker (HDMI ARC)] on
your TV setting menu.
Connect with the Sound Bar and TV using
Optical ( ) or HDMI ARC ( ).
Additional Device Connection
aConnect to the external device as follows.
TV
OR
(Set-top Box,
Player etc.)
bSet the input source by pressing Fon the remote
control or unit repeatedly.
yHDMI connection is unavailable if your TV
does not support HDMI ARC.
yIf this unit is connected by OPTICAL and
ARC at the same time, the ARC signal has a
higher priority.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit
http://opensource.lge.com.
In addition to the source code, all referred license terms,
warranty disclaimers and copyright notices are available
for download.
LG Electronics will also provide open source code to you
on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping
and handling) upon email request to opensource@lge.
com. This oer is valid for a period of three years after our
last shipment of this product. This oer is valid to anyone
in receipt of this information.
Additional Information
Specication
Power
consumption Refer to the main label.
AC adapter
yModel :
DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput :
100 - 240 V ~ 50 - 60 Hz
1.2 A
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890 mm x 55 mm x 85 mm
(35 inch x 2.17 inch x 3.35 inch)
With foot
Bus Power
Supply (USB) 5 V 0 500 mA
Amplier (Total
RMS Output
power) 420 W RMS
Design and specications are subject to change
without notice.
Rear Surround sound
Wireless Rear Speakers Kit included for real
surround sound.(SPJ4-S)
SJ4R.DUSASLK_SIM_ENG_MFL70205127.indd 5-8 2018-05-08  10:17:59

SIMPLE MANUAL
Wireless
Rear Speakers
Kit
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
SPJ4-S
ENGLISHENGLISH
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China Copyright © 2018 LG Electronics Inc. All Rights Reserved.
www.lg.com
MFL70205128
SJ4R(SPJ4-S).DUSASLK_SIM_MFL70205128.indd 1-2 2018-05-08  10:19:21

FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and the
receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modications in construction of this device
which are not expressly approved by the party responsible
for compliance could void the user’s authority to operate
the equipment
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any other
transmitter.
Responsible Party:
LG Electronics USA, Inc.
1000 Sylvan Avenue
Englewood Cliffs, NJ 07632
Tel: [phone]
aConnect the power cord of the wireless receiver
to the AC outlet.
bTurn on the unit: The unit and wireless receiver
will be automatically connected. The receiver's
yellow - green LED turns on
Wireless Receiver Connection Manually
If the rear speakers do not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless receiver.
yThe yellow - green LED on the wireless receiver
blinks quickly.
bTurn on the main unit.
cPairing is completed.
yThe yellow - green LED on the wireless receiver
turns on.
Rear Speakers Connection1
Wireless Receiver Connection2
aConnect the speaker cables to rear speakers
correctly.
bConnect the Wireless Receiver and the rear
speakers (Grey: right, Blue: left) with the speakers
cables.
cTurn on the Surround function to enjoy surround
sound.
Speaker design and connection method may be
different according to models.
Rear speaker
(Left)
Wireless
Receiver Rear speaker
(Right)
Transparent
Black stripe
Transparent
Black stripe
Surround Sound On/Off
When you turn on surround function, you can enjoy
magnificent surround sound for all the input sound
source with rear speakers.
The initial setting for the surround function is
OFF, turn the surround function ON to use it.
SJ4R/LASC58R/SJ4Y
Surround On: Press and hold REAR LEVEL obutton
on the remote control about 2 seconds.
Surround Off: Press and hold REAR LEVEL pbutton
on the remote control about 2 seconds.
SJ5Y
Surround On: Press and hold AUTO VOL button on the
remote control about 2 seconds and then press AUTO
VOL button repeateadly to select ON - SURROUND in
the display window.
Surround Off: Press and hold AUTO VOL button on the
remote control about 2 seconds and then press AUTO
VOL button repeateadly to select OFF - SURROUND in
the display window.
Additional Information
Specication of Wireless receiver
Power
requirement
Refer to the main label on the
wireless receiver.
Power
consumption
Refer to the main label on the
wireless receiver.
Dimensions
(W x H x D)
Approx.
60 mm x 220 mm x 175 mm
(2.36 inch x 8.66 inch x 6.88
inch)
Design and specications are subject to change
without notice.
About Ferrite Core (Optional)
twice
SJ4R(SPJ4-S).DUSASLK_SIM_MFL70205128.indd 3-4 2018-05-08  10:19:22
