LG SLM3D User manual

SIMPLE MANUAL
Wireless
Sound Bar
MFL70585665
ENGLISH
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner's Manual.
Some of the content in this manual may differ from your unit.
MODEL
SLM3D
FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and
the receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modications in construction
of this device which are not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any
other transmitter.
Supplier's Declaration of Conformity
Trade Name LG
Responsible Party LG Electronics USA, Inc.
Address 111 Sylvan Avenue, North Building
Englewood Cliffs, New Jersey
07632
Email lg.envir[email protected]om
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China
2105_Rev03
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 1,4 2021-05-28   10:20:33

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37
Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37

Front Panel
··································Standby / On
·······························Selects Function
·························Adjusts Volume
ASC/BASS BLAST/CINEMA: Selects the sound effect.
NIGHT ON/OFF: Turns down the volume at night.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Rear Panel
DC IN ·················· Connect to the AC adapter
OPTICAL IN · · · · · · · · · · · Connect to an Optical device
USB/··················Connect to a USB device
Subwoofer Connection1
aConnect the sound bar to the TV using Optical
cable.
bSet up [External Speaker (Optical)] on your TV
setting menu.
TV
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top Box,
Player etc.)
bSet the input source by pressing Frepeatedly.
TV Connection2
The buttons are located on the rear. Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of the sound bar and
the wireless subwoofer to the outlet.
bTurn on the sound bar.
c The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
yellow green LED turns on.
Manual Subwoofer Connection
If the subwoofer does not make sound, try to
connect manually.
aPress PAIRING button on the rear of the
wireless subwoofer.
yThe yellow green LED on the front of the
wireless subwoofer blinks quickly.
(If the yellow green LED does not blink, press
and hold the PAIRING button.)
bTurn on the sound bar.
c Pairing is completed.
yThe yellow green LED on the front of the
wireless subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m (3.3 ft) to prevent wireless
interference.
>
1 m
(3.3 ft)
Specication
Power
consumption Refer to the main label.
AC adapter
yModel : DA-38A25
yManufacturer : Asian Power
Devices Inc.
yInput : 100 - 240 V ~ 50 - 60 Hz
yOutput : 25 V 01.52 A
yModel : MS-Z1520R250-
038A0-P
yManufacturer : MOSO POWER
SUPPLY TECHNOLOGY CO., LTD.
yInput : 100 - 240 V ~ 50/60 Hz
yOutput : 25 V 01.52 A
Dimensions
(W x H x D)
Approx.
890.0 mm x 53.0 mm x 85.0 mm
(35.0 inch x 2.1 inch x 3.3 inch)
Without foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
300 W RMS
Design and specications are subject to change
without notice.
Additional Information
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 5-8 2021-05-28   10:20:37

SIMPLE MANUAL
Wireless
Sound Bar
MFL70585665
ENGLISH
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner's Manual.
Some of the content in this manual may differ from your unit.
MODEL
SLM3D
FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and
the receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modications in construction
of this device which are not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any
other transmitter.
Supplier's Declaration of Conformity
Trade Name LG
Responsible Party LG Electronics USA, Inc.
Address 111 Sylvan Avenue, North Building
Englewood Cliffs, New Jersey
07632
Email lg.envir[email protected]om
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China
2105_Rev03
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 1,4 2021-05-28   10:20:33

SIMPLE MANUAL
Wireless
Sound Bar
MFL70585665
ENGLISH
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner's Manual.
Some of the content in this manual may differ from your unit.
MODEL
SLM3D
FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and
the receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modications in construction
of this device which are not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any
other transmitter.
Supplier's Declaration of Conformity
Trade Name LG
Responsible Party LG Electronics USA, Inc.
Address 111 Sylvan Avenue, North Building
Englewood Cliffs, New Jersey
07632
Email lg.envir[email protected]
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China
2105_Rev03
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 1,4 2021-05-28   10:20:33

SIMPLE MANUAL
Wireless
Sound Bar
MFL70585665
ENGLISH
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner's Manual.
Some of the content in this manual may differ from your unit.
MODEL
SLM3D
FCC Compliance Statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference
by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and
the receiver.
yConnect the equipment to an outlet on a circuit
different from that to which the receiver is connected.
yConsult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation. Any changes or modications in construction
of this device which are not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for
an uncontrolled environment. This transmitter must not
be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment should be installed and operated with
minimum distance 20 cm (7.8 inches) between the
antenna and your body. Users must follow the specic
operating instructions for satisfying RF exposure
compliance.
FCC Radio Frequency Interference Requirements:
High power radars are allocated as primary users of the
5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These
radar stations can cause interference with and/or damage
this device. This device cannot be co-located with any
other transmitter.
Supplier's Declaration of Conformity
Trade Name LG
Responsible Party LG Electronics USA, Inc.
Address 111 Sylvan Avenue, North Building
Englewood Cliffs, New Jersey
07632
Email [email protected]om
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
Printed in China
2105_Rev03
SK4D.DUSAMLK(SLM3D)_SIM (Sheet)_MFL70585665.indd 1,4 2021-05-28   10:20:33
