SIMPLE MANUAL
Wireless
Sound Bar
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit
http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
SNH5
2102_Rev02
ENGLISH FRANÇAIS
MFL71670172
SNH5.DDZALLK_SIM_ENG_MFL71670172.indd 1 2021-02-18  8:17:38

Front Panel
1(Standby) ··········Switches the unit ON or OFF.
F(Function) ························Selects function.
p/o(Volume)····················Adjusts volume.
Rear Panel
WOOFER 3 Ω···············Connect to a Subwoofer.
HDMI OUT (TV ARC)··············· Connect to a TV.
HDMI IN ··········Connect to device with HDMI OUT.
OPTICAL IN ············Connect to an optical device.
USB Port ····················Connect to a USB device.
Make sure to properly align and connect the
optical cable; improper alignment may cause
damage to the jack.
Subwoofer Connection
Place the subwoofer near the sound bar and follow
steps below.
a Connect a subwoofer cord to the sound bar.
• When connecting a Subwoofer cord to the
unit, insert the connector until it clicks.
b Turn on the sound bar.
SNH5.DDZALLK_SIM_ENG_MFL71670172.indd 2 2021-02-18  8:17:38

TV Connection
Connect the sound bar and TV using Optical ( ) or
HDMI ARC ( ).
Optical Connection
a Connect the sound bar to the TV using Optical
cable.
b Set up [External Speaker (Optical)] on your TV
setting menu.
TV
HDMI (ARC) Connection
a Connect the sound bar to the TV using HDMI
cable.
b Set up [External Speaker (HDMI ARC)] on your
TV setting menu.
TV
• HDMI connection is unavailable if your TV
does not support HDMI ARC.
• If this unit is connected by OPTICAL and
ARC at the same time, the ARC signal
has a higher priority.
Additional Device Connection
a Connect to the external device like as follow.
OR
TV
(Set-top Box,
Player etc.)
OR
b Set the input source by pressing Frepeatedly.
Remote control
Replacement of Battery
C/V:Skip/Search
N:Play/Pause
-Bluetooth connection lock (BT LOCK): Select
the Bluetooth function by pressing Frepeatedly.
Long press Nand press it again to limit
Bluetooth connection to only BT and LG TV.
SOUND EFFECT: Selects a sound effect mode.
-TV remote: Long press SOUND EFFECT and
press it again to use TV remote control.
FOLDER W/S: Searches a folder.
J:Displaystheinformationofale,aninputsource
or connected Bluetooth device name.
-Auto Power ON/OFF: Long press Jand press
it again.
: Adjusts the sound level of the adjustable speakers.
REPEAT:Listenstoyourlesrepeatedlyorrandomly.
SNH5.DDZALLK_SIM_ENG_MFL71670172.indd 3 2021-02-18  8:17:39

Additional Information
Specication
Power
Requirements Refer to the main label.
Power
consumption Refer to the main label.
Dimensions
(W x H x D)
Approx.
990.0 mm X 97.0 mm X
125.0 mm With foot
Bus Power
Supply (USB) 5 V 0500 mA
Amplier
(Total RMS
Output
power)
600 W RMS
Designandspecicationsaresubjecttochange
without notice.
OPEN SOURCE SOFTWARE NOTICE
INFORMATION
To obtain the source code under GPL, LGPL, MPL, and
other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request to
opensourc[email protected].
This offer is valid for a period of three years after our
last shipment of this product. This offer is valid to
anyone in receipt of this information.
