LG CK43 Specification sheet

Please read this manual carefully before operating your set and retain it for future reference.
To view the instructions of advanced features, visit http://www.lg.com and then download
Owner’s Manual. Some of the content in this manual may differ from your unit.
MODEL
CK43
SIMPLE MANUAL
Mini Hi-Fi
System
MFL70382772
POWER: This unit operates on a mains supply of
200 - 240 V ~, 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved main
plug. When replacing the fuse, always use of the same
rating approved to BS 1362. Never use this plug with the
fuse cover omitted. To obtain a replacement fuse cover
contact your dealer. If the type of plug supplied is not
suitable for the mains sockets in your home, then the plug
should be removed and a suitable type tted. Please refer
to the wiring instructions below:
Warning: A mains plug removed from the mains lead of this
unit must be destroyed. A mains plug with bared wires is
hazardous if inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the letter E or
with the earth symbol 6or coloured green or green and
yellow. If any other plug is tted, use same rating of fuse in
the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in your
plug, proceed as follows: The wire which is coloured blue
must be connected to the terminal which is marked with
the letter N or coloured black. The wire which is coloured
brown must be connected to the terminal which is marked
with the letter L or coloured red.
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 300 mm x
163 mm x 241 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 300 W RMS
Design and specications are subject to change without
notice.
Replacement of battery
(R03)
(R03)
ENGLISH
CK43-FB.DKENHLB_SIM_ENG_MFL.indd 2 2018-08-22  7:50:08
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.
1807_Rev02

Front Panel
a USB 1 Port
You can play sound les by connecting the USB device.
b Display window
c (Remote sensor)
d USB 2 Port
You can play sound les by connecting the USB device.
e MASTER VOL. (Volume)
Adjust speaker volume.
f BASS BLAST (or BASS BLAST+)
Press to select BASS (or BASS+) effect directly.
USB REC / DEMO
- Records to USB.
- To stop Recording, press and hold for 3 seconds.
- In power off status, if you press USB REC / DEMO,
show DEMO mode.
3WIRELESS LINK
- Selects MAIN or OTHER on WIRELESS PARTY LINK mode.
- Enable or disable WIRELESS PARTY LINK mode.
g F(Function)
Selects the function and input source.
V(Skip/Search)
- Skips forward.
- Searches for a section within a track/le.
- Selects the radio stations.
B (Open/Close)
Opens and closes the disc tray.
h AUTO DJ
Selects the AUTO DJ mode.
N (Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
i 1(Standby)
Turns the power on or off.
C(Skip/Search)
- Skips backward.
- Searches for a section within a track/le.
- Selects the radio stations.
Z(Stop)
Stops playback or cancels DELETE function.
j Disc tray
k SPECIAL EQ
Chooses special equalizer.
SEARCH
Moves to folder or file in selection mode.
OK
Selects a folder when searching a file.
l EQUALIZER / SEARCH
- Chooses sound impressions.
- Searches a folder or a le.
a d
e
l
k fj
b c
ghi
Rear Panel
a Power cord
bSPEAKERS terminals
cAUX IN (L/R)
Connect an auxiliary device.
dANTENNA (FM)
Download the Music Flow Bluetooth App to your
device. (Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
Speaker Connection
Red
Black
a
b c d
