LG CL65 Specification sheet

Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 350.0 mm x
163.0 mm x 251.0 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 950 W RMS
Design and specications are subject to change without
notice.
Replacement of battery
(R03)
(R03)
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
POWER: This unit operates on a mains supply of
200 - 240 V ~ 50 - 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use a fuse of
the same rating and approved to BS 1362. Never use this
plug with the fuse cover omitted. To obtain a replacement
fuse cover contact your dealer. If the type of plug supplied
is not suitable for the mains sockets in your home, then
the plug should be removed and a suitable type tted.
Please refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared wires
is hazardous if inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the letter E or
with the earth symbol 6or coloured green or green and
yellow. If any other plug is tted, use same rating of fuse in
the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in your
plug, proceed as follows: The wire which is coloured blue
must be connected to the terminal which is marked with
the letter N or coloured black. The wire which is coloured
brown must be connected to the terminal which is marked
with the letter L or coloured red.
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
SIMPLE MANUAL
Mini Hi-Fi
System
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may
differ from your unit.
MODEL
CL65
1907_Rev01
MFL71101814
ENGLISH
CL65-FB.DKENHLK_SIM (Sheet)_MFL71101814.indd 1-2 2019-05-31  12:18:56

Front Panel
a
hijklmn
b c d e f
og
a USB 1 Port
You can play sound les by connecting the USB device.
b 1(Standby)
Turns the power on or off.
c Display window
d (Remote sensor)
e 3TWIN
Connects two speakers for TWIN mode in WIRELESS PARTY
LINK.
fUSB 2 Port
You can play sound les by connecting the USB device.
g VOLUME
-Adjust speaker volume.
- Adjusts microphone volume.
h MIC VOL (Microphone volume)
Selects microphone volume mode.
MIC (Microphone) ECHO
Selects ECHO mode.
VOICE CANCELLER
You can reduce the vocal tones during music playback from
various input sources.
VOCAL EFFECTS
Selects various vocal effects mode.
i F (Function)
Selects the function and input source.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
V(Skip/Search)
- Skips forward.
- Searches for a section within a track/le.
- Selects the radio stations.
KEY CHANGER (L/l)
Changes the key to suit your vocal range.
jDisc tray
k USB REC / DEMO
- Records to USB.
- Stops Recording.
- In power off status, if you press USB REC / DEMO, show
DEMO mode.
Z(Stop)
Stops playback or cancels DELETE function.
C(Skip/Search)
- Skips backward.
- Searches for a section within a track/le.
- Selects the radio stations.
B(Open/Close)
Opens and closes the disc tray.
AUTO DJ
Selects the AUTO DJ mode.
Rear Panel
a
b c d e
100 100
aPower cord
b SPEAKERS terminals
c SPEAKER LIGHTING SYSTEM
Connect the speaker lighting cables.
d AUX IN 2 (L/R)
Connect an auxiliary device.
e ANTENNA (FM)
Speaker Connection
100 100
100 100
l LIGHTING
Selects the lighting mode.
SPECIAL EQ / BASS BLAST (or BASS BLAST+)
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect directly.
SEARCH
Moves to folder or le in selection mode.
OK
Selects a folder when searching a le.
m MIC (Microphone) jack
n AUX IN 1 jack
o EQUALIZER / SEARCH & MULTI
- Chooses sound impressions.
- Searches a folder or a le.
- Selects the lighting effects.
Download the LG XBOOM App to your device.
(Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
