LG HECTO2 User manual

OWNER’S MANUAL
Laser TV
HECTO2
Please read the safety information carefully before using the product.
www.lg.com

2LICENSE
LICENSE
Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX
®
is a digital video format created by
DivX, LLC, a subsidiary of Rovi Corporation. This is an ofcial
DivX Certied
®
device that has passed rigorous testing to verify
that it plays DivX video. Visit divx.com for more information and
software tools to convert your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied
®
device must be registered in order to play purchased
DivX Video-on-Demand (VOD) movies. To obtain your registration
code, locate the DivX VOD section in your device setup menu.
Go to vod.divx.com for more information on how to complete your
registration.
DivX Certied
®
to play DivX
®
video up to HD 1080p, including
premium content.
DivX
®
, DivX Certied
®
and associated logos are trademarks of
Rovi Corporation or its subsidiaries and are used under license.
Covered by one or more of the following U.S. patents: 7,295,673;
7,460,668; 7,515,710; 7,519,274
The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
For DTS patents, see http://patents.dts.com. Manufactured under
license from DTS Licensing Limited. DTS, the Symbol, & DTS
and the Symbol together are registered trademarks, and DTS
2.0+Digital Out is a trademark of DTS, Inc. © DTS, Inc. All Rights
Reserved.
This device meets the EMC requirements for home appliances (Class B) and is
intended for home usage. This device can be used in all regions.
•The product images and On-Screen Display (OSD) in this manual are examples to
help you understand how to operate the product, so they may be different from the
actual Laser TV.
NOTE

3
SAFETYINSTRUCTIONS
SAFETYINSTRUCTIONS
Please take note of the safety instructions to prevent any potential accident or misuse of
the Laser TV.
• Safety precautions are given in two forms, i.e. Warning and Caution as detailed below.
WARNING: Failure to follow the instructions may cause serious injury and even
death.
CAUTION: Failure to follow the instructions may cause injury to persons or damage
to the product.
• Read the owner’s manual carefully and keep it to hand.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED
SERVICE PERSONNEL.
The lightning ash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufcient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE
AND ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
Readtheseinstructions.
Keeptheseinstructions.
Heedallwarnings.
Followallinstructions.
IndoorInstallation
WARNING
• Do not place the product in direct
sunlight or near heat sources such as
radiators, fires, stoves, etc.
– This may cause re.
• Do not place inflammables such as
flammable spray near the product.
– This may cause re.
• Do not allow children to cling to or climb
up to the product.
– This may cause the product to fall,
causing injury or death.

4SAFETYINSTRUCTIONS
• Do not place the product directly on a
carpet, rug or place where ventilation
is restricted such as a book shelf or
closet.
– This may cause the product’s
internal temperature to rise and
cause re.
• Do not place the product close to
sources of steam, oil or oil mist, such
as humidifiers and kitchen counters.
– Failure to do so may result in re,
electric shock, or corrosion.
• Do not install the product onto a wall or
ceiling that is close to sources of oil or
oil mist.
– The product may be damaged and
fall, resulting in serious injury.
• Do not place the product where it might
be exposed to dust.
– This may cause re.
• Do not use the product in a damp
place, such as a bathroom or a place
exposed to the wind and rain, where it
is likely to get wet.
– This may cause re or electric shock.
• Do not allow a tablecloth or curtain to
block the vents.
– This may cause the internal
temperature of the product to rise
and cause re.
• The distance between the air vent
of the product and the wall should
be more than 30 cm for ventilation
purposes.
– Otherwise, this may cause the
internal temperature of the product to
rise and cause re.
• When installing the product on a ceiling,
a professional technician should install
it using the authorized tools. If installed
improperly, the product may fall.
– This may cause personal injury or
property damage. For installation
of the product, please contact the
customer support center.
• If you use a ceiling mounting device,
use adhesive to prevent loosening of
screws, or apply oil or lubricant to the
product, this may cause the case to
crack and the product to fall.
• This may also cause serious personal
injury to the person below the device
(if any) and damage to the product as
well.
CAUTION
• When installing the product on a table
or shelf, be careful not to place it near
the edge.
– This may fall causing injury to
persons or the product malfunction.
Make sure that you use the cabinet
or stand that ts the product.
• Turn off the product, disconnect it from
the power supply and all connected
apparatus before moving it.
– Otherwise, the power cord may be
damaged causing re or electric
shock.
• Do not place the product on an
unstable or vibrating surface such as a
wobbly shelf or a slope.
– It may fall or ip and cause injury.
• Be careful not to tip or drop the product
over when connecting external devices
to the product.
– This may cause injury to persons or
damage to the product.

5
SAFETYINSTRUCTIONS
Power
WARNING
• The appliance coupler is used as the
disconnect device.
– Please make sure the device is
installed near the wall outlet to which
it is connected and that the outlet is
easily accessible.
• The grounding wire should be
connected.
– Be sure to connect the grounding
wire to avoid damage to the product
or an electric shock when there is a
short circuit.
• If it is not possible to ground the unit,
purchase a circuit breaker and connect
the product to its wall outlet.
• Do not try to ground the product to the
gas pipe, water pipe, lightning rod, or
telephone line, etc.
• The power plug should be inserted fully
into the power outlet.
– An unstable connection may cause
re.
• Do not place heavy objects on the
power cord.
– This may cause re or electric shock.
• Never touch the power plug with a wet
hand.
– This may cause electric shock.
• Do not plug too many devices into one
multi-power outlet.
– This may cause re due to the power
outlet overheating.
• Remove dust or contaminants around
power plug pins or wall outlets.
– Failure to do so may cause re.
• To turn off the main power, remove the
power plug, which should be positioned
so it is easy to access for operation.
CAUTION
• Hold the plug firmly when unplugging.
– A broken wire in the cord may cause
re.
• Ensure the power cord and plug are
not damaged, modified, severely bent,
twisted, pulled, sandwiched or hot. Do
not use the product if the power outlet
is loose.
– This may cause re or electric shock.
• Keep the power cord away from any
heating devices.
– The cord coating may melt and
cause re or electric shock.
• Place the product where people will not
trip over or tread on the power cord to
protect the power cord and plug from
any damage.
– This may cause re or electric shock.
• Do not turn the product on or off
by plugging in the power plug or
unplugging it from the wall outlet.
(Do not use the power plug as a
switch.)
– This may cause electric shock or
product malfunction.
• Do not insert a conductor into the other
side of the wall outlet while the power
plug is inserted into the wall outlet.
• In addition, do not touch the power plug
immediately after it is disconnected
from the wall outlet.
– This may cause electric shock.
• Only use the official power cord
provided by LG Electronics. Do not use
other power cords.
– This may cause re or electric shock.

6SAFETYINSTRUCTIONS
WheninUse
WARNING
• Do not place anything containing liquid
on top of the product, such as a vase,
flower pot, cup, cosmetics, or medicine;
or ornaments, candles, etc.
– This may cause re or electric shock,
or injury due to falling.
• In the event that there is a heavy
impact on the product or the cabinet
is damaged, switch it off, unplug it
from the power outlet and contact an
authorized service center.
– Failure to do so may cause re or
electric shock.
• Do not insert pieces of metal, such
as coins, hairpins or metal debris, or
flammable materials, such as paper or
matches, into the product.
– This may cause re or electric shock.
• In the event that liquid or a foreign
object falls into the product, switch it off
and unplug it from the power outlet and
contact our service center.
– Failure to do so may cause re or
electric shock.
• Make sure that a child does not swallow
the batteries when you replace the old
remote control batteries with new ones.
Keep batteries out of reach of children.
– If a child swallows a battery, consult
a doctor immediately.
• Do not look directly into the lens when
the product is in use. The strong light
may damage your eyes.
• When the product is on or has just
been turned off, avoid touching the air
vent because it will be very hot.
• If there is a gas leak, do not touch
the wall outlet. Open the window for
ventilation.
– A spark may cause a re or burn.
• Never touch the product or power cord
during thunder or lightning.
– This may cause electric shock.
• Do not use the product near electronic
devices that generate a strong
magnetic field.
• Do not wear the plastic package used
to pack the product around your head.
– This may cause suffocation.
• Do not touch the product with your
hand for a long time when it is running.
• When you play a game by connecting
a game console to a product, it is
recommended that you maintain a
distance of more than 1.5 times the
diagonal length of the screen.
• Make sure that the length of connecting
cable is long enough.
– Otherwise, the product may fall
causing personal injury or damage to
the product.
CAUTION
• Do not place a heavy object on the
product.
– It may fall down and cause physical
injury.
• Be careful to protect the lens from
heavy impact during transportation.
• Do not touch the cover glass of the
product.
– Otherwise, the cover glass may be
damaged.
• Do not use any sharp tools on the
product, such as a knife or hammer,
because this may damage the casing.

7
SAFETYINSTRUCTIONS
• In the event that no image appears
on the screen or no sound is heard,
stop using the product. Switch off the
product, unplug it from the power outlet
and contact our service center.Failure to
do so may cause fire or electric shock.
• Do not drop anything onto the product
or apply heavy pressure to it.
– This may cause injury to persons or
the product malfunction.
• It is recommended that you maintain a
distance of more than 1.5 - 3 times the
diagonal length of the screen between
your eyes and the screen.
– If you watch the screen at a close
distance for a long time, your
eyesight may become worse.
• When closing the door of the product,
be careful not to jam your finger.
– This may cause injury to persons or
the product malfunction.
• Do not block the light emitted from the
product’s lens with a book or a cover.
Long exposure to the light may melt or
burn the object, possibly causing fire.
In addition, the lens may be overheated
and the product may be damaged
by the reflected light. Stop projecting
temporarily or turn off the power.
• Do not start the product with volume high.
– High volume may damage hearing. Be
sure to lower the volume before turning
off the product. Raise the volume
gradually after turning on the product.
• When you go out, place the product out
of reach of pets or other animals, and
unplug it from the wall outlet.
– Otherwise, it may cause short circuit
and re.
• Do not use high voltage electrical
equipment near the projector, (e.g. bug
zapper).
– This may result in product
malfunction.
Cleaning
WARNING
• Do not spray water directly to the
product when cleaning. Do not allow
water to get into the product or do not
allow it to get wet.
– This may cause re or electric shock.
• In the event that smoke or a strange
smell comes out from the product or a
foreign object falls into the product, stop
using it. Switch off the product, unplug
it from the power outlet and contact our
service center.
– Otherwise, this may cause re or
electric shock.
• To remove dust or stains on the cover
glass, use an air spray or use a swab
or soft cloth to wipe the glass gently.
CAUTION
• Contact your seller or our service
center once a year to clean the internal
parts of the product.
– If you do not clean the Laser TV
for a long period of time, dust will
accumulate, which may cause re or
damage to the product.
• When cleaning plastic parts, such as
the product case, unplug the power
first and wipe with a soft cloth. Do not
spray with water or wipe with a wet
cloth. When cleaning the plastic parts,
such as the product case, do not use
cleanser, automobile or industrial
shiner, abrasive or wax, benzene,
alcohol, etc., which can damage the
product.
– This can cause re, electric shock
or product damage (deformation,
corrosion and damage).

8SAFETYINSTRUCTIONS
Others
WARNING
• Only a qualified technician can
disassemble or modify the product.
For inspection, adjustment, or repair,
contact your seller or our service center.
– Otherwise, this may cause re or
electric shock.
• Do not stare directly into lens when in
operation, eye damage can occure.
• No user serviceable parts inside unit.
High voltage parts can cause shock
and even electrocution.
• Proper ventilation required, do not block
airflow around unit.
Doing so can cause injury and internal
overheating.
• To prevent damage to lamp, unit must
remain plugged in for approximately 3
minutes after power down to allow for
proper cool down (not applicable on
LED models).
• Do not touch the lens; doing so can
result in burns or damage to lens.
Lens and unit may be HOT during and
immediately after use.
Use caution when handling unit,
allowing for proper cool down.
• Only use a grounded electrical outlet.
• Do not insert anything into or cover up
the exhaust vents.
– This may result in re or electric
shock.
• Follow all maintenance guidelines
for optimal use; service only at an
authorized service center.
• Lamp contains mercury and as such
must be disposed of according to local,
state and federal laws (not applicable
on LED models).
CAUTION
• Make sure you use the same type of
new battery for replacement.
• Do not mix new batteries with old ones.
– Burst or leaking batteries may cause
re or electric shock.
• Unplug the power cord if the product is
not used for a long period.
– Accumulated dust may cause
electric shock due to overheating,
ignition, or poor insulation, or re due
to a short circuit.
• Do not charge the battery using any
devices other than the one provided
with the product.
– This may cause damage to the
battery or re.
• Dispose of the used battery properly.
– Failure to do so may cause
explosion or re. The correct method
of disposal may vary depending on
your country or region. Dispose of
the battery pack according to the
appropriate instructions.
• Do not throw or disassemble the
battery.
– This may cause re or explosion due
to damage to the battery.
• Always use batteries approved and
certified by LG Electronics.Failure to do
so may cause fire or explosion.
• Store the battery away from metallic
objects, such as keys and paper clips.
– Excess current may cause a rapid
increase in temperature, resulting in
damage to battery, re or burns.
• Do not store the battery near any heat
source, such as a heater. This may
cause fire or product malfunction.

9
SAFETYINSTRUCTIONS
• Do not store it at temperatures higher
than 60 °C or in high humidity.
– This may cause explosion or re.
• Keep the battery out of reach of
children.
– Failure to do so may cause personal
injury or product malfunction.
• Make sure that the battery is installed
correctly.Failure to do so may cause
explosion or fire.
• The battery contains lithium-ion, so it
must be handled with care.
– Failure to do so may cause
explosion or re.
Antenna
WARNING
• If you are using an outdoor antenna,
please install it away from electrical
wires to make sure it does not touch
any nearby wires even when it falls
down due to heavy wind.
• Failure to do so may cause electric
shock or physical injury.
CAUTION
• To prevent any raindrops flow into the
product, bend the outdoor antenna wire
where it comes indoors.
• Raindrops flowing into the product may
cause fire or electric shock.
Antennagroundingaccordingtothe
NationalElectricalCode,ANSI/NFPA70
Antenna Lead in Wire
Grounding Conductor
(NEC Section 810-21)
Antenna Discharge Unit
(NEC Section 810-20)
Power Service
GroundingElectrode
System (NEC Art
250, Part H)
NEC:NationalElectricalCode
Ground Clamp
Electric Service
Equipment
Ground Clamp
ForUSA
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the
CATV system installer’s attention to
Article 820 - 40 of the National Electric
Code (U.S.A.). The code provides
guidelines for proper grounding and, in
particular, species that the cable ground
shall be connected to the grounding
system of the building, as close to the
point of the cable entry as practical.
EyeCareSensor
WARNING
• Do not poke the sensor with a sharp
object.
– This can damage the sensor and
cause it to malfunction.
Laser
WARNING
• This product contains a laser module.
Do not disassemble or modify the
product as this could be dangerous.
• You risk being exposed to laser
radiation if you manipulate or alter the
product in a way not specified in the
user manual.
• To protect your eyes avoid looking
directly into the bright light from the unit.
• Prevent babies and children or anyone
with a disease or injury from looking at
the light.
• Please kindly take a 5 W 440 - 460 nm
Laser protective goggles when you
need direct access the Light, and
do not use sun glasses for the eye
protection.

10 SAFETYINSTRUCTIONS
CAUTION
• Use of controls or adjustments or
performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
• This product is a class 2 laser device
that meets IEC 60825-1.
LaserTVstandard:class2laserproduct
• Wavelength: 446 nm
• Wave source : Approximately 0.2 mW
• Light output: < 24.5 mW
• Radiation angle: 66 °
• Built-in laser standard: Class 3B laser
module
• Wavelength: 440 nm - 455 nm
• Light output: approx. 3.5 W x 24
Viewing direction
Laser beam
direction
Screen
LASERRADIATION
DO NOT STARE INTO BEAM CLASS 2
LASER PRODUCT
– This laser Laser TV is a Risk Group 2
device that meets safety standard IEC
62471 standard.
The label of Laser TV is attached to the
top of the product.
LaserTVLabel
Laser warning symbol and danger symbol

11
SAFETYINSTRUCTIONS
USA
FederalCommunicationsCommission
(FCC)Statement
You are cautioned that changes or
modications not expressly approved by
the part responsible for compliance could
void the user’s authority to operate the
equipment.
This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of
the FCC rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications. However, there
is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to correct
the interference by one or more of the
following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
1) this device may not cause harmful
interference, and
2) this device must accept any
interference received, including
interference that may cause undesired
operation of the device.
CAUTION : Any changes or modications
not expressly approved by the party
responsible for compliance could void the
user’s authority to operate this equipment.
FCCRadioFrequency
InterferenceRequirements
(forUNIIdevices)
High power radars are allocated as
primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar
stations can cause interference with and/
or damage this device. This device cannot
be co-located with any other transmitter.
FCCRFRadiationExposure
Statement:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment. This transmitter
must not be co-located or operating in
conjunction with any other antenna or
transmitter.
This equipment should be installed and
operated with minimum distance 20 cm
between the radiator and your body. End
users must follow the specic operating
instructions for satisfying RF exposure
compliance.

12 SAFETYINSTRUCTIONS
CANADA
IndustryCanadaStatement:
This device complies with RSS-210 of
the Industry Canada Rules. Operation is
subject to the following two conditions:
1) this device may not cause interference
and
2) this device must accept any
interference, including interference that
may cause undesired operation of the
device.
Avisd’IndustrieCanada:
Cet appareil est conforme à la norme
CNR-210 des règlements d’Industrie
Canada. Son fonctionnement est sujet
aux deux conditions suivantes :
1) Cet appareil ne doit pas provoquer
d’interférences et
2) Cet appareil doit accepter toutes les
interférences, y compris celles pouvant
entraîner son dysfonctionnement.
ICRadiationExposure
Statement:
This equipment complies with IC
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20 cm between the
radiator & your body.
NOTE: THE MANUFACTURER IS NOT
RESPONSIBLE FOR ANY RADIO OR
TV INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS
TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE
USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
Avisd’IndustrieCanada
surl’expositionaux
rayonnements
Cet appareil est conforme aux limites
d’exposition aux rayonnements d’Industrie
Canada pour un environnement non
contrôlé. Il doit être installé de façon
à garder une distance minimale de
20 centimètres entre la source de
rayonnements et votre corps.
REMARQUE : LE FABRICANT
N’EST PAS RESPONSABLE DES
INTERFÉRENCES
RADIOÉLECTRIQUES CAUSÉES
PAR DES MODIFICATIONS NON
AUTORISÉES APPORTÉES À
CET APPAREIL. DE TELLES
MODIFICATIONS POURRAIENT
ANNULER L’AUTORISATION
ACCORDÉE À L’UTILISATEUR DE
FAIRE FONCTIONNER L’APPAREIL.

13
SAFETYINSTRUCTIONS
Forproducthavingthe
wirelessfunctionusing
5GHzfrequencybands
Warning
i. the device for operation in the band
5150–5250 MHz is only for indoor
use to reduce the potential for harmful
interference to co-channel mobile satellite
systems;
ii. the maximum antenna gain permitted
for devices in the bands 5250–5350 MHz
and 5470–5725 MHz shall comply with
the e.i.r.p. limit; and
iii. the maximum antenna gain permitted
for devices in the band 5725–5825
MHz shall comply with the e.i.r.p. limits
specied for point-to-point and non point-
to-point operation as appropriate.
iv. High-power radars are allocated as
primary users (i.e. priority users) of the
bands 5250–5350 MHz and 5650–5850
MHz and that these radars could cause
interference and/or damage to LE-LAN
devices.
Avertissement
i. les dispositifs fonctionnant dans la
bande 5 150-5 250 MHz sont réservés
uniquement pour une utilisation à
l’intérieur an de réduire les risques de
brouillage préjudiciable aux systèmes
de satellites mobiles utilisant les mêmes
canaux;
ii. le gain maximal d’antenne permis pour
les dispositifs utilisant les bandes 5 250-
5 350 MHz et 5 470-5 725 MHz doit se
conformer à la limite de p.i.r.e.;
iii. le gain maximal d’antenne permis (pour
les dispositifs utilisant la bande 5 725-
5 825 MHz) doit se conformer à la limite
de p.i.r.e. spéciée pour l’exploitation
point à point et non point à point, selon
le cas.
iv. Radars de haute puissance sont
désignés utilisateurs principaux (c.-à-d.,
qu’ils ont la priorité) pour les bandes
5 250-5 350 MHz et 5 650-5 850 MHz
et que ces radars pourraient causer du
brouillage et/ou des dommages aux
dispositifs LAN-EL.
LGRecyclingPolicy
LG Electronics offers a customized
e-waste take-back & recycling service that
meets local needs and requirements in
the countries where e-waste regulations
are in place, and also provides product
and packaging take-back & recycling
service voluntarily in some countries.
LG Electronics evaluates products’
recyclability at the design step using
LG’s recyclability evaluation tool, with
the goal of improving recyclability where
practicable. Through these activities,
LG seeks to contribute to conserving
natural resources and protecting the
environment.
For more information about the LG
Recycling Policy, please visit our
global site at http://www.lg.com/global/
sustainability/environment/take-back-
recycling

14 CONTENTS
CONTENTS
LICENSE 2
SAFETYINSTRUCTIONS 3
PREPARATION 17
Accessories 17
OptionalAccessories 18
PartsandComponents 19
– Front 19
– Back 20
StatusIndicator 21
Installation 22
– Installation Precautions 22
– Projection Distance per
Screen Size 23
– Kensington Security System 24
MAGICREMOTECONTROL 25
– To Register the Magic Remote
Control 27
– To Re-register the Magic Remote
Control 27
– Using the Magic Remote Control 28
SETTINGUPTHETV 29
ConnectingtheAntennaorCable 29
WatchingLaserTV 30
– Initial Setup 30
– Watching with the TV 33
ToSetChannel 33
– To View Program Information 33
– To set favorite channels 34
– To use Favorite 34
AdditionalOptions 34
– Adjusting Aspect Ratio 34
– Using the Edge Adj Function 35
– Changing Input Device 37
– To Use SIMPLINK 38
UsingtheQuickMenu 40
ToSetSound 41
– To Set Sound Output 41
– To connect and use a Bluetooth
headset 43
– Using the Multi Audio 43
ENTERTAINMENT 44
ToUseSmartFeatures 44
– To Use Home Screen 44
– To Use MY APPS 45
– To Edit Items in MY APPS 45
ToConnectNetwork 46
– One-click Network Connection 46
– To Connect to a Network Through
Set Expert 46
– To Use the Wi-Fi Direct Function 46
– To Use the Miracast™/
Intel’s WiDi Function 47
– Tips for Network Settings 48
TagOn 49
– What is Tag On? 49
– To Start Tag On For the First Time 49
– To use the Tag On 50
SMARTSHARE 51
BeforeUsing 51
– Connecting a USB Device 51
– Removing a USB Device 51
TouseSmartShare™ 53
– Watching the Videos 54
– Viewing the Photos 56
– Listening to Music 57
– To Set SmartShare™ Related
Functions 58

15
CONTENTS
ToUsetheLGCloud 61
– What is LG Cloud? 61
– To Use LG Cloud 61
ToconnectDLNA 63
– To Connect a DLNA-authenticated
Smartphone 63
– To connect a DLNA DMR
(Digital Media Renderer) 63
– To connect a DLNA DMP
(Digital Media Player) 64
– SmartShare™ PC SW Installing
and Setting 64
– In Case of a DLNA Malfunction 65
ToUseAPremiumService 66
– To Use Paid Content 67
– To Reset Premium 67
TouseLGSmartWorld 68
ToUseSearchFunction 69
ToUsetheVoiceRecognition
Function 70
– Using this Function
Through Search 70
– Using this Function on the Internet 70
ToUseVoiceMateFunction 71
– What Is Voice Mate? 71
– How to Use Voice Mate? 72
– What Are Other Functions
of Voice Mate? 72
WhatIsOnNow? 73
– To Use On Now 73
ToUseInternet 75
FrequentlyAskedQuestionsfor
SmartLaserTV 76
USINGADVANCEDFUNCTIONS 80
ToUseScreenRemote 80
– To Use Screen Remote 80
– To Control a Device Connected
to the Porjector Using the Screen
Remote 80
ToUsetheUniversalControl
function 81
ToControlaLaserTVUsing
aSmartphone 82
ToUseaUSBInputDeviceOn
aLaserTV 83
– To Use a USB Wired/wireless
Mouse 83
– To Use a USB Wired/wireless
Keyboard 83
CUSTOMIZINGSETTINGS 84
SETTINGS 84
PICTURESettings 85
SOUNDSettings 90
CHANNELSettings 93
TIMESettings 94
LOCKSettings 95
OPTIONSettings 97
NETWORKSettings 103
SUPPORT 104
CONNECTINGDEVICES 105
ConnectinganHDReceiver,
DVDPlayer,orVCR 106
– HDMI connection 106
– HDMI to DVI Connection 107
ConnectingExternalDevices 108
– AV Connection 108
– Component Connection 108
ConnectingaPC 109
– HDMI Connection 109

16 CONTENTS
ConnectingHeadphones 110
ConnectingaLaptop 111
– HDMI connection 111
ConnectingaDigitalAmp 112
UsingtheMirroringFunctionof
aMobilePhone 113
– MHL Connection 113
SERIALCOMMUNICATION
FUNCTION 114
UsingSerialCommunication 114
EstablishingSerial
Communication 114
CommunicationProtocol 115
KeyCode 122
MAINTENANCE 123
Cleaning 123
– Cleaning Cover Glass 123
– Cleaning the Laser TV Case 123
INFORMATION 124
ToupdateLaserTVsoftware 124
Beforereportingaproblem,
checkthefollowing: 125
– General 125
– Picture 125
– Sound 126
– PC connection problem 127
– Problems replaying movies in My
Media 128
SPECIFICATIONS 129

17
PREPARATION
PREPARATION
Accessories
Check the accessories provided with the product.
The picture may be different from the actual product.
Accessories are subject to change without prior notice in order to improve the performance
of the product. New accessories may be added or old ones may be removed.
CH
VOL
BACK SMART
/Q.MENU
Tag On
Magic Remote Control
Two AA Batteries Tag On User Guide
Owner’s Manual CD Power Cord Polishing Cloth
Ez Bracket (AJ-BB105)
• When connecting an HDMI or USB cable, or
connecting a USB flash drive to the HDMI or USB port,
use a product that has a width of 24 mm or less and a
height of 10 mm or less. If the USB cable or USB flash
drive does not fit the USB ports of the Laser TV, use
an extension cable that supports USB 2.0.
A10 mm B24 mm
• Use a certified cable with the HDMI logo attached.
• If you do not use a certified HDMI cable, the screen may not display or a connection
error may occur. (Recommended HDMI cable types)
– High-Speed HDMI
®
/
TM
Cable
– High-Speed HDMI
®
/
TM
Cable with Ethernet

18 PREPARATION
OptionalAccessories
To purchase optional accessories, visit an electronics store or an online shopping site.
Optional extras are subject to change without prior notice in order to improve the product
quality, and new optional accessories may be added.
Video Cable Audio Cable HDMI Cable
Optical Cable PC Audio Port
Connection Cable
Cables for Connecting
External Devices
Ceiling Bracket
(AJ-CB100) Sound Bar MHL Cable
Laser TV Projection
Screen (SC200)

19
PREPARATION
PartsandComponents
• This Laser TV is manufactured using high-precision technology. You may, however,
see tiny black dots and/or bright spots that continuously appear on the screen. This is a
normal result of the manufacturing process and does not indicate a malfunction.
• Ceiling light glare depends on the light levels in a room and the distance between the
product and the ceiling. It is not a product defect.
Front
Control Panel
Vent
1
Vent
1
Electric Door
Speaker
USB IN 2 Port
Remote control
sensor
Button Description
Changes the channel or sets the features.
Adjusts the volume level, or enters a sub menu and changes the
settings.
Shows the current mode and saves changes to the settings.
Displays or closes the Settings menu.
Changes the input source.
Turns the the Laser TV on or off.
• Press the “USB IN 2” label shown in the figure above to make the USB IN 2 port
visible.
NOTE

20 PREPARATION
Back
RS-232C IN
1
2
3 4 5 6 7
8 9
Description
1
COMPONENT IN Port
2
USB IN 1 Port
3
H/P OUT Port
4
AV IN Port
5
ANTENNA/CABLE IN Port
6
HDMI IN 1 (ARC), 2 (PC), 3 (MHL) Port
7
LAN Port
8
OPTICAL DIGITAL AUDIO OUT Port
In standby mode, digital audio is not output.
9
RS-232C IN Port
