LG GCW1069CS User manual

WaveRider Installation
INTERNAL MOUNTING
www.heartlandMicroPayments.com 2115 Chapman Road, Suite 159, Chattanooga TN 37421 800.332.4835
SINGLE MACHINE
CARD ONLY

2
www.heartlandMicroPayments.com
Laundry Machine Model Numbers
This document applies to the WaveReader installation process
following LG model numbers:
If you cannot locate the model number of the machine you require in the
lists above, please contact MicroPayments Customer Service at:
Tel: [phone] Press 2
Washers
GCW1069CS
Dryers
GD1329CES

3
www.heartlandMicroPayments.com
The tools required for the installation process are as follows:
Required Tools &
Installation Kit Contents
#T-20 Pin-in-Star Torx Driver
Phillips Head Screwdriver (medium)
Small Flat-Head Screwdriver
11/32” Ratchet or Nut Driver
Item
Qty
Part Number
Description
1
1
WLAU-NNNNNN
WaveReader
WaveReader
1
This following tables list the required components for the installation process. If
you cannot locate and/or identify any of the components listed above, please
contact MicroPayments Customer Service at 800-332-4835 , then press 2.

4
www.heartlandMicroPayments.com
Interface Harness
1
2
KIT-HRN-050-6-008
Harness Kit for LG –Card Only
Item
Qty
Part Number
Description
1
1
ASM-050-6-008
LG Card Only Interface Cable
2
1
AYS-050-6-008
Cable, Service Mode Switch - LG
KIT-050-6-008
Bracket Kit for WaveReader Surface Mount
Item
Qty
Part Number
Description
1
1
MFP-050-6-017-001
Bracket –LG Wave
2
4
NUT-8X32SHKEP
Nut, 8x32, Steel, Hex KEP (not pictured)
3
2
SRW-632X..312FMC
Screw 632x.312 FH PHIL M100 (not pictured)
Internal Mounting Trim Plate Kit
1

5
!! WARNING !!
MAKE SURE THAT ALL POWER HAS BEEN REMOVED FROM
THE MACHINE BEFORE ATTEMPTING TO INSTALL ANY
HARDWARE OR CABLING!
1
Preparation
Disconnect the laundry machine from all power sources
before performing any of the following steps.
Only perform the following steps after the WaveReader
has been physically installed in the machine.
www.heartlandMicroPayments.com
Carefully remove card label decal using
small flat head screw driver.
Discard Decal.
5
www.heartlandMicroPayments.com

6
Installation
www.heartlandMicroPayments.com
3
2Pull out and up on the
dispenser drawer, detaching
it from the machine.
Locate the two Pin-In-Star
security screws, one on
each side of the control
panel. Use the T20 Security
Pin-In-Star Driver. Set the
screws aside keeping them
close at hand.
4Insert the WaveReader card guide through the LG
Bracket Adapter. Using the provided 6-32 Flat Head
Phillips Machine Screws attach the LG Bracket Adapter
onto the rear of the WaveReader in the 4 tapped holes.

7
Installation
Locate the ribbon cable
connector on the Circuit
Board at the rear of the
WaveReader. Using your
thumb nails and placing
them on the wings of the
small tabs, pull the slide
downward as shown
www.heartlandMicroPayments.com
5
6
7
Gently pull the white
ribbon cable out of the
connector.
Please be careful to pull
the ribbon cable from the
direction shown.
Using a small screwdriver,
remove the 2 Phillips head
machine screws from the
Circuit Board.
Make sure to keep track of
them.

8
Installation
8
www.heartlandMicroPayments.com
9
10
Detach the Circuit Board
from the WaveReader.
Keep it close by, as you
will need it soon.
Detach the control panel
from the machine and flip
downward as show, exposing
the controller box and wiring
harness.
With the WaveReader
attached to the LG Adapter
Bracket and the Circuit Board
Removed, slide the card
guide and ribbon cable
through the front of the
control panel as shown.

12
13
9
Installation
11
www.heartlandMicroPayments.com
Using the provided 8x32 Locking
Nuts, bolt in the Adapter
Bracket to the Control Panel.
Reattach the Circuit Board to the
Card Guide using a small Phillips
head screw driver.
Slide the Ribbon Cable into the
ribbon connector slot located on
the Circuit Board. Using your
thumb nail, lock the slide back into
place by pushing it back in the
direction of the arrow.
14 Check to see that the ribbon cable
is secured evenly and not at an
angle as not to cross connections
and short out a wire.

16
10
Installation
15
www.heartlandMicroPayments.com
17
With the Control Panel flipped
down, locate the white controller
box. On the controller box will be
4 Phillips head machine screws
located 2 to each side. Remove
the screws from the unit and
set aside for re-installation
Flip the
controller
box cover
over as
shown.
Looking down on top of
the LG Controller board,
in the bottom left hand
corner find the
connector labeled
“ESUDS OUT PIN2.”
Using the WaveReader Interface Cable, locate the connector with four wires attached:
brown, orange, yellow, and white. Plug the connector into “ESUDS OUT PIN2.”
