LG F1443KD User manual

WASHING MACHINE
SERVICE MANUAL
CAUTION
READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS
CORRECTLY BEFORE OFFERING SERVICE.
BEFORE SERVICING WASHING MACHINE, UNPLUG THE POWER CORD
TO AVOID THE RISK OF ELECTRICAL SHOCK.
WHEN SERVICING INTERNAL PARTS, USE ONLY SERVICE PARTS
SUPPLIED FROM LG.
AFTER SERVICING THE ELECTRICAL WIRE, INSURE THAT INSULATION
TAPE IS APPLIED TO PREVENT ELECTRICAL SHORTAGE.
MODEL : WD14060D6
website : http://biz.lgservice.com
e-mail : http://LGEservice.com/techsup.html

2
CONTENTS
1. SPECIFICATIONS ............................................................................................................................. 3
2. FEATURES & TECHNICAL EXPLANATION ..................................................................................... 4
3. PARTS IDENTIFICATION ................................................................................................................. 6
4. INSTALLATION .................................................................................................................................. 7
5. OPERATION ................................................................................................................................... 13
6. WIRING DIAGRAM / PCB LAYOUT / PROGRAM CHART ............................................................ 15
7. TROUBLESHOOTING......................................................................................................................19
7-1.BEFORE SVC CHECKING ...................................................................................................... 19
7-2.LOAD TEST MODE .................................................................................................................. 19
7-3.HOW TO CHECK THE WATER LEVEL FREQUENCY ............................................................ 20
7-4.
HOW TO CHECK THE TEMPERATURE OF EACH THERMISTOR AT OPERATING CONDITION 20
7-5.HOW TO CHECK THE VIBRATION SENSOR ......................................................................... 21
7-6.ERROR DISPLAY ..................................................................................................................... 22
7-7 TROUBLESHOOTING WITH ERROR CODES ....................................................................... 24
• IE (Water Inlet Error) .............................................................................................................. 24
• UE (Unbalance Error) ............................................................................................................. 25
• OE (Water Outlet Error) .......................................................................................................... 26
• FE (Over Flow Error) .............................................................................................................. 28
• PE (Pressure Sensor Error) ...................................................................................................29
• dE (Door open Error) .............................................................................................................. 30
• tE (Thermistor (Heating) Error) ............................................................................................... 31
• LE (Motor Locked Error) ......................................................................................................... 32
• AE (Water leakage) ................................................................................................................ 33
8. TROUBLESHOOTING WITHOUT ERROR CODES ...................................................................... 34
• No Power ................................................................................................................................ 34
• Vibration & Noise During spin ................................................................................................35
• Detergent & Softener does not flow in .................................................................................... 36
• Water Leak ............................................................................................................................. 37
9. PART INSPECTION ........................................................................................................................ 39
9-1 FILTER ASSEMBLY(LINE FILTER) .......................................................................................... 39
9-2 DOOR LOCK SWITCH ASSEMBLY.......................................................................................... 40
9-3 STATOR ASSEMBLY ................................................................................................................ 42
9-4 PUMP MOTOR ASSEMBLY...................................................................................................... 45
9-5 INLET VALVE ASSEMBLY ........................................................................................................ 46
10. DISASSEMBLY INSTRUCTIONS ................................................................................................. 47
11. EXPLODED VIEW AND PART LIST ............................................................................................. 61

3
1. SPECIFICATION
ITEM
POWER SUPPLY
PRODUCT WEIGHT
OPERATION WATER PRESSURE
CONTROL TYPE
WASH CAPACITY
DIMENSION
WASH PROGRAM
RINSE
DOOR SWITCH TYPE
WATER LEVEL
RESERVATION
SENSING LAUNDRY AMOUNT
FUZZY LOGIC
DISPLAY REMAINING TIME
ERROR DIAGNOSIS
POWER AUTO OFF
CHILD LOCK
AUTO RESTART
TIME SAVE
ELECTRICITY
CONSUMPTION
WASHING
SPIN
DRAIN MOTOR
STEAM HEATER
WASH HEATER
REVOLUTION
SPEED
WASH
SPIN No Spin/400/600/800/1000/1200/1400
46rpm
100 ~ 600 kPa (1.0 kgf/cm2
~ 6.0 kgf/cm
2
)
Electronic
Refer to the Rating Label
600mm(W)x640mm(D)x850mm(H)
Cotton, Cotton Eco, Mix, Easy Care Duvet, Allergy Care,
Refresh, Sports Wear, Dark Wash, Delicate, Wool,
Intensive 60, Quick 30, Silent Wash
Normal, Rinse
+, Rinse ++, Rinse ++Hold, Normal+Hold
PTC+Solenoid
10 steps (by sensor)
From 3 hours to 19 hours
Adapted
Adapted
Adapted
8 items
Adapted
Adapted
Adapted
Adapted
190W
380W
30W
1200W
2120W
240V~, 50Hz
WD14060D6
70kg
To reduce the risk of personal injury, adhere to all industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
Failure to follow all of the safety warnings in this manual could result in property damage, personal
injury or death.
WARNING

4
ITEM F1443KD(1~9)
POWER SUPPLY
PRODUCT WEIGHT
OPERATION WATER PRESSURE
CONTROL TYPE
WASH CAPACITY
DIMENSION
WASH PROGRAM
RINSE
DOOR SWITCH TYPE
WATER LEVEL
RESERVATION
SENSING LAUNDRY AMOUNT
FUZZY LOGIC
DISPLAY REMAINING TIME
ERROR DIAGNOSIS
POWER AUTO OFF
CHILD LOCK
AUTO RESTART
TIME SAVE
ELECTRICITY
CONSUMPTION
WASHING
SPIN
DRAIN MOTOR
STEAM HEATER
WASH HEATER
REVOLUTION
SPEED
WASH
SPIN
F1443KD(1~9) No Spin/400/600/800/1000/1200/1400
46rpm
100 ~ 1000 kPa (1.0 kgf/cm2~ 10.0 kgf/cm2)
Electronic
Refer to the Rating Label
600mm(W)x640mm(D)x850mm(H)
Cotton, Cotton Eco, Mix, Easy Care Duvet, Baby Care,
Skin Care, Sports Wear, Dark Wash, Delicate, Wool,
Intensive 60, Quick 30, Silent Wash
Normal, Rinse+, Rinse++, Rinse++Hold, Normal+Hold
PTC+Solenoid
10 steps (by sensor)
From 3 hours to 19 hours
Adapted
Adapted
Adapted
8 items
Adapted
Adapted
Adapted
Adapted
190W
380W
30W
1200W
2120W
220V-240V~, 50Hz
70kg
To reduce the risk of personal injury, adhere to all industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
Failure to follow all of the safety warnings in this manual could result in property damage, personal
injury or death.
WARNING

5
2. FEATURES & TECHNICAL EXPLANATION
2-1. FEATURES
Direct Drive System
The advanced Brushless DC motor directly drives the drum without belt and pulley.
Water Circulation
The detergent water from the drum is sprayed directly over the load ;
this enables the clothes to get soaked more quickly during the cycle.
The detergent suds can be removed more easily by the water shower during rinse cycle.
The water circulation system uses both water and detergent more efficiently.
Built-in Heater
Internal heater automatically heats the water to the best temperature on selected cycles.
Child Lock
The Child lock prevents children from pressing any Buttons to change the settings during
operation.
More economical by Intelligent Wash System
Intelligent Wash System detects the amount of load and water temperature, and then
determines the optimum water level and washing time to minimize energy and water
consumption.
Low noise speed control system
By sensing the amount of load and balance, it evenly distributes load to minimize the
spinning noise level.
Safety device (Aqua lock)
Aqua lock System is designed for detecting water leakage during operation to prevent
water from spilling on the floor.
Steam Washing and Refresh
Steam Washing features upgraded washing performance with low energy consumption.
Refresh cycle reduces wrinkles from dry clothes.

6
2-2. DETERMINE WASHING TIME BY FUZZY LOGIC
To get the best washing performance optimal time is determined by sensing the water
temperature, selected washing temperature and laundry amount.
2-3. WATER LEVEL CONTROL
This model adopts a pressure sensor which can sense the water level in the tub.
Water supply is stopped when the water level reach the preset level, then washing program proceeds.
Spinning does not proceed until the water in the tub reduces to a certain level.
water
temperature
washing time
rinse time
the best
washing
performance
spin rhythm, time
laundry
amount
FUZZY
LOGIC
selected
washing
temperature
SENSING EFFECT PROCESSING DETERMINATION
2-4. THE DOOR CAN NOT BE OPENED
While program is operating.
While Door Lock light is on.

7
3. PARTS IDENTIFICATION
Drawer
Drum
Door
Drain Hose
Adjustable Feet
Transit Bolts
Control Panel
Power plug
Drain Pump Filter
Drain Plug
Lower Cover Cap
If the supply cord is damaged,
it must be replaced by the
manufacturer or its authorized
service technician in order to
avoid a hazard.
ACCESSORIES
Inlet hose(1EA) Option : Hot / Cold(2EA) Spanner

8
4. INSTALLATION
INSTALLATION
The appliance should be installed as follows.
Check the conditions of installation area.
1. Check level ground.
On raised foundations or upper level homes, the vibrations can be caused by the type of flooring.
It may be necessary to move the machine to a different area in the home or have the floor
reinforced to properly support the operation of the unit.
2. Check for humidity or any foreign objects under the feet.
Clean the floor, there should be no foreign objects under the feet.
If the unit has foreign objects underneath the feet, this will prevent the unit from being leveled properly
and will cause vibrations and slipping.
Remove any foreign objects, if any from underneath the machine and level unit properly.
See below for examples of foreign objects.
1
Open the box and check appliance condition.
2
horizontal
Carpet Paper Laminated
paper
Purchased
stopper
Base Packing
Washer
Spanner
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and
drain hose.
4. Remove the inlet hose from the drum.
Keep the spanner provided for future use.

9
Use spanner to remove transit bolts.
3
Check the distance between the appliance and the wall.
4
The tap connection and hose connection must be parallel.
5
Transit bolts
More than 2cm If the distance is less than 2cm,
the water supply hose will be
kinked or folded.
Unscrew
1. Unscrew the adapter ring plate and the 4 adapter retaining screws.
2. Push the adapter onto the end of the tap so that the rubber seal forms
a watertight connection. Tighten the adapter ring plate and the 4
screws.
3. Push the water supply hose vertically upwards so that the rubber
packing within in the hose can adhere completely to the tap and then
tighten it by screwing it to the right.
• Water supply pressure must be between 100 kPa and 1000 kPa (1.0 ~ 10.0 kgf / cm
2
)
• Do not strip or crossthread when connecting Inlet hose to the valve.
• If the water supply pressure is more than 1000 kPa, a decompression device should be installed.
• Periodically check the condition of the hose and replace the hose if necessary.
Type-A : Connecting Screw-type hose to tap with thread
• Screw the hose connector onto water supply tap.
■Connecting water supply hose
Step1 : Check rubber seal inlet hose
Step2 : Connect hose to water tap
• Two rubber seals are supplied with the water inlet hoses.
They are used for preventing water leaks. Make sure the connection to
taps are sufficiently tight.
Upper
connector Rubber
packing
Plate
Water supply
hose
Fixing screw
Hose
connector
Rubber
seal
Type-B : Connecting Screw-type hose to tap without thread
1. Unscrew the 3 bolts with the spanner supplied.
2. Take out the 3 bolts along with the rubber bungs by slightly
twisting the bung.
3. Close the holes with the caps supplied.
Keep the transit bolts for future use.

10
Please use the horizontal tap
Horizontal tap Extension tap Square tap
1. Unscrew the adapter ring plate and the 4 adapter retaining
screws.
2. Remove the guide plate if the tap is too large to fit the
adapter.
3. Push the adapter onto the end of the tap so that the rubber
seal forms a watertight connection.
Tighten the adapter ring plate and the 4 screws.
4. Pull the connector latch plate down, push the inlet hose onto
the adapter, and release the connector latch plate.
Make sure the adapter locks into place.
After completing connection, if water leaks from the hose, repeat the same steps.
Use the most conventional type of faucet for water supply. In case the faucet is square or too big, remove the
spacing ring before inserting the faucet into the adaptor.
Ring plate
Guide plate
Latch plate
Type-C : Connecting one touch type hose to tap without thread
Step3: Connect hose to washer
• Make sure that there are no kinks in the hose and that they are not
crushed.
When your washer has two valves.
• The Inlet hose With the red connector is for the hot water tap.
• If the washer has two valves, energy is saved by using the hot valve.
After connecting inlet hose to water tap, turn on the
water taps to flush out foreign substances (dirt, sand or
sawdust) in the water lines. Let water drain into a
bucket, and check the water temperature.

11
Connect Drain Hose.
6
Connect power plug.
7
If the drain hose is not installed properly, the unit will not drain properly.
This allows water to back flow into the unit which can cause odors.
Refer to Owner Manual for proper drain hose installation.
The odor could also be coming from the home’s drain to which the drain hose is attached.
In this type of drain hose installation, the odor could be coming from the standpipe.
This odor can come up the drain hose and into the unit.
Pour a cup or two of bleach or vinegar down the home drain
and let it sit for 24 hours before running another cycle.
This will help eliminate odor from the home drain.
If a cycle is started too soon after doing this, it will not help the issue.
Connect the power plug to the wall outlet. Avoid connecting several electric devices,
it may be the cause of a fire.
about 100 cm
about 145 cm
about 105 cm
Laundry tub
Max. 100cm
min. 60cm
Max. 100cm
min. 60cm
Retainer
Tie
strap
Hose
min. 60 cm
max. 100 cm

12
Rubber Cup
Check the horizontality with a level (Gage).
8
Step 1
If washing machine legs are loose or not Screwed in, then tighten with the spanner wrench.
Using the level, level the washing machine from front to back and side to side.
Step 2
Use the spanner wrench to adjust Legs until level and try the Diagonal test.
Step 3
Perform a Rinse and Spin with some clothing in the machine.
To do this, put 2~3kg of clothing in the unit, turn on the unit, Select the Rinse+Spin
and then start. When the unit reaches the spin cycle, watch for vibrations.
If the unit is vibrating, make small adjustments to the leg until they subside. (Repeat step 2)
Step 4
Tighten the lock nut against the base of the machine to lock the position leg.
Lower the foot until there is no gap between floor and foot.
And only use adjustment rubber when difference at the leg adjustment is more than 10mm.
Place your right hand on the back, right corner and your left hand on the front,
left corner of the unit, then attempt to rock the unit from corner to corner.
Then, move your right hand to the front, right side and your left hand to the
back, left corner and attempt to rock the unit from corner to corner.
If the unit is level, it will not rock. However, if the unit is not level, it will rock.
If the unit rocks, it will be necessary to adjust the leveling feet of the unit.
Adjust the foot under the hand that is on the front of the machine.
How to perform a diagonal test:
A level
Higher
Tighten
Adjustable feet
Diagonal test
Tighten
Adjustable feet
Higher
Tighten
Adjustable feet
Lower
4620ER4002B
(Gray)
for Wooden floors
Rubber Cup
4620ER4002A
(Black)
for Tile floors
Lock nut
10mm
Adjustable bolt
Tighen the lock nut
Floor
No Gap
Floor
No Gap
Floor
Gap

13
Test operation
9
1Preparation
for
washing.
·Connect the power plug to the
outlet.
·Connect the inlet hose.
2Press the power button. 3Press the START/PAUSE
button.
6Check the water heating.
·Press the left Option + temp
button simultaneously and the
present temperature will be
displayed. Page 20
·Check if the drum rotates
clockwise and counterclockwise.
5
Check automatic reverse turn.
4Check the water supply.
·Check if water is supplied through
the detergent dispenser.
7Check the drain and spin
functions.
·Turn power off and then power on.
·Select the spin rpm
·Press the START PAUSE button.
·Check the spin and drain
functions.
·Turn power off and then power on.
·Listen for a click to determine if the
door is unlocking.
8Turn power off and open
the door.
9Water removal.
·If SVC is needed during check,
remove the remaining water by
pulling out the hose cap.
·In case of Coloreds program.

14
Use this button to turn the
power On/Off.
Rotate the Cycle selector
knob to select the cycle
designed for different
types of fabric and soil
levels.
Use this button to Start/
Stop the washer.
Time Delay : Allows the start of any cycle to be delayed
for 3~19 hours.
Steam Wash : By pressing the Steam Wash button, if Steam
Function is selected, the Steam Wash button will light up.
Favorite : Favorite program allows you to store a
customized wash cycle for future use.
Pre Wash : Use this option for load that needs protreatment.
Adds 17minutes pre wash and drain.
Medic Rinse : For best results or for cleaner rinsing, you can choose
Medic Rinse option
Rinse + Spin : This can be Helpful in preventing fresh stains from setting
in fabrics.
Time Save : This option can be used to reduce the time of a wash program.
To use this option press option button before wash program is started.
Intensive : If the laundry is heavily Soiled, ìIntensiveî option is effective.
Cycle Selector Additional programs
Power
Start/Pause Option Button
5. OPERATION (F1443KDS / F1243KDS(1~9))

15
Use this option to prevent unwanted
use of the washer. Press and hold
Option left and right button for 3 seconds
to lock/unlock control.
When Child lock is set, CHILD LOCK
lights and all buttons are disabled
except the Power button. You can
lock the washer while it is operating.
The Beep on/off function can be set by pressing
and holding the Option and Rinse button
simultaneouly.
Select a water temperature based
on the type of load you are
washing.
By pressing the Rinse button, the
Rinse type can be selected.
This display shows:
a) the estimated time remaining in the
cycle when operating.
To change the spin speed, turn the
Spin knob to cycle through available
options.
Child Lock
EST. T ime remaining
Spin Selector knob
Tub Clean course can be set by
pressing and holding Rinse and
Te mp button simultaneously.
Tub Clean is a special cycle to
clean the inside of the washer.
Tub Clean
Beep on/off
Rinse, Temp. Button
In case of abormal operation, error
indications are displayed.
(
)
• See troubleshooting
ting
am.
e.

16
Use this button to turn the
power  .
Rotate the  
 to select the cycle
designed for different
types of fabric and soil
levels.
Use this button to Start/
Stop the washer.
Time Delay : Allows the start of any cycle to be delayed
for 3~19 hours.
Crease Care : If you want to prevent creasing, select Crease
Care option.
Favorite : Favorite program allows you to store a
customized wash cycle for future use.
Pre Wash : Use this option for load that needs protreatment.
Adds 17minutes pre wash and drain.
Medic Rinse : For best results or for cleaner rinsing, you can choose
Medic Rinse option
Rinse + Spin : This can be Helpful in preventing fresh stains from setting
in fabrics.
Time Save : This option can be used to reduce the time of a wash program.
To use this option press option button before wash program is started.
Intensive : If the laundry is heavily Soiled, Intensive option is effective.
Cycle Selector Additional programs
Power
Start/Pause
Option Button

17
Use this option to prevent unwanted
use of the washer. Press and hold
Option left and right button for 3 seconds
to lock/unlock control.
When Child lock is set, CHI D OCK
lights and all buttons are disabled
except the Power button. You can
lock the washer while it is operating.
The Beep on/off function can be set by pressing
and holding the Option and Rinse button
simultaneouly.
Select a water temperature based
on the type of load you are
washing.
By pressing the Rinse button, the
Rinse type can be selected.
This display shows:
a) the estimated time remaining in the
cycle when operating.
To change the spin speed, turn the
Spin knob to cycle through available
options.
Child Lock
EST. T ime remaining
Spin Selector knob
Tub Clean course can be set by
pressing and holding Rinse and
Temp button simultaneously.
Tub Clean is a special cycle to
clean the inside of the washer.
Tub Clean
Beep on/off
Rinse, Temp. Button
In case of abormal operation, error
indications are displayed.
(
)
¥ See troubleshooting
ting
am.
e.

18
6. WIRING DIAGRAM / PCB LAYOUT / PROGRAM CHART
(Option)
(Option)
Wiring Diagram 1/3
(Option)
(Option)
(Option)
(Option)
Full Wiring Diagram
1/3 2/3 3/3

19
Wiring Diagram 2/3
(Option)
(Option)

20
Wiring Diagram 3/3
