LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 1 of 46
L
LW W2 21 10 00 0A AP P
U
Us se er r’ ’s s M Ma an nu ua al l

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 2 of 46
Contents
Chapter 1 Overview of the system.......................................................................................... 4
1.1 Introduction......................................................................................................................... 4
1.1.1. Specification ............................................................................................................................... 5
1.1.2. Appearance.................................................................................................................................. 6
1.1.3. Components................................................................................................................................ 8
1.2. Hardware Installation............................................................................................... 9
1.3. Network Setting for PC..........................................................................................11
Chapter 2 WEB Server Manual........................................................................................ 14
2.1 Execution of WEB Server and AP connection to WEB
Server............................................................................................................................................... 14
2.2. Menu description of WEB Server............................................................... 16
2.2.1. Basic configuration Menu......................................................................................................... 16
2.2.2. 802.11b Menu ........................................................................................................................... 20
2.2.3. RADIUS Server Menu.............................................................................................................. 23
2.2.4. DHCP/NAT Server Menu ...................................................................................................... 25
2.2.5. SNMP Server Menu............................................................................................................... 27
2.2.6. DMZ Server Menu................................................................................................................. 29
2.2.7. MAC Filter Menu ..................................................................................................................... 30
2.2.8. IP Filter Menu........................................................................................................................... 32
2.2.9 Advanced Menu...................................................................................................................... 34
2.2.10. Save Menu .............................................................................................................................. 36
2.2.11. Reboot Menu........................................................................................................................... 37
2.2.12. Upgrade Menu ........................................................................................................................ 38
2.2.13. Default Value Menu................................................................................................................ 39
Chapter 3 Console Window Manual.................................................................................. 40
3.1. Connecting Console Window......................................................................... 40
3.2. Setting Configuration Elements.................................................................. 43

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 3 of 46
All the contents described in the document may not be used without written permission of LG
Electronics Inc., Ltd.
This user manual may be changed without notification as function and specification of
LW2100AP have changed, and the changed contents can be free downloaded when you visit
our LG Electronics homepage(http://www.lgnetwork.com/)
The intellectual rights of this user manual belong to LG Electronics Inc., Ltd.
Microsoft, Windows, Windows95, Windows98, Windows ME, Windows 2000 and Windows NT
are trademarks of Microsoft Corporation.
Other company names or products stated in this user manual may be trademarks of each
company or owner.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 4 of 46
Chapter 1 Overview of the system
1.1 Introduction
The LW2100AP delivers the freedom to configure the network without wire and functions as an
IEEE 802.3 Ethernet-based Residential Gateway. It provides 10/100 Dual Speed Ethernet port
for a DSL Modem, Cable Modem, or other Broadband access device and one 10M Ethernet port
for connection to a home or small office network.
LW2100AP can forward all packet between local and Internet such as ICMP, FTP, Real Audio,
Quake, H.225 packet. Also support virtual server(DMZ server) that forward incoming packet to
specified LAN host system.
LW2100AP supports DHCP server to setup network configuration for each local PC dynamically.
LW2100AP use graphical user interface(web-browser) to setup, check system status, change
password, and upgrade system image.
The LW2100AP has one local 10Mbps Ethernet port and one 10/100Mbps Dual Speed Ethernet
global port. The local port can be connected directly to a single computer or it can be
connected to an Ethernet hub or switch to provide Internet Sharing and Firewall protection to a
local area network. The global port can be connected to any Cable, DSL, or Broadband modem
with an Ethernet port.
Unlike proxy server or NAT software that requires the software server to remain visible on the
Internet, no local computers are directly and externally visible when using the LW2100AP.
Integrated DHCP services allow up to 63 users to get their IP address automatically on boot up
from the LW2100AP.
The LW2100AP can be set to allow separate FTP, Web, and Multiplayer game servers to share
the same Internet-visible IP address while still protecting the servers and local users from
hackers.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 6 of 46
1.1.2. Appearance
 Front view
There are LEDs with the system to indicate the operation status of the system and
port status.
POWER : The LED turns on as the power applies to the system.
LAN1 : The LED is on while the LAN1 connection is active.
The LED is blinking while the system receives packets via this port.
LAN2 : The LED is on while the LAN2 connection is active.
The LED is blinking while the system receives packets via this port.
AIR1/AIR2 : The LED turns on while the default/optional wireless connection is active..
The LED is blinking while the system receives packets via this air link.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 7 of 46
• Rear view
The system is equipped with LAN1 port and LAN2 port for Ethernet interface,
RJ-11 console port for management.
LAN1 : Global Port, RJ-45
10/100Mbps Ethernet to an external Cable/DSL Modem or LAN Switch/Hub
LAN2 : Local Port, RJ-45, 10Mbps Ethernet
Console : connection to PC COM port.
DC5V : connect the power adapter.
Antenna1 : Dipole Antenna
Antenna2(Optional) : Dipole Antenna

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 8 of 46
1.1.3. Components
Item Included in
Standard package
Description Purpose
Console cable Connects from console port of
LW2100AP to RS232C Port on PC
Power adapter Connects from LW2100AP to power
source
LW2100AP Main Unit
Antenna
Manuals User’s Guide

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 9 of 46
1.2. Hardware Installation
The configuration information of connected AP is displayed.`
1. Choose the place with the consideration of power outlet and network connection to install
LW2100AP.
2. Use a UTP Ethernet Straight-though cable to connect the DSL/Cable Modem to the
LAN1(Global) port.
3. Use a UTP Ethernet Straight-though Cable to connect the LAN2(Local) port to a free port on
your hub or switch OR Use a Cross-Over cable to connect directly to a PC.
4. Connect the PowerAdapter to the DC 5V port on the LW2100AP and into a wall outlet.
LW2100AP
HUB
Internet
ADSL Modem
or Cable Modem
or Uplink HUB

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 10 of 46
5. onsole cable connection
Using the Console cable included in the package, connect a Serial port of the administrator
computer to the Console port of LW2100AP. One end of the console cable with the RJ45
connector is connected to the console port on the back panel of the system and the other
end is connected to the 9-pin serial port of a RS-232 based terminal such as workstation, PC
or notebook as shown in the following figure. Then, fix the cable to the AP using the screws
hanging on both sides of the connector.
RouterConsole Port
Terminal port (male)

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 11 of 46
1.3. Network Setting for PC
Client machines(PC) require no software, simply set them to accept a dynamically assigned IP
address and reboot. Each time they are powered up the LW2100AP will recognize them and
set their IP address to instantly connect them to the LAN.
If you want to use an assigned (static) IP address, you can select “Specify an IP address” in
“TCP/IP Properties” window.
 How to Set DHCP Client (in Win98)
a. Select Control Panel(Network('TCP/IP' (TCP/IP is only for LGE card). Then the
“TCP/IP Properties” window will be brought to the screen. Click the “IP
Address” tab in the “TCP/IP Properties” window. Select “Obtain an IP address
automatically”. Then reboot the system.
Go into the DOS window to check whether the IP address is normally assigned after the
system reboots. Then execute the command of winipcfg.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 12 of 46
Click the “More Info” button in the “IP Configuration” window as above to view information on IP
Configuration of LGE Wireless LAN Card. Below is the window displayed when you click the
“More Info” button.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 13 of 46
Above is the window to show information on IP Address and Subnet Mask assigned by
AP, Default Gateway, DHCP Server, IP Address use time, etc. To be assigned a new IP
Address, click the “Release All” button followed by “Renew All”. The existing IP
address can be re-assigned. In case the existing IP address is already assigned to
another user, you may be re-assigned a different user’s IP address
LGE

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 14 of 46
Chapter 2 WEB Server Manual
2.1 Execution of WEB Server and AP connection to WEB Server
This chapter explains how to connect the LW2100AP to the Internet using Web-based
management tool.
The first step is to execute the Internet browser directly and to enter the IP address of an AP to
connect. At this time, it is possible only if the IP address of an AP to connect is already known.
The default IP address of an AP in factory shipment is 10.0.0.1
The AP connection to WEB Server is available for a PC that can execute the Internet browser
and connect with the Internet. If the AP connection to WEB Server operates normally, a window
indicating to input the password of connected AP is open.
The default value of the username and the password is “root”, “lw2100ap” respectively.
If the password is correctly entered, the initial Home screen displays as follows.
At this time, the access to WEB Server is available.
* The Web-based management system is fully compatible with Microsoft Internet Explorer
versions 4.0 or later and Netscape Communicator versions 4.0 or later. Earlier versions of these
browsers cannot use all features of the management system.
10.0.0.1

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 15 of 46
Navigation buttons appear at the left of the page.
You use the navigation buttons to display other management pages

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 16 of 46
2.2. Menu description of WEB Server
2.2.1. Basic configuration Menu
The Basic configuration Menu displays the Vendor Name, AP name, Password, ESSID, Default
Channel, MAC Address, IP Address, Subnet Mask, and Gateway information of connected AP.
Current System
 Vendor Name : The AP system supplier.
 AP name : The AP name is not an essential setting, but it helps identify the Access
Point in your network.
 Password : Used to change the password of connected AP. Enter a password to
change in “Password” and Retype in “Password Confirm”. The password for Password
and Retype shall be identical. If the password is wrong or not correct, an error message

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 17 of 46
is displayed and the changed value is not applied.
 ESSID: An ID to distinguish the cells of radio LAN network. The clients equipped with
the radio LAN shall be setup with the same ID to make communication with the AP. To
provide the roaming between APs in adjacent area, the SSID of AP in adjacent area
shall be identical. The string used for SSID shall consist of up to 32 alphabets and
figures except blank and special characters (by distinguishing capital and small letters). .
It is setup as “LGE” in factory shipment.
 Default Channel: The default channel can be 1 ~ 14 channels. It depends on the
country and in Korea we use 1 ~ 13 channel. If two or more APs are used in adjacent
area, they need to use different channels to avoid the interference. In adjacent area, it is
recommended to set the channels with at least five channels of interval. It is setup as
channel 1 in factory shipment.
 AP Mode: Used to determine the AP mode as Access Point or Repeater. In “Access
Point” mode, AP acts as normal AP. In “Repeater” mode, AP acts as wireless repeater
for connecting separated area.
WAN(10/100M) Parameters
 WAN(LAN1) Connection Type : IP(for Office LAN user), PPPoE(for ADSL user)
 MAC Address: This MAC(Media Access Control) address is a unique serial number
permanently assigned to the Access Point’s WAN Ethernet controller. You cannot
change this MAC Address.
 WAN(LAN1) IP Address: Describes the IP address of AP. For the communication with
AP Manager and for the connection with WEB Server and Telnet, it is setup as 10.0.0.1
in factory shipment.
 WAN(LAN1) Subnet Mask: Describes the subnet mask of AP. It determines that the IP
Address belongs to which subnet. It is setup as 255.255.255.0 in factory shipment. Upon
changing, user shall inquire of the related person about the matters.
 WAN(LAN1) Default Gateway: Describes the default gateway of AP. It is setup as
10.0.0.254 in factory shipment. Upon changing, user shall inquire of the related person
about the matters.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 18 of 46
 Primary DNS : Enter the IP address of the primary domain name server on your
network. It is setup as 10.0.0.101 in factory shipment. Upon changing, user shall inquire
of the related person about the matters.
 Secondary DNS : Enter the IP address of the secondary domain name server on your
network. It is setup as 10.0.0.102 in factory shipment. Upon changing, user shall inquire
of the related person about the matters.
LAN(10M) parameters
MAC Address : This MAC(Media Access Control) address is a unique serial number

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 19 of 46
 permanently assigned to the Access Point’s LAN Ethernet controller. You cannot change
this MAC Address.
 LAN(LAN2) IP Address: Describes the IP address of AP. For the communication with
AP Manager and for the connection with WEB Server and Telnet, it is set up as
192.168.0.1 in factory shipment.
 LAN(LAN2) Subnet Mask: Describes the subnet mask of AP. It determines that the IP
Address belongs to which subnet. It is set up as 255.255.255.0 in factory shipment.
Upon changing, user shall inquire of the related person about the matters.
 Modify : Used to change the item value of Basic Menu. Change the value of each item
in input column and click related button, and then the configuration value will be
changed. However, if the “SAVE” is not performed, the changed value will be returned to
the previous value when AP is rebooted. Refer to the “SAVE” menu.
 Cancel : Used to cancel the changed item value of Basic Menu.

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 20 of 46
2.2.2. 802.11b Menu
The 802.11b Menu displays the WEP related information including WEP use, WEP Generation,
Passphrase, WEP Default Key, Key 1, Key 2, Key 3, Key 4 and others.
 WEP: Stands for Wired Equivalent Privacy. It is a function to provide the data security
for the radio communication users and can be set to 64 bits or 128 bits. The web related
information setting for the clients to communicate with related AP should be the same as
that of AP.
 WEP Generation: A method to generate the web key. There are the Manual and
Passphrase. In case of Manual, it is to enter directly the web key for generation. In case
of Passphrase, when a word is entered in accordance with the pre-defined method with
the radio LAN, the web key corresponding to the related word will be automatically

LW2100AP User’s Manual
Version 1.4 2002.05.14
Copyright© 2002 LG Electronics Inc., LTD.
Page 21 of 46
generated.
 Passphrase: In case the WEB Generation is setup as Passphrase, this is a place to
enter the word for the web key generation.
 WEP Default Key: In case the WEB is set to 64 bits, this is the assigned default key. It
can be assigned as 1 ~ 4. In case of 128 bits, it is not necessary to enter.
 Key 1, Key2, Key3, Key4: A place to enter actual key value. Only the HEX values (0~9,
A~F) can be entered. It is possible only if the WEP Generation is Manual.
 Basic Rates : The highest rates specified will be the rate that the AP will use when
transmitting broadcast/multicast and management frames.. The rates are expressed in
megabits per second.
 Beacon Interval : The amount of time between beacons in kilomicroseconds. One
Kusec equals 1,024 micro seconds.
