Libelium Meshlium Xtreme User manual

-2- v4.0
Meshlium X
treme
Document version: v4.0 - 02/2013
© Libelium Comunicaciones Distribuidas S.L.
INDEX
1. Introduction......................................................................................................................................... 3
2. Meshlium’s Donnots ............................................................................................................................ 4
3. Meshlium’s Hardware Setup ............................................................................................................... 5
4. Turning on Meshlium .......................................................................................................................... 6
5. Accessing Meshlium ............................................................................................................................ 7
5.1. Manager System...........................................................................................................................................................................7
5.2. SSH ....................................................................................................................................................................................................9
Index

-3- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
1. Introduction
The aim of this Guide is to introduce the user to Meshlium in a practical way.
Meshlium is a complex device and a learning process must be completed. Libelium oers several Guides and examples which
will help the developer.
The present Guide was created in the hope of helping the developer in the very rst steps with Meshlium. We advice to follow
this Guide when the user wants to start the learning process. The last chapter will try to plan a learning process, proposing
further steps.

-4- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
2. Meshlium’s Donnots
The following list shows just some of the actions that produce the most common failures and warranty-voiding cases. Complete
documentation about usage can be found at:
http://www.libelium.com/development/meshlium
Failure to comply with the recommendations of use will entail the guarantee cancellation.
Software:
1. Do not access Meshlium with the shell terminal unless you have advanced Linux skills. Use the Meshlium Manager web
application in order to congure and setup Meshlium. A bad usage of the shell terminal commands may leave Meshlium
without connection or within a unstable mode. All the failures derived from a wrong usage of the shell terminal are not
covered under the warranty.
2. In the case you congured Meshlium through the terminal, there is not a method to take Meshlium to the conguration by
default: the only way to get connection again is sending Meshlium back to Libelium and hiring this service. However, if you
only use the Manager System, you can always go to the default conguration by clicking the “Presets” button.
3. Do not interrupt the power supply before shutting down Meshlium properly through the“Shutdown”or “Restart”buttons
in the Manager System or through the restart-secure and shutdown-secure commands from the terminal. If you do not do
so you may take the system corrupted.
4. If you need to modify a le or directory, after executing the command remountrw and modifying it, execute immediately
the command remountro.
5. In the case of developing an application for Meshlium, store the les in /mnt/user and not in other directory.
6. Regarding packages:
•Do not ever use the ‘apt-get’ command; if needed, use the ‘aptitude’ command.
•Do not ever make an ‘upgrade’ command of the entire system (not even using ‘aptitude’).
•Before installing new packages with ‘aptitude’, execute the ‘update’option.
Hardware:
1. Do not open the Meshlium enclosure in any case. This will automatically make the warranty void.
2. Do not handle the numbered metallic seals in the screws of Meshlium (in the new version): their integrity is the proof that
the Meshlium enclosure has not been opened. If they have been handled, opened or broken, the warranty is void. In the
previous version, the same terms apply to the special sticker seal.
3. Do not submerge Meshlium in liquids.
4. Do not place Meshlium on places or equipment where the device could be exposed to shocks and/or vibrations.
5. Do not expose Meshlium to temperatures below -20 ºC or above 50 ºc.
6. Meshlium’s microprocessor must not overpass 70 ºC. The user must make sure that this temperature is never reached,
especially when using Wi Scan.
7. Do not power Meshlium with other power sources than the original provided by Libelium.

-5- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
3. Meshlium’s Hardware Setup
This is the easiest hardware setup for Meshlium. Make sure you know how to do this setup rst, before going into advanced
powering options (solar panel, batteries).
1. Take the Meshlium casing and unscrew the Ethernet connector cap shown in the drawing.
2. Join the end that has the IP65 protection of the IP65 Ethernet cable to said connector and screw the cap on to x it.
3. Connect the other end of the cable to the PoE input marked “PoE”. As explained in the section “Before using Meshlium” of
Meshlium Technical Guide, make sure that the PoE is indoors.
4. Take the supplied PoE power adaptor and plug it into the corresponding PeE connector.
5. Plug the other end of the adaptor into the 220V socket and your Meshlium is now ready to operate.
Figure 1: How connect Meshlium to 220V
At Libelium we oer an equipment for operating at 12V. It is very important to bear in mind that not all batteries supply the
same voltage. You must use a 12V battery .
Note: Take special care to ensure that the battery you connect has the same power rating as the kit that you have purchased.

-6- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
4. Turning on Meshlium
Meshlium includes an internal speaker which will emit “beep!” sounds when initializing, rebooting and shutting down in order
to inform about the state of the process.
Initialization beeps:
•1 short beep when Meshlium is powered
•1 long beep when Meshlium starts launching the operate system
•2 long beeps when Meshlium has nished starting and it is ready to be used
Reboot and Shutting down beeps:
•1 long beep when the reboot order is executed
•2 long beeps when the system has been completely closed and Meshlium can be powered o.
Note: The “beep!” sound is not really loud so you will have to take attention and be close to the Meshlium box in order to hear them
clearly.
Note: It is highly important to wait for the 2 long beeps to power Meshlium o (rovove power cable). Otherwise, the system could be
corrupted. Warranty does not consider.

-7- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
5. Accessing Meshlium
5.1. Manager System
Meshlium comes with all the radios ready to be used. Just “plug & mesh!”. All the Meshlium nodes come with the Wi AP ready
so that users can connect using their Wi devices. Connect the Ethernet cable to your network hub, restart Meshlium and it will
automatically get an IP address from your network using DHCP *.
(*) For the Meshlium Mesh AP and for the Meshlium ZigBee Mesh AP the Internet connection depends on the Gateway of the
network.
Then access Meshlium through the Wi connection. First of all, look in your PC for the available access points and connect to
the one called “meshlium”.
Figure 2: Access Meshlium through the Wi connection
No password is needed as the network is public (you can change it later in the Wi AP Interface options). When you select it,
Meshlium will give an IP address from the range 10.10.10.10 to 10.10.10.250.
Now you can open your browser and access to the Meshlium Manager System:
•URL: http://10.10.10.1/ManagerSystem
•user: root
•password: libelium

-8- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
Figure 3: Login Form Manager System 3.0
Figure 4: ManagerSystem 3.0

-9- v4.0
Meshlium X
treme
Meshlium Xtreme - Quickstart Guide
You are now inside the Manager System, the tool for controlling most of the features of Meshlium in an easy way. You can
just browse the tabs to explore the possibilities of Meshlium. We advice to read the Meshlium Technical Guide thoroughly,
specially the chapters about the features you need to use.
Further step for you could be to congure Ethernet or Wi in a dierent way, if you have solid knowledge about networks. Please
be careful since you could leave Meshlium unaccessible.
Next step may be to check the Wi or Bluetooth scan features, in the case you ordered them.
If you are interested in Wireless Sensor Networks, it is always recommended to start the XBee development with one Waspmote
and one Gateway. There XBee Guides and examples to be studied. Once you have completed your development withWaspmote
units and Gateway, you can try now to connect your Waspmotes XBees to Meshlium. To do so, we advise to read rst the
“802.15.4 tutorial” or “ZigBee tutorial”. Then, you can start receiving frames in your Meshlium, and save them into a data base.
5.2. SSH
Note: SSH access is only recommended for advanced users, with solid computer/Linux skills. Improper modications to the le
system can leave the system without response. Warranty does not consider this kind of failures.
Access to the Meshlium le system:
•user: root
•IP: 10.10.10.1
•password: libelium
Figure 5: SSH access
