1:4 HDMI Distribution Amp / Splitter
DL-HD14-H2
REV 220616

USER MANUAL / DL-HD14-H2
2
The DigitaLinx Series is a family of extension, routing, and switching products designed
to allow digital signals to extend beyond their limitations. Liberty’s latest addition, DL-
HD14-H2, is a 1:4 HDMI splitter with built scaling and reliably distributes one HDMI input
signal to two outputs at resolutions up to 4K@60Hz 4:4:4 chroma subsampling. It follows
HDCP 2.2 and HDMI 2.0b specications, including supported data rates up to 18 Gbps, HDR
(high dynamic range), 3D and HD lossless audio formats. With the built-in scaler, when
connected to dierent displays, the corresponding HDMI output is capable of scaling down
automatically (down to 1080P) to feed an optimal output signal to its attached display.
PRODUCT OVERVIEW
PACKAGE CONTENTS
• (1) HDMI 1:4 Splitter
• (1) DC-5V-1A Power Adapter
• (2) Mounting Brackets

USER MANUAL / DL-HD14-H2 3
1. Power LED: When ON/OFF device is powered ON/OFF
2. HDMI Input LED: When ON, HDMI signal is detected, when OFF no HDMI signal is
detected
3. HDMI Output LED: When ON HDMI display is connected, When OFF no HDMI display
is connected
Front Panel
PRODUCT VIEW
1 2 3

USER MANUAL / DL-HD14-H2
4
Rear Panel
1. 5V: Power adapter connection
2. HDMI OUTPUT: Connect HDMI displays using High Speed HDMI cables
3. HDMI INPUT: Connect HDMI input using High Speed HDMI cable
12
3
PRODUCT VIEW

USER MANUAL / DL-HD14-H2 5
APPLICATION EXAMPLE

USER MANUAL / DL-HD14-H2
6
TECHNICAL SPECIFICATIONS
Video
Input / Output Signal Type HDMI with 4K@60Hz 4:4:4, HDCP 2.2, HDR, 3D
Input / Output Resolution Support Up to 4096x2160@60Hz, including 4K@30Hz/60Hz,
1080P/720P
Input Type (1) HDMI Type A
Output Type (4) HDMI Type A
Deep Color 4K: 8/10/12bit
1080P: Up to 8bit
Maximum Data Rate 18bps
Maximum Pixel Clock 600MHz
HDMI Transmission Distance Input / Output: 15m / 50’ - 1080p@60Hz
Input / Output: 10m / 33’ - 4K@30Hz
Input / Output: 5m / 16’ - 4K@60Hz
Audio
Supported Formats Fully supports audio formats in HDMI 2.0
specication, including PCM, Dolby TrueHD, Dolby
Atmos, DTS-HD Master Audio, DTS:X
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Humidity 10% to 90%, non-condensing
ESD Protection Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply DC 5V 1A
Power Consumption (Maximum) 1.8W
Device Dimension (W x H x D) 140mm x 20mm x 65.2mm/
5.5’’ x 0.8’’ x 2.6’’
Product Weight 0.24kg/0.53lb
Warranty 5 Years
Certication CE, FCC, RoHS
