LIBERTY AV SOLUTIONS DIGITALINX DL-S42-H2 User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 191206 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
DL-S42-H2 Quick Install Guide
This guide is for quick installaon only.
For complete owners manual go to www.libav.com or use a QR reader to access the
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

DL-S42-H2 Quick Guide
3
The DigitaLinx DL-S42-H2 is a simple 4x2 HDMI 2.0 matrix switcher that features four HDMI inputs
and two HDMI outputs with HDCP 2.2 support and capable of handling resoluons up 4K@60Hz
4:4:4 / 8 bit color with stac and dynamic HDR output support. The DL-S42-H2 supports digital opcal
audio de-embedding from both outputs and analog audio de-embedding from output 1. The switcher
also supports Audio Return Channel (ARC) on output 2, the digital opcal audio on output 2 can be
congured manually to either pass the HDMI audio stream from the routed HDMI input or from the
HDMI / ARC audio stream from the connected TV. Each output port supports auto down scaling from
4K to 1080P independently.
The DL-S42-H2 can be controlled via front panel buons, IR remote, API commands using RS232 or
Ethernet. A web server / GUI is built in that features A/V switching control, automac display control
and input EDID management.
Product Overview
Package Contents
• DL-S42-H2 HDBaseT Receiver
• (1) Quick Install Guide
• (1) IR Remote
• (1) 3 pin Phoenix Male Connector
• (1) DC5V Power Supply with US, UK, EU and AU adapter plugs
• (2) Mounng Brackets

DL-S42-H2 Quick Guide
4
Front / Back Panel View
1. POWER LED
• When ON; Device is powered on
• When OFF; Device is powered o
2. OUTPUT1 - Output 1 input selecon buon
3. INPUT LEDs
• When ON; HDMI (1-4) is selected
• When OFF; HDMI (1-4) is not selected
4. OUTPUT2 - Output 2 input selecon buon
5. INPUT LEDs
• When ON; HDMI (1-4) is selected
• When OFF; HDMI (1-4) is not selected
6. IR - IR Receiver window
7. DC5V - Power plug input
8. HDMI IN 1-4 - HDMI Inputs 1-4
9. HDMI OUT1 - HDMI Output 1
10. OPTICAL - Digital audio output - de-embeds mul channel HDMI audio from selected input
11. ANALOG - Analog audio output - de-embeds 2 channel HDMI audio from selected input
12. HDMI OUT2 - HDMI Output 2
13. OPTICAL / ARC - Digital audio output - de-embeds mul channel HDMI audio from selected input
OR via ARC / HDMI from connected TV display
14. OPTICAL / ARC SWITCH - Manual switch for conguring digital audio output
15. RS232 - Phoenix connector for RS232 system control
16. Ethernet - RJ45 connector for Ethernet system control
1 2 3 4 5 6
7 8 9 10 11 12 13 14 15 16

DL-S42-H2 Quick Guide
5
Connecvity Instrucons
1. Verify all components included with the switcher are present before installaon.
2. If the switcher is going to be permanently mounted in a rack, aach the mounng brackets of the
DL-S42-H2 matrix switcher.
3. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
4. Connect the source devices to the HDMI inputs using HDMI cables that are less than or equal to 5
meters in length for 4k/60Hz signals. For source devices that are further away, it is highly recommended
to install an extender such as the Digitalinx DL-HD70 or DL-HD2100.
5. Connect the display devices to HDMI outputs using HDMI cables that are less than or equal to 5
meters in length for 4k/60Hz signals. For display devices that are further away, it is highly recommended
to install an extender such as the Digitalinx DL-HD70, DL-HDE100 or DL-HD2100.
6. Connect the audio outputs to an audio amplier using either the digital or analog outputs.
7. Insert the matrix power supply unit to power on the switcher.
8. Power on aached audio/video devices.
9. Route input to outputs using the matrix front panel buons, IR remote control, built in web GUI,
serial RS232 or Ethernet using telnet port 23.

DL-S42-H2 Quick Guide
6
Cabling Wiring Requirements
Ethernet Control
The DL-S42-H2 may be controlled via Ethernet using web browser for web server control or by using
telnet commands using port 23. See owners manual online at www.libav.com for API.
The TCP/IP port requires a standard straight-through
Category 5 or greater cable with the TIA/EIA-568B crimp
paern for opmal operaon.
The default sengs for the TCP/IP port are:
IP address: 192.168.1.254 subnet 255.255.255.0
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Connect the Ethernet cable between the matrix and a
router with a straight-through cable or between the matrix
and a PC computer with a crossover cable. To connect to
the web server built into the DL-S42-H2 type the default
IP address of the switcher into a browser on the PC. Be
sure the PC is in the same Network ID of the DL-S42-H2, ie
192.168.1/24.
RS232 Control
The RS232 connecon on the matrix is 3 pin
phoenix. See below for RS232 conguraon.
• 115200 baud
• 8 Data Bits
• 1 Stop Bit
• Parity = none
TX RX G
RX TX G
DL-S42-H2
RS232 PORT
CONTROL
RS232
PINOUT
Connecng to
System Controller

DL-S42-H2 Quick Guide
7
Technical Specicaons
Input/Output Connecons
HDMI Inputs Four (4) HDMI Type A Receptacle
HDMI Outputs Two (2) HDMI Type A Receptacle
TCP/IP One (1) 8P8C Port (Shielded RJ45 Female)
RS232 One (1) 3 pin Phoenix connector
Audio - One (1) Analog L/R audio outputs, 3.5mm connectors
- Two (2) Digital audio outputs, Toslink connectors
Supported Audio, Video, and Embedded Control
Video Resoluons Up to 4K@60Hz 4:4:4 8 bit
Maximum Passive HDMI Cable Distance 5m for 4k60 signals
Video Compliance HDMI 2.0b and HDCP 2.2
Embedded HDMI Audio Up to PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD
Master Audio and DTS:X
De-embedded Audio - Digital and Analog Analog L/R Out: PCM 2.0
Digital Toslink Out (De-embedded HDMI audio and ARC au-
dio): Up to Dolby 5.1, DTS 5.1
Device Control Parameters
Ethernet 100BaseT
RS232 Baud Rate 115200 baud
Chassis and Environmental
Enclosure Painted Aluminum
Dimensions (H x W x D) 246mm x 22mm x 100.2mm / 9.69” x 0.87” x 3.94”
Shipping Weight 0.62kg / 1.37lb
Operang Temperature 0° to +45° C (+32° to +113° F)
Operang Humidity 10% to 90%, Non-condensing
Storage Temperature -20° to +70° C ( -4° to +140° F)
Storage Humidity 10% to 90%, Non-condensing
Power, ESD, and Regulatory
Power Supply 100V-240VAC / 50-60 Hz
Power Consumpon 3.3W (Max.)
ESD Protecon 8kV air, 4kV contact
Product Regulatory FCC, CE, RoHS
Other
Standard Warranty 5 years
Included Accessories Quick Install Guide, IR Remote, (1) 3 Pin Phoenix Connector,
Rack Mounng Clips with Screws, (1) AC power adapter with
US, UK, EU and AU power plugs
