Liberty DigitaLinx DL-1H1A-WPKT-W User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 180529 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
DL-1H1A-WPKT-W Install Guide

DL-1H1A-WPKT-W Install Guide
3
The Digitalinx DL-1H1A-WPKT-W HDBaseT extender set transmits HDMI, audio and
RS232 over single category 6 twisted pair cable. The DL-1H1A-WPKT-W can transmit 4K
resolu ons up to 4K@60Hz, 4:2:0 up to 40m / 120’ and 1080P up to 70m / 230’. The
audio circuit is completely separate and is not dependent on the HDMI input source to
be ac ve. The Digitalinx DL-1H1A-WPKT-W is HDMI 1.4b and HDCP 2.2 compliant and
supports CEC pass through. The DL-1H1A-WPKT-W HDBaseT receiver powers wall plate
transmi er via HDBaseT so there is no need for an external power supply for the wall
plate.
The DL-1H1A-WPKT-W is sold only as a set. The individual transmi er and receiver are
not compa ble with other HDBaseT devices due to proprietary PoE circuitry.
Product Overview
Package Contents
• DL-1H1A-WPKT-W Wall plate extender set
• Quick Install Guide
• (1) Decora cover plate
• (1) 3 Pin phoenix connector
• (1) 2 Pin phoenix connector
• (1) DC24V 1A power supply with US, UK, EU and AU power adapter plugs
• (2) Moun ng ears with moun ng screws

DL-1H1A-WPKT-W Install Guide
4
Transmi er / Receiver View
Transmi er
1
3
2
4
5 6
23
( )
1. HDMI IN - Video source input
2. ACTIVE LED
• When LED is green, unit is received ac ve HDMI signal
• When LED is off , no ac ve HDMI signal is present
3. AUDIO IN - 3.5 mm analog audio source input
4. HDBaseT OUT - HDBaseT output port
5. RS232 - Serial port for transmi ng / receiving RS232 signals
6. DC24V - Phoenix connector for connec ng external power supply
Note: The DL-1H1A-WPKT-W-TX can receive power via HDBaseT from the receiver when connected
together with a Category 6 F/UTP cable
13456
2
1. HDMI OUT - HDMI output to connect to display technology
2. AUDIO OUT - 3.5mm analog audio output port
3. RS232 - Serial port for transmi ng / receiving RS232 signals
4. DC24V - Locking connector for connec ng external power supply
5. POWER LED - When power is received, the LED will be ON
6. HDBaseT IN - HDBaseT input port
Receiver

DL-1H1A-WPKT-W Install Guide
5
Connec vity Instruc ons
1. Verify all components included with the extender set are present before installa on.
2. If the extenders are going to be permanently mounted to a surface, a ach the
included moun ng brackets with the supplied screws.
3. Turn off power and disconnect the audio/video equipment by following the
manufacturer’s instruc ons.
4. Connect Category 6 or greater twisted pair cable with RJ45 connectors between the
transmi er (DL-1H1A-WPKT-W-TX) and the receiver (DL-H1A-WPKT-W-RX). TIA/EIA-
568B straight-through wiring connec ons must be used with all HDBaseT extenders.
5. Connect an HDMI cable and any desired control accessories between the display and
the receiver (DL-H1A-WPKT-W-RX).
6. Connect an HDMI cable and any desired control accessories between the source and
the transmi er (DL-1H1A-WPKT-W-TX).
7. Connect the included power supply to the DL-1H1A-WPKT-W receiver and lock the
power supply to the power connector by twis ng the locking collar clockwise.
8. Power on a ached audio/video devices.

DL-1H1A-WPKT-W Install Guide
6
TIA/EIA-568B
Orange/White
Orange
Green/White
Blue
Blue/White
Green
Brown/White
Brown
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
1 8
Twisted Pair Wiring
Use TIA/EIA-568B wiring for Category 6
connec on between send and receive
units.
Cabling Requirements
HDBaseT Cabling
To ensure proper performance of the DL-1H1A-WPKT-W, it is recommended that you
use solid core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may
perform well but may not support power over HDBaseT reliably.
For op mized HDBaseT performance use the following Liberty Wire and Cable branded
cabling;
Category 6 plenum; 24-4P-P-L6SH
Category 6A plenum; 24-4P-P-L6ASH
Category 6 NON-plenum; 24-4P-L6SH
Category 6A NON -plenum; 24-4P-L6ASH
When using shielded category cabling A LWAY S ...
....use shielded connectors
....properly ground the category cable
RS232 Wiring
Connect the controller or device RX signal
to TX on the DL-1H1A-WPKT-W extender.
Connect the controller or device TX signal to
Rx on the DL-1H1A-WPKT-W extender.

DL-1H1A-WPKT-W Install Guide
7
Technical Specifi ca ons
VIDEO
Video Inputs (TX) (1) HDMI
Video Input Connector (TX) (1) HDMI type A
Input Video Signal HDMI
Video Output (RX) (1) HDMI
Video Output Connector (RX) (1) HDMI type A
Output Video Signal HDMI
Input Resolu ons Supported Up to 3840 x 2160 @ 60Hz, 4:2:0, 8bit color depth
Standards Compliant with HDMI 1.4b & HDCP2.2
AUDIO
Supported output formats (HDMI) LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,
DTS-EX,DTS-96/24, DTS High Res, DTS-HD Master
Audio, DSD
Supported output formats (Analog) PCM 2.0
Audio Input / Output Stereo analog
Audio Input / Output Connector (1) 3.5mm TRS audio jack
Audio Output Impedance 70 Ohms
Frequency Response 20Hz~20K Hz
CONTROL
Control Port / Connector (1) RS232 (TX) / 3 phoenix connector
(1) RS232 (RX) / 3 phoenix connector
OTHER
System Bandwidth 10.2Gbps
Opera ng Temperature 0C ~ +40C
Storage Temperature -20C ~ +60C
Humidity 20% ~ 90%
Power Supply Input:100V~240V AC; Output: 24V DC 1A
Power Consump on 9 wa s
Dimension (W*H*D) TX:103.5mm * 30mm * 46mm / 4” * .1.2” * 1.8”
RX:124mm * 16mm * 75mm / 4.9” * .6” * 2.9”
Weight TX:163g / .36 lbs
RX:200g / .44 lbs
Warranty 5 years
Cer fi ca on CE, FCC, RoHS
