Liberty DigitaLinx DL-HDR-H2 User manual

11675 Ridgeline Drive
Colorado Springs, CO
80921
Rev 181220 Phone: [phone]
Toll-Free: 800-530-8998
Fax: [phone]
DL-HDR-H2 Quick Install Guide

DL-HDR-H2 Quick Guide
3
The DigitaLinx DL-HDR-H2 is an HDMI 2.0b booster / equalizer designed to extend HDMI signals up
to 4k@60Hz / 4:4:4 / 8 bit color up to 20 meters / 66 feet. The DL-HDR-H2 supports HDMI 2.0b and
HDCP 2.2 encrypon.
The total transmission distance of a 4K@60Hz / 4:4:4 / 8 bit color signal (~17-18Gbps) is up to
20 meters / 66 feet, maximum distance from the HDMI output of the DL-HDR-H2 to TV display is
10 meters / 33 feet using a High Speed HDMI cable rated at 18Gbps
The total transmission distance of a 4K@30Hz / 4:4:4 / 8 bit color signal (~9Gbps) is up to
35 meters / 115 feet, maximum distance from the HDMI output of the DL-HDR-H2 to TV display is
15 meters / 50 feet using a High Speed HDMI cable rated at 10.2Gbps
The total transmission distance of a FullHD 1080p signal (~4.9Gbps) is up to 50 meters / 165 feet,
maximum distance from the HDMI output of the DL-HDR-H2 to TV display is 30 meters / 100 feet using
a Standard Speed HDMI cable rated at 4.9Gbps
Product Overview
Package Contents
• DL-HDR-H2 HDMI 2.0b Booster
• Quick Install Guide
• (1) DC5V 1A US power supply
• (1) Micro USB-B to USB-A Cable
• (2) Mounng ears with mounng screws

DL-HDR-H2 Quick Guide
4
Connecvity Instrucons
1. Verify all components included with the booster are present before installaon.
2. If the extenders are going to be permanently mounted to a surface, aach the included
mounng brackets with the supplied screws.
3. Turn o power and disconnect the audio/video equipment by following the manufacturer’s
instrucons.
4. Connect an HDMI cable between the A/V source and the DL-HDR-H2 booster.
5. CConnect an HDMI cable between the display and the DL-HDR-H2 booster.
6. Connect the included power supply to the DL-HDR-H2 booster.
7. Power on aached audio/video devices.
Front and Back View
1 2 3
FRONT BACK
1. HDMI IN - HDMI input port for connecon to HDMI video source
2. 5VDC - Micro USB B power supply port
3. HDMI OUT - HDMI output port for connecon to display

DL-HDR-H2 Quick Guide
5
Wiring Diagram
Media Player
HDMI
BACK
FRONT
4K@60Hz: 10m / 33’ max
4K@30Hz: 15m / 50’ max
1080p: 30m / 100’ max
4K@60Hz: 10m / 33’ max
4K@30Hz: 20m / 66 max
1080p: 20m / 66’ max
Display

DL-HDR-H2 Quick Guide
6
Technical Specicaons
Supported Audio and Video
Video Compliance HDMI 2.0b, HDCP2.2
Input / Output Resoluon Support Up to 4096x2160@60Hz (4:4:4 chroma sub-sampling / 8 bit deep color)
System Characteriscs / Cabling Requirements
Maximum Distance (Input) 4K@60Hz 4:4:4 (~17-18Gbps): 10 meters / 33 feet
4K@30Hz 4:4:4 (~10Gbps): 20 meters / 66 feet
1080p (4.9Gbps): 20 meters / 66 feet
Maximum Distance (Output) 4K@60Hz 4:4:4 (~17-18Gbps): 10 meters / 33 feet
4K@30Hz 4:4:4 (~10Gbps): 15 meters / 50 feet
1080p (4.9Gbps): 30 meters / 100 feet
Cable Requirements 4K@60Hz 4:4:4 (~17-18Gbps): High Speed HDMI rated at 18Gbps
4K@30Hz 4:4:4 (~10Gbps): High Speed HDMI rated at 10.2Gbps
1080p (4.9Gbps): 20 meters / Standard Speed HDMI rated at 4.9Gbps
Bandwidth 18 Gbps
Chassis and Environmental
Dimensions (H x W x D) 12 mm x 45.5 mm x 49 mm (.5 in x 1.8 in x 1.9 in)
Product Weight 55g / 0..1lbs
Operang Temperature -25° to +55° C (-4° to +131° F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Operang Humidity (Environment) 10% to 90%, Non-condensing
ESD Protecon Human-body Model:
±8kV (Air-gap discharge)
±4kV (Contact discharge
Surge Protecon Voltage: ±1 kV
Power
Maximum Power Consumpon 1 wa (max)
Power Supply Input Voltage 100-240V AC at 50-60 Hz
Power Supply Output Voltage 5V DC 1A
Regulatory CE, FCC, RoHS
Other
Standard Warranty 5 Years
Included Items Quick Install Guide, US Power Supply, Micro USB-B to USB-A Cable, (2) Mount-
ing Brackets with mounng Screws
Distances and picture quality may be aected by cable grade, cable quality, source and desnaon equipment, RF and
electrical interference.
