Life Fitness Signature Series SUB User manual

SIGNATURE SERIES
SUB
Customer Support Services
PARTS LIST
Page 1
SIGNATURE UTILITY BENCH

Page 2
CONTENTS
________________________________________
SUB SIGNATURE UTILITY BENCH
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
BASE FRAME ASSEMBLY 5
BASE FRAME ASSEMBLY LEGEND 6
SEAT FRAME ASSEMBLY 7
IMAGE 8
________________________________________
NOTE: SUBSTITUTE PART NUMBERS ENDING
WITH ‘XX’ WITH THE REQUIRED COLOR CODES.
01 = WHITE
FRAME PADS
02 = PLATINUM
01 = BLACK
99 = CUSTOM

COMPONENT ASSEMBLY
________________________________________
Page 3
SEE PAGE 4 FOR LEGEND
SUB SIGNATURE UTILITY BENCH
8
9
1
5
7
6
5
7
6
5
6
2
4
3
10

Page 4
________________________________________
COMPONENT ASSEMBLY LEGEND
SUB SIGNATURE UTILITY BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 78411XX PTD ASSY, SUB, BASE FRAME
2 1 78412XX PTD ASSY, SUB, SEAT FRAME
3 1 74689XX PAD 18 X 9 CONVEX
4 1 78138XX PAD, 10 X 16 TAPERED CONVEX
5 6 3237403 PLUG, 1" HOLE
6 8 3102514 WASHER, FLAT 3/8" SAE ST ZN
7 4 LEA3256204 SCREW, M10 X1.5 35MM
8 2 3256202 SCREW, M10 X1.5 25MM
9 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
10 1 8137801 DECAL, WARNING, VERT, MULTI-LANG SHEET

Page 5
BASE FRAME ASSEMBLY - 78411XX
________________________________________
SEE PAGE 6 FOR LEGEND
4
2
1
8
3
7
6
5
SUB SIGNATURE UTILITY BENCH

Page 6
________________________________________
BASE FRAME ASSEMBLY LEGEND
SUB SIGNATURE UTILITY BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 78411XX PTD ASSY, SUB, BASE FRAME
2 3 7800401 CAP, LRG FLOV END
3 3 7821702 GUARD PAINT
4 3 7810801 PAD, RUBBER FOOT
5 12 3114407 WASHER, SAE #10
6 30 3239102 SCREW, M5X12 PHL PAN TT ST BZ
7 1 8106101 LABEL, LIFE FIT 13/16 X 4-3/8'' SG
8 1 8106801 LABEL, SERIAL NUMBER, LARGE

3
2
1
Page 7
________________________________________
SEAT FRAME ASSEMBLY - 78412XX
SUB SIGNATURE UTILITY BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 78412XX PTD ASSY, SUB, SEAT FRAME
2 2 7800501 CAP, SML FLOV END
3 1 LEA7002401 LABEL, V WARNING 4.5 X 1.625

Page 8
________________________________________
SUB SIGNATURE UTILITY BENCH
