SIGNATURE SERIES
SOFB-002
Customer Support Services
PARTS LIST
Page 1
SIGNATURE OLYMPIC FLAT BENCH

Page 2
CONTENTS
________________________________________
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
________________________________________
NOTE: SUBSTITUTE PART NUMBERS ENDING
WITH ‘XX’ WITH THE REQUIRED COLOR CODES.
01 = WHITE
FRAME PADS
02 = PLATINUM
01 = BLACK
99 = CUSTOM
PAGE
COMPONENT ASSEMBLY 3
COMPONENT ASSEMBLY LEGEND 4
CENTER FRAME ASSEMBLY 5
CENTER FRAME ASSEMBLY LEGEND 6
LEFT UPRIGHT ASSEMBLY 7
LEFT UPRIGHT ASSEMBLY LEGEND 8
RIGHT UPRIGHT ASSEMBLY 9
RIGHT UPRIGHT ASSEMBLY LEGEND 10
IMAGE 11
NOTE: PEGS ON VERSION 2 UPRIGHTS HAVE BEEN RAISED. REV 1
AND REV 2 UPRIGHTS ARE NOT COMPATIBLE.
________________________________________

2
8
7
3
1
5
6
10
9
4
11
COMPONENT ASSEMBLY
________________________________________
Page 3
SEE PAGE 4 FOR LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH

Page 4
________________________________________
COMPONENT ASSEMBLY LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 78521XX PTD ASSY, SOFB, CENTER FRAME
2 1 85036XX PTD ASSY, SOFB, UPRIGHT LEFT
3 1 85034XX PTD ASSY, SOFB, UPRIGHT RIGHT
4 5 3256204 SCREW, M10 X 1.5 35MM
5 4 3256206 SCREW, M10 X 1.5 45MM ZN
6 4 3242002 NUT, M10 X 1.5 HEX NYLOCK
7 1 78219XX PAD, HEAD REST
8 1 78218XX PAD, 36 X 11 FLAT
9 13 3102514 WASHER, FLAT 3/8 IN SAE ST ZN
10 5 3237403 PLUG, 1" HOLE
11 1 8137701 DECAL, WARNING, HORIZ, MULTI-LANG SHT, 10-0109-016, BNR

Page 5
CENTER FRAME ASSEMBLY - 78521XX
________________________________________
SEE PAGE 6 FOR LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
9
2
1
2
3
8
7
6
5
4

Page 6
________________________________________
CENTER FRAME ASSEMBLY LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 78039XX WLDMT, SOFB, CENTER FRAME
2 2 7800401 CAP, LRG FLOV END
3 1 7800501 CAP, SML FLOV END
4 1 7334001 FOOT, 2.50 X 4.49 FLOV
5 2 3251202 SCREW, M10 X1.5 X 25MM UNS HEX CS ST ZN
6 2 3102514 WASHER, FLAT 3/8" SAE ST ZN
7 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
8 1 7340201 COVER, FOOT - STRAIGHT
9 1 AK58-00245-0000 MEDALLION;"BUG"; PUR

Page 7
________________________________________
LEFT UPRIGHT ASSEMBLY - 85036XX
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
SEE PAGE 8 FOR LEGEND
1
2
3
4
5
6
7
8
9
10
11
12

________________________________________
LEFT UPRIGHT ASSEMBLY LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
Page 8
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 85036XX PTD ASSY, SOFB, UPRIGHT LEFT
2 11 3102514 WASHER, FLAT 3/8 IN SAE ST ZN
3 2 3251202 M10 X 1.5 X 25MM UNS HEX CS ST ZN
4 9 3256202 SCREW, M10 X 1.5 25MM ZN
5 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
6 1 7804601 GUARD, BAR CATCH, 10-0112-013, BNR
7 1 7340201 COVER, FOOT - STRAIGHT
8 1 7800401 CAP; LRG FLOV END
9 2 7804501 HOOK, BAR CATCH, 10-0112-012, BNR
10 1 7334001 FOOT, 2.50 X 4.49 FLOV, 10-0074-046, BNR
11 1 8077501 GUARD, BAR CATCH, LOWER, 10-0112-020, BNR
12 1 8003301 LABEL, LIFE FIT 2-1/2 X 15 SG, 10-0177-025, BNR

________________________________________
RIGHT UPRIGHT ASSEMBLY - 85034XX
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
Page 9
SEE PAGE 10 FOR LEGEND
1
2
3
4
5
6
7
8
9
10
11
12
13
14

________________________________________
RIGHT UPRIGHT ASSEMBLY LEGEND
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
Page 10
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 85034XX PTD ASSY, SOFB, UPRIGHT RIGHT
2 11 3102514 WASHER, FLAT 3/8 IN SAE ST ZN
3 9 3256202 SCREW, M10 X 1.5 25MM ZN
4 2 3251202 M10 X 1.5 X 25MM UNS HEX CS ST ZN
5 2 3242002 NUT, M10 X 1.5 HEX NYLOCK
6 1 7334001 FOOT, 2.50 X 4.49 FLOV, 10-0074-046, BNR
7 1 7340201 COVER, FOOT - STRAIGHT
8 1 7800401 CAP; LRG FLOV END
9 2 7804501 HOOK, BAR CATCH, 10-0112-012, BNR
10 1 7804601 GUARD, BAR CATCH, 10-0112-013, BNR
11 1 8077501 GUARD, BAR CATCH, LOWER, 10-0112-020, BNR
12 1 8003301 LABEL, LIFE FIT 2-1/2 X 15 SG, 10-0177-025, BNR
13 1 8106801 LABEL, SERIAL NUMBER, LARGE, 10-0123-001, BNR
14 1 7002501 LABEL; H WARNING 4.5 X 1.625

Page 11
________________________________________
SOFB-002 SIGNATURE OLYMPIC FLAT BENCH
