Life Smart LS051CH User manual

Simply Brilliant
Setting up your LifeSmart™ Air Purifier
Air Purifier
User Guide Version 1.0
Model. LS051CH

Product Presentation
Power Plug Hole
Filter Gate
Air Intake(Bottom)
Air Outlet
Three Sides Gird
Air Inlet
Screen Board

Install
Anticlockwise
rotate and take
out the filter
Open the packing box and
remove the power line
Connect the power line to
plug at the bottom of the
machine, and plug into the
power switch
There is a power
sign above the power
interface
Cut and remove
the filter bag
Put the filter back, and
locking the door in
clockwise direction
Note
Be sure lock to the original point
Remove the power line
1
2Install Filter
Machine Bottom
Connect the power line
3

Usage
Note
When mobile phone can’t connect the purifier
Right Position
-----------------------------------------------------------------------------
APP download
In order to get the better performance of the air purifier, the air
inlet should be maintain a suitable distance with walls and other
obstructions.
User opens the scan tool trough
mobile Devices, scanning the
two-dimensional Code in machine
back.
For technical support or FAQ's please visit us at
www.ilifesmart.sg and find out how to contact
our happiness team in your region.
20cm & above
20cm & above
20cm & above

Screen Display
Fan Speed Adjustment Intelligence Mode/WIFI Connection
Filter Life
Fan Speed
Power Switch
Indoor Humidity Outdoor Temperature
Speed Adjustment Power Switch Intelligent Mode
WIFI ConnectionSleep Mode
WIFI Connection Super Speed Mode
Indoor PM2.5
After power supply, power on default mode is
intelligent mode.
The fan speed include AUTO, Night, Gear 1,Gear 2 and
Gear 3,power on default speed is AUTO, when the machine
is working, press the button in 3 seconds, it come to Super
Fan Speed.
Based on the indoor air quality, the machine can
adjust fan speed automatically. The machine
include WIFI function(More details, please refer the
WIFI manual ).
When the machine start up, the WIFI Connection
logo will be flashing once per 0.5 second, after 30
seconds, the logo will stop light.
After Sleep Mode operate, the brightness of
PM2.5 data’s display area and only 3 buttons
in the screen will become tiny light.
Super Speed Mode
Please change into the Super Speed Mode, when the air
pollution is heavy, press Fan Speed Adjustment button in 3
seconds for change. After Super Speed operate 20 minutes,
the mode will change into Intelligent Mode.

The machine screen can show the life of the
filter, according to the operating state of the
device and the internal algorithm, determine
whether to replace the filter, if need to be
replaced, the panel of filter will be flashing.
MaintainingFilter Presentation
Rrplacing Filter
Filters sectional
Drawing
Pre-filter
HEPA Filter
Mixed Activated Carbon Filter 2
Pre-Filter, with a 360-degree barrel
structure, can filter dust, hair, fines and
other large suspended solids.
Using high-density Apollo HEPA filters,
is capable of adsorbing harmful PM2.5,
PM0.3, pollen and other particulate
matter.
Coconut Shell Activated carbon mixed
with catalyst. The high efficiency of
active carbon and the long life of the
catalyst are both considered. In the
deodorant performance, for the
formaldehyde, ammonia, toluene,
acetic acid has a high efficiency of
removal rate, more wide range of
deodorant. Filter replacement cycle is about 6 months, when tested the
filters need to be replaced, the indicator will start to flash, the
flashed indicator can be stopped by pressing any key. If do not
replace filters, the screen display will indicate to replace again at
the next time turn on the machine.
Buy Filter Element
Please visit：www.ilifesmart.com
Filter Element Installation
Please follow “Installation” step.
Replace Filter Element Prompt
After replacing filter element and turn on the machine, then
press“ ”，at the same time, after filter element reduction
succeed, the purifier will restart the cloud calculation.

Specifications
Troubleshooting Table
Household appliances hazardous substancs statement
Model
Size
Weight
WIFI Connection
LS0051CH
717*333mm
7.8kg
Android/IOS
Effective area
Power
Noises
CADR value
40.6㎡-69.6㎡
1.8~70W
Standard≤65dB
Standard Mode CADR value: 528m3/h
Note: Follow (air purifier)(GB/T18801)The new national standard draft estimates
Represent
The content of hazardous substances in all homogeneous
materials that are below SJ / T11363-2006 standard limit requirement.
Represent
The content of hazardous substances in all homogeneous
materials of the part exceeded SJ / T11363-2006 standard limit
requirement
x
Walt Rated power 220V~ 50Hz
Symptom Can Not Boot Noisy Runtime Poor Purification
Checklist
If the filters and compartment
door at the bottom is securely
in place. If the power cord is
connected to the bit.
Checking if the filter has been
installed, Whether the filter
plastic bags have been
removed.
Check if the filter has been
installed, Whether the filter
plastic bags have been removed
and it is locked into place.
Shell
Circuit board
Accessory
Pb Hg Cd Cr PBB PBDE
6+
(Super Speed Mode CADR value: 584m, opened
within short-term in extreme environments.）
（Super Speed≤68dB，Super Speed Mode≠Normal working condition,
opened within short-term in extreme environments.）

Attention
Make sure the host machine is stopped working when moving, meanwhile, unplug it.
Handing
Installation
Electrical
Power Attention
AC Power Cord
In use
Restriction
The host machine fails to launch when the filter element bin gate was not installed properly.
The space between the hosy machine inlet opening and the wall or other shelters should be kept over 20cm.
Do not writing, pinch, bend or twist AC power cord, otherwise, the filter element will be exposed or broken-down.
Do not drag AC power cord when disconnect it.
Do not use unmatched AC electrical connector receptacle.
Do not use the provided AC power cord on other equipments
Follow the guidelines when using AC power cord and electrical connector receptacle or otherwise may
cause fire, electric shock or broken;
Connect the attached power cord to the appropriate electrical connector receptacle.
Only use the provided power cord of Mfresh， do not use other brand’s power cord.
Please disconnect the AC power cord when perform maintenance or move Mfresh Air purifier.
Please stop using when the product has abnormal sound, abnormal smell, high temperature, wind fan
improper rotation etc.
Do not put finger or other foreign body into the protector, removable part, inlet opening and outlet opening.
Do not close to the host machine with hair, textile, in case of entangling or shielding the inlet opening and outlet opening.
Do not sit, lean on or tilt the main body.
Please ventilate when using combustion apparatus at the same time, in case of monoxide poisoning.
Do not use under the below circumstances, otherwise, electrical shock, fire or other injuries may occur：
Easy to fall and other unsteady environments.
Bathroom, high temperature, damp, easy to soak in water cases.
