lifelong LLSWM70D User manual

WASHING MACHINE
Built for Home. Built for India.
User Manual
Manufactured for & Marketed by :
Lifelong Online Retail Private Limited
For queries and complaints:
please contact: [email protected]
www.lifelongindiaonline.com

INTRODUCTION:
Dear Customer,
Congratulations! We welcome you to the Lifelong family, as you welcome
our Lifelong Semi-Automatic Washing Machine to be a part of your home.
At Lifelong, our products are carefully built for the needs of India, which is
why we have crafted a diverse range of innovative products, across a
spectrum of categories - Home, Kitchen, Grooming, Fitness, Lifestyle and
Smart Home, to better help you. We then deliver them at the best prices,
enriching your everyday living.
We are sure you can't wait to start using your new Lifelong
Semi-Automatic Washing Machine.
We know we can't!
Looking forward to building our bond for life, cheers!
Thank you, Team Lifelong
12
LLSWM70D/LLSWM75D
LLSWM80D

TABLE OF CONTENTS :
1. About the Product
2. Marking of Product
3. Dos and Don’ts
4. Control Panel Information
5. How to use
6. Device Cleaning
7. Product Specifications
8. Troubleshooting guide
9. Terms & Conditions
10. Warranty Card
ABOUT THE PRODUCT:
3
8
9
7
Power Cord
Drain Pipe
Castor Wheels
Hose Clamp
Inlet Hose
10
11
Note : Graphics and Images shown in manual may differ than actual product, it is for reference only
The Lifelong Semi-Automatic Washing Machine will help you with all your laundry needs.
We are confident you will enjoy the superior performance and reliability.
4
MARKING OF PRODUCT:
8
12
4
5
6
7
9
3
10
11
1
2
3
4
5
6
Control Panel
Water Inlet
Wash Lid
Tub
Spin Lid
Base

56
DOS AND DON’TS:
• Please insert the power cord into a rated voltage outlet. Be sure to use a single-
phase three pin outlet. Also, the terminal of the outlet must be grounded. If possible,
please install an electric leakage protector.
• When the machine is in use, place the power plug in a location where it can be easily
inserted and extracted by hand. Be sure to remove the plug if power failure occurs,
when moving or cleaning the machine, or when the machine is idle.
• If the power cord is faulty, in order to avoid risk it must only be replaced by our
authorized after sale service technicians. Remember to keep the pin of the power
plug clean.
• Do not place the machine in a damp place like the bathroom and never wash it
with water. Do not place wet laundry on the control panel.
• Do not use water warmer than 50 °C .
• If the washing machine is installed on the ground near carpet, make sure to keep the
ventilation hole clear of obstruction.
• Do not share the outlet with other electric appliances. If the power plug is damaged or
feels loose when plugged into the outlet, stop using the plug immediately. Rated
current of fuse:5A.
Note : Graphics and Images shown in manual may differ than actual product, it is for reference only
.
8
9
7
Base
Mid Cover
Drain Pipe
Caster Wheel
Power Cord
10
11
2
3
4
5
6
Control Panel
Wash Lid
Tub
Water Selector
Spin Lid
1Water Inlet

7 8
CONTROL PANEL INFORMATION:
• Do not stretch your hands into the working machine. It is dangerous even if the
rotation is slow. Take special care of the children. This appliance is not intended
for use by people (including children) with reduced physical, sensory, or mental
capabilities of, lack of experience and knowledge unless they have been
given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Do not attempt to take apart, repair or alter the machine by yourself.
• Do not put any high temperature or heavy objects on the washing machine.
• Do not wash laundry with volatile or flammable materials (such as thinner,
petrol etc.).
• Disabled children or those not under adult supervision should not operate
the machine.
N
o
r
m
a
l
1
1
2
3
3
4
4
5
2
Water Inlet
LLSWM70D/LLSWM75D
LLSWM80D

910
HOW TO USE:
1. Water Inlet: Used to fill water
2. Wash Timer:
- Used to set Wash timer for washing clothes. Put Clothes in wash tub with water
and detergent.
- Select timer for a time period required from 0-15 minutes.
- A buzzer sound shall indicate the end of wash period.
3. Wash Selector: Select wash options from given programs.
4. Spin Timer:
- This is used to set spin timer for 0-5 minutes.
- After washing, load clothes into spin tub to spin.
5. Water Selector:
- This is used to direct water supply into wash tub or Spin Tub.
Pre-wash:
• The maximum capacity during washing and spinning cycles refers to the max
weight of standard dry laundry that can be washed or spun at one time.
• The laundry quantity during one washing cycle should be lower than the
rated capacity.
• Thickness, size, and the type of cloth will influence actual
capacity.
• It is acceptable to put in a reasonable amount of laundry as the
laundry will be mixed around during the washing process.
• To avoid splashing, do not select the “Maximum” water level for low
loads. Using high suds detergent is not recommended.
• Check to see if the items have special washing requirements
• Do not overload the washer. Stretch and loosen the laundry before
putting it into the washer.
• For heavily soiled laundry, try to remove dirt such as mud or dust first and apply
detergent in advance. This will help to remove the stains more easily.
Detergent Use:
• Method 1 - directly dissolving in the machine:
1. Add a small quantity of water to the machine.
2. Add the detergent powder. Run washing machine for 30 seconds to dissolve
powder completely.
3. Place laundry into the washing machine and select a suitable water level.
• Method 2 - instantly dissolving the detergent powder:
1. Prepare warm water at 30 °C and a container.
2. Add the detergent powder while stirring until it dissolves fully.

11 12
• Laundry powder is more prone to damage laundry than liquid detergent.
Please exercise caution and do not exceed the maximum quantity.
• Dosages of detergent powder may vary. Please follow the instructions on the
detergent
Using Bleach Detergent:
• Add water to suitable levels. Dilute the bleach with a separate container.
Pour it slowly into the washing machine.
• Avoid using whitening agents on laundry with colours and/or patterns as
they are prone to lose colour.
• The whitening agent should not come in direct contact with the laundry.
• Refer to the product instructions for information on proper usage and quantity.
• Dissolve powder whitening agents before use.
Recommended washing procedure:
1. Open the water tap and fill the water tub about half way.
2. Put in the laundry detergent and allow it to disperse well.
3. Put in the clothes to be washed and add water in accordance with the amount
of cloth load.
4. Set the WASH TIMER as desired depending on the fabric type and the degree
of soilage.
5. When washing is finished, set the drain selector to drain.
Note: Ensure that the clothes rotate freely, if not, reduce the cloth load from the machine.
Rinsing and Dry Rinsing:
1. Rinsing: Fill the wash tub appropriately for the number of clothing being washed
and set wash timer for 15 minutes.
2. Intermediate spin rinse: Put clothes inside the spin tub set the water supply selected to
SPIN TUB. Open the water and keep it open for 1-2 minutes and then close the tap.
Spin for 1 minute, and when the rinsing is over, set the drain selector to DRAIN.
Do not keep the water tap open when the spin tub is rotating, otherwise the machine
will malfunction.
Spin Drying:
1. Distribute laundry into the spin tub evenly and smoothly.
2. Insert the gland into the tub properly. Close the inner and outer cover of the
spin tub.
3. Spin Select an appropriate spin time according to the condition of the laundry and
start the spinning cycle.
• During the spinning cycle, if any abnormal sound occurs, it is generally due to the
laundry being placed in a slanted fashion. Please stop the machine and re-arrange the
laundry accordingly.
• During the spinning cycle, the machine will pause if the outer cover of the spin tub is
opened. Close it to resume the spinning cycle.

REFERENCE GUIDE:
Table 1: Detergent Guide
LowWater Level
Amount of Detergent
Amount of Concentrate Detergent
WASH LOAD
40 gm
25 gm 30 gm 38 gm 40 gm
Amount of Softener 22 ml 26 ml 29 ml 35 ml
50 gm 60 gm 64 gm
Medium High Over Flow
Table 2: Laundry Guide
STRONG STRONG
STRONG
STRONG
Wash 15 minutes
Wash 15 minutes
Wash 15 minutes
STRONG
STRONG
GentleWash Selector
Wash Selector
Wash Selector
Gentle
Gentle
System
13 14
• Wipe the entire unit with a soft dry cloth.
• Use neutral detergent to wipe if the machine is excessively dirty.
• Do not apply water directly when cleaning.
• After washing, disconnect the water inlet hose.
• Do not store water in the machine for long periods of time. Drain the water
immediately after each use.
• Pull out the power plug and hang up the power cord.
• Hang up the drain hose. Wipe off water drops on the surface and inside the
machine with a clean, soft cloth.
• Open the cover of the wash cycle compartment and the inner/outer covers
of the spin cycle compartment for a short period (about one hour), then close them.
DEVICE CLEANING:

15 16
PRODUCT SPECIFICATIONS:
TROUBLESHOOTING GUIDE:
TROUBLESHOOTING TABLE:
Model
Max. Rated Capacity Wash
Buzzer
Soak
Max. Rated Capacity Spin
Power Supply
LLSWM70D
7.0 kg
Yes
No
4.5 kg
230V / 50 Hz
LLSWM75D
7.5 kg
Yes
No
4.5 kg
230V / 50 Hz
LLSWM80D
8.0 kg
Yes
Yes
5.0 kg
230V / 50 Hz
Wash Timer
Spin Timer
Net Dimension (mm) W*D*H
Gross Dimension (mm) W*D*H
Net Weight (kg)
Gross Weight (kg)
15 Min
5 Min
750 x 450 x 905
810 x 495 x 955
18 kg
21 kg
15 Min
5 Min
750 x 450 x 960
810 x 495 x 1005
19 kg
22.5 kg
35 Min
5 Min
810 x 480 x 970
830 x 520 x 1010
19 kg
21.5 kg

17 18
Consumer Warranty Card
Dear Customer,
Thank you for choosing a Lifelong consumer product. All Lifelong Consumer products
are designed and manufactured to the highest standards to deliver high quality
performance, as well as easy installation and use. At Lifelong, we believe in
providing not only service, but adding value to your purchase. The warranty has
therefore been designed especially for you with your interest at heart.
Warranty Service
All Lifelong consumer products are covered against manufacturing defects from them
date of purchase.
Name of the product:
Model:
Warranty coverage: 2 Year on product and 5 Years on motor
Please note: Purchase receipt is necessary for warranty verification.
Customer Care: [email protected]
Customer Details
Name:
Address:
Home Number:
Office Number:
E-mail Address:
Product Details
Model No.:
Serial No.:
Purchase Date:
Invoice Number:
Online Site:
Please log on to www.lifelongindiaonline.com and complete the online warranty form with your
personal and product details within 14 days.
Terms and Conditions:
1.This warranty is void if:
a. The completely filled warranty card is not presented
at the time of servicing the product.
b. The product is not operated according to the
instructions given under the user manual.
C. Damages are caused by lightning, abnormal
voltage, water or other liquid intrusion, fire, flood,
accident, negligence or improper handling.
d. Product has been damaged due to installation,
repairs, alterations or modifications by unauthorized
service organizations or persons.
e. Product label specifying the model number, serial
number and production code has been removed
and altered.
f. Defects or parts requiring replacement due to
ordinary wear and tear, corrosion, rust or stains,
scratches, dents on the casing or paintwork of the
product.
g. Claims damaged and/or missing parts
(accessories) after 7 days from the original date of
goods received.
h. Defects or faults in product which have been used
for commercial/industrial purposes or which have
been rented/leased or have been otherwise subject
to non-household/non-domestic use.
2. Repairs or replacements will be carried out by
authorized service provider.
3. During the limited warranty period, Lifelong or its
authorized service provider will repair without charge
the defective unit inclusive of labor and parts and
restore the unit to its optimum working condition. All
defective parts used for the warranty repair should be
surrendered to Lifelong and/or its authorised servicer.
4. All expenses incurred in collecting the unit (s) or
part(s) thereof from authorised service provider as
will as any other expenses and incidentals will be
5. Lifelong obligations are limited to the repair and
replacement of the defective product. Except as set
forth above, there are no other express or implied
warranty and all warrantied, conditions or other terms
implied by statute or common law (including any
warranty of satisfactory quality, merchantability or
fitness for a particular purpose) are excluded to the
fullest extent permitted by the lass.
6. Lifelong total liability for damages relating to or arising
out of the purchase or use of the product regardless of
the type or cause of such damage of the form of
characterization of the claim asserted (e.g. contract or
tort) shall not exceed the original purchase price paid
for the product.
7. However in no event shall Lifelong and Lifelong
authorized distributors be liable for any punitive, special
incidental, indirect or consequential losses or damages
whatsoever (including without limitation, damages for
the loss of revenue, business, profits, goodwill, or
contracts, business interruptions, loss of business
information or any other pecuniary loss.) Whether or
not Lifelong has been advised of the possibility of such
damages.These limitations shall apply not with
standing the failure of the essential purpose of any
limited warranty. This limited warranty does not affect
consumer's statutory rights under the law.
8. No carrier, dealer or employee is thereof authorized to
make modifications to this warranty and you should not
reply on any such representation. Lifelong reserves the
right to amend the terms and conditions if necessary.
