Alliance Laundry Systems P Series User manual

Programming
www.comlaundry.com
Washer-Extractor
Cabinet Hardmount
P-Series Microcomputer
Refer to page 2 for Model Identification
CHM166C
Part No. F232064R3
May 2008
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
© Copyright 2008, Alliance Laundry Systems LLC
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any
means without the expressed written consent of the publisher.
F232064 1
Table of
Contents
Introduction......................................................................................... 2
Model Identification ............................................................................. 2
Nameplate Location.............................................................................. 3
Replacement Parts ................................................................................ 3
Customer Service.................................................................................. 3
Safety Information.............................................................................. 4
Explanation of Safety Messages........................................................... 4
Important Safety Instructions ............................................................... 4
Safety Decals ........................................................................................ 6
Operator Safety..................................................................................... 7
Programming ...................................................................................... 8
P-Series Microcomputers...................................................................... 8
Key Functions In Programming Mode ................................................. 8
Setup Mode........................................................................................... 8
Run Mode or Test Mode .................................................................. 8
Vend Price Enabled or Disabled ...................................................... 9
Coin Blocking Coil or Supply 3....................................................... 9
1 or 4 Amounts to Start.................................................................... 9
Coin Value ....................................................................................... 9
Amount to Start................................................................................ 9
Cycle Programming .............................................................................. 9
Entering Program Mode................................................................... 10
Programming a Cycle ...................................................................... 10
Supply Dispenser .................................................................................. 12
Cycle Segment Charts........................................................................... 13
P-Computer Cycle Charts ..................................................................... 16

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232064
2
Introduction
Model Identification
Information in this manual is applicable to these
models.
HC18PC2 UC18PC2
HC25PC2 UC25PC2
HC35PC2 UC35PC2
HC50PC2 UC50PC2
HC80PC2 UC80PC2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Introduction
3
F232064
Nameplate Location
The nameplate is located at the rear of the machine and
inside door. Always provide the machine’s serial
number and model number when ordering parts or
when seeking technical assistance.
Replacement Parts
If literature or replacement parts are required, contact
the source from whom the machine was purchased
or contact Alliance Laundry Systems LLC at
[phone] for the name and address of the
nearest authorized parts distributor.
Customer Service
For technical assistance, call the following number:
[phone]
Ripon, Wisconsin U.S.A.
CHM167R
1Nameplate
CHM167R
1

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232064
4
Safety Information
Explanation of Safety Messages
Precautionary statements (“DANGER,” “WARNING,”
and “CAUTION”), followed by specific instructions,
are found in this manual and on machine decals. These
precautions are intended for the personal safety of the
operator, user, servicer, and those maintaining the
machine.
Additional precautionary statements (“IMPORTANT”
and “NOTE”) are followed by specific instructions.
IMPORTANT: The word “IMPORTANT” is used
to inform the reader of specific procedures where
minor machine damage will occur if the procedure
is not followed.
NOTE: The word “NOTE” is used to communicate
installation, operation, maintenance or servicing
information that is important but not hazard
related.
Important Safety Instructions
1. Read all instructions before using the washer.
2. Refer to the GROUNDING INSTRUCTIONS in
the INSTALLATION manual for the proper
grounding of the washer.
3. Do not wash textiles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, kerosene, waxes, cooking oils, dry-
cleaning solvents, or other flammable or
explosive substances as they give off vapors that
could ignite or explode.
4. Do not add gasoline, dry-cleaning solvents, or
other flammable or explosive substances to the
wash water. These substances give off vapors that
could ignite or explode.
5. Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS
IS EXPLOSIVE. If the hot water system has not
been used for such a period, before using a
washing machine or combination washer-dryer,
turn on all hot water faucets and let the water
flow from each for several minutes. This will
release any accumulated hydrogen gas. The gas is
flammable, do not smoke or use an open flame
during this time.
6. Do not allow children to play on or in the washer.
Close supervision of children is necessary when
the washer is used near children. This is a safety
rule for all appliances.
7. Before the washer is removed from service or
discarded, remove the door to the washing
compartment.
8. Do not reach into the washer if the wash drum is
moving.
DANGER indicates the presence of a
hazard that will cause severe personal
injury, death, or substantial property
damage if the danger is ignored.
DANGER
WARNING indicates the presence of a
hazard that can cause severe personal
injury, death, or substantial property
damage if the warning is ignored.
WARNING
CAUTION indicates the presence of a
hazard that will or can cause minor
personal injury or property damage if the
caution is ignored.
CAUTION
To reduce the risk of fire, electric shock,
serious injury or death to persons when
using your washer, follow these basic
precautions:
W023
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
5
F232064
9. Do not install or store the washer where it will be
exposed to water and/or weather.
10. Do not tamper with the controls.
11. Do not repair or replace any part of the washer, or
attempt any servicing unless specifically
recommended in the user-maintenance
instructions or in published user-repair
instructions that the user understands and has the
skills to carry out.
12. To reduce the risk of an electric shock or fire, DO
NOT use an extension cord or an adapter to
connect the washer to the electrical power source.
13. Use washer only for its intended purpose,
washing textiles.
14. Never wash machine parts or automotive parts in
the machine. This could result in serious damage
to the basket.
15. ALWAYS disconnect the washer from electrical
supply before attempting any service. Disconnect
the power cord by grasping the plug, not the cord.
16. Install the washer according to the
INSTALLATION INSTRUCTIONS. All
connections for water, drain, electrical power and
grounding must comply with local codes and be
made by licensed personnel when required.
17. To reduce the risk of fire, textiles which have
traces of any flammable substances such as
vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything
containing wax or chemicals such as in mops and
cleaning cloths, must not be put into the washer.
These flammable substances may cause the
fabric to catch on fire by itself.
18. Do not use fabric softeners or products to
eliminate static unless recommended by the
manufacturer of the fabric softener or product.
19. Keep washer in good condition. Bumping or
dropping the washer can damage safety features.
If this occurs, have washer checked by a qualified
service person.
20. If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
21. Be sure water connections have a shut-off valve
and that fill hose connections are tight. CLOSE
the shut-off valves at the end of each wash day.
22. Loading door MUST BE CLOSED any time the
washer is to fill, tumble or spin. DO NOT bypass
the loading door switch by permitting the washer
to operate with the loading door open.
23. Always read and follow manufacturer’s
instructions on packages of laundry and cleaning
aids. Heed all warnings or precautions. To reduce
the risk of poisoning or chemical burns, keep
them out of the reach of children at all times
(preferably in a locked cabinet).
24. Always follow the fabric care instructions
supplied by the textile manufacturer.
25. Never operate the washer with any guards and/or
panels removed.
26. DO NOT operate the washer with missing or
broken parts.
27. DO NOT bypass any safety devices.
28. Failure to install, maintain, and/or operate this
washer according to the manufacturer’s
instructions may result in conditions which can
produce bodily injury and/or property damage.
NOTE: The WARNINGS and IMPORTANT
SAFETY INSTRUCTIONS appearing in this
manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
Any problems or conditions not understood should be
reported to the dealer, distributor, service agent or the
manufacturer.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
F232064
6
IMPORTANT: Ensure that the recommended
clearances for inspection and maintenance
are provided. Never allow the inspection and
maintenance space to be blocked.
Safety Decals
Safety decals appear at crucial locations on the
machine. Failure to maintain legible safety decals
could result in injury to the operator or service
technician.
To provide personal safety and keep the machine in
proper working order, follow all maintenance and
safety procedures presented in this manual. If
questions regarding safety arise, contact the
manufacturer immediately.
Use manufacturer-authorized spare parts to avoid
safety hazards.
This machine must be installed, adjusted,
and serviced by qualified electrical
maintenance personnel familiar with the
construction and operation of this type of
machinery. They must also be familiar
with the potential hazards involved.
Failure to observe this warning may result
in personal injury and/or equipment
damage, and may void the warranty.
SW004
WARNING
Install the machine on a level floor of
sufficient strength. Failure to do so may
result in conditions which can produce
serious injury, death and/or property
damage.
W703
WARNING
Be careful around the open door,
particularly when loading from a level
below the door. Impact with door edges
can cause personal injury.
SW025
CAUTION
Never touch internal or external steam
pipes, connections, or components.
These surfaces can be extremely hot and
will cause severe burns. The steam must
be turned off and the pipe, connections,
and components allowed to cool before
the pipe can be touched.
SW014
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Safety Information
7
F232064
Operator Safety
To ensure the safety of machine operators, the
following maintenance checks must be performed
daily:
1. Prior to operating the machine, verify that all
warning signs are present and legible. Missing or
illegible signs must be replaced immediately.
Make certain that spares are available.
2. Check door interlock before starting operation of
the machine:
a. Attempt to start the machine with the door
open. The machine should not start with the
door open.
b. Close the door without locking it and attempt
to start the machine. The machine should not
start with the door unlocked.
c. Close and lock the door and start a cycle.
Attempt to open the door while the cycle is in
progress. The door should not open.
If the door lock and interlock are not functioning
properly, call a service technician.
3. Do not attempt to operate the machine if any of
the following conditions are present:
a. The door does not remain securely locked
during the entire cycle.
b. Excessively high water level is evident.
c. Machine is not connected to a properly
grounded circuit.
Do not bypass any safety devices in the machine.
NEVER insert hands or objects into
basket until it has completely stopped.
Doing so could result in serious injury.
SW012
WARNING
Never operate the machine with a
bypassed or disconnected balance
system. Operating the machine with
severe out-of-balance loads could result
in personal injury and serious equipment
damage.
SW039
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F232064
8
Programming
P-Series Microcomputers
The computer board is inside the control module. Near
the center of the board is a small toggle switch: this is
the RUN/PROGRAM mode switch.
The switch is normally in the up (RUN mode)
position. To enter PROGRAM mode, flip the switch to
the down position. The display will now show “Pro.”
Since the keypad operates in a slightly different
fashion when in PROGRAM mode, pay careful
attention to the programming instructions provided in
this manual.
Key Functions In Programming
Mode
Hot–The Hot key is used to enter and exit cycle
PROGRAM mode. The Hot key can also be used to
exit SETUP mode.
Warm–The Warm key is used to scroll forward
through program segment steps and setup options.
Cold/Normal–The Cold/Normal key is used to scroll
forward from segment to segment, to increase
numerical values such as step times, coin
denomination, and vend prices, and to switch between
available options.
Cold/Delicate–The Cold/Delicate key is used to enter
SETUP mode. The Cold/Delicate key is also used to
scroll backward from segment to segment, to decrease
numerical values such as step times, coin
denomination, and vend prices, and to switch between
available options.
Setup Mode
Setup options are programmable options that are in
effect for all wash formulas. These options include:
●RUN mode or TEST mode
●Vend price enabled or disabled
●Coin blocking coil or supply 3
●1 or 4 amounts to start
●Coin value
●Amount to start
To enter SETUP mode, press the Cold/Delicate key
while the display is showing “Pro.” Once in SETUP
mode, use the Cold/Normal or Cold/Delicate key to
change the selected option. Use the Warm key to
accept the selected option and move on to the next one.
Press the Hot key at any time to exit SETUP mode.
Run Mode or Test Mode
This setup option allows the machine to be placed in
TEST mode for troubleshooting purposes. When in
TEST mode, the computer allows one cycle to be run
without having to meet the vend price. While that
cycle is running, pressing the keypad keys will
advance the cycle to the next cycle step. The computer
returns to RUN mode upon completion of the test
cycle.
If “tESt” is selected, the machine will be in TEST
mode when the RUN/PROGRAM switch is placed in
the RUN (up) position. If “norN” is selected, the
machine will be in RUN mode when the RUN/
PROGRAM switch is placed in the RUN (up) position.

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
9
F232064
Vend Price Enabled or Disabled
This setup option determines whether or not the vend
price must be met before a cycle can be started. If
“PAY” is selected, the vend price must be met. If
“FrEE” is selected, no vend amount is necessary to
start a cycle.
Coin Blocking Coil or Supply 3
This setup option determines whether the computer
controls a coin blocking coil or allows a supply 3 to be
programmed. If “CoiL” is selected, the computer will
control a coin blocking coil. If “S3” is selected, supply
3 will be available for programming.
1 or 4 Amounts to Start
This setup option determines whether a single vend
price will be used to start any cycle or a separate vend
price will be used to start each cycle.
If “1AtS” is selected, a single vend price will be used
for all four cycles. When in RUN mode, the display
will flash “PAY” alternately with the vend price.
If “4AtS” is selected, each cycle will have a separate
vend price. When in RUN mode, the display will scroll
through the four cycles, alternately showing the
respective vend price for each cycle.
Coin Value
This setup option establishes the value of the coin type
accepted by the coin meter. Use the Cold/Normal and/
or Cold/Delicate keys to set this value. If either of
these keys is pressed and held, the displayed value
changes more rapidly.
Amount to Start
This setup option sets the vend price (or prices)
necessary to start a cycle. If “1AtS” was selected
during setup, one value will be available for
modification. If “4AtS” was selected during setup, the
vend price for each cycle will be available for
modification. Use the Cold/Normal and/or Cold/
Delicate keys to set the vend price value(s). If either of
these keys is pressed and held, the displayed value
changes more rapidly.
Cycle Programming
To edit an existing cycle, press the Hot key while the
display is showing “Pro.” The display will show “CY
?” Press the key which corresponds to the desired
cycle (Hot, Warm, Cold/Normal and Cold/Delicate).
The display will show “PrE.” The computer is now in
cycle programming mode.
All 4 cycle programs can be customized within a
preset program structure. Each cycle program consists
of 6 program segments. See Table 1.
When modifying a cycle, a time must be entered for
each segment. To skip a segment or spin, set the time
to “00.” Refer to Tabl e 2 for time parameters for each
segment and spin.
Cycle Program Segments
Segment Display Segment Display
Prewash PrE Rinse 2 rin2
Wash UASH Rinse 3 rin3
Rinse 1 rin1 Rinse 4 rin4
Table 1
Time Parameters
Function Minimum Maximum
Prewash 60 seconds 1800 seconds
Wash 60 seconds 1800 seconds
Rinse 1 60 seconds 300 seconds
Rinse 2 60 seconds 300 seconds
Rinse 3 60 seconds 300 seconds
Rinse 4 60 seconds 300 seconds
Intermediate Spin 60 seconds 120 seconds
Final Spin 60 seconds 600 seconds
Table 2

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232064
10
Entering Program Mode
1. Unlock and raise top cover.
2. Remove control module cover.
3. Locate the Run/Program Mode switch near
center of computer board inside control module.
Refer to Figure 1.
Figure 1
4. Flip switch to down position to enter PROGRAM
Mode. Display will show “PrE”.
Programming a Cycle
1. Select the cycle number to program: CY1, CY2,
CY3 or CY4 by pressing Hot, Warm, Cold/
Normal or Cold Delicate.
2. Press the Cold/Normal or Cold/Delicate key until
the computer display shows the segment to be
edited. The Cold/Normal key scrolls forward
through the segments and the Cold/Delicate key
scrolls backwards through the segments.
NOTE: The computer will exit cycle programming
mode if one of the following happens:
•The Hot key is pressed.
•The Warm key is pressed when the final spin
time is displayed.
•The Warm key is pressed when the time of
“00” is displayed for “rin4.”
•The Cold/Normal key is pressed when the
display shows “rin4.”
•The Cold/Delicate key is pressed when the
display shows “PrE.”
3. Once the desired segment is displayed, press the
Warm key. The Warm key is used to step forward
through the cycle segment steps.
4. Use the Cold/Normal or Cold/Delicate key to set
the desired segment time. Set the value to “00” to
skip the segment. Press the Warm key.
NOTE: The computer does not count down the
remaining cycle time during fills or drains. The
computer resumes counting down cycle time once
the programmed fill level is reached and when the
machine has drained.
5. Use the Cold/Normal or Cold/Delicate key to
select the desired fill temperature. Refer to
Table 3.
Refer to the Cycle Segment Chart section for detailed
descriptions of cycles.
6. Press the Warm key.
7. Use the Cold/Normal or Cold/Delicate key to
select the desired fill level. Refer to
Table 4.
B152R
1Run/Program Mode Switch
2Computer Board
1
2
Fill Temperature Options
Display Fill Type
CFIL Cold fill
HFIL Hot fill
bFIL Warm fill
Table 3
Water Level Options
Display Fill Level
LOLE Low Level
HILE High Level
SLUC* Overflow
*Machines shipped to France only.
Table 4
To avoid personal injury, recommended
inlet water temperature should be no
higher than 125°Fahrenheit (51°Celsius).
W709
WARNING

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
11
F232064
NOTE: “SLUC” is only available in the prewash
segment. If “SLUC” is selected, the segment time
will begin counting down once high level is reached.
The fill valve(s) will remain on for the timed
duration of the segment.
8. Press the Warm key.
9. For wash and rinse 1 segments only, use the
Cold/Normal or Cold/Delicate key to enable or
disable the bleach step. If “nobL” is selected, the
bleach step is disabled. If “bL” is selected, the
bleach step is enabled. Press the Warm key.
10. For prewash, wash, rinse 1, and rinse 4 segments
only, use the Cold/Normal or Cold/Delicate key
to enable or disable the supply step. If “nSUP” is
selected, the supply step is disabled. If “SUP” is
selected, the supply step is enabled. Press the
Warm key.
11. If the supply step was enabled, use the Cold/
Normal or Cold/Delicate key to select the desired
supply option. Refer to Table 5.
12. Press the Warm key.
13. Use the Cold/Normal or Cold/Delicate key to
select the desired spin time. Set this value to ”00”
to skip the spin step. Press the Warm key. The
display will now show the identifier for the next
program segment.
14. Press the Hot key at any time to complete the
cycle programming procedure.
15. Flip switch to up position to return to RUN mode.
Supply Options
Display Supply
SUP1 Supply 1
SUP2 Supply 2
SUP3* Supply 3
* Supply 3 is available only if the “S3”/“CoiL” setup
option is set to “S3.”
Table 5

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232064
12
Supply Dispenser
The supply dispenser compartments are designated 1,
2, and 3, in that order, viewed from the front of the
machine, left to right.
Compartment 1 flushes with each fill. Compartment 2
flushes when the program calls for supply 2 during a
fill. Compartment 3 flushes when the program calls for
supply 3 during a fill.
If the program calls for a coin blocking coil instead of
supply 3 during a fill, compartment 3 flushes with
compartment 2.
Figure 2
Figure 3
MW005B
1Detergent
2Bleach
3Softner
Supply Dispenser
Compartments
123
MW005B
18-Pound, 25-Pound, 27-Pound, 35-Pound,
and 50-Pound Capacity Machines
CHM514R
1Detergent
2Bleach
3Softner
CHM514R
80-Pound Capacity Machines
123
Supply Cups
Supply Dispenser
Compartments

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
13
F232064
Cycle Segment Charts
Segment 1 (Prewash)
Display
Instructions
Use the Cold/Normal or Cold/Delicate key to change.
Press the Warm key to advance.
PrE
00 or 60 to 1800 Select segment time: 60 to 1800 seconds (00 to skip segment)
HFIL, CFIL, or bFIL Select “HFIL” (hot fill), “CFIL” (cold fill), or “bFIL” (warm fill)
LOLE, HILE,
or SLUC
Select fill level: “LOLE” (low water level), “HILE” (high water level), or “SLUC” (overflow
fill)
nSUP or SUP Select “nSup” (supply step disabled) or “SUP” (supply step enabled)
SUP1–SUP3* Select supply 1–3
SPIn (flashed for one second)
tINE (flashed for one second)
00 or 60 to 120 Select time for spin: 60 to 120 seconds (00 for no spin)
* Available only if “SUP” is selected. “SUP3” is available only if the “S3”/“CoiL” setup option is set to “S3.”
Tabl e 6
Segment 2 (Wash)
Display
Instructions
Use the Cold/Normal or Cold/Delicate key to change.
Press the Warm key to advance.
UASH
00 or 60 to 1800 Select segment time: 60 to 1800 seconds (00 to skip segment)
HFIL, CFIL, or bFIL Select “HFIL” (hot fill), “CFIL” (cold fill), or “bFIL” (warm fill)
LOLE or HILE Select fill level: “LOLE” (low) or “HILE” (high) water level
nobL or bL Select “nobL” (supply step disabled) or “bL” (supply step enabled)
nSUP or SUP Select “nSup” (supply step disabled) or “SUP” (supply step enabled)
SUP1–SUP3* Select supply 1–3
SPIn (flashed for one second)
tINE (flashed for one second)
00 or 60 to 120 Select time for spin: 60 to 120 seconds (00 for no spin)
* Available only if “SUP” is selected. “SUP3” is available only if the “S3”/“CoiL” setup option is set to “S3.”
Tabl e 7
Cycle Segment Charts (continued)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232064
14
Cycle Segment Charts (continued)
Segment 3 (Rinse 1)
Display
Instructions
Use the Cold/Normal or Cold/Delicate key to change.
Press the Warm key to advance.
rin1
00 or 60 to 300 Select segment time: 60 to 300 seconds (00 to skip segment)
HFIL, CFIL, or bFIL Select “HFIL” (hot fill), “CFIL” (cold fill), or “bFIL” (warm fill)
LOLE or HILE Select fill level: “LOLE” (low) or “HILE” (high) water level
nobL or bL Select “nobL” (supply step disabled) or “bL” (supply step enabled)
nSUP or SUP Select “nSup” (supply step disabled) or “SUP” (supply step enabled)
SUP1–SUP3* Select supply 1–3
SPIn (flashed for one second)
tINE (flashed for one second)
00 or 60 to 120 Select time for spin: 60 to 120 seconds (00 for no spin)
* Available only if “SUP” is selected. “SUP3” is available only if the “S3”/“CoiL” setup option is set to “S3.”
Tabl e 8
Segments 4 and 5 (Rinses 2 and 3)
Display
Instructions
Use the Cold/Normal or Cold/Delicate key to change.
Press the Warm key to advance.
rin2 or rin3
00 or 60 to 300 Select segment time: 60 to 300 seconds (00 to skip segment)
HFIL, CFIL, or bFIL Select “HFIL” (hot fill), “CFIL” (cold fill), or “bFIL” (warm fill)
LOLE or HILE Select fill level: “LOLE” (low), or “HILE” (high) water level
SPIn (flashed for one second)
tINE (flashed for one second)
00 or 60 to 120 Select time for spin: 60 to 120 seconds (00 for no spin)
Tabl e 9
Cycle Segment Charts (continued)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
15
F232064
Cycle Segment Charts (continued)
Segment 6 (Rinse 4)
Display
Instructions
Use the Cold/Normal or Cold/Delicate key to change.
Press the Warm key to advance.
rin4
00 or 60 to 300 Select segment time: 60 to 300 seconds (00 to skip segment)
HFIL, CFIL, or bFIL Select “HFIL” (hot fill), “CFIL” (cold fill), or “bFIL” (warm fill)
LOLE or HILE Select fill level: “LOLE” (low), or “HILE” (high) water level
nSUP or SUP Select “nSup” (supply step disabled) or “SUP” (supply step enabled)
SUP1–SUP3* Select supply 1–3
SPIn (flashed for one second)
tINE (flashed for one second)
00 or 60 to 600 Select time for spin: 60 to 600 seconds (00 for no spin)
* Available only if “SUP” is selected. “SUP3” is available only if the “S3”/“CoiL” setup option is set to “S3.”
Table 10

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
F232064
16
P-Computer Cycle Charts
P-Computer Standard Cycles
Program Hot Warm Cold/Normal Cold/Delicate
Prewash
Time (Sec) 120 120 120 00
Water Warm Warm Cold ---
Level High High High ---
Supply No No No ---
Spin (Sec) 60 60 60 ---
Wash
Time (Sec) 240 240 240 240
Water Hot Warm Cold Cold
Level Low Low Low Low
Bleach Yes Ye s Ye s No
Supply 1 1 1 1
Spin (Sec) 60 60 60 60
Rinse 1
Time (Sec) 90 90 90 90
Water Cold Cold Cold Cold
Level High High High High
Bleach No No No No
Supply No No No No
Spin (Sec) 60 60 60 60
Rinse 2
Time (Sec) 90 90 90 90
Water Cold Cold Cold Cold
Level High High High High
Spin (Sec) 60 60 60 60
Rinse 3
Time (Sec) 00 00 00 00
Water --- --- --- ---
Level --- --- --- ---
Spin (Sec) --- --- --- ---
Rinse 4
Time (Sec) 90 90 90 90
Water Cold Cold Cold Cold
Level High High High High
Supply 2 2 2 2
Spin (Sec) 240 240 240 120
Table 11

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Programming
17
F232064
P-Computer cycle charts (continued)
Cycle:
Prewash Wash Rinse 1
Time (Sec) Time (Sec) Time (Sec)
Water Water Water
Level Level Level
Supply Bleach Bleach
Drain Supply Supply
Spin (Sec) Drain Drain
Spin (Sec) Spin (Sec)
Rinse 2 Rinse 3 Rinse 4
Time (Sec) Time (Sec) Time (Sec)
Water Water Water
Level Level Level
Spin (Sec) Spin (Sec) Supply
Spin (Sec)
Table 12
