Lifestyle L3218 User manual

L3218
L3220
Transporter-
Aluminum Wheelchair
Transport Chair
2 in 1
WEIGHT CAPACITY
300 LBS
Available Colors:

Unfold Transporter by tilting to one side and pushing down on seat rails.
Lift Backrest using the handgrips until both Release Levers lock into place.
Attach Footrests by aligning holes on Footrests with hinge pins on outside of front
frame then swing Footrests to front until Footrest Release Levers lock into place.
Adjust Footrest length by loosening the Screw Knob and moving the inner tubing
up or down to desired setting making sure the Footplate is at least 2 ½ inches
from the floor for proper clearance. Then tighten Screw Knob until secure.
USER MANUAL - Transporter Aluminum Wheelchair Transport Chair 2 in 1
GENERAL EXPLANATION
2
1
2
3
ASSEMBLY INSTRUCTIONS
To Fold the Translator for Storage
Read entire manual and save for future reference. If you do not understand
any part of this manual or require additional assistance, contact your healthcare
provider or your Lifestyle Mobility Aids Dealer. Failure to follow the instructions in
this manual can lead to personal injury and/or property damage.
4
Push Handle
Armrest Height Adjustment Button
Mesh Storage Pocket Fold Down
Backrest
Release Lever
Hand Grip
Heel Strap
24” Rear Wheel
Footplate
To Set Up the Translator for Use
1
Make sure the Footrests are in the forward locked position with the Footplates in
the vertical position or REMOVE the Footrests by pulling the Release Levers,
swinging the Footrests outward and lifting them from the hinge pins.
Push the Release Levers on the Backrest toward the chair and fold down.
Standing behind the chair, grab the center of the seat and pull up until
2
3
Soft Side Guards
Footrest Release Lever
7” Caster
Quick Release
Axle Button
8” Rear Wheel
Tipping Lever
Footrest Height
Adjustment Screw Knob
Wheel Locks (4)
2 for 24” Wheel &
2 for Rear 8” Wheel
fully closed.

3
(See Figure 3)
When the Armrests are lowered completely, they fit easily under a desk or table.
(See Figure 4)
Converting from Wheelchair to Transport Chair
Press and hold the Quick Release Button in the wheel hub and
The chair is now ready for use with an
(See Figure 5)
NOTE: Attendant should always let the user know what actions
Converting from Transport Chair to Wheelchair
Lift the chair slightly and while holding in the Quick Release
Axle Bushing. Release the button
wheels should spin freely and not
be able to be pulled off. (See Figure 6)
FIGURE 3 FIGURE 4
FIGURE 5
FIGURE 6
Axle
Axle
Bushing
Adjusting Armrests
Lowered
Raised
OPERATING INSTRUCTIONS
Make sure Wheel Locks are engaged before entering or exiting the Transporter and that the
Front Casters are in the forward position which increases the wheelbase to help prevent tipping.
User Operated Wheel Locks on the 24” Wheel engage by pushing the levers forward until
they lock into place and disengage by pulling back on the levers until the wheels roll freely.
(See Figure 1)
Attendant Operated Wheel Locks on the 8” Rear Wheel engage by pulling up on the levers
until they lock into place and disengage by pushing down on the levers until the wheels
(See Figure 2)
Operating Wheel Locks
FIGURE 1 FIGURE 2
roll freely.
Button, insert the Axle into the
and test the wheel is secure by pulling it away from the chair.
When installed correctly, the
pull away from the chair.
Attendant.
they are preparing to take.
To adjust Armrests, hold in Adjustment Button while raising or lowering the armrest.
Then release Adjustment Button into the desired setting.

MAINTENANCE
› Clean frame with a damp cloth and dust weekly.
› Clean upholstery and armrests with mild soap and water.
› Never use abrasive cleaners or scouring pads.
› If exposed to liquid, dry the wheelchair thoroughly as soon as possible.
› If any component appears worn or is not working properly, contact your dealer
for repair and/or appropriate replacement parts.
WARRANTY
Limited Lifetime warranty against manufacturing defects.
This warranty does not cover product failure due to misuse, negligence, improper storage or handling,
improper operation or unauthorized modifications.
Normal wear and tear on non-durable components, such as rubber accessories and casters are not covered under this
warranty. These items are subject to normal wear and need periodic replacement.
For Warranty Service, it is recommended but not required that the product be returned to the Lifestyle Mobility Aids dealer
through whom it was originally purchased. However, all Lifestyle Mobility Aids Dealers are qualified to assist you in obtaining
warranty service. If the product is to be returned to Lifestyle Mobility Aids, prior authorization will be required. In the event
of a defect covered by this warranty, Lifestyle Mobility Aids will determine if the product will be repaired or replaced.
This Lifestyle Mobility Aids product is identified by a serial number at the time of manufacture. Removing or defacing the
serial number label may void this warranty. If you have questions about your Lifestyle Mobility Aids product or this warranty,
please contact us at [e-mail].
SAFETY PRECAUTIONS
› Do not operate on streets, roadways, grass, slippery surfaces, stairs or escalators.
› Do not use as an occupant restraint in a motor vehicle. User must always transfer to
the vehicle seat and use the restraint provided by the vehicle manufacturer.
› Wheel locks are not brakes and are not to be used when wheelchair is moving.
Wheel locks are only intended to keep the wheelchair in place when it is at a complete stop.
› Always engage wheel locks before transferring and when using a wheelchair lift or elevator.
› Do not attempt inclines or declines greater than a 10% grade.
› Do not turn wheelchair while going downhill, as wheelchair could tip over.
› Do not stand or step on the footplates while transferring to or from your wheelchair. This could
cause the wheelchair to tip or may cause personal injury or damage to your wheelchair.
› The footplates should not be set lower than 2.5” from the floor to permit proper
clearance of potential obstructions.
› To reduce the risk of tipping: Before leaning or reaching forward, sit back in the seat and make
sure casters are rotated fully toward front of wheelchair. Do not lean over the top of the wheelchair
back. Do not tie down or attach anything to the wheels. Do not stand on Footplates.
› Unauthorized modification or the use of unauthorized replacement parts could change
the structure of the wheelchair, void the warranty, and create a hazardous condition resulting in
serious personal injury.
Improper use of the Transporter may result in personal injury and/or property damage.
Lifestyle Mobility Aids is not liable for personal injury or property damage due to failure to
follow the instructions or recommendations in the manual or improper use of this product.
If you discover a problem, contact your Lifestyle Mobility Aids Dealer for assistance.
