TO SET UP WHEELCHAIR
Open wheelchair by tilting to one side and pushing
down on seat rail until opened.
Attach foot rests by aligning holes on tabs at top of
foot rests with hinge pins on outside of front frame,
then swing foot rests to front until Foot Rest release
levers lock into place.
Adjust foot rest length (while user is seated) by
loosening the cam lever just above the foot plate,
pushing in the adjustment button and sliding the
inner tubing up or down to desired setting until the
adjustment button protrudes fully from the
adjustment hole. Then snap cam lever back into
place.
Make sure the foot plate is at least 2.5” from the floor
for proper clearance.
TO FOLD WHEELCHAIR FOR STORAGE
Make sure the foot rests are in the forward (locked) position
with the foot plates in the vertical position or remove the foot
rests by pulling the release levers, swinging the foot rests
outward and lifting them from the hinge pins.
Standing behind the chair, grab the center of the seat and
pull up until closed.
Clean frame with a damp cloth and dust weekly.
Clean upholstery and armrests with mild soap and
water.
Never use abrasive cleansers or scouring pads.
If exposed to liquid, dry the wheelchair thoroughly as
soon as possible.
If any component appears worn or is not working
properly, contact an authorized dealer for repair
and/or appropriate replacement parts.
Solid rubber tires need minimal maintenance, but
should be cleaned occasionally with a damp cloth.
If tires become severely worn or cracking appears,
contact an authorized dealer.
Wheels and Casters should be checked periodically
and adjusted and lubricated as needed by an
authorized dealer.
V2: 3/05/21
Lifestyle Mobility Aids
[e-mail]
www.lifestylemobilityaids.com
1-877-843-6464
3200 Tyrone Blvd N
St. Petersburg, FL 33710

M170-1-116SF
M170-1-116ELR
M170-1-118SF
M170-1-118ELR
M170-1-120SF
M170-1-120ELR
Limited Lifetime warranty against manufacturing defects.
This warranty does not cover product failure due to misuse,
negligence, improper storage or handling, improper operation
or unauthorized modifications.
Normal wear and tear on non-durable components, such as
rubber accessories and casters are not covered under this
warranty. These items are subject to normal wear and need
periodic replacement.
For Warranty Service, it is recommended but not required that
the product be returned to the Lifestyle Mobility Aids dealer
through whom it was originally purchased. However, all
Lifestyle Mobility Aids Dealers are qualified to assist you in
obtaining warranty service. If the product is to be returned to
Lifestyle Mobility Aids, prior authorization will be required.
In the event of a defect covered by this warranty, Lifestyle
Mobility Aids will determine if the product will be repaired or
replaced.
Do NOT attempt to adjust or operate wheelchair without
reading carefully all instructions in this manual.
Do NOT use as an occupant restraint in a motor vehicle. User
must always transfer to the vehicle seat.
Do NOT operate on streets, roadways, grass, slippery
surfaces, stairs or escalators.
Wheel locks are not brakes and are not to be used when
wheelchair is moving. Wheel locks are only intended to keep
the wheelchair in place when it is at a complete stop.
Always engage wheel locks before transferring and when
using a wheelchair lift or elevator.
Do NOT attempt inclines or declines greater than a 10% grade.
Do NOT stand or step on the foot plates while transferring to
or from your wheelchair. This could cause the wheelchair to
tip or may cause personal injury or damage to your
wheelchair.
To reduce the risk of tipping: Before leaning or reaching
forward, sit back in the seat and make sure casters are
rotated fully toward front of wheelchair. Do not lean over the
top of the wheelchair back. Do not tie down or attach
anything to the wheels. Do not stand on Foot Plates.
Unauthorized modification or the use of unauthorized
replacement parts could change the structure of the
wheelchair, void the warranty, and create a hazardous
condition resulting in serious personal injury.
Flow
Wheelchair
300 LBS
WEIGHT CAPACITY
