BraunAbility RBC User manual

BUTTERFLY CLIPS
User Manual
EN Instructions for tting and use

2RBC, RBCL
Thank you for choosing
Buttery Clips
from BraunAbility!
The following manual is an important part of the product, providing
you with information on how to achieve maximum performance
and safe operation. Keep the manual in a safe place so that you can
refer to it when necessary.
If you have any questions about your equipment, please contact us.
Once again, thank you for placing your condence in our products!
Safe vehicle adaptation solutions
For your safety BraunAbility products are
designed and tested according to current
directives and standards.

Safety information
Fit and use
After care
Limitation of use
Fitting the Buttery Clips onto the seat frame
Space parts & ancillary items
Equipment storage and maintenance
Warranty
4
6
7
8
8
3
RBC, RBCL
EN
Index
“Declaration of conformity” at the end of the manual.

Limitation of use
Safety information
4RBC, RBCL

Buttery Clip with M8 bolt - RBC
Buttery Clip with M10 bolt - RBCL
5
RBC, RBCL
EN
Fit and use

Fitting the Buttery Clips on to the seat frame
Fit and use
M2 Application Only
1. Two pairs of Buttery Clips are normally required for each seat.
2. If it is intended that the seat should face the rear please contact BraunAbility.
3. Place the xings in the rails where the seat is to be positioned.
4. Remove the washer and nut from each xing.
5. Position the seat on the xings, place a washer & nut on all studs and tighten; a screw
tightening torque of 40Nm (30lbft) is recommended.
6. To achieve maximum strength as an assembly the xing studs must protrude beyond
the nut by a minimum of 1.5mm
6RBC, RBCL

WARNING
If it is intended that the seat should face the rear,
please contact BraunAbility.
Space parts & ancillary items
Fit and use
RBC
1. NC-U3/8-Z 3/8” UNF Binx Nut
2. WA-M10-Z Washer
RBCL
1. NC-M10-Z M10, Nyloc Zinc Plate Nut
2. WA-M10-Z Washer
Additional washers and binx nuts can be purchased.
Please contact sales ofce for details.
7
RBC, RBCL
EN
Fit and use

Equipment storage and maintenance
After care
Regularly inspect Buttery Clips for damage, wear or malfunction. If any problems are identied
replace immediately.
Warranty
BraunAbility products are extensively tested using BraunAbility anchorage systems, and our full
warranty normally only applies to BraunAbility equipment when used with BraunAbility branded
anchorages or as instructed.
BraunAbility have also participated in test programs with other manufacturers anchorage
products and will support warranty on the BraunAbility products when used in conjunction with
such jointly tested systems.
For further details on specic applications please contact the Sales Ofce. In other situations,
using BraunAbility products, for which BraunAbility has not participated in a joint test program,
a limited BraunAbility warranty will apply.
8RBC, RBCL

Declaration of conformity
Conforms to following directives
standards and regulations /
2001/85/EC Annexe VII Paragraphs 3.8.2.8 & 3.8.2.9
76/115/EEC
R.14.07
R.107.06
BS EN 1789:2007+A2:2014
BraunAbility, Martock, 14th June 2019
Rob Butcher
Director of Engineering
Manufacturer /
BraunAbility UK Ltd
Unwin House
The Horseshoe Coat Road
Martock, Somerset, TA12 6EY
UK
Phone: [phone]
E-mail: [e-mail]
www.braunability.eu
Declares that the products /
RBC, RBCL

Accredited by URS as testing laboratory in accordance with ISO/IEC 17025:2005
Quality system certied in accordance with ISO 9001:2008
Illustrations, descriptions and specications in the user manual are based on current product information.
BraunAbility UK Ltd reserves the right to make alterations without previous notice.
© 2019 BraunAbility UK Ltd

UI1566C
