Lifetime 125 Quick start guide

®
4/05/2007
VISIT THE LIFETIME WEB SITE:
WWW.LIFETIME.COM
30” Shed Extension Kit for Existing
11’ Sheds
MODEL #0125
ASSEMBLY
INSTRUCTIONS AND
OWNER’S MANUAL
Save this instruction in the event you must contact the manufacturer for replacement parts.
For Assistance, including missing or broken parts,
Call Customer Service at:
1 [phone]
** Do Not Contact the Store **
INSTRUCTION #1026972
Copy

BEFORE BEGINNING ASSEMBLY
Identify and inventory all parts using the checklist boxes on the Parts List. Keep the
hardware bags and their contents separate. If any parts are missing, call our Customer
Service Department.
**A MINIMUM OF TWO ADULTS ARE REQUIRED FOR ASSEMBLY**
SAFETY INSTRUCTIONS
Failure to follow these safety instructions may result in serious injury or property damage. Proper and complete
assembly, use and supervision is essential for proper operation and to reduce the risk of accident or injury. A high probability
of serious injury exists if this display is not installed, maintained, or operated properly. • If using a ladder during assembly,
use extreme caution. Follow all warnings and cautions on the ladder carefully. • 2 people are required for assembly. •
Misuse could result in system failure. • If technical assistance is required, contact the manufacturer.
Most injuries are caused by misuse and/or failure to follow instructions.
PARTS LIST
AA 1020443 Center Roof Cap 1
AB 1019503 Gutter Channel 2
AC 1007977 Wall Support Channel 2
AD 1007988 Truss Channel 1
AE 1007996 Inner Roof Panel 2
AF 1007997 Wall Panel 2
AG 1009232 Skylight 1
AJ 1008000 Inner Floor Panel 2
AK 1008001 Roof Support Strip 4
AM 1020423 Truss Support Strip 2
Shed Parts Box [1019238]
Skylight Hardware Bag [1011616] 1
LA BW01200 #10-1” Fender Washer 7
LB 1010132 #10 x 5/8” Pan Head Screw 7
Truss Extension Hardware Bag [1016014] 1
FA 1009117 Floor Bracket 2
FB 300072 1/4” x 1 1/2” Hex Bolt 11
FC BN00300 1/4” Cap Nut 11
FD 1012933 Center Gutter Connector 1
Shed Screw Hardware Bag [1011615] 1
SS BS07500 1/4” x 5/8” Screw 60
SS
LB
LA
FB
FC
1. 7/16” Wrenches (2)
2. 3/8” Wrenches (2)
3. #2 Phillips screwdriver or
Electric drill with phillips head
Tools and Materials Required for
Assembly
(Not Included)
FA
FD

3
AA AE AF AG
AC
AB
AD
HARDWARE IS NOT ACTUAL SIZE
(unless otherwise indicated)
If you are Extending an New Shed
1. To obtain instructions for extending a new shed, contact our Customer Service Department.
AJ AK
AM
1 [phone]
To extend a never assembled shed,
Call Customer Service for Instructions:
a. This extension kit adds another 30” to the length of your shed. Before beginning expansion of your shed be
sure that your site can accomodate the new size.
Site Selection

4
Opt. 2.1: Remove the four Lower Roof Panels and two Center Roof Caps
(leave Skylights in place) that are highlighted below.
Opt. 2.2: Remove all screws from the highlighted Wall Panel that connect it to adjoing Wall Panels
and to the Wall Support.
**Save all hardware for re-assembly!**
ATTENTION: If your existing shed is anchored to the ground, remove all
anchoring hardware before following these steps.
Option 2: Add Extension Kit to an Existing Shed
Note: Your shed may be shorter than shown above. Skip the very back Roof Panels (slightly more nar-
row than the middle Roof Panels) and then remove the next two Roof Panels from each side of the shed
(along with the connected Roof Caps).
Repeat Steps 2.2 through 2.4 for both sides of the shed.
Remove
this panel.
Remove
this panel.

5
Opt. 2.3: Tip the Wall Panel inward.
Opt. 2.4: Use a long at screwdriver to gently pry the bottom corner of the Wall Panel so that it has room to slide
on the inside of other Wall Panels. Slide the Wall Panel to the left, and then remove the panel.
Note: To remove a Wall Panel, slide it to the left (when looking at it from inside the
shed) until it lifts out.
Note: As you remove the Wall Panels, have one person support the Truss assembly so that it does not
fall over.

6
Opt. 2.5: Remove the Truss assembly and set it aside for later.
Opt. 2.6: With at least on person on each side of the shed, tip the back section of the shed forward to about a 45
degree angle and slide the back section away from the shed..

7
Opt. 2.7: Fit together the two Inner Floor Panel extensions (AJ).
Opt. 2.8: Connect the Inner Floor Panel extensions (AJ) to the other Inner Floor Panels on the main section
of the shed.
AJ
AJ
Opt. 2.9: With at least on person on each side of the shed, tip the back section of the shed forward to about a 45
degree angle and slide it forward to re-connect it to the rest of the shed.

8
Finger Tighten Hardware
AM AM
WARNING
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department at the number
on Page One. Exposed threads on the end of
the Bolt may cause serious injuries.
Opt. 2.11: Attach a Gutter Channel (AB) (Truss Support Strips (AM) t inside Gutter Channel (AB)). Attach
Truss Channel (AD) to Gutter Channel (AB) at each end.
AB
AB
AB
AM (x2)
FB
FC
FB
FC
Tighten All Hardware
Opt. 2.12: Attach Truss Assembly to two Wall Support Channels (AC). Do not completely tighten the Cap Nut
(FC) until after truss is secured to the wall.
AC
FB
FC Use Second
Holes from
the end.
AB
AC
FD
FB
FC
AB
AB
AM
Opt. 2.10: Fit two Truss Support Strips (AM) together. Bolt Truss Support Strips (AM), Center Gutter
Connector (FD) and two Gutter Channels (AB). Refer to the Owner’s Manual that came with your shed when
assembling other truss frames.

9
Note: As new panel slides into place be sure that screw bosses along the sides interlock
properly with the adjoining Wall Panels.
1
2
1. Set Wall Panel Tabs into Floor Panel Slots.
2. Slide Wall Panel to the left until the Wall Panel locks into place.
3. Use a Rubber Mallet to nudge the panel into position. Be careful
not to damage the edge of the wall panel.
3
Opt. 2.13: Replace the two Wall Panels that were previously removed. Add the two new Wall Panels that came
with this kit.
Opt. 2.14: Replace the Truss assembly that was previously removed. Add the new Truss assembly from steps
2.9 to 2.11.

10
Opt. 2.15: Replace the four Lower Roof Panels that were previously removed. Add the two new Lower Roof
Panels that came with this kit.
Opt. 2.16: Install the Skylight (AG) into the Center Roof Cap (AA) that came with this Kit.
Opt. 2.17: Install both Center Roof Caps (with Skylights) onto the shed.
Attach Roof Cap (AA) to Truss on both
sides with 1/4” x 5/8” Screws (SS).
Attach Skylight with #10 Washers
(LA) and #10 x 5/8” Screws (LB).
Only use a hand
screwdriver for the
Skylights
AA
AG

11
Congratulations on your Lifetime®Outdoor Shed purchase. By following the
instructions below, your new Lifetime shed should provide you with years of service
and enjoyment.
Cleaning and Care
The polyethylene walls and shelves are stain- and solvent resistant. To clean, use a mild soap and a soft-bristled
brush. Abrasive cleaning materials may scratch the plastic and are not recommended. Repair scratches or
rust spots on the metal by Sanding the affected area lightly; using a rust preventative spray primer; and nally,
spraying with a high-gloss spray enamel paint. Avoid placing a direct heat source on or near surfaces unless
using a heat barrier.
For warranty details or to register your product, visit
www.lifetime.com or call 801-776-1532
Model #
0111 Window Shutters
Two decorative window shutters.
0112 Shed Lights (2 pack)
Two battery powered Touch Lights.
0113 16” Pegboard Strips w/ hardware
Two sixteen inch Pegboard Strips with hooks. Great for hanging large items such as:
rakes, shovels, or other tools.
0114 10” Shelf Kit w/ hardware (5 pack)
Five 30” x 10” Shelves with hardware.
0115 14” Shelf Kit w/ hardware (5 pack)
Five 30” x 14” Shelves with hardware.
6426 60” Shed Extension Kit w/ 2 windows
Extend your shed ve feet for the ultimate storage building.
Enhance your Lifetime®Outdoor Shed by purchasing the following Shed
Accessories:
Or call:
1 [phone]
To purchase shed accessories, visit us at:
www.buylifetime.com
