LifeTrak Core C200 Technical manual

Information Guide

The bands of your C200 are reversible and replaceable:
1. Carefully slide the bands off the Core. The bands can
slide in either direction.
HOW TO
CHANGE
YOUR
BANDS
C200 bands are available in a variety of colors.
Visit us at LifeTrakUSA.com
1

Clasp plate
2. On the short band (top band), remove the Clasp plate
by pulling up and away from the band.
HOW TO
CHANGE
YOUR
BANDS
2

3. Place the Clasp on the reverse side of the band into
VJGVYQJQNGU2TGUUſTON[CTQWPFVJGVYQJQNGUVQ
secure the Clasp. You may hear it snap in place.
Make sure the base of the Clasp pins are fully secured
into the band (see image below).
HOW TO
CHANGE
YOUR
BANDS
3

(QTCOQTGTGſPGFſVVJG
Clasp can be rotated before
placing into the band.
5. Carefully slide the bands
back onto the Core. The
bands can slide in either
direction.
HOW TO
CHANGE
YOUR
BANDS
4

1. Your body is always burning calories, even when
sleeping or not in motion. Our All-Day Calorie meter
accounts for these calories burned.
2. You will see calories burned even during periods of
non-activity.
HELPFUL
HINTS:
ALL-DAY
CALORIE
Your C200 allows for a more comprehensive calorie
count by factoring in calories burned simply through
living, in addition to any exercise and activity. This is a
great tool to compare against your daily calorie intake!
Your C200 will also provide a more accurate calorie count
by calculating in your heart rate reading whenever it is
taken. So remember to get your heart rate throughout the
day and more frequently during your exercise.
ALL-DAY
CALORIE
5

+H[QWCTGJCXKPIFKHſEWNV[CESWKTKPI[QWTUVGRUVT[VJG
following:
1. Take 30 - 40 steps before checking your step count.
2. If your steps are being over or undercounted, try
adjusting the sensitivity level (in Advanced Setup).
Step count is determined by actual steps. Arm motion
can affect this count.
HELPFUL
HINTS:
STEP
COUNT
For a more accurate distance, your C200 adjusts
your stride length based on how fast you are
walking or running.
AUTO
CALIBRATED
DISTANCE
6

+H[QWCTGJCXKPIFKHſEWNV[CESWKTKPI[QWTJGCTVTCVGVT[
the following:
1. Make sure your C200 is snugly strapped to your wrist.
#NQQUGſVOCMGUKVOQTGFKHſEWNVVQRTQRGTN[OGCUWTG
your heart rate.
7RQPRWVVKPI[QWT%QPHQTVJGſTUVVKOGCNNQYQPG
minute to warm up before trying to obtain your heart rate.
3. When touching the heart sensor button (VIEW), make
UWTG[QWCTGWUKPIVJGUQHVƀCVRCFUQH[QWTſPIGTUPQV
VJGVKRUQH[QWTſPIGTU
4. Touch gently with enough pressure to activate the
heart sensor button (VIEW). Pressing too hard can make
KVFKHſEWNVVQOGCUWTG[QWTJGCTVTCVG
HELPFUL
HINTS:
HEART
RATE
7

5. Make sure the back metal plate of your C200 is laying
ƀCVQP[QWTUMKP
/CMGUWTG[QWTYTKUVCPFſPIGTUCTGENGCPCPFHTGG
from dirt, oils, or lotions.
7. Clean the heart sensor button (VIEW) and back metal
plate with a mild soap and water, or similar cleaning
solution.
/QKUVGPYKVJYCVGTVJGRCFUQHVJGſPIGTU[QWCTG
using to contact the heart sensor button (VIEW).
9. Moisten with water the surface between the back metal
plate of your C200 and the skin on your wrist.
HELPFUL
HINTS:
HEART
RATE
8

Ŗ;QWT%DWVVQPUCTGPQVKPVGPFGFHQTWUGKPQT
under water as this may cause water leakage.
Ŗ#XQKFTQWIJWUCIGQTUGXGTGKORCEVU
Ŗ-GGRVJGJGCTVUGPUQTDWVVQPVIEW) and
back metal plate free from dirt, oils, or other
contaminants.
Ŗ2GTKQFKECNN[ENGCP[QWT%WUKPICUQHVENQVJYKVJ
mild soap and water, or similar cleaning solution.
Ŗ-GGR[QWT%QWVQHGZVTGOGJGCVQTEQNF
Ŗ&QPQVGZRQUG;QWT%VQKPVGPUGFKTGEVUWPNKIJV
for long periods of time.
Ŗ&QPQVGZRQUG[QWT%VQEJGOKECNUUWEJCU
gasoline, alcohol, or solvents.
CARE &
MAINTENANCE
9

Battery replacement will be required from time to time, and
should occur when:
Ŗ6JGFKURNC[HCFGUKPRCTVQTEQORNGVGN[
Ŗ6JG*GCTV4CVGHWPEVKQPYKNNPQVCEVKXCVG
The battery life will vary depending on usage.
We recommend battery replacement be done by a watch
repair service center to ensure the water seals are not
compromised during the process.
Your C200 uses one (1) standard lithium replacement
battery: CR2032
BATTERY
10

Your C200 and S-Pulse™ technology are a result of, and
protected by, the following patents:
US: 5,738,104 & 5,876,350
Europe: EPO 0861045B1
Your C200 is warranted for a period of one (1) year from
the date of purchase from an authorized retailer.
If defective, return it with the original receipt, or copy, to
your original retailer or to LifeTrak for a replacement.
This warranty covers defects in materials and
workmanship only. It does not cover the battery, damage
due to abuse or misuse, accidents, or any commercial
use.
PATENT
LIMITED
ONE (1)
YEAR
WARRANTY
11

The warranty stated above is the only warranty
applicable to this product. All other warranties,
expressed or implied, including all implied warranties
QHOGTEJCPVCDKNKV[QTſVPGUUHQTCRCTVKEWNCTRWTRQUG
are hereby disclaimed. No verbal or written information
given by LifeTrak, its agents or employees shall create
a guarantee or in any way increase the scope of this
warranty.
4GRCKTQTTGRNCEGOGPVCURTQXKFGFWPFGTVJKUYCTTCPV[
is the exclusive remedy of the consumer. LifeTrak shall
not be liable for incidental or consequential damages
resulting form the use of this product or arising out
of any breach of any express or implied warranty on
this product. Except to the extent prohibited by law,
CP[KORNKGFYCTTCPV[QHOGTEJCPVCDKNKV[QTſVPGUUHQT
a particular purpose on this product is limited to the
applicable warranty period set forth above. Consumer
rights may vary from state to state.
LIMITATIONS
12

Your C200 is not a medical device, nor intended for use
in medical or patient monitoring applications. It is not
intended for use in any commercial application.
Always consult a physician before starting any physical
activity.
The features and/or images of your C200 may
vary slightly from those described in this guide.
The information in this manual is intended to be for
informational purposes only, and is subject to change
without notice.
DISCLAIMER
13

Workout
Chronograph range: 9 hr,
59 min, 59 sec
Step range: 0-99,999 steps
Calorie range: 0-99,999
Distance range: 621.3 mi /
999.9 km
*KUVQT[
Memory: 7-day memory
*GCTV4CVG
*GCTVTCVGTCPIG
BPM
Time
AM, PM, hour, minute,
seconds
12/24 hr format
Calendar: month, day, date
(w/auto leap year adjustment)
Advanced Setup
Age range: 5-99
*GKIJVTCPIGKP
100-220 cm
Weight range: 44-440 lb /
20-200 kg
Other
Backlight
Water resistant up to
30 meters
SPECIFICATIONS
14

Ŗ'OCKNUWRRQTV".KHG6TCM75#EQO
Ŗ9GDUKVGYYY.KHG6TCM75#EQO
Ŗ2JQPG
Ŗ/CKN
LifeTrak
39962 Cedar Blvd, Ste 285
Newark, CA 94560
For additional band colors, accessories
and other innovative products, visit us at
LifeTrakUSA.com.
Copyright © 2013 LifeTrak™. All rights reserved. Duplication or copying of all or part of this manual
without the express written consent of LifeTrak is prohibited.
CONTACT
