Liftup Flexstep v2 User manual

User manual

FlexStep V2

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

Liftup A/S | Hagensvej 21 | DK-9530 Støvring | Denmark | T: +45 96 86 30 20 | M: s[email protected] | www.liftup.dk | CVR DK-1015 3964




Contents
Foreword...................................................................................................................................................4
Declarations..............................................................................................................................................5
1 Regulatory approvals.........................................................................................................................7
2 EC declaration of conformity..........................................................................................................9
Labelling of the equipment..................................................................................................................10
Factory approval test (FAT) ...............................................................................................................11
Terms of use...........................................................................................................................................12
Technical specifications........................................................................................................................13
Safety instructions.................................................................................................................................16
1 Installation and maintenance .........................................................................................................16
2 Unintended movements of FlexStep...........................................................................................16
3 Lift movement...................................................................................................................................16
4 Avoiding personal injury.................................................................................................................16
5 Overload of the lift..........................................................................................................................16
6 Personal safety..................................................................................................................................17
7 Anti-crushing .....................................................................................................................................17
7.1 Infrared anti-crushing feature...............................................................................................18
8 Safety barriers...................................................................................................................................18
8.1 Ramp as roll-off protection...................................................................................................18
8.2 Doors as roll-off protection.................................................................................................18
8.3 Vertical safety barrier.............................................................................................................19
9 Handling..............................................................................................................................................19
10 Unlocking door in case of emergency.........................................................................................20
11 Lifts accessible to the public (only certain countries).............................................................21
12 Emergency lighting ...........................................................................................................................21
Functionality ...........................................................................................................................................21
Assembly .................................................................................................................................................21
Start-up....................................................................................................................................................22
Instructions for the use .......................................................................................................................22
1 Daily use.............................................................................................................................................23
2 Operating FlexStep from the TOP level ....................................................................................24
3 Operating FlexStep from the BOTTOM level..........................................................................24
4 Operating FlexStep on the platform ...........................................................................................25

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

11.5 Return to stairs and auto return..................................................................................................25

11.6 Emergency stop................................................................................................................................26

11.7 ON/OFF switch................................................................................................................................26

11.8 Audible alarms ..................................................................................................................................27

11.9 Emergency alarm devices (optional equipment).......................................................................28

12. Operation................................................................................................................................................29

12.1 Battery backup..................................................................................................................................29

12.2 Calibration following emergency stop/power failure ..............................................................29

13. Maintenance............................................................................................................................................30

14. Pairing transmitter and receiver ........................................................................................................32

14.1 Remote control and receiver 2,4GHz ........................................................................................32

14.2 Wireless call station and receiver 2.4GHz.................................................................................34

15. Installation and handover.....................................................................................................................35

16. Maintenance checklist ..........................................................................................................................36

17. Service log...............................................................................................................................................38

17.1 Service logbook ................................................................................................................................38

17.2 Online service log (only certain countries) ...............................................................................39

18. Spare parts and accessories................................................................................................................40

19. Disassembly ............................................................................................................................................41

20. Disposal ...................................................................................................................................................41

21. Right of complaint.................................................................................................................................41

February 2020

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

1. Foreword

Congratulations on purchasing your new FlexStep V2 wheelchair lift –an aesthetic and

innovative 2-in-1 solution providing you with both an ordinary staircase and a sophisticated

stairlift –be it in your home, office or other place.

This is an original user manual for your new FlexStep V2. Hereinafter we use the term FlexStep

for FlexStep V2, if nothing else is specifically indicated.

It is important to read this manual before using the lift.

Setup and installation MUST be undertaken by a qualified Liftup service technician, so as to

ensure correct assembly. Improper assembly can lead to unintended risks of personal injury.

Service and maintenance must be performed in accordance with Liftup’s terms of sale and

delivery and in compliance with local ordinances and regulations as regards the intervals between

service inspections.

FlexStep V2 is an elegant combination of regular stairs and wheelchair lift, which easily provides

wheelchair users and the walking-impaired access between two levels.

In this user manual “FlexStep V2” in the function as stairlift will be mentioned as

“lift”.

The lift is easy to operate using operating panels mounted on the wall, on the lift, or by means

of a remote control (optional equipment).

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

2. Declarations

Manufacturer: Liftup A/S

Address: Hagensvej 21, DK-9530 Støvring, Denmark

Telephone no.: +45 9686 3020

Liftup, the Liftup logo and Liftup are trademarks of Liftup A/S, registered in the United States

and in other countries. All other trademarks are the property of their respective owners.

The following Product Limited Warranty gives Resellers specific legal rights. You may have

others, which vary from state/jurisdiction to state/jurisdiction.

Product Limited Warranty

Subject to the terms and conditions set forth herein, Liftup A/S (

“Liftup”

) makes the following

warranty only to its Resellers who purchase the FlexStep V2 product (

“Product”

) directly from

Liftup: for a period of one (1) year from the date of shipment from Liftup, the Product will

substantially conform to Liftup’s standard published specifications for the Product and the

Product hardware will be substantially free from defects in materials and workmanship. The

foregoing warranty shall not apply to embedded software/firmware components.

THIS PRODUCT LIMITED WARRANTY IS PROVIDED TO RESELLERS AND TO RESELLERS

ONLY. RESELLER IS SOLELY RESPONSIBLE FOR ANY AND ALL WARRANTIES MADE TO

ITS CUSTOMERS, AND LIFTUP MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND

SHALL HAVE NO OBLIGATIONS OR LIABILITY TO RESELLER’S CUSTOMERS OR END-

USERS OF THE PRODUCT. RESELLER SHALL NOT MAKE ANY REPRESENTATIONS OR

WARRANTIES ON LIFTUP’S BEHALF, AND SHALL FULLY INDEMNIFY, DEFEND AND

HOLD LIFTUP HARMLESS FROM ANY BREACH OF THE FOREGOING. IF RESELLER

DISTRIBUTES PRODUCT TO END-USER CUSTOMERS, RESELLER SHALL BE SOLELY

RESPONSIBLE FOR PREPARING AND PROVIDING PRODUCT WARRANTIES AND

PRODUCT LITERATURE TO END-USERS.

Warranty Remedies

If the Product fails during the warranty period for reasons covered by this Product Limited

Warranty and Reseller notifies Liftup of such failure during the warranty period, Liftup is at

option to repair OR replace the nonconforming Product, OR refund the purchase price paid by

Reseller for the Product, provided that Reseller returns the Product to Liftup in accordance

with Liftup’s standard return material authorization procedures or as otherwise instructed by

Liftup.

Warranty Exclusions and Disclaimers

The foregoing Product Limited Warranty shall only apply in the event and to the extent that (i)

the Product is properly and correctly installed, configured, interfaced, maintained, stored and

operated in accordance with Liftup’s specifications, and (ii) the Product is not modified or

misused. This Product Limited Warranty shall not apply to, and Liftup shall not be responsible

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

for, defects or performance problems resulting from: (a) the combination or utilization of the

Product with hardware or software products, information, data, systems, interfaces, services or

devices not made, supplied or specified by Liftup; (b) the operation of the Product under any

specifications other than, or in addition to, Liftup’s standard published specifications for the

Product; (c) the unauthorized installation, modification or use of the Product; (d) damage caused

by: accident, lightning or other electrical discharge, water immersion or spray, or exposure to

environmental conditions for which the Product is not intended; or (e) normal wear and tear

on consumable parts, including by way of example and without limitation, batteries.

LIFTUP DOES NOT WARRANT OR GUARANTEE THE RESULTS OBTAINED THROUGH

THE USE OF THE PRODUCT. THE FOREGOING TERMS OF THE PRODUCT LIMITED

WARRANTY STATE LIFTUP’S ENTIRE LIABILITY, AND RESELLER’S EXCLUSIVE REMEDIES,

RELATING TO THE USE AND PERFORMANCE OF THE PRODUCT EXCEPT AS

OTHERWISE EXPRESSLY PROVIDED FOR IN THIS PRODUCT LIMITED WARRANTY, THE

PRODUCT, ACCOMPANYING DOCUMENTATION AND MATERIALS, AND/OR ANY

EMBEDDED SOFTWARE/FIRMWARE AND UPDATES THERETO ARE PROVIDED “AS-IS”

AND WITHOUT EXPRESS OR IMPLIED WARRANTIES OF ANY KIND, BY EITHER LIFTUP

OR ANYONE WHO HAS BEEN INVOLVED IN ITS CREATION, PRODUCTION,

INSTALLATION OR DISTRIBUTION, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

TITLE AND NONINFRINGEMENT. THE STATED EXPRESS WARRANTIES ARE IN LIEU OF

ALL OBLIGATIONS OR LIABILITIES ON THE PART OF LIFTUP ARISING OUT OF, OR IN

CONNECTION WITH, THE PRODUCT. WITHOUT LIMITING THE GENERALITY OF THE

FOREGOING:

THE PRODUCT MAY CONTAIN TECHNOLOGY THAT IS NOT FAULT TOLERANT AND

IS NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE IN ENVIRONMENTS OR

APPLICATIONS IN WHICH THE FAILURE OF THE PRODUCT WOULD LEAD TO DEATH,

PERSONAL INJURY OR SEVERE PHYSICAL OR ENVIRONMENTAL DAMAGE OR SEVERE

FINANCIAL LOSS. ANY USE OR DISTRIBUTION BY RESELLER OR ITS CUSTOMERS IN

CONNECTION WITH ANY SUCH ENVIRONMENT OR APPLICATION SHALL BE AT

RESELLER’S AND ITS CUSTOMERS’ SOLE RISK, AND LIFTUP SHALL HAVE NO LIABILITY

WHATSOEVER IN CONNECTION THEREWITH. RESELLER SHALL INDEMNIFY AND

HOLD LIFTUP AND ITS SUPPLIERS HARMLESS FROM ANY CLAIM BROUGHT AGAINST

LIFTUP WHICH ARISES FROM RESELLER’S USE OR DISTRIBUTION OF THE PRODUCT IN

CONNECTION WITH SUCH ENVIVRONMENTS OR APPLICATIONS. SOME STATES AND

JURISDICTIONS DO NOT ALLOW LIMITATIONS ON DURATION OR THE EXCLUSION

OF AN IMPLIED WARRANTY, SO CERTAIN OF THE ABOVE LIMITATIONS MAY NOT

APPLY TO EVERY RESELLER.

Embedded Software/Firmware

The Product and associated tools, if any, may contain embedded software/firmware, which is

licensed, not sold, and is only for use within the Product as an integral part thereof. Such

embedded software/firmware (which includes all updates thereto) contains valuable trade

secrets and is proprietary to Liftup A/S and its suppliers. To the greatest extent permitted by

law, such embedded software/firmware may not be modified, copied, disassembled, decompiled

or reverse engineered. Liftup reserves all other rights.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

Limitation of Liability

LIFTUP’S ENTIRE LIABILITY REGARDING THE PRODUCT SHALL BE LIMITED TO THE

AMOUNT ACTUALLY PAID BY RESELLER FOR THE PRODUCT. TO THE MAXIMUM

EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL LIFTUP OR ITS

SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES WHATSOEVER UNDER ANY CIRCUMSTANCE OR LEGAL THEORY

RELATING IN ANY WAY TO THE PRODUCTS, ACCOMPANYING DOCUMENTATION

AND MATERIALS, AND ANY EMBEDDED SOFTWARE/FIRMWARE AND UPDATES

THERETO (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS

PROFITS,

BUSINESS INTERRUPTION, LOSS OF DATA OR ANY OTHER PECUNIARY LOSS),

REGARDLESS OF WHETHER LIFTUP HAS BEEN ADVISED OF THE POSSIBILITY OF ANY

SUCH LOSS AND REGARDLESS OF THE COURSE OF DEALING BETWEEN LIFTUP AND

RESELLER. BECAUSE SOME STATES AND JURISDICTIONS DO NOT ALLOW THE

EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL

DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO EVERY RESELLER.

Notices

Class B Statement –Notice to Users. This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio

communication. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Consult the dealer or an experienced radio/TV technician for help.

Changes and modifications not expressly approved by the manufacturer or registrant of this

equipment can void your authority to operate this equipment under Federal Communications

Commission rules.

2.1 Regulatory approvals

FCC/IC

The radio module contained in the FlexStep V2 and associated remote comply with the FCC

Part 15.249 and the Industry Canada requirements RSS-GEN, RSS-210

The radio module contained in the FlexStep V2 and associated remotes complies with Part 15

of the FCC rules and with Industry Canada license exempt standard(s). Operation is subject to

the following two conditions:

(1) This device may not cause harmful interference, and

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

(2) This device must accept any interference received, including interference that may cause

undesired operation.

The radio module contained in the FlexStep V2 and associated remotes are SAR test excluded

according to FCC KDB 447498, RSS102 and EN 62479 at separation distances larger than 5 mm

and less than 50 mm.

With respect to radio frequency radiation exposure Information, it is declared; that this equip-

ment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

This gives an extra margin, since the remote control normally, only is used in “controlled

environment” for approx. 30 seconds when lifting, and typically only a few times a day.

FlexStep V2 contains:

Handheld REMOTE1

Wall mounted REMOTE2:

FCC ID:

2AK8H-MODULE1

FCC ID:

2AK8H-REMOTE1

FCC ID:

2AK8H-REMOTE2

IC:

22516-MODULE1

IC:

22516-REMOTE1

IC:

22516-REMOTE2

EU Declaration of Conformity: CE

(Machinery Directive and RED (Radio module and remote))

ASME 18.1 2014 (US/FDA)

The FlexStep V2 complies with key requirements of the ASME 18.1 Safety Standard for Platform

lifts and Stairway Chairlifts, section 5 “Private Residence Platform Lifts”. Please note that not all

possible configurations of the FlexStep V2 are in compliance –consult your reseller for further

information.

ACMA (AUS/NZ)

The FlexStep V2 complies with the Australian/New Zealand Radio communication Act 2400-

2483 MHz, and is labelled accordingly:

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

2.2 EC declaration of conformity

Directive 2006/42/EC on machinery

Manufacturer: Liftup A/S

Address: Hagensvej 21, DK-9530 Støvring, Denmark

Telephone no.: +45 9686 3020

hereby declares that:

Lift: FlexStep V2

Combination stairlift for wheelchair users and the walking-

impaired

Year: 2019

conforms to the key health and safety requirements of Directive 2006/42/EC on

machinery.

Additionally, it conforms to:

EMC-directive 2014/30/EU

RoHS-directive 2011/65/EU

Radio Equipment Directive

(RED) 2014/53/EU

Relevant parts of the following were, for example, used in the assessment:

ISO 9386-1:2000 Power-operated lifting platforms for persons with impaired

mobility

DS/EN 60204-1 Safety of machinery –Electrical equipment of machines.

DS/EN 13849-1 and -2 Safety-related parts of control systems

CEO

Søren Elisiussen

Position

Name

Liftup A/S, Hagensvej 21, DK-9530 Støvring, Denmark

Place

10 February 2020

Date

Signature

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

3. Labelling of the equipment

Insert copy of

CE certification mark here

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

4. Factory approval test (FAT)

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

5. Terms of use

As a lift, the equipment is solely for the use of wheelchair users or persons with impaired

mobility. The maximum load is 400 kg or a maximum of 2 persons evenly distributed on the

platform.

Read this user manual thoroughly before using the lift

IMPORTANT! The platform must NOT be used for goods transport, including

loaded pallets or other types of heavy loads.

IMPORTANT! No persons must be on the FlexStep when it is moving to or from

stair mode, but only when it is functioning as a platform.

IMPORTANT! The owner of this lift is obliged to maintain it according to the

Maintenance Guide in section 13.

Do not dispose of batteries or electrical or electronic equipment with unsorted

household rubbish. When disposing of this device, ensure compliance with local

ordinances and regulations.

The maximum load is 400 kg or a maximum of 2 persons

evenly distributed on the platform.

If the lift is accessible to the public, it is the responsibility of the owner to ensure that inspections

are performed in accordance with the legal provisions and at correct intervals, and that

necessary safety equipment is provided for.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

6. Technical specifications

Position at bottom landing

Staircase

Position at top landing

All scale drawings for 2+1, 2+2, 3, 3+1, 4, 4+1, 5 and 6 step FlexStep V2 in standard widths are

available at https://www.liftup.dk/en/products/flexstep/

Technical specifications

Power: 110 - 240 V/50 Hz (1.1A) Max: 90 W, Standby < 6 W

Lifting capacity: 400 kg or 2 persons

Lifting height: 0 - 1250 mm

Platform size:

Internal dimensions: W 700/800/900/1000 mm - L 900 mm - 1800 mm

External dimensions: W 930 –1230 mm - L 1095 - 2010 mm

Dead weight: 125 - 205 kg

Noise level: < 70 dB

Water and dust: >50V: IP67 (Power Supply) / <50V: IP23 / <10V: IPxx

Speed/temp.:

°C

mm/sek.

+40˚C - +5˚C

40 mm

+5˚C - -10˚C

20 mm

-10˚C - -20˚C

10 mm

Max. 200 kg

-20˚C - -25˚C

10 mm

Approval: Directive 2006/42/EC on machinery

Duty cycle: 2 min. / 5 min.

Battery capacity: 30 cycles at 25 ˚C. Fully charged = 5 hours

Flat battery: 10 min. charge = 1 trip

All radio components comply with the following standards:

EU 2014/53/EU, Radio Equipment Directive (RED)

FCC (USA) CFR 47 Part 15

DS/EN 62479:2010 Assessment of the compliance of low-power electronic and

electrical equipment with the basic restrictions related to

human exposure to electromagnetic fields (10 MHz to 300 GHz)

DS/EN 300 440, v2.1.1 Short Range Devices (SRD); Radio equipment to be used in the

1 GHz to 40 GHz frequency range; (Electromagnetic

compatibility and Radio spectrum Matters Draft)

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

DS/EN 301489-1, v2.2.0 ElectroMagnetic Compatibility (EMC) standard for radio

equipment and services, Draft

DS/EN301489-17, v3.2.0 ElectroMagnetic Compatibility (EMC) standard for radio

equipment and services

AS/NZS 4268 Radio Equipment and Systems –Short Range devices

AS/NZS 2772.2 Radio Frequency Fields (mean power <1 mW)

MODULE1:

2,4GHz Short Range devices. FCC ID: 2AK8H-MODULE1

Receiver Class 3

Dimensions (L x W x H): 72 x 33 x 10mm / 2,83 x 1,30 x 0,40 in.

Weight: 10 g (0,035 lbs.)

Frequencies: 2,410GHz 2,435GHz and 2,460GHz

Duty cycle: < 1% (only TX for pairing Remotes)

Power: < 0,6mW Controlled environment

Supply: 5,6 Volt 30mA

Water and dust: IP XX (shall be mounted inside Liftup products)

Working temperature: +5ºC to +40ºC/ 41ºF to 104ºF

Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF

Expected service life: > 5 years

Handheld REMOTE1:

2,4GHz Short Range devices. FCC ID: 2AK8H-REMOTE1

Receiver Class 3

Dimensions (L x W x H): 96 x 47 x 24mm / 3,79 x 1,85 x 0,95 in.

Weight: 48 g (0,11 lbs.)

Frequencies: 2,410GHz 2,435GHz and 2,460GHz

Duty cycle: < 1%

Power: <0,6mW Controlled environment, Hold to run

Battery: 3 Volt CR2032

Water and dust: IP 42

Working temperature: +5ºC to +40ºC / 41ºF to 104ºF

Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF

Expected service life: > 5 years

Wall mounted REMOTE2:

2,4GHZ Short Range devices. FCC ID: 2AK8H-REMOTE2

Receiver Class 3

Dimensions (L x W x H): 80 x 64 x 33mm / 3,15 x 2,52 x 1,30 in.

Weight: 75 g (0,17 lbs.)

Frequencies: 2,410GHz 2,435GHz and 2,460GHz

Duty cycle: < 1%

Power: < 0,6mW Controlled environment, Hold to run.

Battery: 3 Volt CR2032

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

Water and dust: IP 42

Working temperature: +5ºC to +40ºC/ 41ºF to 104ºF

Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF

Expected service life: > 5 years

Right reserved to make technical modifications.

Patented product

The following patents apply to the product:

•EP1254858,

•EP1600416

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

7. Safety instructions

7.1 Installation and maintenance

Do NOT try to install or service your FlexStep yourself –this MUST be done by an authorised*

service technician. Do NOT remove the protective or safety plates, as this may lead to personal

injury.

*Has completed a Liftup product and service course.

7.2 Unintended movements of FlexStep

If during the use of your FlexStep, movement or action occurs which is not described in this

manual, stop the unit and call technical assistance.

Should your FlexStep not move with plane movement as a platform, calibrate the lift by running

the platform down to floor level. If the problem continues, call technical assistance.

7.3 Lift movement

The space under the lift must be kept free of all objects which may impair its downward

movement. Otherwise the lift cannot be moved to the lowest level and thus not be used as a

wheelchair lift.

Should an object hinder lift downward movement, the anti-crushing safety feature will be

activated (see section 7.7).

7.4 Avoiding personal injury

Do NOT transform the FlexStep from stairs into platform or the reverse when persons or

objects are on the stairs.

So as to avoid personal injury it is NOT permitted to use the FlexStep V2 when someone is at

risk of being injured by crushing, cutting, falling, slipping, or similar.

It is important that the operator/user ensures that the lift can move without putting anyone or

anything at risk.

Be extra careful when there are small children, elderly or disabled people on or near the

stairs/platform, as these groups cannot always be expected to be able to foresee the possible

consequences of lift movement.

7.5 Overload of the lift

In order to avoid damage to the lift in the event of overload (max. 400 kg evenly distributed), it

is fitted with an overload cut-out, which when triggered halts the lift and issues an audible alarm

(see section 11.8). In such cases, run the lift down in order to exit it.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

7.6 Personal safety

FlexStep is fitted with various safety features which ensure that the user or other people are

not injured when using the lift.

WARNING! Although the lift comes fitted with various safety features never use it

if persons or animals are close by, as there may otherwise be a risk of crushing.

Never allow children to play with the lift.

7.7 Anti-crushing

Beneath the entire lift a number of pressure plates (anti-crushing) are fitted which are activated

if an object is going to be crushed below. When this feature is activated the lift stops and then

runs approx. 2 cm upwards, while at the same time an audible alarm is issued (see section 11.8).

If the anti-crushing feature is activated, release the operating button. Remove any objects under

the lift, and it can then be run to the “lower landing” or “staircase” states. (If needed, run the

lift upwards so you can more easily remove objects underneath it).

IMPORTANT! Keep in mind that when the lift is used outside, leaves, branches and

snow can affect the anti-crushing safety feature, and so you should check regularly

that the lift will not be obstructed when moving downward.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

7.7.1 Infrared anti-crushing feature

Infrared sensors are fitted between the steps in order to avoid crushing between them.

Infrared sensors prevent crushing between the steps

If the IR sensors are disrupted when the FlexStep V2 moves from staircase to platform or the

reverse, movement will stop, and an audible alarm will sound (see section 11.8).

7.8 Safety barriers

7.8.1 Ramp as roll-off protection

If the lift is fitted with a ramp, the ramp will first pull up and lock before the lift begins to move.

The ramp now acts as roll-off protection. When the lift returns to floor level, the ramp will

automatically lower (keep the button pressed) and act as a drive-on/drive-off ramp.

Ramp as roll-off protection

Ramp as a drive-on/drive-off ramp

7.8.2 Doors as roll-off protection

If the lift is fitted with doors, they will close before it begins to move. The doors will always be

closed, when the lift has moved off ground level. If the lift is fitted with doors, it can be equipped

with automatic door locks. The automatic door locks will secure that the doors are locked

before the lift begins to move.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

7.8.3 Vertical safety barrier

If the lift is fitted with a vertical safety barrier (optional equipment) at the upper level, it will

close before the lift begins to move. The vertical safety barrier will always be closed, when the

lift is not at the upper level.

The vertical safety barrier is closed and locked

when the lift is not at the top level.

7.9 Handling

The lift is normally supplied by your dealer, who also takes care of installation.

IMPORTANT! Do not try to move the lift manually, as this can lead to personal

injury. The product should be moved and handled using suitable lifting equipment

(pallet-truck, roller plate, or similar).

DO NOT subject the lift to severe knocks/blows as these can affect functionality.

Keep the associated remote control (supplementary equipment) dry and do not subject it to

severe blows. Cleaning may only be performed using a well-wrung cloth.

USER MANUAL –FLEXSTEP V2 –AUS VERSION 1.0

7.10 Unlocking door in case of emergency

In case of emergency/malfunction: Release the folding spring bolt.

1. Pull the spring out from the shaft of the

clevis, using a suitable tool, screwdriver,

ruler, bottle-opener, etc.

2. From outside, you can approach the lower

side

3. The spring is released

4. When the spring is released pull out the

bolt.

Please note!

The bolt may be difficult to pull out,

because of pressure on the door actuator.

5. Now the door can be moved freely
