Lanta Orion Move User guide
Owner Handbook
Orion Move™
1
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
Owner Handbook
Orion Move™
2
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
Owner Handbook
Lanta Product Safety
USE & MAINTENANCE
YOU MUST READ THESE WARNINGS carefully because they include important
safety information about the installation, operation and maintenance of this
product. Follow all instructions to maintain Manufacturer Warranty and for your
own safety.
BEFORE operating this device.
these products be used outdoors unless stated otherwise.
operation.
solvents or liquids to clean the product.
product for any reason. This will invalidate your Manufacturer Warranty and
may impair the safety features of the product.
or moisture. The unit must be repaired by an authorised service centre only.
Manufacturer Warranty is void if unit is opened or adapted in any way. Operator
safety may be compromised if this product is not operated and maintained
in accordance with the details contained in this Owner Handbook.
plug or any other location - it is essential for user safety.
with one of the same type, size and value.
producing high voltages from its outputs and has mains voltages inside the
cabinet.
MAINS WARNINGS
operating range of the product.
connected to a power pack or other dimmer.
plug or any other location - it is essential for user safety.
unplug from the mains.
PHYSICAL WARNINGS
Always secure the product to a fastening device using a safety chain.
manner, stop using the unit immediately and contact your supplier.
as a whole or handle if provided.
LASER WARNINGS - WHERE APPLICABLE
if lasers are used incorrectly.
light directly strikes the eyes.
audience or other personnel could get direct laser beams or bright reflections
into their eyes.
NON INTERLOCKING HOUSING WARNINGS
emitters.
laser radiation.
blindness, skin burns, and fires.
LASER SAFETY NOTES - WHERE APPLICABLE
YOU MUST READ THIS LASER SAFETY INFORMATION
Laser light is many thousands of times more concentrated than light from
any other kind of light source and as so it poses a real danger to the sight.
the light sensitive portion at the back of the eye called the retina. Even if you
your audience. Even very small amounts of laser light are potentially hazardous
even at long distances.
Laser eye injuries can happen quicker than you can blink.
beams that are radiated out at high speed. There is a misconception that
beams are potentially hazardous to the eyes and should never be directed
into an audience at any time.
because these beams are being moved by a mechanical device, it is
possible for that device to stop moving and then direct the laser beam
to test the laser before any public use.
damage to the product and could allow emission of higher laser levels
hazardous.
by a skilled and well-trained operator, familiar with the data included in this
manual.
understand the legal obligations and responsibilities in force at the time and
location of use.
We recommend visiting the Government Health & Safety website
http://www.hse.gov.uk or search for “Controlling the radiation safety of display
laser installations” for further information.
Owner Handbook
Orion Move™
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
1065mm
177mm
95mm
INSIDE THE BOX
Orion Move™
SPECIFICATIONS
Model Number L26456
Light Source 8 x 9W CREE LEDs
Beam Angle 1.6°
Control 1, 12, 24 Channel DMX 512
control channels, LED display
Control
Connections
3 Pin Female XLR, 3 Pin Male XLR
IEC IN & OUT
Run Modes Auto, DMX, Sound Active
Built in Program, Master Slave
Construction Die Cast Steel
Power Requirement 240V AC 50/60Hz
Power Consumption 72w
Dimensions (mm) 1065 x 95 x177
Weight (kg) 8.7
INTRODUCTION
Lanta are committed to providing high quality products at cost-effective prices
to the professional lighting market. Since the first product was launched in
2006, Lanta has established a reputation for reliability, common sense design
and customer support that has become the envy of others.
Other Lanta Lighting range include:
Professional Lighting:
traditional lights while at the same time requiring significantly lower power and
generating far less unwanted heat.
Performance Lasers:
Recent advances have reduced the costs of Lasers, made them more portable
and brought improved performance and reliability. With step and animation
Atmospheric Effects:
Whenyouneedspecialatmosphericseffects,Lantahave everything frombubble
consumables specially designed to get the best from the range.
Control Gear:
Our website can be found at www.lantalighting.com and is available for the
support on this and other high quality products from Lanta
UNPACKING & INSPECTION
packing materials in case you need to transport the device, pass it on to a new
and accessories to ensure they have arrived with you in good condition and
DO NOT USE IT.
not the manufacturer.
SAFETY INFORMATION
All information regarding important safety information about the installation,
operation and maintenance of this product can be found at the back of this
force at the time of manufacture and are fully compliant with them.
MANUFACTURER WARRANTY
and material failure during normal use and operation for a period of 12
months from first use or from original date of sale (whichever is the earliest)
providing all of the terms indicated in the warranty section have been fully
complied with.
connected item or items or any consequential loss associated with the failure
of the product howsoever caused.
connected, used inappropriately or in conflict with the instructions herein,
or the product model or serial number has been damaged, removed,
tampered with, obliterated or made partly unreadable by any person or
persons, the Manufacturer Warranty is irrevocably null and void.
transferrable during the Warranty period.
Owner Handbook
Orion Move™
4
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
OPERATING MODES
There are distinct operating modes that are supported by this unit. To select,
AUTO
AUTO RUN MODE
AUTO
>Led
>Bar
LED OPTION:
“e-Auto” or “e-Manul”.
“e-Auto”
“SPEED” from 01-20
“FREQ” from 00-20Hz
“e-Manul”
and the flash speed.
“Gray”
“Freq”
BAR OPTION:
“m-Auto” or “m-Manul”.
“m-Auto” from 1-16.
“m-Manul”
“L-BAR”
“R-BAR”
SHOW MODE
SHOW
SOUND MODE
sound
SLAVE MODE
slave
SETTINGS
settings
each setting.
“BL Time”
“Adjust” of the Left or Right bar
from “-999” to “+999”
“Reset”
DMX MODE
dmx
each setting.
“Address”
“Channel”
“16-ch”.
Dmx In
. . . . . . .
signal is being received correctly.
Owner Handbook
Orion Move™
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
DMX CHANNEL SETTINGS
dmx
1CH
0--19
20-29 SHOW1
SHOW2
40-49
SHOW4
60-69
70-79 SHOW6
SHOW7
90-99
100-109 SHOW9
110-119 SHOW10
12CH
16CH
0-9
10-19
20-29 SHOW1
SHOW2
40-49
SHOW4
60-69
70-79 SHOW6
SHOW7
90-99
100-109 SHOW9
110-119 SHOW10
0-14
www.lantalighting.com
Lanta lighting is very focussed on saving the planet.
Our products are low energy and our packaging
is reduced to the minimum possible. We include
our handbooks and specification sheets as part of
our paper reduction programme. All our product
handbooks and spec sheets are available on-line.
available on any internet enabled device, at any
time of the day or night, anywhere on the planet!
© Lanta Lighting™ 2006-2014. Terms Apply. All trademarks are the property of their respective owners. E&OE. All specifications and details are correct at time of print. Revision 1
