4SB324 (28) (35) (42)
Decorative, Pendalux Suspension, Basic Canopy
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
A
B
Body Diagram
C
4
45º
6
3
5
Complete Luminaire consists of Body and Suspension. Order each separately.
3 Cables to Single Stem Suspension, with Swivel, Basic Canopy.
Catalog No. Nominal Overall Length (A)* Nominal Length (B)* Suspension (Center Stem) and Canopy Finish
4SB324PB 17 ⅞" 13 ⅜" Polished Brass
4SB324SB 17 ⅞" 13 ⅜" Satin Brass
4SB324SN 17 ⅞" 13 ⅜" Satin Nickel
4SB324WH 17 ⅞" 13 ⅜" White
4SB328PB 21 11 ⁄16"16 ¼" Polished Brass
4SB328SB 21 11 ⁄16"16 ¼" Satin Brass
4SB328SN 21 11 ⁄16"16 ¼" Satin Nickel
4SB328WH 21 11 ⁄16"16 ¼" White
4SB335PB 27 5⁄16" 20 ½" Polished Brass
4SB335SB 27 5⁄16" 20 ½" Satin Brass
4SB335SN 27 5⁄16" 20 ½" Satin Nickel
4SB335WH 27 5⁄16" 20 ½" White
4SB342PB 32 ⅝" 24 ½" Polished Brass
4SB342SB 32 ⅝" 24 ½" Satin Brass
4SB342SN 32 ⅝" 24 ½" Satin Nickel
4SB342WH 32 ⅝" 24 ½" White
*Add this length (A) to Body length (C) from Body Spec Sheet(s) to get Total Luminaire Nominal OAL.

4SB324 (28) (35) (42)
Decorative, Pendalux Suspension, Basic Canopy
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
4SB324 May 24, 2011
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2011.All rights reserved.
Job Information Type:
Specifications
1. Suspension Size: For optimum performance, testing
recommends luminaire total OAL (overall length) in proportion
to the body diameter. For close-to-ceiling mounting, it is
suggested to use shorter single stems as noted on Spec Sheet
SB115. Total luminaire OAL is defined from the bottom of the
diffuser to ceiling plane. Note: 3 Cable suspension cannot be
used with Cirrus Pendalux Series.
2. Stem Wires: Equipped with 120" of leads with keyed
connectors for quick connection to body wiring.
3. Suspension: Swivel (central) stem, ⅝" steel tube. Die-cast
ball hanger standard.
4. Cables: Reflector bowl is suspended from a central point on
three 1⁄16" stainless steel cables.
5. Mounting Strap (Cross Bar): Die-formed galvanized steel.
6. Canopy: Steel, 7" diameter, fastened internally, no exposed
hardware. Ball hanger on stem that fits into cross bar allows
installation on ceilings with slope up to 45 degrees. Complies
with California Earthquake Code.
7. Cutting Jig: All suspensions are equipped with a cutting jig
that simplifies cutting of center stem pipe in the field .
Options & Accessories
If a longer overall length is desired, use a suspension paired with
a larger body.
If an overall length of greater than 42" is desired, use an
extension stem. Order as a third additional component to make
complete fixture. Please see Spec Sheet No. 4SXT.
Mounting
Mounts directly to 4" outlet box, using crossbar hanger, supplied.
Note: Additional luminaire support plate provided with 35/42"
diameter body to allow luminaire to be supported independent of
the outlet box.
Labels
cULus. Suitable for damp locations.
A
B
Body Diagram
C
4
45º
6
3
5
