ALTER METALYTE LOUVER
2’ X 2’ RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, TT5, 5 1/2” DEEP
MICROPERFORATED MESH WHITE LAMP SHIELD
GREY SOLID LOUVER BLADES STATIC
Efficiency 40.7%.
Flat blade louver with lens overlay
and perforated curved side blades.
Semi-specular aluminum reflectors with
lengthwise ridges.
No visible welding, screws, latches, springs,
hooks, rivets or plastic supports.
5-1/2” deep, one-piece body for easy
installation.
Choice of white microperforated blade,
white solid blade or grey solid blade.
Easy access to ballast through lamp
compartment.
Fits standard T-grid, exposed slot T-grid
ceilings and drywall ceilings.
Fully recessed luminaire and lamp
compartment.
Optional hold-down clips.
Luminaire can be row mounted.
MOUNTING METHODS/FEATURES DIMENSIONS
FIXTURE TYPE
JOB INFORMATION:
VOLTS
L10-60
QVS2GPTLG2FT
Suited to standard exposed Slot T-grid
ceilings
Microperforated mesh white lamp shields
grey solid louver
Microperforated mesh white lamp shields
white mesh louver
Ceiling compatibility
Suited to standard exposed T-grid ceilings
Microperforated mesh white lamp shields
white solid louver
2X40W
Semi-spec reflector with lenghwise ridges
Genlyte Thomas Company

ORDERING INFORMATION Explanation of Catalogue Number Example: QVS2GPTLG2FT120SB
SPECIFICATIONS
MATERIALS: One piece chassis constructed from die formed
20 gauge cold rolled steel. Optic - Semi-specular matte aluminum
reflector with lenghtwise ridges. Soft white acrylic film on inside of lamp
shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic
matte high reflectance paint finish. Louver - flat blade louver with soft
white acrylic overlay.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast. If K.Os
are within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by CSA, UL
QVS2GPTLG2FT
QVS
FAMILY
QVS: Quality
Visual Static
recessed direct/
indirect fluorescent
2
LUMINAIRE
WIDTH
24"
G
CEILING
TYPE
G=Grid
PT
LAMP
SHIELD
PT=Semi-specular matte
reflector /
Microperforated mesh
lamp shield
LAMP
QUANTITY
3
LAMP/FIXTURE
LENGTH
FT= TT5
Bi-tube
120
VOLTAGE
120,277
347
SB
OPTIONS
F = Internal Fusing
(consult factory)
N= Emergency Lighting
System (for U.S.)
O =Emergency Lighting
System (for Canada)
R =Radio Interface
Filter
BALLAST
SB: 40W TT5 Elect.
BE: 50W TT5 Elect.
BD: 55W TT5 Elect.
PB: 40W TT5 PowerSpec HDF Dimming †
DA: iGEN DALI †
SHIELD DETAILING
LG= Grey solid flat blade louver
LV= White perforated flat blade louver
LW= White solid flat blade louver
We reserve the right to change, materials and finish in any way that will not alter installed appearance or reduce function and performance.
ALTER METALYTE LOUVER
2’ X 2’ RECESSED DIRECT/INDIRECT FLUORESCENT
LG 2 FT
† Not available in 347V.LPB : Number of lamps per ballast
