Brisa™Linear Planar Surface Mount FP28LEC
Page 1 of 2 Wall/Ceiling Mount T5 Fluorescent, ADA Compliant
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C0309
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier is a Philips group brand
Features
1. Housing Ends: Die-cast aluminum.
2. Housing Sides: Extruded aluminum.
3. Back Pan: Stamped 18ga. (0.048”) sheet metal.
4. Diffuser: Planar clear glass with opal diffuse glass or planar clear acrylic
with opal diffuse acrylic.
5. Junction Box Cover: (2) Die-cast aluminum, easy installation
(provided with luminaire).
6. Fixture Mounting Plate: Mounts directly to a 4” octagonal J-Box
(Not Shown in Drawing).
Mounting
Mounts directly to switch box or 4” octagonal J-Box or electrical conduit.
Octagonal box mounting requires use of “J-Box Covers” and “Support Plate” sup-
plied standard.
Electrical
7. Ballast
A. Electronic Dimming FP28LEC1 FP28LEC2
Voltage: 120V 277V
Total Input Watts: 36W 38.8W
Max Line Current: (Amps) 0.30A 0.14A
Power Factor: <0.95 <0.95
MAX. THD %: >20% >20%
Starting Temp.: 50°F, 10°C 50°F, 10°C
8. Luminaire-Ballast Disconnect: Meets NEC 410.130(G)
and CEC Disconnect Requirements.
Lamping (by others)
General Electric Osram/Sylvania Philips
(1) 28W T5 Linear Fluorescent
F28W/T5/*/ECO FP28/* F28T5/*/ALTO
*Manufactures Color Temperature Designation
Finish
Satin Aluminum.
Labels
CULus Listed. Suitable for Dry Locations.
Diffuser Ordering Information
Catalog No. Description Finish Dimensions (Nominal)
FPA3 Acrylic Planar Diffuser Opal 5" x 48"
FPG3 Glass Planar Diffuser Opal 5" x 48"
Fixture Ordering Information (Single Lamp)
Catalog No. Description Finish Wattage Volts Lamp Ballast (EC0-10)
FP28LEC1 Linear Planar Surface Mount Satin aluminum 28W 120V (1) T5 ECO T528-1201
FP28LEC2 Linear Planar Surface Mount with Emergency Satin aluminum 28W 277V (1) T5 ECO T528-2771
152
43
45 3/8"
[1153mm]
3"
[76mm]
48 1/2"
[1232mm]
4 9/16"
[115mm]
6 1/8"
[156mm]
4 1/8"
[104mm]
3"
[76mm]
7

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • C0309
Lightolier is a Philips group brand
Brisa™Linear Planar Surface Mount FP28LEC
Page 2 of 2 Wall/Ceiling Mount T5 Fluorescent, ADA Compliant
Candlepower Summary
Angle Along 22.5. 45 67.5 Across. Output
Lumens
0 351 351 351 351 351
5 351 350 349 349 347 33
15 340 338 338 340 338 96
25 316 317 320 323 321 148
35 284 286 291 296 295 182
45 242 247 256 264 263 197
55 193 201 213 220 221 188
65 137 147 160 167 169 155
75 76 86 98 104 105 101
85 19 29 41 47 49 44
90 6 16 27 32 33
95 7 17 27 32 33 27
105 10 18 31 40 43 30
115 10 17 30 41 45 29
125 10 18 27 37 41 24
135 9 14 21 30 33 17
145 8 11 18 21 22 10
155 7 8 12 16 18 6
165 6 7 8 9 11 2
175 8 8 7 6 5 1
180 7 7 7 7 7
100
200
300
400
0°30°
60°
90°
Certied Test Report no. 3648FR
Computed by LSI Program **TEST-LITE**
SC= 1.3
Prepared For:
Lightolier
Fall River, MA
TESTED ACCORDING TO IES PROCEDURES. TEST DISTANCE EXCEEDS FIVE
TIMES THE GREATEST LUMINOUS OPENING OF LUMINAIRE.
Zonal Lumens and Percentages
Zone Lumens % Lamp %Luminaire
0-30 276 10.60 21.47
459 17.59 35.61
844 32.34 65.47
144 43.84 88.75
685 26.25 53.14
300 11.50 23.28
145 5.56 11.25
1289 49.40 100.00
0-40
0-60
0-90
40-90
60-90
90-180
0-180
** Efciency = 49.4% **
Coefficients of Utilization
Ceiling 80% 70% 50% 30% 10%
Wall 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0
RCR Zonal Cavity Method - Effective Floor Reflectance = 20%
Room Cavity Ratio
0 .57 .57 .57 .57 .56 .56 .56 .56 .52 .52 .52 .48 .48 .48 .45 .45 .45 .44
1 .52 .50 .48 .46 .50 .48 .46 .45 .45 .44 .42 .42 . 41 .40 .40 .39 .38 .36
2 .48 .44 .40 .37 .46 .42 .39 .36 .39 .37 .35 .37 .35 .33 .35 .33 .32 .30
3 .43 .38 .34 .31 .42 .37 .33 .30 .35 .32 .29 .33 .30 .28 .31 .29 .27 .26
4 .40 .34 .29 .26 .38 .33 .29 .26 .31 .27 .25 .29 .26 .24 .27 .25 .23 .22
5 .36 .30 .25 .22 .35 .29 .25 .22 .27 .24 .21 .26 .23 .20 .24 .22 .19 .18
6 .33 .27 .22 .19 .32 .26 .22 .19 .24 .21 .18 .23 .20 .17 .22 . 19 .17 .16
7 .30 .24 .19 .16 .29 .23 .19 .16 .22 .18 .16 .21 .17 .15 .20 .17 .15 .14
8 .28 .21 .17 .14 .27 .21 .17 .14 .20 .16 .13 .19 .15 .13 .18 .15 .13 .12
9 .26 .19 .15 .12 .25 .19 .15 .12 .18 .14 .12 .17 .13 .11 .16 .13 .11 .10
10 .24 .17 .13 .11 .23 .17 .13 .11 .16 .13 .10 .15 .12 .10 .14 .12 .10 .09
Determined In Accordance With Current IES Published Procedures
Luminaire Input Watts = 32.0
DECORATIVE LUMINAIRE CAT. # FP28U / FPA3 28W
SYLVANIA T-5 LAMPS. LUMEN RATING = 2610 LMS.
BALLAST/ ADVANCE ICN-2S28
FP28U / FPA3
