SMITH SYSTEM Planner Studio User manual

Document #: 179679
REVISED: 01/2020
Assembly Instructions
Planner Studio
Adjustable Height Tables
If you have damaged or missing components,
please contact customer service at 1-800-328-1061

Document #: 179679
REVISED: 01/2020
Hardware and Components
PLANNER STUDIO TOP
QTY. 1
PACK #70008
( LOW RANGE: #77239 )
PLANNER STUDIO LEG BASE
QTY. 2
PLANNER STUDIO SUPPORT CHANNEL
QTY. 1
1/4”-20 X 3”BOLT
QTY. 6
1/4”-20 LOCK NUT
QTY. 6
#10 X 3/4”WOOD SCREW
QTY. 28
3/8”-16 X 5/8”SET SCREW
QTY. 8
PACK #70009
( LOW RANGE: #77240 )
3/16”ALLEN WRENCH
QTY. 1
PLANNER STUDIO ADJUSTABLE
LEG WITH GLIDES
QTY. 4
PLANNER STUDIO ADJUSTABLE
LEG FOR CASTERS
QTY. 4
CASTER WRENCH
QTY. 1
4”CASTER
QTY. 4

Document #: 179679
REVISED: 01/2020
Special Notes:
•TOOLS REQUIRED:
•Drill w/#2 phillips driver bit, or #2 phillips head screwdriver.
•7/16” socket & ratchet, or 7/16” wrench.
•Check that all components are accounted for and undamaged beforeassembling.
•Please assemble the product in a clean and dry area.
•You will need another person to help assemble the product. Team lifting required.
•Clean the product with a mild cleaner and a damp cloth.

Document #: 179679
REVISED: 01/2020
Assembly Instructions
1. Lay top down on a clean smooth surface that will not harm the top finish. Underside of
top should be exposed. Top is heavy, team lifting is advised.
2. Position the support channel(s) onto the top, as shown. Do not attach support channel
to top yet. First attach the legs, one at a time, to the support channel(s) by using the
supplied 1/4”-20 x 3” bolts and 1/4”-20 lock nuts.
Helpful Hint: The nut goes on the inside; bolt head seen on the outside.
Helpful Hint: Make sure legs are facing the right direction, as shown.

Document #: 179679
REVISED: 01/2020
3. Attach the now assembled frame to the wood top using #10 x 3/4”wood
screws. Hole pattern on underside of top serves as a guide for proper
positioning.
4. CASTER / GLIDE INSTALLATION
a. GLIDES - Install adjustable legs into leg base, place at desired height and then lock
in place using 3/8”-16 x 5/8” set screws.

Document #: 179679
REVISED: 01/2020
4. CASTER / GLIDE INSTALLATION (continued)
b. CASTERS - Step 1: Install adjustable legs into leg base, place at desired height and
then lock in place using 3/8”-16 x 5/8” set screws.
CASTERS - Step 2: Install casters using the caster wrench provided. Hand tighten
until very snug.
STEP 1
STEP 2

Document #: 179679
REVISED: 01/2020
5. With a partner, team lift table and flip to the upright position.
Helpful Hint: Lock all casters to prevent unexpected rolling when table legs touch down.
ASSEMBLY COMPLETE
…TABLE WITH GLIDES
…TABLE WITH CASTERS
