Lightolier Calculite ProSpec PB3P3810 User manual

8 3/4”
39 1/2”L X 10”W
PB3P3810BL = (Flanged) Black/White
PB3P3810WL = (Flanged) White
PB3P3810BTL = (Trimless) Black
PB3P3810WTL = (Trimless) White
21" L X 7" W Opening
7” OC 7” OC
6
4
1211 3
10
8
5
1 3/4”
7
9
Flanged Trimless
Top View
13"
42 1/4"
8"
Calculite®ProSpec®Linear Downlight PB3P3810
Page 1 of 2 3 Light PAR38 Series B
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Features
1. Aperture Frame: Provides clean support for lamp holders and overlapping
flange or trimless installation. Extruded aluminum. Rigidly welded together
on all corners.
2. Media Cartridge: Allows convenient loading and removal of one accessory.
Easily installed and removed for lamping with a simple twisting motion.
Constructed of die formed aluminum.
3. Adjustable Ring: Allows 360° horizontal and 30°, max. 45° (on length); 40°
(on width) vertical adjustment.
4. Tortiontite Spring: For easy installation of aperture frame.
5. Housing: Die formed 22 ga. steel. Finish: Black
6. Mounting Brackets: Adjustable vertically from outside of housing.
7. Thermal Protector: Meets NEC, UL, and CSA requirements.
8. Lampholder: Porcelain medium based; nickel plated screw shell.
Prewired with #18 SF-1 leads to junction box.
9. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box. Allows inspection from
below.
10. Lamp and Accessory Support: .032" steel, flared for easy entry of Media
Cartridge.
11. Lens Retaining Ring: .093" spring steel rod. Holds accessories in place.
Electrical
UL/cUL listed for through branch circuit wiring with maximum of (8) no. 12 AWG,
90°C.
Ceiling Cutout: 22 1/16" L x 8 3/16" W
Ordering Information: PAR38 Series B
Cat. No. Lamp Ceiling Trim Aperture Finish
PB3P3810BL (3) 100W PAR38 Overlap Black with White Flange
PB3P3810WL (3) 100W PAR38 Overlap White with White Flange
PB3P3810BTL (3) 100W PAR38 Trimless Black
PB3P3810WTL (3) 100W PAR38 Trimless White
Finish
All painted finishes are powder coated baked enamel.
Options & Accessories
Accessories: 4 3/4" dia. series, filters, lenses, screens, and louvers (1) max.
Label
UL/cUL (Suitable for Damp Location), I.B.E.W.

PB3P3810
03/02
Calculite®ProSpec®Linear Downlight PB3P3810
Page 2 of 2 3 Light PAR38 Series B
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • B0711
Job Information Type:
Lighting Performance Data
