OAKWORKS Spa OAKWORKS ProLuxe Series User manual

USER MANUAL
www.oakworks.com · 717.235.6807
OAKWORKS®
ProLuxe Series

© Copyright 2021
OAKWORKS®, Inc.
Printed in U.S.A.
All rights are reserved. No part
of this document may be
photocopied, reproduced or
translated to another language
without prior written consent
of OAKWORKS®, Inc.
OAKWORKS®is a registered
trademark of OAKWORKS®, Inc.
Notice
The information contained within
this document is subject to change
without notice and should not
be construed as a commitment by
OAKWORKS®, Inc.
OAKWORKS®, Inc. encourages
requests for technical specifica-
tions and the like documentation to
ensure accuracy. The appropriate
documentation is available upon
request.
OAKWORKS®, Inc. shall not be
liable for incidental or consequen-
tial damages in connection with or
arising out of the furnishing, per-
formance, or use of this document
and the program material which it
describes.

TABLE OF CONTENTS
Product Use Description ............................................................................................. 1
Important Safety Instructions
Symbol Identification ........................................................................................... 1
Safety Instructions ........................................................................................... 2-3
Installation
Grounding ........................................................................................................... 4
Product Description & Photo
ProLuxe Electric Salon Top ................................................................................. 5
Control Operation - ProLuxe Electric Salon Top .................................................. 5
ProLuxe Lift Assist Salon Top ............................................................................. 7
Controls Operation - ProLuxe Lift Assist Salon Top............................................. 8
ProLuxe Lift Assist Backrest Top......................................................................... 9
Controls Operation - ProLuxe Lift Assist Backrest Top ...................................... 10
ProLuxe Flat Top............................................................................................... 11
Controls Operation - ProLuxe Flat Top .............................................................. 12
Directions for Use
Adjusting the Back Rest section ........................................................................ 13
Adjusting the Leg Rest section .......................................................................... 13
Moving the table................................................................................................ 14
Dual Locking Casters Use ................................................................................. 14
Hot Towel Cabi & Storage Shelf........................................................................ 15
Removing Top Pad............................................................................................ 16
Adjustable Breast Comfort (ABC) System (Option)............................................ 17
Integrated Heated Top (Option)......................................................................... 18
QuickLock Face Rest (Accessory Option).......................................................... 19
Adjustable Side Arm Rests (Accessory Option) ................................................. 20
Boiance Shelf Support (Accessory Option)........................................................ 21
Bluetooth Speaker (Accessory Option) .............................................................. 22
Cleaning & Disinfection
Recommended Cleaners/Disinfectants .............................................................. 23
Cleaning Process .............................................................................................. 23
Inspections & Maintenance ....................................................................................... 24
Warranty Information ................................................................................................ 24
Model Number & Serial Number
Proluxe Series................................................................................................... 25
Specifications
Table Dimensions.............................................................................................. 26
Storage and Cabi Shelf Dimensions .................................................................. 26
Product Specifications....................................................................................... 27
Environmental Conditions.................................................................................. 27
Electrical Specifications..................................................................................... 27
Guidance and manufacturer’s declaration -
Electromagnetic emissions ................................................................................ 28
Recommended separation distances ................................................................. 28
Guidance and manufacturer’s declaration -
Electromagnetic immunity............................................................................. 29-30
Contact Information ...................................................................................... back cover

This symbol, when used in this manual and on product labels, represents a caution
warning. Be sure to read and comply with all precautions and warnings.
This symbol, when used in this manual and on product labels, warns against an elec-
trical shock hazard. Be sure to observe and comply with all warnings.
This symbol, when used in this manual or on product labels, indicates a Protective
Earth (Ground) Terminal.
This symbol, when used in this manual or on product labels, indicates the date of
manufacture of the device.
This symbol, when used in this manual or on product labels, indicates alternating
current (AC).
This symbol, when used in this manual or on product labels, indicates direct current
(DC).
This symbol is used to indicate that the operator should consult the user manual.
UL 2601-1
CSA C22.2NO.601.1
IEC 60601-2(2001-09)
CCUSUS
LL
II
SS
TT
EE
DD
R
UL 2601-1
CSA C22.2NO.601.1
IEC 60601-2(2001-09)
CCUSUS
LL
II
SS
TT
EE
DD
R
~
----
PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS
PRODUCT USE DESCRIPTION
Oakworks ProLuxe Series offers a variety of positioning capabilities for massage therapists and spa
professionals of all specialties. On these multifunctional professional tables, the practitioner can per-
form numerous protocols with ease and comfort. The fully electric ProLuxe Series is especially effec-
tive when professional protocols require specific positioning for the client. While the client receives
comfortable, relaxing support, the comfort level of the therapeutic professional is enhanced by supe-
rior ergonomics.
It is intended to be operated by Massage Therapists in a professional environment. No special train-
ing is required but a review of the following Safety Instructions is important for the safety of the oper-
ator and client. The massage professional should read and understand this entire manual before use
with a client. There are no known contraindications to the use of this equipment.
The ProLuxe Series should not be used in any other manner than that described within this manual.
Use of any unnecessary force or unauthorized procedures could result in injury to practitioner, client
or equipment.
SYMBOL IDENTIFICATION
1

IMPORTANT SAFETY INSTRUCTIONS
DANGER
To reduce risk of electric shock:
1. Always unplug this furnishing from the electrical outlet before cleaning.
2. Connect this furnishing to a properly grounded outlet only. See Grounding Instructions in this manual.
Electrical Shock Hazard - The power supply/control module is located on the lift frame. No user serviceable parts
are inside. Refer servicing to qualified personnel. Unplug wall plug prior to contact with any cables connected to
the power supply.
WARNING
To reduce the risk of burns, fire, electric shock or injury to persons:
1. Unplug from outlet before adding or removing parts.
2. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use at 717.235.6807.
3. Keep the cord away from heated surfaces.
4. Never drop or insert any object into any opening.
5. Do not use outdoors.
6. Use this furnishing only for its intended use as described in these instructions. Do not use attachments not rec-
ommended by the manufacturer.
7. To disconnect, turn all controls to the off position, then remove plug from outlet.
8. Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a
qualified electrician if you are in doubt as to whether the product is properly grounded.
9. Do not modify the plug provided with the product - If it will not fit the outlet, have a proper outlet installed by a
qualified electrician
WARNING
• Risk of Injury - 550 lbs. (250 kg.) maximum load.
• Risk of Injury - Do not operate this equipment unless properly trained.
• Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled per-
sons.
• This unit is For Commercial Use Only and to be operated only by trained personnel..
• Lifting & Top motion electric motors are rated at 10% duty cycle max. (2 minutes on, 18 minutes off)
PINCH HAZARD
• Keep hands, feet and controls away from the table while making adjustments.
• Risk of Injury - Not to be used in locations where children or people with cognitive disabilities are antici-
pated to be present.
• Risk of Injury - Children should NEVER be near the table when in use.
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
2

IMPORTANT SAFETY INSTRUCTIONS
ENTRAPMENT
• Risk of Injury - The picture below indicate areas of entrapment that can occur when operating this equip-
ment. It is the responsibility of the operator to ensure that bystanders are not in or around these areas dur-
ing operation.
CAUTION
• The use of accessories, transducers, and cables other than those specified by the manufacturer, may
result in increased emissions or decreased immunity of the table.
• The table should not be used adjacent to or stacked with other equipment. If adjacent or stacked use is
necessary, the table should be observed to verify normal operation in the configuration in which it will be
used.
• The table is designed to be a stand-alone table. This table must not be modified or incorporated into any
other equipment.
• Proper operation of this equipment is very important for the safety of the operator, client, and any other
individuals in the area of this equipment. Directions for use of this equipment are described in this manual.
The operator should read these sections carefully.
• Weight Limit: (client and accessories) 550 lbs. (250 kg.) Do not exceed.
• Adjustable Breast Comfort (ABC) System Weight Limit: 100 lbs. (45 kg.)
• Do not sit on the ABC System. Only use the ABC System as intended. Do not place foreign objects into the
ABC System. For safety of your client, use a cloth sheet between the ABC System and your client.
• Be certain that the table is completely lowered without any tilt being present prior to discharging an ambu-
latory client. The client may lose balance and fall.
• When lowering the table, make sure there is nothing underneath the tabletop that can impede motion (like
stools, cabinets, accessory parts, cleaners, etc.) When using the table Height Up function, do not place
anything between the metal frame and the base structure. Damage can occur to the table.
• Do not sit on backrest or footrest sections.
• Before moving any of the tables, disconnect the power cord from the power outlet.
• The table weighs as much as 200 lbs. (91 kg.)
• Do not lift table by the tabletop pad. This can damage the removable pad. Use extreme caution when lift-
ing the table to move it. 2 people are required to move the table safely.
• Do not use the table to transport a client.
3

The Tables come completely assembled and ready to use. Plug the cord into a functioning outlet that
is rated for the table. (See Grounding below)
Arrange the power cord and control cords so that they will not create a tripping hazard and where the
controls are located to your liking and are conveniently accessible.
Be sure access to plug is not blocked for disconnecting the table from power.
INSTALLATION
GROUNDING
Grounding for 120 Volt products:
This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug
shown below. See Grounding Methods - US 120V Example. Make sure that the product is connected
to an outlet having the same configuration as the plug. No adapter should be used with this product.
Grounding for 230 Volt products:
This product is rated for less than 15 amperes and is for use on a circuit having a nominal rating
of 230 volts and is factory-equipped with specific electric plug to permit connection to a proper
circuit. Make sure that the product is connected to an outlet having the same configuration as the
plug. No adapter should be used.
Correct Implementation Incorrect Implementation
Risk of Electric Shock - Connect this furnishing to a properly grounded outlet
only.
DANGER

Grounding Methods - US 120V Example
4

PRODUCT DESCRIPTION
ProLuxe
Electric Salon Top
STANDARD SPECIFICATIONS
Motion 1* Powered 22”-40” (57-102 cm.) Height Range
Motion 2 Powered 0-70º Backrest
Motion 3 Powered 0-30º Foot Rest
Foot Control All powered motions
Table Voltage Options 120V/60Hz - 230V/50Hz
Table Capacity 550 lbs. (250 kg.) (client and accessories)
Widths 29” (74 cm.), 31” (79 cm.), or 33” (84 cm.)
Length 73” (185 cm.)
Padding 4” (10 cm.) or 6” (15 cm.) Aerocel Foam™
Table Weight 200 lbs. (91 kg.)
* Height Range with Cabi/ Storage Shelves is 28” - 40” (71 - 102 cm).
OPTIONS
Adjustable Breast Comfort (ABC) System
Dual Locking Casters
Cabi/ Storage Shelves
Integrated Heated Top
ACCESSORIES
QuickLock Face Rest
Boiance Shelf Support
Side Arm Rests
5
For electrical specs, see Specifications section.

CAUTION Do not sit on the backrest or leg rest sections. Be sure the self-locking molded rubber feet are flat side
down to ensure safety and stability. The hood area under the backrest top is not designed for stor-
age. DO NOT use this area for holding anything. Damage can occur to the table.
DIRECTIONS FOR USE
CONTROL OPERATIONS - ELECTRIC SALON TABLE
The ProLuxe Electric Salon Tables offer height, backrest, footrest, and optional ABC positioning with electronic
ease. Operate the foot and/ or optional hand control as shown below to raise or lower the height, backrest,
footrest, or optional ABC functions of the table.
Backrest Down
Backrest Up
Height Down
Height Up
Footrest Down
Footrest Up
P/N: 71567-1 P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2 P/N: 71569-2
Backrest DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Backrest UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Footrest UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Footrest DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
ABC UP
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC DOWN
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC SYSTEM UP
ABC SYSTEM DOWN
ABC Option
ABC Option
Backrest Down
Backrest Up
Height Down
Height Up
Footrest Down
Footrest Up
ABC Down
ABC Up
FOOT CONTROL WITH ABC
STANDARD FOOT CONTROL
OPTIONAL HAND CONTROL
6

PRODUCT DESCRIPTION
ProLuxe
Lift-Assist Salon Top
STANDARD SPECIFICATIONS
Motion 1* Powered 22”-40” (57-102 cm.) Height Range
Motion 2 Manual 0-80º Backrest
Motion 3 Manual 0-30º Foot Rest
Foot Control Height Range
Table Voltage Options 120V/60Hz - 230V/50Hz
Table Capacity 550 lbs. (250 kg.) (client and accessories)
Widths 29” (74 cm.), 31” (79 cm.), or 33” (84 cm.)
Length 73” (185 cm.)
Padding 4” (10 cm.) or 6” (15 cm.) Aerocel Foam™
Table Weight 190 lbs. (86 kg.)
* Height Range with Cabi/ Storage Shelves is 28” - 40” (71 - 102 cm).
OPTIONS
Adjustable Breast Comfort (ABC) System
Dual Locking Casters
Cabi/ Storage Shelves
Integrated Heated Top
ACCESSORIES
QuickLock Face Rest
Boiance Shelf Support
Side Arm Rests
7
For electrical specs, see Specifications section.

DIRECTIONS FOR USE
CONTROL OPERATIONS - LIFT-ASSIST SALON TABLES
P/N: 71567-1 P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2 P/N: 71569-2
The ProLuxe Lift-Assist Salon tables offer height positioning with electronic ease. Operate the foot and/
or optional hand control as shown below to raise or lower the height of the table and operate the optional
ABC.
DOWN
UP
Height
UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height
DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height Down
ABC Down
ABC
UP
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC
DOWN
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC SYSTEM UP
ABC SYSTEM DOWN
ABC Up Height Up
FOOT CONTROL WITH ABC
STANDARD FOOT CONTROL
ABC OptionABC Option
CAUTION
OPTIONAL HAND CONTROL
Do not sit on the backrest or footrest sections. Be sure the self-locking molded rubber feet are flat side
down to ensure safety and stability. The hood area under the backrest top is not designed for stor-
age. DO NOT use this area for holding anything. Damage can occur to the table.
8

PRODUCT DESCRIPTION
ProLuxe
Lift-Assist Backrest Top
STANDARD SPECIFICATIONS
Motion 1* Powered 22”-40” (57-102 cm.) Height Range
Motion 2 Manual 0-80º Backrest
Foot Control Height Range
Table Voltage Options 120V/60Hz - 230V/50Hz
Table Capacity 550 lbs. (250 kg.) (client and accessories)
Widths 29” (74 cm.), 31” (79 cm.), or 33” (84 cm.)
Length 73” (185 cm.)
Padding 4” (10 cm.) or 6” (15 cm.) Aerocel Foam™
Table Weight 180 lbs. (82 kg.)
* Height Range with Cabi/ Storage Shelves is 28” - 40” (71 - 102 cm).
OPTIONS
Adjustable Breast Comfort (ABC) System
Dual Locking Casters
Cabi/ Storage Shelves
Integrated Heated Top
ACCESSORIES
QuickLock Face Rest
Boiance Shelf Support
9
For electrical specs, see Specifications section.

DIRECTIONS FOR USE
CONTROL OPERATIONS - LIFT-ASSIST BACKREST TABLES
P/N: 71567-1 P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2 P/N: 71569-2
The ProLuxe Lift-Assist Backrest tables offer height positioning with electronic ease. Operate the foot and/or
optional hand control as shown below to raise or lower the height of the table and operate the optional ABC.
DOWN
UP
Height
UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height
DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height Down
ABC Down
ABC
UP
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC
DOWN
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC SYSTEM UP
ABC SYSTEM DOWN
ABC Up Height Up
FOOT CONTROL WITH ABC
STANDARD FOOT CONTROL
ABC OptionABC Option
CAUTION
OPTIONAL HAND CONTROL
Do not sit on the backrest section. Be sure the self-locking molded rubber feet are flat side down to
ensure safety and stability. The hood area under the backrest top is not designed for storage. DO
NOT use this area for holding anything. Damage can occur to the table.
10

PRODUCT DESCRIPTION
ProLuxe
Flat Top
For electrical specs, see Specifications section.
STANDARD SPECIFICATIONS
Motion 1* Powered 19”-36.5” (48-93 cm.) Height Range
Foot Control Height Range
Table Voltage Options 120V/60Hz - 230V/50Hz
Table Capacity 550 lbs. (250 kg.) (client and accessories)
Widths 29” (74 cm.), 31” (79 cm.), or 33” (84 cm.)
Length 73” (185 cm.)
Padding 4” (10 cm.) or 6” (15 cm.) Aerocel Foam™
Table Weight 170 lbs. (70 kg.)
* Height Range with Cabi/ Storage Shelves is 26” -36.5” (66 - 93 cm).
OPTIONS
Adjustable Breast Comfort (ABC) System
Dual Locking Casters
Cabi/ Storage Shelves
Integrated Heated Top
ACCESSORIES
QuickLock Face Rest
Boiance Shelf Support
11

CONTROL OPERATIONS - FLAT TOP TABLES
DIRECTIONS FOR USE
P/N: 71567-1 P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2 P/N: 71569-2
The ProLuxe Flat Top tables offer height positioning with electronic ease. Operate the foot and/or optional
hand control as shown below to raise or lower the height of the table and operate the optional ABC.
DOWN
UP
Height
UP
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height
DOWN
P/N: 71567-1 P/N: 71569-1P/N: 71568-1
Clear Window
Blue PMS #283C
Height Down
ABC Down
ABC
UP
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC
DOWN
P/N: 71567-1
P/N: 71569-1
Clear Window
Blue PMS #283C
P/N: 71568-1 P/N: 71567-2
P/N: 71569-2
ABC SYSTEM UP
ABC SYSTEM DOWN
ABC Up Height Up
FOOT CONTROL WITH ABC
STANDARD FOOT CONTROL
ABC OptionABC Option
CAUTION Be sure the self-locking molded rubber feet are flat side down to ensure safety and stability.
OPTIONAL HAND CONTROL
12

DIRECTIONS FOR USE
TO RAISE THE BACKREST
Raise the back rest by pressing the lever
under the head section and lifting up to
the desired height. It is recommended that
clients take some of their weight off the
back rest while you lift.
CAUTION
LIFT-ASSIST BACKREST ADJUSTMENT
Do not sit on the backrest section.
TO LOWER THE BACKREST:
Press the lever under the head section and
push the back rest down.
LIFT-ASSIST LEG REST ADJUSTMENT
TO RAISE THE LEG REST
Raise the leg rest by pulling the lever on
the side of the leg section and raise to the
desired height. It is recommended that
clients take some of their weight of the leg
rest while you lift.
TO LOWER THE LEG REST
Pull the lever on the side of the leg
section and push the leg section down.
Release the lever once the leg rest is at
its desired location and the leg section will
stay in place.
TO CHANGE POSITION OF THE LEG REST LEVER
The leg rest lever can be moved to the opposite side of the table. First, remove the screws from
the lever and replace the screws. Move the lever to the opposite side of the table. Remove the
screws that are there and mount the lever.
TO CHANGE POSITION OF THE BACKREST LEVER
The backrest lever can be moved to the opposite side of the back rest by removing the
screws and relocating the hand lever to the opposite side of the top into the four pre-drilled
holes.
13

All casters should be locked at all times during use with a client.
DUAL LOCKING CASTERS USE
LOCKING THE CASTERS
1. Place your shoe on the end of the casters locking tab.
2. Press firmly downward until you hear a clicking noise
and the caster is locked.
UN-LOCKING THE CASTERS
1. Place your shoe on top of the casters locking tab.
2. Press firmly inward and downward until you hear a
clicking noise and the caster is unlocked.
The tables are equipped with two wheels at one end and two self-locking, molded rubber feet at the other.
When ready to move the table, first lower the table to its lowest position. On models with a back rest, it is
recommended to raise the back rest to a high position. Then be sure the power source is disconnected.
Place the cord & all controls out of the way on top of your table before moving the table. Lay a towel or a
cloth down on your table top to protect the surface from any debris from the bottom of your foot control.
Two people are required to safely move the table. Grasp the table frame securely at the end with the molded
rubber feet. Raise the table to allow the wheels at the foot end to move freely. Bending at the knees before
lifting to prevent back strain or possible injury.
Move the table carefully to the next location, lower the table and release. Check the self-locking molded
rubber feet to be sure they are flat side down. This position “locks” the table and allows sturdy height adjust-
ments. Place the foot controls in position on the floor. Connect the power cord to the outlet and test the
foot control.
CAUTION
MOVING THE TABLE
Before moving any of the tables, disconnect the power cord from the power outlet. The
table weighs as much as 200 lbs. (91 kg.) Use extreme caution when lifting the table
to move it. Two people are required to move the table safely. DO NOT use the table to
transport a client.
DIRECTIONS FOR USE
Grasp the table
frame securely
here at both sides
of the brace.
14

DIRECTIONS FOR USE
HOT TOWEL CABI SHELF & STORAGE SHELF
CAUTION • The Anti-Tip Strap must be installed when using a Hot Towel Cabi.
• Do not overload the storage Shelf. [Max load weight is 25 lbs. (11.3 kg)]
• Do not use electrical devices that require more than 15 amps with the power strip.
• Make sure all cords are safely located out of the way to avoid trip hazards.
• Make sure no cords are pinched when the table is raised and lowered.
• Open the Hot Towel Cabi slowly to prevent hot steam from burning the client when it is
located and the head end of the table.
The Cabi Shelf holds a Hot Towel Cabi with dimensions
no greater than 17.9” W x 12.6” D x 11.4” H.
Place the Hot Towel Cabi on the Cabi Shelf and center it.
Wrap the Anti-Tip Strap tightly around the Cabi and shelf
as shown to secure it against tipping.
Anti-Tip
Strap
PRODUCT USE:
The shelves are designed to provide storage areas for items needed during treatment and equipment. The
shelves will change the overall height range of the table.
Storage
Shelf
Cabi
Shelf
CABI SHELF DIRECTIONS FOR USE:
Plug Hot Towel Cabi into the Power Strip located on the
table rail or underneath the platform. Make sure all cords
are out of the way to prevent a trip hazard.
15
Power
Strip

DIRECTIONS FOR USE
REMOVING TOP PAD
The top pad has been designed to be easily removable and replaceable with no tools needed.
Thumb Screw Locations (4 per side)
1. Unscrew the thumb screw clockwise until the thumb screw is completely
removed. Repeat for all 8 thumb screws. If the thumbs screws are on too
tight, a 3/16” bit can be used.
2. Lift top pad off the platform.
IF THE TABLE HAS A HEATED TOP:
Unplug the table from the wall outlet and disconnect the wires circled from the control box located under the
platform. Pull the cables through the platform before completely removing the top pad.
TO REMOVE THE TOP PAD:
The top pad is attached to the platform with 8 thumb screws located below the platform as shown.
Heated Top Cables
16

DIRECTIONS FOR USE
ADJUSTABLE BREAST COMFORT (ABC) SYSTEM (OPTION)
CAUTION
• ABC System Weight Limit - 100 lbs. (45 kg.) Do not sit on the ABC System.
• Do not place foreign objects into the ABC System. Only use as intended.
• For safety of your client, use a cloth sheet between the ABC System and your client.
When turning clients over in the supine
position, you may use the cushion to level
during or after their change of position. IT is
not important that the cushion be completely
level. As in prone positions, make small
changes in height and check in with the client.
In Prone positions, for male or female clients when the face rest is in use, lower
the cushion approximately 3/4” at a time (This is approximately 1 second of
lowering) and check in with the client regarding their comfort after making the
change. Incrementally lower the cushion until the client reports they are com-
fortable. Sometimes going back up a little will be preferred. This whole process
takes no more than 15-20 seconds. After lowering, check headrest position to
ensure comfort & support. NOTE: Breast size is not the only determinate of cush-
ion location. Every person’s comfort spot is different, regardless of breast size.
If you are using the head rest in the
Supine position, you may use the cush-
ion at relatively high heights to facilitate
stretching for short periods of time. It is
not recommended that clients experience
this position for more than a few minutes.
The OAKWORKS®Adjustable Breast Comfort (ABC) System is designed to lower the pressure on breasts and pectoral
muscles, allowing the client to relax and create a more comfortable position for their spine. The height of the cushion is
easily adjusted up and down in small increments by using the hand control. We recommend that the cushion height be
adjusted in the following ways:
*Always start with the cushion top level with the top of the table for Prone or Supine Positioning*
PRONE POSITIONING
SUPINE POSITIONING
HEAD REST USE IN SUPINE
17
