Architectural Decorative CS100
Page 1 of 1 Undercabinet Magnetic Track LED
Features
• Ultra low profile track with steel insert
• Magnetic light modules can be positioned anywhere along the track. Modules
can be moved, added, or removed according to lighting needs.
• Finish: Light modules – matte aluminum
Track – Clear anodized aluminum
• Light Modules: Shallow architecturally pleasing shape. Concealed integrated
fins in light module body with concentric vent designed to create air circula-
tion to maintain appropriate junction temperature of LEDs.
• Up to (7) light modules per single wired track.
• Remote low profile power supply – 50W 120V.
Magnetic Light Module: (3) 1W 3000K white LEDs. Average expected life,
under normal operating conditions is 50,000 hours with 70% lumen maintenance
of original light output.
Electrical: Max connected load – 4W per fixture.
Power Supply LED-RPS-50: Class 2 24V DC output is remote mounted, 120V
input. Max Connected System Load – 50W per power supply.
Wiring: 5ft track pre-wired with 8ft cord. 24V DC only.
Material: Light Modules – die-cast aluminum
Track – extruded aluminum
Mounting: Track – pre-drilled holes for screw mounting (screws not included).
Magnetic light modules can be placed anywhere along track.
Labels
cULus listed, Dry Location.
2 3/4"
[70 mm]
13/16"
[20 mm]
2 15/16"
[75 mm]
Track Depth .290"
Track with Puck Depth 29/32"
1 1/2"
[38 mm] 3 13/16"
[98 mm]
Catalog Number Finish Description Wattage Voltage
CS100AL Matte Aluminum 5ft Track With Switch NA 24V DC
CS101AL Matte Aluminum Magnetic Light Module 4W 24V DC
LED-RPS-50* Matte Black Remote Power Supply 50W Max. 120V
* See below for remote power supply dimensions.
