FORTIS U-SHAPE
Assembly Instructions
Thank you for your purchase!
Iron Age Office furniture is uniquely and individually
fabricated. For this reason, your furniture is pre-assembled
and labeled before shipping. Labels are marked on the
underside of the furniture. Most furniture is then
deconstructed prior to shipping. Pieces that uniquely
correspond can typically be found on the same pallet.
Assembly is best completed by keeping the pieces that
correspond together. Clear your work area of anything that
could scratch furniture surfaces. If possible, cover your
work area with a clean, soft blanket. Carefully flip
any wooden tops over and inspect the bottom sides for markings.
Match legs, flat brackets, etc.
to the appropriate labels.
If you need further assistance of any kind,
please contact:
Iron Age Office Operations Manager
Henry Dover
678-725-1473 (c)
[e-mail]

HARDWARE
Screws are shown actual size. You may receive extra hardware with your unit.
14-10 LAG BOLT
QTY: 44
SCREEN BOLT
QTY: 4
SCREEN NUT
QTY: 4
LEVELING FOOT
QTY: 8 9/16 Crescent Wrench
15/16 Crescent Wrench
3/8 Hex Drive
#3 Square Drive
Tools Required
1
2
3
4

PARTS *
B1
R1
M1
*
A
B
1
2
MS1
SPLICE PLATE
STANDARD LEG
RIGHT TABBED LEG
LEFT TABBED LEG MAIN TOP
RETURN
TOP
MAIN SCREEN
SPLICE PLATE
BACK TOP
1
2
*
A
B
M1
R1
B1
MS1

ASSEMBLY
STEP 1
Place wood tops face down on a clean surface.
STEP 2
Align legs using markings on
the underside of the wood tops.
Tabbed legs should be placed so that
tabs are facing each other.
Screw in all legs with
(4) 14-10 lag bolts in each leg.
Screw in (4) 14-10
Lag bolts in each leg
using a #3 square drive.
STEP 3
Attach screen to front tabbed legs
with (4) screen bolts and (4) screen nuts.
Insert screen bolts into
the front of the screen
through the tabbed legs
using a 3/8 hex drive.
Fasten screen nut to screen bolt
on backside of screen using a
15/16 crescent wrench.
B1
R1
M1
B1
R1
M1
2*
*
1
1
2
1
MS1
3
2

ASSEMBLY
STEP 4
Screw in (1) leveling foot in each leg.
Screw in leveling foot into
each leg with 9/16 crescent wrench.
4
*
*
1
2
STEP 5
Align splice plates following markings on
backside of the main and back tops.
B1
B
M1
A
Screw in (3) 14-10 lag bolts in each splice plate
on the underside of the main top to secure splice plates.

ASSEMBLY
STEP 6
Flip main and and back desks to
an upright postition.
Align return top in between
main and back desks, resting
the top on the
two splice plates.
CARE INSTRUCTIONS
To care for either wooden or metal surfaces of Iron Age Office products,
gently wipe with a soft cloth dampened with water and a mild dishwashing liquid.
Once satisfied, dry with a soft cloth.
Screw in remaining (3) 14-10 lag bolts in each splice plate
on the underside of the return top to secure splice plates.
B1
R1
M1
B
A
1
STEP 7
Enjoy your desk!
