Lightolier Lytespan 83W4 User manual

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • D0410
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lytespan® Track Lighting System 83W4
Page 1 of 2 PowerArc™ Modular T-4 Single Ended Metal Halide Wall Washer
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
5 3/8"
(137mm)
1 9/16"
(40mm)
9/32"
(7mm)
2 5/8"
(67mm)
3 3/4"
(95mm)
2 7/16"
(62mm)
4 7/8"
(124mm)
7
1
5
4
3
6
2
8
Features
1. Housing: .10" thick extruded aluminum body.
2. Vertical Pivot: 0 - 180° vertical adjustment.
3. Horizontal Pivot: Die cast track adapter with infinite rotation.
4. Track Attachment Fitting: Molded polycarbonate; rotates into track.
5. Safety Lens: Tempered 1/8" glass. Meets or exceeds U.L. safety
requirements for metal halide lamps.
6. Lamp Cartridge: Die cast aluminum. Allows easy side relamping without
removal of lens.
7. Power Connector: 5kv rated with insulated pins. Connects to ballast
module. Keyed for polarity.
8. End Caps: Die cast aluminum.
9. Lampholder: (not shown) G8.5 base, 5kv pulse rated. High temperature
ceramic body.
Accessories
83EW18WH, BK, AL 18" Extension Wand
83EW48WH, BK, AL 48" Extension Wand
83EC72WH, BK 6' Extension Cord
83PCWH, BK Pipe Clamp
83MPTWH, BK Mounting Bracket
22VZ4WH, BK, AL Visor
Electrical
See ballast module spec sheet.
Ordering Information
Catalog No. Finishes Track Mountings Ballast Module Lamp
83W4WH Matte White All Lytespan® Track Systems and Multi- Use one of: T4 or T4.5, G8.5 Base, Single
83W4BK Matte Black point. PowerArc™ Modular canopies, 83B20E Ended, Ceramic Metal Halide
83W4AL Metallic Aluminum extension wands, mounting brackets or 83CY39E 83B70SE 70W Max.
pipe clamps. Not compatible with 83B39LE 83CY70E
ProSpec® or ATOM® 83B39E 83B70E
}
Compatible with
83B39LE, 83B70E only

631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2010 Philips Group • D0410
Job Information Type:
Lytespan® Track Lighting System 83W4
Page 2 of 2 PowerArc™ Modular T-4 Single Ended Metal Halide Wall Washer
Distance From Ceiling
La mp Information:
70W CDM T4 Single Ended Metal Halide.
Initial Lumens: 6400
CRI: 83
Rated Avg. life: 6,000 - 9,000 hrs.
Lighting Data
1' 150 125 56 18 8 4
2' 146 121 67 26 10 4
3' 86 75 51 27 12 5
4' 54 47 36 23 12 5
5' 35 32 25 18 10 5
6' 25 23 19 14 9 5
7' 18 17 14 11 8 5
8' 13 12 11 9 7 4
9' 10 9 8 7 6 4
169 118 169
166 138 166
111 105 111
79 79 79
57 56 57
46 45 46
36 35 36
28 28 28
23 23 23
Footcandles on Wall
Track 3 Feet From Wall Single Unit Multiple Units
4'
157 39 157
150 54 150
90 55 90
61 49 61
40 36 40
32 31 32
25 25 25
19 20 19
16 16 16
6'
3'
50°
EXAMPLE: With track located 4' from wall and multiple units spaced
6' on center and aimed 50˚ from horizontal, the illumination on wall 4'
from ceiling will be 58 f.c. beneath units and 51 f.c. between units.
1' 66 61 39 17 5 1
2' 94 84 58 29 12 5
3' 72 66 49 30 15 7
4' 49 45 36 25 15 8
5' 34 31 26 20 13 8
6' 24 23 19 16 11 7
7' 18 17 15 13 10 7
8' 14 14 12 10 8 6
9' 11 11 10 8 7 5
75 79 75
118 120 118
104 105 104
82 82 82
64 63 64
50 48 50
40 40 41
34 34 34
29 28 29
68 54 68
104 84 104
86 80 86
66 65 66
52 52 52
40 39 40
33 32 33
28 28 28
23 23 24
66 34 66
98 57 98
78 60 78
58 51 58
44 43 45
34 33 34
27 27 27
24 24 24
20 20 20
Track 4 Feet From Wall Single Unit Multiple Units
4' 5' 6'
4'
Distance From Ceiling
Footcandles are average and rounded off and data for multiple units are based on a minimum of five units.
Footcandles on wall:
58 f.c.
51 f.c.
58 f.c.
4'
50ϒ
6'
4'
0' 1' 2' 3' 4' 5'
0' 1' 2' 3' 4' 5'
Beam Center
Beam Center
160 67 160
154 88 154
96 77 96
66 63 66
46 45 46
37 37 37
29 29 29
23 23 23
19 19 19
5'
50°
For 20W: Multiply values by .25 Rated Lamp Life 7,500 - 9,000 Hrs.
For 39W: Multiply values by .50 Rated Lamp Life 9,000 - 10,000 Hrs.
