Lytecaster Recessed Downlighting 378X
Page 1 of 2 3 3/4" (95mm) Aperture Adjustable Elbow MR16
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • D0212
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
378STX
378WHX
378BKX
Stainless Steel Plated
White Paint
Black Paint
Remodeler
Remodeler
Remodeler
Non-IC
Non-IC
IC
IC
Airseal / IC
Airseal / IC
300MRSPX
3401MREX
303MRE*
302MRSPX
302MREX
302MRIC9SPX
302MRIC7SPX
302MRAICSPX
302MRAICEX
50W MR16
50W MR16
37W MR16
50W MR16
50W MR16
37W MR16
37W MR16
50W MR16
50W MR16
*Certified for wall application with 303MRE with 37W MR16
Complete fixture consists of Reflector Trim & Power Pack. Select each separately.
Reflector Trim Frame-In Kit Lamp
Features
1. Flange: Die-cast aluminum .070" (2mm) thick.
2. Elbow Housing: Die-Cast aluminum; provides 358° horizontal rotation and
0° to 70° vertical adjustment. Retracts to provide fully recessed downlight.
85° vertical adjustment. Retracts to provide fully recessed downlight.
3. Mounting Clips (2): 24ga. spring steel, zinc plated. Provide easy snap-in /
snap out action.
4. Lamp Guard: 1 3/4" (45mm) dia. borosilicate glass.
Frame-In Kit
Note: For complete Frame-In Kit specifications, see 300 frame specification
sheets.
Labels
CSA, UL Suitable for damp locations.
1/4"
(6mm)
1-1/8" MAX.
(29mm)
MR16
7-3/8"
(187mm)
4-1/2"
(114mm)
70°

Lytecaster Recessed Downlighting 378X
Page 2 of 2 3 3/4" (95mm) Aperture Adjustable Elbow MR16
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2012 Philips Group • D0212
