Harmony Series
White LED Architectural Lighting
Page 1 of 2
Job Information Type:
Job Name:
Cat. No.:
Notes:
Features
Illumination: Illumination
is provided by two field-
replaceable white LED
m o d u l e s a n d a v a c u u m p l a t e d
polycarbonate reflector. The
reflector design has been
optimized to produce a 1
footcandle average illumination
along a 6' x 30' path of egress
when placed at a mounting
height of 8' AFF.
Housing: Durable and fully
gasketed die cast aluminum
housing and cover with UV
stabilized polycarbonate
lens. A full range of pleasing
architecturally inspired powder
coated finishes are available
(see below). Wall mount to
standard 3 1/2" or 4" octagonal
junction box or single gang
junction box. Surface conduit
entry knockout located on
top of housing. Tamperproof
hardware is included standard.
Operating Temperature
Range: AC-Only Models
Standard Wet Location:
-40°F (-40°C) to 104°F (40°C)
Standard Wet Location w/
2CKT Option:
-40°F (-40°C) to 104°F (40°C)
Self-Powered Models
Standard Wet Location:
32°F (0°C) to 104°F (40°C)
Standard Wet Location w/
Heater Option:
-40°F (-40°C) to 104°F (40°C)
Battery: Maintenance-free
sealed nickel metal hydride
with 10-year life.
Diagnostic Electronics
(standard): 120/277 VAC
dual voltage input with surge
protection is standard on all
AC models. On self-powered
models, charging system is
microprocessor driven with
software embedded diagnostic
routine and temperature
compensation. 120/277 VAC
input, surge protection,
brownout, AC lockout and low
voltage disconnect features are
standard.
Self-Testing Diagnostics
(optional): The diagnostic/
charging platform with optional
self-testing mode automatically
runs a one-minute self-test
every 30 days and a 30-minute
test on the sixth and twelfth
month. A one-minute or
90-minute test may be initiated
via the push to test switch on
the unit or by activating the
appropriate test command on
the optional IR test device.
Electrical Specifications:
AC Only Models:
0.203A (120 VAC)
0.087A (277 VAC)
AC Only, 2 Circuit Models:
0.203A (120 VAC)
0.087A (277 VAC)
Self-Powered Models without
Heater:
0.198A (120 VAC)
0.088A (277 VAC)
Self-Powered Models with
Heater:
0.366A (120 VAC)
0.148A (277 VAC)
Code Compliance
UL 924 and 1598 listed. UL wet
location listed standard. NFPA
101, NEC, BOCA, OSHA and
IBC illumination standards.
ADA compliant.
Warranty
Three year full electronics
warranty. Five year full plus five
year prorated NiMH battery
warranty.
HNBR31KSD2
11.4"
(28.96 cm)
0.8"
(2.03 cm)
3.6"
(9.14 cm)
0.9"
(2.29 cm)

Harmony Series
White LED Architectural Lighting
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
Harmony Series May 1, 2012
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2012.All rights reserved.
Job Information Type:
Ordering Information
Series
H= Harmony
LED Lighting
Fixture
A= AC Only
N= Self-Powered
Emergency Unit with
Nickel Metal Hydride
Battery (NiMH)
Battery/Type
SD2 = Diagnostic
Electronics
Model Designator
Optics
Wall mounted 8' AFF
8 ft.
30 ft.
* The optics layout shown is intended to be used as reference only. Standard reflectances used were 80/50/20. Lightolier is not responsible for site specific conditions that
may alter the results.
SD2
2CKT1 = Two-Circuit 120/120 VAC (AC only models)
2CKT2 = Two-Circuit 277/277 VAC (AC only models)
DC = Universal 12-48 VDC Remote Emergency Input
(AC only models)
EX = Special Input Transformer (specify voltage &
frequency)1
HR = Heater Option for -40°C to 40°C Ambient
T= Self-Testing Diagnostics
TA = Audible Self-Testing Diagnostics
TD = Time Delay
Factory Installed Options1
Accessories (order as a separate item)
SDREMOTE = Infrared Remote Test Device
T10TPTOOL = Tamperproof Driver and Bit
H
W= White
B= Black
A= Aluminum
G= Gunmetal
BR = Ornamental Bronze
AC = Aged Copper
VG = Velvet Green
N= Nickel
GA = Granite
Housing Color
20 ft.
6 ft.
0.2 FC min.
1 FC min.
1 FC avg.
8 ft.
30 ft.
24 ft.
6 ft.
0.2 FC min.
1 FC min.
1 FC avg.
Normal or Emergency Operation (AC Only and AC 2 Circuit)
Dual fixtures on 27’ centers, 8’ AFF, provide an average of
1 footcandle on a 5’ wide path.
Single fixture provides an average of 1 footcandle over
20 feet on a 6’ wide path.
Emergency Operation (Self-Powered)
Dual fixtures on 30’ centers, 8’ AFF, provide an average of
1 footcandle on a 6’ wide path.
Single fixture provides an average of 1 footcandle over
24 feet on a 6’ wide path.
AC Only Mode Emergency Mode
Note
1) Some option combinations may impact UL
listing. Consult factory for specifics.
31K = 3,100 Kelvin
65K = 6,500 Kelvin
LED Designator
