Ballard Designs Montego MB498 User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 9-30-2021 Page 1 of 4
PRODUCT NAME: Montego Bed
ITEM NUMBER: MB498
ASSEMBLED DIMENSIONS : KING - 61”H x 82.25”W x 85.4”L
QUEEN - 60”H x 65”W x 85.4”L
MADE IN INDONESIA
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Page 2 of 4
Ltr.
A 8
B 8
Qty. Hardware Included
Ltr.
5
4
1
1
Qty. Components
C 8
TOOLS NEEDED:
Wrench (included), Phillips Screwdriver
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
I
H
J
G
F
2
D
E 1
10
NOTE: Assemble bed in area of intended use.
Threaded Bolt
Nut
Washer
Screw
Wrench
Headboard (F)
Footboard (G)
Side Rail (H)
Support Slat (I)
Support Foot (J)
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Page 3 of 4
STEP 1: ATTACH SIDE RAILS TO HEADBOARD AND FOOTBOARD
Insert and tighten Bolts (A) into both sides of Headboard (F). Align holes in Siderails (H) over ends
of Bolts then add Washer (C) followed by Nut (B). Using Wrench (E), firmly tighten Nuts until Side-
rails are secured to Headboard. Repeat process for Footboard.
(A)
(F)
(H)
(C)
(B)(E)
(G)
STEP 2: ATTACH A SUPPORT FOOT TO EACH SUPPORT SLAT
Remove protective plastic covering from each bolt on Support Foot (J) then insert each into
pre-drilled holes in FOUR Support Slats (I). NOTE: Metal T-nut faces up. Insert Support Foot
from the side opposite the T-nut. Firmly tighten and secure. One Support Slat will NOT have a
Support Foot. This slat is installed nearest the Footboard so it cannot be seen after assembly.
T-nut in Support Slat faces
up.
NOTE
(J)
(I)
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Page 4 of 4
STEP 4: ATTACH SUPPORT SLATS TO SIDE RAILS
Align pre-drilled holes in each end of Support Slats (I) with pre-drilled holes in the ledge of the Side
Rails (H) and using Screws (D), firmly secure each with a screwdriver.
(H)
(I)
(D)
STEP 4: ADJUST LEVELERS
If necessary, each Support Slat may be leveled by adjusting Leveler located under each Support
Foot (J). Carefully raise off floor and turn clockwise/counterclockwise to adjust.
(J)
NOTE: Install Support Slat without Support
Foot NEAREST Footboard so Foot is not
visible after bed is assembled.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Cleaning and Care
Periodically dust with a soft, dry cloth.
Protect surfaces to prevent damage.
Do not use alcohol based cleaners or polishers.
