INDUSTRIAL & HAZARDOUS LOCATION Emergency Lights
COOPER LIGHTING - SURE-LITES®
COOPER LIGHTING
DIMENSIONS
ORDERING INFORMATION
SAMPLE NUMBER: UMB6TH
CHARGE
TEST
12 1/4"
(311mm)
6 1/2"
(165mm)
6" (152mm) 10" (254mm)
Model Number
UMB1
UMB6
UMB7
UMB8
UMB9
UMB14
UMB15
UMB16
UMB17
Options (add as Suffix)
TDM=Time Delay Monitor
TH=Thermal Heater
Alternate Lamps(1)
Other Options(1)
Accessories
(Order separately)
WG7=Wire Guard
VS2WP=Polycarbonate
Vandal/Weather Shield
Energy Data
Input Current (Max.):
Model No. 120V 277V
UMB1, UMB6, UMB7 .12A .05A
UMB8, UMB9 .30A .13A
UMB14 .06A .03A
UMB15 .07A .04A
UMB16 .13A .06A
UMB17 .15A .07A
ELECTRICAL RATINGS
Rated Wattage to 87 1/2% of Rated D.C. Voltage Lamp Information
Model DC Voltage Battery 1 1/2 Hours 2 Hours 3 Hours 4 Hours Type Wattage Number
UMB1 6 LC 18 15 10 8 Incandescent 8 29-03
UMB6 6 LC 27 24 18 14 Incandescent 8 29-03
UMB7 6 LC 54 48 36 28 Incandescent 8 29-03
UMB8 12 LC 36 30 20 16 Halogen 8 29-16
UMB9 12 LC 54 48 36 28 Halogen 8 29-16
UMB14 6 NC 15 12 8 6 Incandescent 7.2 29-75
UMB15 6 NC 24 18 12 10 Incandescent 7.2 29-75
UMB16 12 NC 30 24 16 12 Halogen 8 29-16
UMB17 12 NC 48 36 24 20 Halogen 8 29-16
(1) Consult your Cooper Lighting Representative.
• NEMA 4X
• Dual-voltage input
120/277VAC, 60Hz
• Grey fiberglass housing
• Two top mounted, fully
adjustable, grey, high-
impact thermoplastic
heads standard
• Glare-free lens with PAR36
sealed beam lamps
• Watertight and corrosion
resistant
• Wet location listed
(32˚F or 0˚C and above)
• Gasketed, internally hinged
front cover
• Remote capability
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching, low-
voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator
light
• UL 924 Listed, Life Safety
NFPA 101, NEC/OSHA,
most state and local codes
UMB SERIES
Wet Location
EMERGENCY LIGHTING
DESCRIPTION
The ideal unit for wet
environments where an
emergency lighting unit will
be exposed to water spray,
penetrating steam, or dampness.
The UMB Series is best suited
for use in areas like waste water
treatment plants, food
processing facilities and most
industrial applications.
