INSTALLATION INSTRUCTIONS FOR LYTECEL (Both LI and LC)
1
© Lightolier 2003 59-31123-000 Printed in U.S.A.
ACCESS PLATE
Remove Access Plate by sliding Access Plate
in the direction of Arrow 1. To remove, lift up
and slide in the direction of Arrow 2. Bend
Fixture Tab up out of body and make ground
and ballast connections. Bend Fixture Tab
back to original position. Replace Access
Plate by reversing removal instructions.
CONTINUOUS ROW COUPLER (LC UNITS
ONLY) Remove screw as shown. Rotate
Continuous Row Coupler (both sides of
2INSTALL FIXTURES onto T-bars as shown.
3
Access
Plate
Access
Plate
Opening
Fixture
Tab
Ground
Screw
Access
Plate
Opening
Tab
1.
2.
Access
Plate
Opening
T-bar
Fixture
T-bar
Screw
Hold-
down Clip
Continuous
Row Coupler
HOLD-DOWN CLIPS (LI UNITS ONLY)
Install Hold-down Clips at beginning and end
of rows.
4
Fixtures
Continuous
Row Coupler
Hold-
down Clip
T-bar
Screw
Hold-
down Clip
Screw
To open Louver,
press Spring Latch
in direction of
Arrow. To close,
insert louver into
Fixture until
Spring Latches
automatically
engage.
5
Fixtures
Fixtures
Fixtures Spring
Latch
Fixtures) and secure Fixtures together with
Screw. Tighten all Screws to secure Fixtures
to T-bar with Hold-down Clips.
