Lightolier Lighting Systems LP-9 User manual

Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems LP-9
1BHFPG -JOFBS1FSG-ZUFÜDN4PMJE*OEJSFDU-JHIU51FS'PPU/PNJOBM4FDUJPO
#
13” (33.02cm)
3”
(7.62cm)
Complete ordering instructions below.
Features
1. Housing: 18 gauge steel. Die-formed steel end cap with concealed access
holes for through wiring. No exposed fasteners or hardware.
others.
2. Lamping: Two T8 32 watt fluorescent lamps per 4-foot section. Provided by
3. Reflector: Precision die-formed CRS painted high reflectance white.
Module Ordering Information
Style Series LampsType Options
2T8 = 2F32T8 4= 4-Foot U= Universal Voltage Blank = No Options
8= 8-Foot E= Emergency Pack DS = A-B Switch
D1 = Dimming 120v X4 = 4 Wire for Dimming &
Switched Emergency
D2 = Dimming 277v
LP 2 2T8A
Length Ballast
Electrical
Ballast is universal voltage, <10% THD, .88 ballast factor, instant start. 3 con-
ductor, 18 gauge wire. Color-coded quick connectors allow ease of connection
for joiner modules. For special circuiting consult factory. Cord is 18/3 SJT. Factory
installed ballast disconnect allows the ballast to be disconnected fromand
reconnected to incoming power under load without turning the entire circuit off.
Dimming: 120/277 VAC, 4 wire feed required.
Emergency Battery Pack: 32 watt: 450 lumens @ 90 minutes.
Options
Dual Switching: Order the DS option for separate row switching. DS option
automatically ships with the X4 option included.
Mountings
Cable Suspension (not shown) - 4-1/2” (11.43cm) diameter flat canopy finished
white enamel, 1/16” (0.16cm) diameter stainless steel aircraft cable adjustable up
to 36” (91.44cm) without cutting.
4 Wire: Order X4 modules for remainder of the run when using dimming and/or
switched emergency battery pack modules. Also, order the 4 Wire Cord Power Feed
End Sets (LP2EC36X4) when using 4 Wire Modules.
Emergency Circuiting: Special circuiting - consult factory.
Ordering Information
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete run.
3. Order one POWER FEED END SET per run.
4. Order one CABLE ASSEMBLY per MODULE minus one per run.
5. For runs that exceed amperage limits, order the appropriate number of SINGLE
Labels
UL, cUL and I.B.E.W.
Finish
Powder coated baked white enamel. Customcolors available, consult factory.
CABLE & CORD FEEDS.

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt #
Lighting Systems LP-9
1BHFPG -JOFBS1FSG-ZUFÜDN4PMJE*OEJSFDU-JHIU51FS'PPU/PNJOBM4FDUJPO
CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
180 1253 1253 1253 1253 1253
175 1252 1252 1257 1252 1258
165 1211 1223 1238 1263 1257
155 1127 1157 1198 1261 1274
145 978 1043 1121 1235 1259
135 802 903 1023 1191 1229
125 638 780 976 1195 1186
115 435 650 879 1040 1073
105 228 517 664 741 754
95 57 238 229 227 222
90 7 43 19 11 9
85 0 0 0 0 0
75 0 0 0 0 0
65 0 0 0 0 0
55 0 0 0 0 0
45 0 0 0 0 0
35 0 0 0 0 0
25 0 0 0 0 0
15 0 0 0 0 0
500000
000000
Mounting Accessories
Performance
REPORT NO: LRL 300-1Y
CAT NO: LP2A2T84U
LAMPS: 2 F32T8
LUMENS: 2900
EFFICIENCY: 87.8%
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY
REFLECTANCE
80 70 50
WALL REFLECTANCE
70 50 30 70 50 30 50 30 10
084848471 7171494949
176736965 6260424140
269635959 5450373533
363565054 4843333027
457494349 4237292623
552433745 3732262220
648383241 3328231917
744342838 2924201714
841312535 2621181513
938282232 2419171311
10 35 25 20 30 22 17 15 12 10
20% FLOOR CAVITY REFLECTANCE
ROOM CAVITY RATIO
Fixture Lengths & Mounting Locations
CANDLEPOWER CURVE
DISTRIBUTION
Zone Lumens % Lamp % Luminaire
0-90 0 0.0 0.0
90-180 5094 87.8 100.0
0-180 5094 87.8 100.0
Ceiling Grid Kit
CGK
Includes both Standard 1” (2.54cm)
Tee Bar Clip & Slot Tee Clip
Power Feed End Set
Standard Cable Length is 36” (91.44cm)
Straight Cord: LP2EC36
4 Wire Cord*: LP2EC36X4
Cable/Joiner Assembly
Standard Cable Length is 36” (91.44cm)
Single Cable: LP2C36
Single Cable & Cord: LP2CC36
Single Cable & 4 Wire Cord: LP2CC36X4 * use for dimming and/or
emergency battery packs
4’ 8’
48” (121.92cm)
4’ 2” (127.00cm)
96” (243.84cm)
8’ 2” (248.92cm)
12’
96” (243.84cm)
12’ 2” (370.84cm)
96” (243.84cm)
16’ 2” (492.76cm)
96” (243.84cm)
96” (243.84cm)
20’ 2” (614.68cm)
96” (243.84cm)
16’
96” (243.84cm)
24’ 2” (736.60cm)
96” (243.84cm)
24’
20’
48” (121.92cm)
48” (121.92cm)
96” (243.84cm)
4-Foot
Module
8-Foot
Module End Set Cable/ Joiner
4-Foot Run 11
8-Foot Run 11
12-Foot Run 111 1
16-Foot Run 21 1
20'-Foot Run 121 2
24'-Foot Run 31 2
